Kramer UTBUS-1XL User manual

P/N: 2900-300076 Rev 5 www.kramerAV.com
USER MANUAL
MODEL:
UTBUS-1xl
Under the Table Connection Bus

Kramer Electronics Ltd.
UTBUS-1xl –Contents
i
Contents
Introduction 1
Getting Started 1
Overview 3
Defining the UTBUS-1xl Enclosure 4
Power Socket Options 5
Power Cord Options 5
Installing the UTBUS-1xl 6
Installing the Required Wall Plate Inserts 6
Installing the Power Socket 6
Installing the Cables 7
Securing the UTBUS-1xl Enclosure to the Table 7
Technical Specifications of the Assembled UTBUS-1xl 8

Kramer Electronics Ltd.
UTBUS-1xl –Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Thank you for purchasing the Kramer UTBUS-1xl,which is ideal for boardrooms, conference
and training rooms!
Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
•Review the contents of this user manual.
Go to www.kramerav.com/downloads/UTBUS-1xl to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where
appropriate).
Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
•Do not secure the cables in tight bundles or roll the slack into tight coils.
•Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
•Position your Kramer UTBUS-1xl away from moisture, excessive sunlight and dust.
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
There are no operator serviceable parts inside the unit.
Glossary
Universal socket
The Universal socket fits almost all power cords, worldwide.
Insert
The insert is fitted in the inner frame. Go to our Web site to check for a
variety of single and dual sized inserts.

Kramer Electronics Ltd.
UTBUS-1xl –Introduction
2
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/support/recycling/.

Kramer Electronics Ltd.
UTBUS-1xl –Overview
3
Overview
The UTBUS-1xl is a furniture-mounted connection bus that is easily installed underneath a
wooden table or podium top. The unit is sturdy, cost-effective, and easy to install.
The UTBUS-1xl:
•Is modular in design, letting you install up to six wall plate inserts, according to your
requirements.
•Has a power socket opening that is suitable for any of the following power sockets: for
the USA, Germany (the Europlug), Belgium-France, Italy, Australia, Israel, Switzerland,
UK, Brazil, South Africa or “Universal” for use anywhere (see compatibility restrictions in
Technical Specifications of the Assembled UTBUS-1xl on page 8).
Power sockets are ordered separately.
Figure 1: UTBUS-1xl Under a Table

Kramer Electronics Ltd.
UTBUS-1xl –Defining the UTBUS-1xl Enclosure
4
Defining the UTBUS-1xl
Enclosure
Figure 2: UTBUS-1xl Under the Table Connection Bus
#
Feature
Function
1
Blank Plates
Six blank covers that can be replaced with wall plate inserts as required
(see Installing the Required Wall Plate Inserts on page 6).
2
Power Socket Opening
Suitable for international power requirements (Suitable for international
power requirements (available with different types of power sockets,
ordered separately, see Power Socket Options on page 5).
3
Outer Rim
For mounting under the table.
4
Tie Holes (12)
Insert self-locking ties through the holes to fix the pass-through cables to
the inside walls of the UTBUS-1xl.
5
Rim Screw Openings (4)
For fixing the UTBUS-1xl under the table (including two open screw
holes).

Kramer Electronics Ltd.
UTBUS-1xl –Defining the UTBUS-1xl Enclosure
5
Power Socket Options
Inner frames support installing the following power socket assemblies.
The Brazilian power sockets are supplied as dual power sockets in a single power socket
assembly (see table below).
Socket Type
Power Specs
Universal:
TS-1U (80-000899)
100-240V AC,
50/60Hz, 5A
Maximum 5A per
power outlet
Fully compatible with power plugs in the UK, India, Italy and
Denmark, as well as with the 2-prong Europlug.
Partially compatible (if the polarity is reversed) with plugs in
China, Switzerland, Israel and the USA. The universal socket does
not supply grounding to plugs in Central Europe and France and so
you should order country specific sockets instead.
Not compatible with South African plugs.
Socket Type
Power Specs
Socket Type
Power Specs
USA:
TS-1US (80-000999)
100-125V AC, 50/60Hz, 5A
Maximum 5A per power outlet
UK:
TS-1UK (91-000022)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Belgium and France:
TS-1FR (80-001399)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Israel:
TS-1IL (80-001799)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Germany and EU:
TS-1DE (80-001299)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
South Africa:
TS-1ZA (80-001699)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Italy:
TS-1IT (80-001499)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Australia:
TS-1AU (80-001599)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Switzerland:
TS-1CH (80-000027)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Brazil:
TS-BR (80-000034)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power
outlet
Power Cord Options
You can order any of the following power cords to use with a modular TBUS:
Power Cord Type
Description
P/N
6ft/110V (North America)
C-AC/US (110V)
91-000099
6ft/125V (Japan)
C-AC/JP (125V)
91-000699
6ft/220V (Europe)
C-AC/EU (220V)
91-000199
6ft/220V (Israel)
C-AC/IL (220V)
91-000999
6ft/250V (UK)
C-AC/UK (250V)
91-000299
6ft/250V (India)
C-AC/IN (250V)
91-001099
6ft/250V/10A (China)
C-AC/CN (250V)
91-001199
6ft/250V/10A (South Africa)
C-AC/ZA (250V)
91-001299

Kramer Electronics Ltd.
UTBUS-1xl –Installing the UTBUS-1xl
6
Installing the UTBUS-1xl
This section describes the UTBUS-1xl installation process:
•Installing the Required Wall Plate Inserts on page 6.
•Installing the Power Socket on page 6.
•Installing the Cables on page 7.
•Securing the UTBUS-1xl Enclosure to the Table on page 7.
Installing the Required Wall Plate Inserts
By default, the mounting surface includes a power socket opening and four blank plates for
optional video, audio and network connectors. Each blank plate can be removed and replaced
with a Kramer passive wall plate insert or connector module for interfacing A/V type signals, if
required. To install a wall-plate insert or connector module, do the following:
1. Unscrew the two screws that attach the blank plate
to the connecting surface and remove the blank
plate (save the two screws).
2. Place the required wall plate insert item over the
opening.
3. Reinsert the two screws to affix the wall plate insert
in position and tighten them.
Installing the Power Socket
To install the power socket:
1. Insert the modular power socket in its place (in this example, a universal power socket is
shown, but you can use any of the available power sockets, see Power Socket
Options on page 5).

Kramer Electronics Ltd.
UTBUS-1xl –Installing the UTBUS-1xl
7
2. Tighten the two screws (supplied with the power socket module).
The power socket is now installed.
Figure 3: Installing the Power Socket
Installing the Cables
To install the cables:
1. Connect the cables to the inside of the unit.
2. Insert the self-locking ties through the tie holes to secure the cables to the inside walls of
the enclosure.
Securing the UTBUS-1xl Enclosure to the Table
To install the UTBUS-1xl underneath the table (as illustrated in Figure 4):
1. Place the unit to the underside of the table and mark the correct location.
2. Insert the four wood screws into the four rim screw holes and fix the
UTBUS-1xl to the table.
Figure 4: Securing the UTBUS-1xl Under the Table
The UTBUS-1xl is ready for use.

Kramer Electronics Ltd.
UTBUS-1xl –Technical Specifications of the Assembled UTBUS-1xl
8
Technical Specifications of the
Assembled UTBUS-1xl
POWER SOURCE
(AC power limits):
Power Socket Assemblies
Universal
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Fully compatible with power plugs in the UK, India, Italy and Denmark,
as well as with the 2-prong Europlug.
Partially compatible (if the polarity is reversed) with plugs in China,
Switzerland, Israel and the USA. The universal socket does not supply
grounding to plugs in Central Europe and France (you should order
country specific sockets instead).
Not compatible with South African plugs.
USA
100-120V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Germany and EU
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Belgium and France
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Italy
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Switzerland
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
UK
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
South Africa
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Australia
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Israel
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Brazil
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
FUSE RATING:
T 6.3A 250V
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
250.2mm x 137.5mm x 65mm (9.85" x 5.41" x 2.56") W, D, H
WEIGHT:
0.7kg (1.54lbs) approx.
ACCESSORIES:
Self-locking ties, wood screws
OPTIONS:
Passive wall plates and interfaces, power socket kits, power cord
Specifications are subject to change without notice at www.kramerav.com

The warranty obligations of Kramer Electronics Inc. (“Kramer Electronics”) for this product are limited to the terms set forth below:
What is Covered
This limited warranty covers defects in materials and workmanship in this product.
What is Not Covered
This limited warranty does not cover any damage, deterioration or malfunction resulting from any alteration, modification, improper or unreasonable use
or maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper packing and shipping (such claims must be presented to
the carrier), lightning, power surges, or other acts of nature. This limited warranty does not cover any damage, deterioration or malfunction resulting
from the installation or removal of this product from any installation, any unauthorized tampering with this product, any repairs attempted by anyone
unauthorized by Kramer Electronics to make such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship
of this product. This limited warranty does not cover cartons, equipment enclosures, cables or accessories used in conjunction with this product.
Without limiting any other exclusion herein, Kramer Electronics does not warrant that the product covered hereby, including, without limitation, the
technology and/or integrated circuit(s) included in the product, will not become obsolete or that such items are or will remain compatible with any other
product or technology with which the product may be used.
How Long this Coverage Lasts
The standard limited warranty for Kramer products is seven (7) years from the date of original purchase, with the following exceptions:
1. All Kramer VIA hardware products are covered by a standard three (3) year warranty for the VIA hardware and a standard three (3) year
warranty for firmware and software updates.
2. All Kramer fiber optic cables, adapter-size fiber optic extenders, active cables, cable retractors, all Kramer speakers and Kramer touch panels
are covered by a standard one (1) year warranty.
3. All Kramer Cobra products, all Kramer Calibre products, all Kramer Minicom digital signage products, all HighSecLabs products, all
streaming, and all wireless products are covered by a standard three (3) year warranty.
4. All Sierra Video MultiViewers are covered by a standard five (5) year warranty.
5. Sierra switchers & control panels are covered by a standard seven (7) year warranty (excluding power supplies and fans that are covered for
three (3) years).
6. K-Touch software is covered by a standard one (1) year warranty for software updates.
7. All Kramer passive cables are covered by a ten (10) year warranty.
Who is Covered
Only the original purchaser of this product is covered under this limited warranty. This limited warranty is not transferable to subsequent purchasers or
owners of this product.
What Kramer Electronics Will Do
Kramer Electronics will, at its sole option, provide one of the following three remedies to whatever extent it shall deem necessary to satisfy a proper
claim under this limited warranty:
1. Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and
labor to complete the repair and restore this product to its proper operating condition. Kramer Electronics will also pay the shipping costs
necessary to return this product once the repair is complete.
2. Replace this product with a direct replacement or with a similar product deemed by Kramer Electronics to perform substantially the same
function as the original product.
3. Issue a refund of the original purchase price less depreciation to be determined based on the age of the product at the time remedy is sought
under this limited warranty.
What Kramer Electronics Will Not Do Under This Limited Warranty
If this product is returned to Kramer Electronics or the authorized dealer from which it was purchased or any other party authorized to repair Kramer
Electronics products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned
uninsured, you assume all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re-
installation of this product from or into any installation. Kramer Electronics will not be responsible for any costs related to any setting up this product, any
adjustment of user controls or any programming required for a specific installation of this product.
How to Obtain a Remedy Under This Limited Warranty
To obtain a remedy under this limited warranty, you must contact either the authorized Kramer Electronics reseller from whom you purchased this
product or the Kramer Electronics office nearest you. For a list of authorized Kramer Electronics resellers and/or Kramer Electronics authorized service
providers, visit our web site at www.kramerav.com or contact the Kramer Electronics office nearest you.
In order to pursue any remedy under this limited warranty, you must possess an original, dated receipt as proof of purchase from an authorized Kramer
Electronics reseller. If this product is returned under this limited warranty, a return authorization number, obtained from Kramer Electronics, will be
required (RMA number). You may also be directed to an authorized reseller or a person authorized by Kramer Electronics to repair the product.
If it is decided that this product should be returned directly to Kramer Electronics, this product should be properly packed, preferably in the original
carton, for shipping. Cartons not bearing a return authorization number will be refused.
Limitation of Liability
THE MAXIMUM LIABILITY OF KRAMER ELECTRONICS UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID
FOR THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY LAW, KRAMER ELECTRONICS IS NOT RESPONSIBLE FOR DIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL
THEORY. Some countries, districts or states do not allow the exclusion or limitation of relief, special, incidental, consequential or indirect damages, or
the limitation of liability to specified amounts, so the above limitations or exclusions may not apply to you.
Exclusive Remedy
TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE MAXIMUM EXTENT
PERMITTED BY LAW, KRAMER ELECTRONICS SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF KRAMER ELECTRONICS CANNOT LAWFULLY DISCLAIM OR
EXCLUDE IMPLIED WARRANTIES UNDER APPLICABLE LAW, THEN ALL IMPLIED WARRANTIES COVERING THIS PRODUCT, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY TO THIS PRODUCT AS PROVIDED UNDER APPLICABLE LAW.
IF ANY PRODUCT TO WHICH THIS LIMITED WARRANTY APPLIES IS A “CONSUMER PRODUCT” UNDER THE MAGNUSON-MOSS WARRANTY ACT (15
U.S.C.A. §2301, ET SEQ.) OR OTHER APPLICABLE LAW, THE FOREGOING DISCLAIMER OF IMPLIED WARRANTIES SHALL NOT APPLY TO YOU, AND
ALL IMPLIED WARRANTIES ON THIS PRODUCT, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR THE PARTICULAR PURPOSE,
SHALL APPLY AS PROVIDED UNDER APPLICABLE LAW.
Other Conditions
This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state.
This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by
Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller. If you are unsure whether a reseller is an
authorized Kramer Electronics reseller, visit our web site at www.kramerav.com or contact a Kramer Electronics office from the list at the end of this
document.
Your rights under this limited warranty are not diminished if you do not complete and return the product registration form or complete and submit the
online product registration form. Kramer Electronics thanks you for purchasing a Kramer Electronics product. We hope it will give you years of
satisfaction.

www.KramerAV.com
[e-mail]
P/N:
2900-300076
Rev:
5
SAFETY WARNING
Disconnect the unit from the power supply before opening andservicing
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to this user manual may be found.
We welcome your questions, comments, and feedback.
