Krell Industries HTS 2 User manual

"rilE I--EAr’~ER IN AUCIIO ENCtINEERINO
HomeTheater
Standard
Surround
Preamp/Processor
Instructions for Use
Owner’s Reference

HomeTheater Standard
SurroundPreamp/Processor
Instructionsfor Use
v 01.2
KrellIndustries,Inc.
45 ConnairRoad
Orange, CT 06477-3650USA
TEL[phone]
FAX[phone]
E-MAIL[email protected]
WEBSITEhttp://www.krellonline.com
Thisproductcomplieswith the EMCdirective (89/336/EEC)andthe low-voltagedirective (73/23/EEC).
WARNINGS
TheHomeTheaterStandardmustbeplacedona firm level surfacewhereit is notexposedto drippingor
splashing.
Theventilation grids onthe top andbottomof the HomeTheaterStandardmustbeunobstructedat all
timesduringoperation.Donot placeflammablematerialaboveor beneaththe component.
Donot removeor bypassthe groundpin onthe endof the ACpowercord. Thiscouldcauseradio frequen-
cyinterference(RFI)to beintroducedinto yourplaybacksystem.
Beforemakingconnectionsto TheHomeTheaterStandard,makesure the backpanelpowerswitch is off.
Makesureall cableterminationsareof thehighestqualityandfree fromfrayedends,shortcircuits, or cold
solderjoints.
THEREARENOUSERSERVICEABLEPARTSINSIDE ANYKRELLPRODUCT.
PleasecontactyourauthorizedKrell dealer,distributor, or Krell if youhaveanyquestionsnotaddressedin
this Owner’sReference.
Thisproductis manufacturedin theUnitedStatesof America.Krell®is aregisteredtrademarkof Krell Industries,Inc., andis restrictedfor usebyKrell
Industries,Inc., its subsidiaries,andauthorizedagents.Krell CurrentMode
TM
is a trademarkof Krell Industries,Inc. "DTS"and"DTSDigital Surround"are
registeredtrademarksof Digital TheaterSystems,Inc. TosLinkis atrademarkof ToshibaCorporation.PHASTLinkis atrademarkof PhastCorporation.
ManufacturedunderlicensefromDolbyLaboratories."Dolby,""ProLogic,"andthe double-Dsymbolaretrademarksof DolbyLaboratories.Confidential
UnpublishedWorks.Copyright1992-1997DolbyLaboratories,Inc. All rightsreserved.All othertrademarksandtradenamesareregisteredto their respec-
tive companies.
©2001byKrellIndustries,Inc. All rightsreserved P/N 305218

Contents
INTRODUCTION
DEFINITIONOF TERMS
UNPACKING
PLACEMENT
ACPowerGuidelines
GETTINGSTARTED
ReadThisFirst
AnIntroduction to SystemSetup
FRONTPANELDESCRIPTION
BACKPANELDESCRIPTION
REMOTECONTROLDESCRIPTION
BatteryInstallation andRemoval
CONNECTINGTHE HOMETHEATERSTANDARD
TO YOURSYSTEM
First: ConnectAnalogandDigital Sources
Next: ConnectVideoSources
Last:ConnectAmplifier(s)
SYSTEMSETUPANDCONFIGURATIONOVERVIEW
SYSTEMSETUPANDCONFIGURATION
Navigatingthe Menu
Accessingthe MainMenu
ConfigureSpeakers
Listening RoomSetup
CalibrateVolume.
ConfigureDevices
ConfigureLevel Adjustment
Operation
SAVINGSETUP, RECALLINGSETUP, ANDRESTORINGFACTORY
DEFAULTSYSTEMCONFIGURATIONSETTINGS
OPERATINGTHE HOMETHEATERSTANDARD
On/Off/Stand-by
TapeInput andOutput
MainZoneandZone2 Operation
OtherOperationFeatures
WARRANTY
RETURNAUTHORIZATIONPROCEDURE
SPECIFICATIONS
Page
1
1
3
4
4
5
5
6
8
14
18
18
23
23
24
24
25
26
26
26
27
29
30
32
39
44
52
53
53
53
54
55
57
58
59-60
Krell HomeTheaterStandard iii

Illustrations
FIGURE1 TheHomeTheaterStandardFront Panel
FIGURE2 TheHomeTheater Standard BackPanel
FIGURE3 TheHomeTheater StandardRemoteControl
Page
7
13
17
iV Krell HomeTheaterStandard

Introduction
Thankyou for your purchaseof the .Krell HomeTheater StandardSurround
Preamp/Processor.
The HomeTheater Standard provides optimummusic and cinema soundtrack
reproductionquality throughKrell CurrentMode,discrete ClassA direct-coupled
circuitry, andbalancedoutputs on all six channels.Broadcastquality switching and
circuitry--including componentvideo, S-video, andcompositevideo--ensure
unmatchedvideo performance.Built-in DolbyDigital, DolbyPro Logic, andDTS
decodingmakethe HomeTheater Standard compatible with virtually any surround
soundsource, including digital videodisc(DVD)softwareanddigital television
broadcasts.
Dualzonecapability gives youa variety of configuration possibilities for whole-house
systems. A handheld remote control, RS-232and optional PHASTLink communications
ports, RC-5baseband,and12 VDCinput/output (12 V trigger) interface integrate the
HomeTheater Standard into any system. TheHomeTheater Standard’s flexible,
modulararchitecture allows you to upgradehardwareand software to accommodate
future surround soundformats and design enhancements.
Theowner’s reference manualcontains important information on placement,
installation, andoperation of the Krell HomeTheaterStandard.Pleasereadthis
information carefully. A thoroughunderstandingof these details helps ensure
satisfactory operation of andlong life for your HomeTheaterStandardandrelated
system components.
Definition of Terms
Followingare the definitions of key termsusedin your owner’sreferencemanual.
INPUT AND OUTPUT CONNECTIONS
Balanced
A symmetricalinput or output circuit that has equalimpedancefrom both input terminals
to a commongroundreference point. Theindustry standardfor professional andsound
recording installations, balancedconnectionshave6 dBmoregain than single-ended
connectionsandallow the use of long interconnect cables. Balancedconnectionsare
completely immuneto induced noise from the systemor the environment.
Krell HomeTheaterStandard

Definition of Terms,continued
Multi-channel(DB-25)
Abalancedinput or outputcircuit that allowsfor the simultaneousconnectionof all
audiooutputsplusone5 VDC(5 Volt trigger) via a single cable.DB-25inputsand
outputsare becomingpopularfor connectinganaudio/videosurroundsoundprocessor
andpoweramplifiers, simplifying the integrationof the twocomponentsinto your
system.
Single-ended
Atwo-wireinput or outputcircuit. Usecarewhenusingsingle-endedconnectionsas the
groundconnectionis madelast andbrokenfirst. Turnthe systemoff prior to makingor
breakingsingle-endedconnections.Single-endedconnectionsare not recommended
for connectionsrequiringlongcableruns.
OPERATION
Off
Whenthe powerswitchonthe backpanelis placedin the downposition andLEDsturn
off, the componentis off.
Stand-by Mode
Whenthe HTSis connectedto ACpowerandthe backpanelpowerswitch is in the up
(on) position, the redstand-byLEDilluminates. Thisindicatesthat the componentis
stand-bymode,a lowpowerconsumptionstatus that keepsthe audioandregulator
circuits at idle. Krell recommendsleavingthe componentin the stand-bymodewhenit
is not playingmusic.
Operational Mode
Whenthe componentis in the stand-bymode,andyoupressthe powerbutton onthe
front panelor the powerkeyon the remotecontrol, the bluepowerLEDilluminates. The
componentis in the operationalmodeandis readyto play music.
TECHNOLOGY
Krell Current Mode
AproprietaryKrell circuit topologyin whichthe audiogainstagesof a component
operatein the currentrather thanthe voltagedomain.Thisuniquetechnologyprovides
the componentwith exceptionalspeedanda widebandwidth.
Krell HEAT
TheKrell termHEAT,or HighEndAudioTheater,is a designapplication incorporated
into Krell componentsto enhancemulti-channelhomeentertainmentsystems.AKrell
HEATsystemis anintegratedhometheater systemconsistingof a state-of-the-art Krell
preamp/processorandmatchingamplifiers that reproducetwochannelandmulti-
channelsourceswith audiophilesoundquality, placingthe audiencein the middleof a
lifelike environment.
2 Krell HomeTheaterStandard

Unpacking
Openthe box andremovethe top.layer of foam. Yousee these items:
1 HomeTheater Standard
1 IEC connector (AC power) cord
1 HomeTheater Standard handheld remote control
1 CR2025lithium battery
1T-15Torx wrench(small "L" type)
1 T-10Torx wrench(small "L" type)
1 12 VDCoutput (12 V trigger) cables
1 packet containing the owner’s reference manual,the RS-232Port developer’s
reference,the "readthis first" insert, andthewarrantyregistration card.
Carefully removethe unit andaccessories from the box. Removethe foamendcaps
andprotective plastic wrapfromthe unit.
Note
If anyof theseitems are not includedin the shippingbox, p/easecontact your
authorizedKrell dealer, distributor, or Krell for assistance.Saveall packingmaterials. If
youmustship your HomeTheaterStandardin the future, repackthe unit in its originaJ
packagingto prevent transit damage.SeeReturn Authorization Procedure, on
page 58.
Krell HomeTheaterStandard

Placement
Beforeyouinstall the HomeTheaterStandardinto yoursystem,reviewthe following
guidelinesto choosethelocationfor thecomponent.Thiswill facilitate a clean,trouble-
freeinstallation.
TheHomeTheaterStandarddoesnot require anytypeof special rack or cabinetfor
installation. Forthe dimensionsof yourHomeTheaterStandardseeSpecifications, on
pages59-60.
TheHomeTheaterStandardrequires at least two inches(5 cm)of clearanceoneach
side andat least twoinches(5 cm)of clearanceaboveandbelowthe component
provideadequateventilation. Further,the HomeTheaterStandardrequiresat least
three inches(7 cm)of clearancebetweenother connectedcomponents.For
installationsinsidecabinetry,extraventilationmaybenecessary.
AC POWERGUIDELINES
TheHomeTheaterStandardhassuperbregulation anddoesnot require a dedicated
ACcircuit. Avoidconnectionsthroughextensioncordsor multiple ACadapters.High
quality 15ampgroundedACstrips areacceptable.Highquality ACline conditionersor
filters maybeusedif theyaregrounded.
Power Cord
TheHomeTheaterStandardshouldbeusedonly with the powercord supplied. Contact
yourauthorizedKrell dealer,distributor, or Krell beforeusinganydevicesdesignedto
alter or stabilize the ACpowerfor the HomeTheaterStandard.
4Krell HomeTheaterStandard

Getting Started
READTHIS FIRST
Performthe following steps to makethe On-ScreenDisplay(OSD)viewableonyour
videomonitor. Thevideoformatandvideosignals of the HomeTheaterStandardand
the videomonitorneedto matchbeforethe OSDis viewable.Thevideoformatof the
videosignal canbeset to either NTSCor PAL.
Thefollowing table details the different videosignalsandvideoformatssupportedby
the HomeTheaterStandard:
Video Typeof Connector Most Commonly Format
Signal LabeledAs Standard
Composite Single-EndedRCA Video, Composite NTSCor PAL
S-Video DIN S, SV,S-Video NTSCor PAL
Component 3 Single-EndedRCA Y, Cr, Cb NTSCor PAL
Toselecttheinitial videosignalandvideoformat:
1. Connectyourvideomonitorto the videooutput connectorsonthe HomeTheater
Standardthat correspondsto the input connectorsonyourvideomonitor(refer to
theabovetable).
2. Poweronthe HomeTheaterStandardby switching the backpanelpowerswitch to
on.Waitfor the HTSto initialize. Thenpressthe powerbuttononthe front panel.
Thefollowing diagramshowsthe front paneldevicebuttonsonthe HomeTheater
Standardandthe default videosignalsandvideoformatsassociatedwith eachbutton:
FRONT o o o o o o
PANEL DVD LD SAT VCR1 TV CD
DEVICE o o o o o o
BUTTON ~ ~ ~ ~ ~ ~
SIGNAL Composite S-Video Component Composite S-Video Component
FORMAT NTSC NTSC NTSC PAL PAL PAL
Pressthe front paneldevicebuttonthat matchesboththe videoformatandvideo
signal compatiblewith yourconnectedvideomonitor(refer to the abovediagram).
Thisbecomesthe currently selectedvideosignal output.
Krell HomeTheaterStandard 5

4. Verify that the video monitor’s video signal input correspondsto the HomeTheater
Standardvideo signal output. Pressthe menukeyon the remotecontrol to verify
that the OSDis nowviewable on the video monitor. Thesystemconfiguration main
menuappears whenthe video format and video signals betweenthe HomeTheater
Standardandyour video monitor are compatible.
If youhaveanyquestionsregardingthe selection of the video format, pleasecall your
authorizedKrell dealer, distributor, or Krell.
AN INTRODUCTION TO SYSTEM SETUP
TheHomeTheater Standardprovides a variety of connection andoperation options for
outstanding musicandcinemasoundtrackreproduction. Totake full advantageof the
features the HomeTheaterStandardoffers, you’ll needto set up your systemin this
order:
1, Connectyour HomeTheater Standardto the desired analog and digital audio
sources, video sources, and amplifiers. SeeConnectingthe HomeTheater
Standard to Your System, on page 23.
2. Configure your HomeTheater Standard’s speakervolume, input devices, andtrims
using the built-in, easy-to-follow SystemSetupandConfiguration menus.Step-by-
step instructions begin on page26, SystemSetup and Configuration.
3. Reviewthe Front Panel, BackPanel, andRemoteControl descriptions for information
on input, zone, andmodeselections, speakeradjustment, input andoutput
connectionsfor analog, digital, andvideo sources, andremotecontrol operation. See
pages7-22for illustrations anddescriptions.
After you’ve connectedandconfigured your HomeTheater Standardand knowits basic
features, you’re ready to go. SeeOperatingthe HomeTheaterStandard,on page53.
6Krell HomeTheaterStandard

Figure1 TheHomeTheaterStandardFrontPanel
10 5 11 6
I
I
--00
-C) "©
12 7 13 8 14 9
SAT VOR
-00 --00
AUX1 AUX2
----00 ----00
15 16
STAND-BY
POWER
-----0
3 2
HTS
BasicOperation
1 PowerButton
2 PowerLED
3 Stand-byLED
4 Infrared Sensor
InputDeviceSelection
ButtonsandLEDs
5 DVDButton andLEDs
6 LDButton andLEDs
7 SATButton andLEDs
8 VCR1Button and LEDs
9 TVButton andLEDs
ZONE
00----
22 18 19
Home Theater Standard
USER
23 29 24
STEREO MUSlO1
--0 ----O
25 26 30
10 CDButton andLEDs
11 TunerButtonandLEDs
12 Auxl ButtonandLEDs
13 Aux2Button andLEDs
14 TapeNCR2Button and LEDs
15 MainZoneandZone2 Button
16 MainZoneandZone2 LEDs
17 InfraredEmitter
ProcessingModeButtonsandLEDs
18StereoButton andLED
19 Music1Button andLED
20Music2Button andLED
21 ProLogicButtonandLED
22 PreampButton andLED
23 FrontPanelDisplay
24 UserButton
25 BalanceButton
Individual ChannelButtons
26CenterButton
27RearButton
28 SubButton
29SaveButton
30Level DownandUpButtons
31RecallButton
20 21
MUSICB PRO LOGIC
---O O--
27 28

Front PanelDescription
SeeFigure1 onpage7
TheHomeTheater Standardfront panel provides poweron andoff; input, zone, and
processingmodeselection; monitoring anddisplay of processorstatus; andbalance
andvolumecontrol. Thefront panel componentsare described below.
Basic Operation
1 Power Button
Thepowerbutton switches the HomeVideoStandardfrom the stand-by to the
operational mode.
Note
Whenyou poweroff while zone2 is se/ected, on/y zone2 turns off. Pressthe power
button or HTSkey a secondtime to poweroff the mainzone.
2 Power LED
Theblue powerLEDilluminates whenthe HomeTheater Standardis in the operational
mode.
3 Stand-by LED
Thered stand-by LEDilluminates whenthe backpanel powerswitch (54) is on,
indicating that the HomeTheater Standardis in stand-by mode.Krell recommendsthat
the backpanelpowerswitch remainin the up position at all times.
4 Infrared Sensor
Theinfrared sensor receives commandsfrom the HomeTheater Standard remote
control. For properremotecontrol operation, makesure the infrared sensoris not
coveredor obstructed.
Input Device Selection Buttons andLEDs
Whenproperly configured, the HomeTheater Standardkeepstrack of eachdevice and
its associated connections. For example,DVDuses Coax1for digital audio, Composite1
for video, and S-1 for analog audio. TheHomeTheater Standardautomatically engages
the correct inputs whenyoupress a front paneldeviceselection button.
TheHomeTheater Standardis equippedwith the following input selections, whichallow
you to select the device connectedto your HomeTheater Standard. Aboveeachdevice
are two LEDs:onered andonegreen. Thered LEDilluminates whenthe input is
engagedandplaying in the mainzone. ThegreenLEE)illuminates whenthe input is
engagedandplaying in zone2.
5 DVDButton and LEDs
Usethis buttonto select thedigital videodiscdevice.
8 Krell HomeTheaterStandard

FrontPanelDescription,continued
6 LD Button and LEDs
Usethis buttonto select the laser disc device.
7 SAT Button and LEDs
Usethis buttonto select the satellite feeddevice.
8 VCR1Button and LEDs
Usethis button to select the VCRdevice.
9 TV Button and LEDs
Usethis buttonto select the television device.
10 CDButton and LEDs
Usethis button to select the compactdisc device.
11 Tuner Button and LEDs
Usethis button to select the AM/FMtuner device.
12 Auxl Button and LEDs
Usethis button to select anauxiliary device, suchas phono,tape, or anadditional DVD,
LD, CD,or VCR.
13 Aux2 Button and LEDs
Usethis button to select a secondauxiliary device, suchas phono,tape, or an
additional DVD,LD, CD,or VCR.
14 Tape/VCR2Button and LEDs
Usethis button to playbackpre-recordedtapes. Youmayalso usethis button to
comparethe output signal of an analog tape recorder to an audio source. SeeTape
Input andOutput, on page53.
15 Main Zoneand Zone2 Button
Usethis button to select either mainzoneor zone2 device control. SeeMainZoneand
Zone2 Operation, on page54.
16 Main Zone and Zone2 LEDs
TheHomeTheater Standardhas two zone device controls, mainor zone2. Aboveeach
device are two LEDs:onered andonegreen. Thered LEDilluminates whenthe input is
engagedandplaying in the mainzone. ThegreenLEDilluminates whenthe input is
engagedandplaying in zone2.
Krell HomeTheaterStandard 9

Front Panel Description, continued
17 Infrared Emitter
Emits the HomeTheater Standardremote operation codeto a learning remote, which
can be programmedto operate the HomeTheater Standard. See ProgramRemote, on
page48.
Processing Mode Buttons and LED$
18 Stereo Button and LED
Usethis button to select the stereo decodingmode,whichallows youto listen to a
stereo recording in two channel(left andright) mode.Thered LEDilluminates whenthis
modeis activated.
Note
Thestereo decodingmodeoperatesonly with ananaloginput or a digital PCMinput (for
example,a compactdisc).
19 Music1 Button and LED
20 Music2 Button and LED
Usethese buttons to engageKrell Music Surroundmode.This music-decoding mode
allows youto listen to a stereo recording in a multi-channel mode.This modecan also
be programmedto create different simulated acoustic environments. Thered LED
illuminates whenthis circuitry is engaged.SeeConfigure Music, on page47.
Note
TheKrell MusicSurrounddecodingmodeoperatesonly with an analoginput or a digital
PCMinput (for example,a compactdisc).
21 Pro Logic Button and LED
Usethis button to engageDolbyProLogic circuitry for usewith all DolbySurround
encodedmaterial, including laser discs, videotapes, television broadcasts,andcompact
discs. Thered LEDilluminates whenthe HomeTheater Standardis in the DolbyPro
Logic decoding mode.
Note
This modeis selectedautomatically if Do/byDigital sourcematerial is encodedfor Pro
Logic. If youwishto turn off this mode,pressthe ProLogicbutton.
22 Preamp Button and LED
Usethis button to sendthe signal fromthe analoginput directly to the volumecontrol,
with no digital processing,using the analogstage of the preamp.This avoidspossible
digital signal degradationandcanbe usedfor componentswith a high quality signal
such as the KPS28c. SeeConfigure Mode,on page36, for information on assigning
the analog input to oneof the device buttons (DVD,LD, SAT,VCR,TV).
10 Krell HomeTheaterStandard

Front Panel Description, continued
23 Front PanelDisplay
Thefront paneldisplay providesstatus messagesfor HomeTheaterStandard
operations,including volumeandbalancelevel, decodingmode,andzoneinformation.
In addition, whena newdeviceis selected,the physicalinputsaredisplayed.The
displayturnsoff after five secondsof inactivity.
24 UserButton
Usethis programmablebutton to select oneof three available dynamicrange
compressionmodes:normal(11 dB), max(imum)(no compression),or night (22
SeeUserButtonSetup,onpage50. In addition, the userbutton canbedeactivated.
25 BalanceButton
Pressthis buttonto adjustthemainleft/right speakerbalance.Thisbuttonconvertsthe
volumelevel controlsto balancecontrols. BAL0 in the front paneldisplaywindow
indicatesthe centerposition. Balancemaybeadjustedin .5 dBincrements,upto 6 dB.
Balancelevels areshownnumericallyonthe front paneldisplay. Thebalancelevel
buttonsrevert to their original functionsasmainvolumelevel controlsafter three
secondsof inactivity.
Individual Channel Buttons
Usethe Center,Rear,andSubbuttonsto changetaste trims (maketemporaryspeaker
output adjustmentsof +/- 10dB). Thesetemporarychangesrevert to 0 dBwhena new
deviceis selectedor the systemis powereddown.Formoreinformationontaste trims
andmaster(programmable)trims, seeConfigureLevel Adjustment,onpage39.
26 CenterButton
Pressthe centerbutton,thenusethe level upanddownbuttons(30) to adjust the
center speakervolume.
27 RearButton
Pressthe rear button,thenusethe level upanddownbuttons(30) to adjustthe rear
speakervolume.
28 SubButton
Pressthe sub(subwoofer)button, thenusethe level upanddownbuttons(30) to adjust
the subwooferspeakervolume.
29 SaveButton
Usethis buttonto savesystemconfigurationsettings andduringlearningremote
programming.SeeSavingSetup, Recalling Setup, andRestoring Factory Default
SystemConfigurationSettings, on page52, andProgramRemote,on page48.
Krell HomeTheaterStandard 11

Front PanelDescription, continued
30 Level DownandUpButtons
Usethevolumelevel buttonsto adjustthe outputfor the entire systemaswell as
balanceandindividual levels for the centerspeaker,rear speakers,andsubwoofers.
Thevolumelevel is shownin the front paneldisplay. SeeSystemSetupand
Configuration, onpage26.
31 Recall Button
Usethis buttonto recall previouslystoredsystemconfigurationsettings. SeeSaving
Setup, Recalling Setup, andRestoring FactoryDefault SystemConfiguration
Settings, onpage52.
12 Krell HomeTheaterStandard

Figure 2 TheHomeTheater StandardBackPanel
32
33 34
35
RIQH’I" LEFT
39 40 37 36
DIQITAL AUDIO
INPUTS
42 45
AnalogAudioOutputsandInputs
32 BalancedAnalogAudioOutputs
33 Single-endedAnalogAudioOutputs
34 Multi-ChannelAudioOutputConnector
35 B-1Left andB-1RightInputs
36 TapeIn Left andRight
37 TapeOutLeft andRight
38 VCR1In Left andRight
39 VCR1OutLeft andRight
40 Zone2 OutLeft andRight
41 S-1,S-2,S-3,S-4,S-5LeftandRightInputs
41 44 43 47 49
Digital AudioInputsandOutputs
42Digital OpticalInputs
43Digital AudioInputs
44Digital AudioOutputs
VideoInputsandOutputs
45S-videoOutputs
46S-videoInputs
47CompositeVideoOutputs
48Composite~/ideoInputs
49 ComponentVideo Outputs
50ComponentVideoInputs
46 51 52
o0 o
oOO
50 48 54 55
RemoteControl
51 RS-232Remoteor
Optional PHASTLink Connector
52 RC-5In
5312 VDCOutandIn
Power
54BackPanelPowerSwitch
55 IECConnector
53

BackPanel Description
SeeFigure2 onpage13
Theback panel of the HomeTheater Standardprovides all input and output
connections, remotecontrol inputs andoutputs, poweron andoff, andpower
connection. Theback panel functions are described below.
AnalogAudio Outputs and Inputs
32 Balanced Analog Audio Outputs
TheHomeTheater Standardis equippedwith six balancedanalog audio channel
outputs,with XLRconnectors,for the left, center,right, left rear, right rear, and
subwoofer.
33 Single-ended Analog Audio Outputs
TheHomeTheater Standardis equippedwith six single-ended analog audio channel
outputs,with RCAconnectors,for theleft, center, right, left rear, right rear, and
subwoofer.
34 Multi-Channel Audio Output Connector
TheHomeTheater Standardis equippedwith a multi-channel audio output, with a DB-
25 connector,whichcontainsthe output connectionsfor all the outputchannels(left,
center, right, left rear, right rear, andsubwoofer).
35 B-1 Left andRight Inputs
TheHomeTheater Standardis equippedwith oneset of balancedinputs with
connectors.
TheXLRpin configurations are as follows:
Pin 1: Shield (ground)
Pin 2: Non-inverting(0
°)
Pin 3: Inverting (180
°)
36 TapeIn Left andRight
TheHomeTheater Standardis equippedwith one set of single-ended tape inputs with
RCAconnectors.
37 TapeOutLeft and Right
TheHomeTheater Standardis equippedwith oneset of single-ended tape outputs with
RCAconnectors.
38 VCR1In Left and Right
TheHomeTheater Standardis equippedwith one set of single-ended inputs with RCA
connectors, for a VCRaudio source.
14 Krell HomeTheaterStandard

BackPanelDescription,continued
39 VCR1Out Left and Right
TheHomeTheater Standardis equippedwith one set of single-ended outputs with RCA
connectors, for a VCRaudio source.
40 Zone2 Out Left andRight
TheHomeTheater Standardis equippedwith one set of single-ended zone 2 audio
outputs with RCAconnectors.
41 S-l, S-2, S-3, S-4, S-5 Left andRightInputs
TheHomeTheaterStandardis equippedwith five sets of single-endedaudio inputs with
RCAconnectors.
Digital AudioInputs andOutputs
42 Digital OpticalInputs
TheHomeTheaterStandardis equippedwith two digital EIAJoptical inputs with
TosLink connectors.
43 Digital AudioInputs
TheHomeTheater Standardis equippedwith six coaxial digital audio inputs with RCA
connectors.
44 Digital AudioOutputs
TheHomeTheaterStandardis equippedwith two digital audio outputs: onecoaxial with
an RCAconnector, and oneEIAJoptical with a TosLink connector.
Video Inputs andOutputs
45 S-video Outputs
TheHomeTheater Standardis equippedwith two S-video outputs with DINconnectors.
ThemainS-video output (labeled OSDon back panel) includes on-screendisplay. For
dubbingpurposes,the secondS-video output doesnot include on-screendisplay.
Note
TheOSDand non-OSDoutputs are not interchangeable.
46 S-video Inputs
TheHomeTheater Standardis equippedwith four S-video inputs with DINconnectors.
47 CompositeVideo Outputs
TheHomeTheater Standard is equipped with two compositevideo outputs with RCA
connectors. Themaincompositevideo output (labeled OSDon backpanel) includes on-
screen display. For dubbingpurposes, the secondcompositevideo output doesnot
include on-screendisplay.
Krell HomeTheaterStandard 15

48 CompositeVideo Inputs
TheHomeTheaterStandardis equippedwith four RCAcompositevideo inputs with
RCAconnectors.
49 ComponentVideo Outputs
TheHomeTheaterStandardis equippedwith oneset of componentvideo outputswith
RCAconnectors.Componentvideo usesthree wires (labeled Y, Cr, andCbon back
panel)to conveythe videosignal, includingthe OSD.
50 ComponentVideo Inputs
TheHomeTheaterStandardis equippedwith two sets of componentvideoinputs.
Remote Control
51 RS-232Remoteor Optional PHASTLink Connector
TheHomeTheaterStandardis equippedwith an RS-232port, whichreceives
messagesfroma computerbasedcontrol system,providingmoreintelligent control of
the HomeTheaterStandard.For moreinformation, see RS-232Port: Sending
CommandsandInterpreting Data, developer’s reference shippedwith the Home
TheaterStandard.
TheHomeTheaterStandardmaybe outfitted with anoptional PHASTLink connector
insteadof anRS-232connector,for integrating the HTSwithin a PHASTsystem.
ContactyourauthorizedKrell dealer,distributor, or Krell for informationaboutthis
connectionoption.
52RC-5In
TheRC-5input makescustominstallation easyandsecureby acceptingbaseband
RC-5input commandsfromhardwiredremotecontrollers.
53 12 VDCOut andIn
The12VDCoutputsendsa 12Volt poweron/off signal to other Krell componentsvia a
12Vtrigger cable,aswell asto otherdevicesthat incorporate12Volt poweron/off
trigger input. TheHomeTheaterStandardhasfour programmable12Volt outputs:
Out1,Out2,Out3,andOut4;oneinput is available.
Note
Whenthe HTSis in the operationalmode,the 12VDCOutprovides12 Vof DCoutput.
Whenthe HTSis in the stand-bymodeor off, the DCoutputis 0 V.
Power
54 BackPanel PowerSwitch
Usethis switchto changethe HomeTheaterStandardfromoff to stand-by.
55 lEO Connector
TheHomeTheaterStandardis equippedwith a standardfemaleIECpowerconnector,
for usewith the ACpowercord.
16 KrellHomeTheaterStandard
