Kroger OXE-100 Quick Reference Guide
Basic Operation
Filling the Fresh Oil Tank
Drain Pan Assembly
Product Racking Recommendations
Filter Menu
Preventive Maintenance
Error Codes
The fresh oil tank automatically tops off the oil in the vat when it senses the oil level is
low. User should add fresh oil to the tank as needed. DO NOT add fresh oil directly to
the vat.
1. Fill empty vat with new oil to the lower level indicator.
2. Turn the POWER switch to the ON position.
3. Allow fryer to heat until set point COOL is reached.
NOTE:
• Push the information (i) button to see set point and true temperature of oil.
• The heat cycles on and off approximately 10 degrees before the setpoint
temperature to help prevent overshooting the setpoint temperature.
4. Press the product button and allow the temperature to reach set point. When
setpoint is reached, READY displays.
Best Practice: To prevent product sticking to racks, lower empty racks into cooking oil
and let cool prior to use.
5. Slide racks of breaded product into lid carrier. Refer to the Product Racking
Recommendations section below.
6. Lower and lock the lid according to the instructions located on the lid, and then
press the appropriate product button.
7. At the end of the cycle, the alarm sounds and DONE displays. Press the DONE
button. The alarm stops.
8. Unlock and raise the lid slowly. Product is very hot.
9. Using the rack handles, remove the racks of product from the carrier, starting with
the top rack.
1. Push and hold until the display reads *MAIN*.
2. Press 1to enter the Filter menu.
3. Use the buttons next to the arrows on the display to access the next set of options.
4. Push the menu button again to cycle to next set of options.
1. QUICK
2. DAILY
3. POLISH
4. DRAIN TO PAN
5. FILL FROM PAN
6. FILL FROM NEW
7. DISPOSE
8. FILL FROM BULK
x. EXIT MENU
Procedure Frequency
Changing of oil.........................................As Required
Changing the lter envelope.....................Daily
Cleaning the vat........................................Daily
Clean slide llers......................................Weekly
Change Drain Pan O-rings........................Quarterly
Change Fresh Oil Tank O-rings................Quarterly Code Cause Correction
E-4 CPU too hot Turn switch to OFF position, then turn switch back to
ON
E-5 Oil Overheating Have heat circuits and temp. probe checked
E-6
(A or B) Temp. probe open
or shorted Have temp. probe checked
E-10 High Limit Tripped Reset the high limit switch located under the control
board, above the condensation pan
E-15
(C or P) Drain valve, close
or open issue
• Ensure drain valves are secure
• Check for obstructions
Fully loaded with 4-bags
(all 4 racks used)
4
3
2
1
4-Bags: Load all four racks as shown
3-Bags: Load racks 1, 2 and 3 only
2-Bags: Load racks 2 and 3 only
1-Bag: Load rack 2 only
High Limit Reset
1. Slide a lter envelope onto the lter screen so the
plug is protruding through the hole.
2. Slide the two handle clamps onto the ends of the
lter screen assembly with the handles opposite
sides of the plug.
3. Place the lter screen plug up in the bottom of the
drain pan.
4. Line up the hole of the pickup tube with the plug
of the lter screen, then press the tube down.
5. Position the pick up tube so that the guides slide
into the notches located on the hold in the front of
the drain pan.
6. Press down on the pick up tube to conrm it is
fully engaged on the lter screen plug and in the
holder.
7. Place the crumb catcher onto the handles of the
clips.
8. Place the lid onto drain pan.
NOTE: During assembly, be sure to apply oil to all O-rings to lubricate to help
prevent tears and loss.

Kroger OXE-100 Quick Reference Guide
1
2
3
Item
No. Description Function
1 Fresh Oil Tank Tops the vat off with fresh oil when low
2 Power Switch Turns power to the unit ON/ OFF
3 Oil Drain Pan Oil is drained into this pan and then is
pumped through filters to help prolong the
use of the oil
Figure 3-2 Figure 3-3
Figure 3-4
11
32
4
5
6
3-1 1 Buttons
When the light is illuminated next to
the button, this indicates this button
has a product or action that can be
reach by pressing.
3-2 2 Menu Button
Press and holding this button will
access the MAIN menu which
include features such as lter, info
mode, and programming.
3-3 3 Info Button
• Press this button once to display
the pressure and temperature
• Press this button twice to
activate the WIPE feature
• Press this button three times to
get LAST FILTER information
3-4 4 Arrow Displays
When an arrow is displayed, this
indicates there is another screen or
option. To access the next option/
screen, press the button next to the
desired arrow.
3-4 5 Plus Display
The plus sign is displayed when the
value of the time/temp/letters can be
changed. Pressing the button next to
the plus sign will increase the value.
3-4 6 Minus Display
The minus sign is displayed when
the value of the time/temp/letters
can be changed. Pressing the button
next to the minus sign will decrease
the value.
Fig. Item
No. Description Function
Component / Control Overview
