KSB Guard Installation instructions

KSB Guard
Installation/Operating Manual

Legal information/Copyright
Installation/Operating Manual KSB Guard
Original operating manual
All rights reserved. The contents provided herein must neither be distributed, copied, reproduced,
edited or processed for any other purpose, nor otherwise transmitted, published or made available to a
third party without the manufacturer's express written consent.
Subject to technical modification without prior notice.
© KSB SE & Co. KGaA, Frankenthal 24/09/2019

Contents
3 of 44
KSB Guard
Contents
1 General.................................................................................................................................................... 5
1.1 Principles ...........................................................................................................................................................5
1.2 Target group.....................................................................................................................................................5
1.3 Other applicable documents............................................................................................................................5
1.4 Symbols .............................................................................................................................................................5
1.5 Key to safety symbols/markings.......................................................................................................................5
2 Safety...................................................................................................................................................... 7
2.1 General..............................................................................................................................................................7
2.2 Intended use .....................................................................................................................................................7
2.3 Personnel qualification and personnel training.............................................................................................7
2.4 Consequences and risks caused by non-compliance with this operating manual........................................7
2.5 Safety awareness ..............................................................................................................................................8
2.6 Software changes .............................................................................................................................................8
3 Transport/Temporary Storage/Disposal............................................................................................... 9
3.1 Checking the condition upon delivery............................................................................................................9
3.2 Transport...........................................................................................................................................................9
3.3 Storage..............................................................................................................................................................9
3.4 Disposal ...........................................................................................................................................................10
4 Description............................................................................................................................................ 11
4.1 General description ........................................................................................................................................11
4.2 Product information.......................................................................................................................................11
4.2.1 Product information as per Regulation No. 1907/2006(REACH) ....................................................11
4.3 Name plates ....................................................................................................................................................11
4.4 Technical data.................................................................................................................................................11
4.5 Function ..........................................................................................................................................................12
4.6 Measured values.............................................................................................................................................13
4.7 Gateway ..........................................................................................................................................................13
4.8 Sensor unit ......................................................................................................................................................14
4.9 Transmission and battery unit .......................................................................................................................14
5 Installation/ Commissioning............................................................................................................... 15
5.1 Setting up access to the KSBGuard system ..................................................................................................15
5.2 Installation ......................................................................................................................................................15
5.2.1 Installing the gateway.......................................................................................................................15
5.2.2 Positioning the transmission and battery unit.................................................................................19
5.2.3 Establishing a connection between the sensor unit and the transmission and battery unit........19
5.2.4 Installing the sensor unit...................................................................................................................19
5.2.5 Installing the transmission and battery unit ....................................................................................20
5.2.6 Routing the connecting cable ...........................................................................................................21
5.3 Assigning and setting up ...............................................................................................................................23
5.4 Commissioning................................................................................................................................................24
6 Operation.............................................................................................................................................. 26
6.1 Operating modes of transmission and battery unit.....................................................................................26
6.2 Taking manual measurement and displaying signal strength.....................................................................26
6.3 Turning off the transmission and battery unit.............................................................................................27
7 Servicing/Maintenance........................................................................................................................ 28
7.1 Replacing the batteries ..................................................................................................................................28
7.2 Replacing the sensor unit...............................................................................................................................29
7.3 Replacing the transmission and battery unit................................................................................................29
7.4 Replacing the gateway...................................................................................................................................29
8 Dismantling .......................................................................................................................................... 30
8.1 Dismantling the gateway...............................................................................................................................30

Contents
4 of 44 KSB Guard
8.2 Dismantling the transmission and battery unit............................................................................................30
8.3 Dismantling the sensor unit...........................................................................................................................31
9 Trouble-shooting.................................................................................................................................. 32
9.1 Trouble-shooting the gateway......................................................................................................................32
9.2 Trouble-shooting the transmission and battery unit/ sensor unit..............................................................32
10 Related Documents.............................................................................................................................. 34
10.1 Recommended mounting position for sensor unit ......................................................................................34
11 Purchase Order Specifications............................................................................................................. 38
11.1 Ordering spare parts ......................................................................................................................................38
11.2 Accessories ......................................................................................................................................................38
12 EU Declaration of Conformity............................................................................................................. 39
Index ..................................................................................................................................................... 40

1 General
5 of 44
KSB Guard
4079.8/02-EN
1 General
1.1 Principles
This operating manual is valid for the type series and variants indicated on the front
cover.
The operating manual describes the proper and safe use of this equipment in all
phases of operation.
The name plate indicates the type series, the main operating data and the serial
number. The serial number uniquely describes the product and is used as
identification in all further business processes.
In the event of damage, immediately contact your nearest KSB service facility to
maintain the right to claim under warranty.
1.2 Target group
This operating manual is aimed at the target group of trained and qualified specialist
technical personnel.
1.3 Other applicable documents
Table1: Overview of other applicable documents
Document Contents
Operating manual for pump/
pump set
Description/operation of pump/pump set
For accessories and/or integrated machinery components, observe the relevant
manufacturer's product literature.
1.4 Symbols
Table2: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product
1.5 Key to safety symbols/markings
Table3: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.

1 General
6 of 44 KSB Guard
4079.8/02-EN
Symbol Description
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information about
protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.

2 Safety
7 of 44
KSB Guard
4079.8/02-EN
2 Safety
!DANGER
All the information contained in this section refers to hazardous situations.
In addition to the present general safety information the action-related safety
information given in the other sections must be observed.
2.1 General
▪This operating manual contains general installation, operating and maintenance
instructions that must be observed to ensure safe operation of the system and
prevent personal injury and damage to property.
▪Comply with all the safety instructions given in the individual sections of this
operating manual.
▪The operating manual must be read and understood by the responsible specialist
personnel/operators prior to installation and commissioning.
▪The contents of this operating manual must be available to the specialist
personnel at the site at all times.
▪Information and markings attached directly to the product must always be
complied with and kept in a perfectly legible condition at all times. This applies
to, for example:
– Markings for connections
– Name plate
▪The operator is responsible for ensuring compliance with all local regulations not
taken into account.
2.2 Intended use
▪The values specified in the technical product literature for the mains voltage and
ambient temperature must not be exceeded. The device must only be operated
in accordance with the instructions provided in the operating manual and other
applicable documents.
2.3 Personnel qualification and personnel training
All personnel involved must be fully qualified to install, operate, maintain and
inspect the equipment this manual refers to. The responsibilities, competence and
supervision of all personnel involved in transport, installation, operation,
maintenance and inspection must be clearly defined by the operator.
Deficits in knowledge must be rectified by means of training and instruction
provided by sufficiently trained specialist personnel. If required, the operator can
commission the manufacturer/supplier to train the personnel.
Training on the device must always be supervised by specialist technical personnel.
2.4 Consequences and risks caused by non-compliance with this operating
manual
▪Non-compliance with this operating manual will lead to forfeiture of warranty
cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
– Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
– Failure of important product functions
– Failure of prescribed maintenance and servicing practices

2 Safety
8 of 44 KSB Guard
4079.8/02-EN
2.5 Safety awareness
In addition to the safety information contained in this operating manual and the
intended use, the following safety regulations shall be complied with:
▪Accident prevention, health regulations and safety regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards, directives and laws
2.6 Software changes
The software has been specially created for this product and thoroughly tested.
Making changes or additions to the software or parts of the software is prohibited.
In irregular intervals updates will be made to the gateway and to the transmission
and battery units. These updates will run automatically in the background and serve
to enhance the product performance.

3 Transport/Temporary Storage/Disposal
9 of 44
KSB Guard
4079.8/02-EN
3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer and the insurer about the damage in writing
immediately.
3.2 Transport
CAUTION
Improper transport
Damage to the device!
▷Always transport the device properly and in its original packaging.
▷For transport, observe the transport instructions on the original packaging.
▷Do not throw device.
1. Upon receipt, unpack the device and check for in-transit damage.
2. Report any in-transit damage to the manufacturer immediately.
3. Dispose of packaging material in accordance with local regulations.
3.3 Storage
If the ambient conditions for storage are met, the function of the device will be
ensured even after a prolonged period of storage.
CAUTION
Damage during storage by humidity, dirt or vermin
Corrosion/contamination of the device!
▷For outdoor storage cover the (packed or unpacked) device and accessories with
water-proof material.
Table4: Ambient conditions for storage
Ambient condition Value
Relative humidity 85% max. (non-condensing)
Ambient temperature -30°C to +60°C
1. Store the device in dry conditions and in its original packaging.
2. Store the device in a dry room in which the atmospheric humidity is maintained
at a constant level (as far as this is possible).
3. Prevent excessive fluctuations in atmospheric humidity (see Ambient conditions
for storage table).

3 Transport/Temporary Storage/Disposal
10 of 44 KSB Guard
4079.8/02-EN
3.4 Disposal
Electrical or electronic equipment marked with the adjacent symbol must not be
disposed of in household waste at the end of its service life.
Contact your local waste disposal partner for returns.
If the used electrical or electronic equipment contains personal data, the operator is
responsible for deleting it before the equipment is returned.
NOTE
Due to certain components it contains, the device is classified as special waste and
meets RoHs 2011/65/EC requirements.
Once decommissioned, the device must be properly disposed of in accordance with
local regulations.

4 Description
11 of 44
KSB Guard
4079.8/02-EN
4 Description
4.1 General description
Monitoring device for monitoring vibrations and temperatures of pump sets.
4.2 Product information
4.2.1 Product information as per Regulation No. 1907/2006(REACH)
For information as per chemicals Regulation (EC) No. 1907/2006 (REACH), see http://
www.ksb.com/reach.
4.3 Name plates
KSB SE & Co.KGaA
www.ksb.com
Ambient Temperature:
Protection Class:
Id. No
0 - 90 °C
IP65
01852755
GS118W220001Serial No
KSB Guard Sensor Unit
Fig.1: Name plate of sensor unit (example)
KSB SE & Co.KGaA
www.ksb.com
Battery Supply: 2 x 1.5V (baby-cell)
0 - 50 °C
IP65
2.4 GHz / < 10mW
Indoor use only
01852758 / 01852753
GT118W260001
Johann-Klein-Str. 9
D-67227 Frankenthal
Protection Class:
KSB Guard Transmission and Battery Unit
Ambient Temperature:
Id. No (Complete System/This Unit):
Serial No
Sensor Network Comm.:
Fig.2: Name plate of transmission and battery unit (example)
Fig.3: Name plate of gateway (example)
4.4 Technical data
Sensor unit Table5: Technical data of sensor unit
Characteristic Value
Material Aluminium
Dimensions [mm] 60x45x30

4 Description
12 of 44 KSB Guard
4079.8/02-EN
Characteristic Value
Enclosure IP65
Cable type 1.5m, PUR, 6-core
Permissible surface temperature of the pump 0 to90°C1)
Transmission and battery
unit
Table6: Technical data of transmission and battery unit
Characteristic Value
Material Plastic
Dimensions [mm] 120x80x50
Enclosure IP65
Permissible surface temperature 0 to 50°C1)
Power supply ▪Transmission and battery
unit with pressure balancing
element:
two 1.5V standard alkaline
batteries (LR20/ mono cells/
sizeD)
▪Transmission and battery
unit without pressure
balancing element:
two 1.5V standard alkaline
batteries (R14/ baby cells/
sizeC)
Wireless module ISM band, 2.4GHz
Connection M8, 6-pin
Gateway Table7: Technical data of gateway
Characteristic Value
Mains voltage 110 - 240V, AC voltage
Mains frequency 50/60Hz
Power input <15W
In-service ambient temperature 0 to 40°C1)
Enclosure IP54
Weight <400g
Dimensions 158×95×45
SMA-RP socket (antenna sensor network) Antenna for 2.4 GHz (WLAN/
Bluetooth)
SMA socket (LTE antenna) Antenna for 2G/3G/4G mobile
data, included in standard
accessories with approx. 5 m
cable
Internal SIM card2) Pre-configured
4.5 Function
Sensor unit The sensor unit is preferably installed at the pump’s bearing bracket or drive lantern,
where it measures the pump’s vibrations and temperature trends using built-in
sensors. This data is sent to the transmission and battery unit.
Transmission and battery
unit
The sensor unit is connected to the transmission and battery unit with a connecting
cable.
The transmission and battery unit sends the recorded data to the gateway via a radio
signal.
1) Higher temperatures than indicated are possible. Contact KSB Support before installation. Contact: +49623386-6400 and
2) The SIM card is pre-installed and cannot be replaced.

4 Description
13 of 44
KSB Guard
4079.8/02-EN
Gateway The gateway collects the data of the sensor unit and transfers it to the KSB Cloud in
encrypted format. The data can be accessed via the KSB Guard app or the
ksbguard.net web portal.
One gateway can process the data of up to 20 transmission and battery units if they
send data every hour. This number is reduced with more frequent data transmission.
4.6 Measured values
Temperature The temperature is measured inside the sensor unit. The values can therefore differ
from the actual surface temperature of the pump set.
Vibrations The vibration values are measured in three axes and usually output as RMS values.
4.7 Gateway
1 2 3 4 5
6
Fig.4: Gateway
1 Antenna connection (data
transmission from transmission and
battery unit)
2 Status LED for supply voltage
3 Status LED S1 for connection status 4 Level LEDs for mobile network
signal strength
5 Antenna connection for mobile
data (LTE)
6 Power supply connection
Table8: Description of LED indicators
No. LED Status Description
2 Supply voltage OFF Device is out of operation or in the initialisation phase.
Green Device is in operation. No faults present.
Red or flashing red Device is in operation. Faults are present.
3 Connection status
S1
OFF Device waiting for mobile data connection
Flashing yellow (approx.
3min after switch-on)
Problems with Internet connection
Green Mobile network and Internet accessible
Green, flashing rapidly New firmware found. Internal firmware update started.
4 Mobile network
signal strength
4th LED green Signal strength > -75dBm
3rd LED green Signal strength > -85dBm

4 Description
14 of 44 KSB Guard
4079.8/02-EN
No. LED Status Description
4 Mobile network
signal strength
2nd LED green Signal strength > -95dBm
1st LED green Signal strength < -95dBm
4.8 Sensor unit
2
1
3
Lorem ipsum
x
y
z
Fig.5: Sensor unit with coordinate system
1 Coordinate system 2 QR code
3 Connecting cable to transmission
and battery unit
4.9 Transmission and battery unit
2
1
3
6
7
4
5
1
2
3
6
4
5
7
8
a) b)
Fig.6: a) Transmission and battery unit without pressure balancing element, b)
Transmission and battery unit with pressure balancing element
1 Position of internal antenna 2 Pushbutton
3 Status LED A 4 Status LED B
5 Level LEDs for indicating the signal
strength of the gateway connection
6 Cover for housing screws
7 Connection for connecting cable to
sensor unit
8 Pressure balancing element
Table9: Description/ function of control elements and LED indicators
Control element/ LED indicator Description
Pushbutton Commissioning, status check, manual measurement
Status LED A Status LEDs for indicating the operating status and for coded output of fault
messages
Status LED B
Level LEDs Signal strength of the gateway connection

5 Installation/ Commissioning
15 of 44
KSB Guard
4079.8/02-EN
5 Installation/ Commissioning
5.1 Setting up access to the KSBGuard system
Send the following information to this e-mail address:
▪E-mail: [email protected]
Table10: Required data
Required data Notes
Organisation’s name
(e.g. company name, such as XY Industrial
Estate, Exampleville Waterworks.)
Company's post/ zip code
Company’s city
Company’s country
Company’s customer number (at KSB if
applicable)
Administrator’s name
(the first company employee who is to have
access to/ use the KSBGuard. This person can
then add further users.)
Administrator’s e-mail address
A customer account will be created with this data.
A system-generated welcome e-mail will be sent to the e-mail address entered. This
e-mail will also contain a prompt to change the initial password.
5.2 Installation
NOTE
For all queries relating to the actual installation (e.g. positioning of sensors,
reception quality) KSB Guard Support will be available. (ðSection9,Page32)
5.2.1 Installing the gateway
DANGER
Risk of falling when working at a great height
Danger to life by falling from a great height!
▷Do not step onto the pump (set) during installation work or dismantling work.
▷Pay attention to safety equipment, such as railings, covers, barriers, etc.
▷Observe the applicable local health and occupational safety regulations and
accident prevention regulations.
WARNING
Work in the immediate vicinity of rotating parts
Risk of hand injury!
▷Always have this work performed by trained personnel.
▷Take particular caution when performing this work.

5 Installation/ Commissioning
16 of 44 KSB Guard
4079.8/02-EN
CAUTION
Incorrect installation
No data transmission!
▷Never connect more than 20 transmission and battery units to a gateway.
One gateway can process the data of up to 20 transmission and battery units if they
send data every hour. This number is reduced with more frequent data transmission.
The manufacturer must be consulted if more than 20 transmission and battery units
are connected or if the data transmission rate is higher.
5.2.1.1 Checking the installation location of the gateway
The installation location of the gateway must meet the following requirements:
▪Temperature 0-40°C3) (ðSection4.4,Page11)
▪Only install and operate the gateway in closed rooms.
▪No direct sunlight
▪Maximum distance between gateway and transmission and battery unit: 30m
▪Area between gateway and transmission and battery unit with as few obstacles
as possible (e.g. walls).
If possible: Install with a line of sight between the pump set to be connected and
the gateway.
5.2.1.2 Installing the gateway antennas
2
1
3
Fig.7: Installing antennas
1 Optimum direction for reception 2 Rod antenna
3 Magnetic base antenna
The antenna cable should not exceed 20 m in length.
1. Screw the supplied rod antenna onto the left connection (Antenna sensor
network).
2. Screw the magnetic base antenna onto the right connection (Antenna LTE).
3. Place the magnetic base antenna in a location that has sufficiently high mobile
network signal strength. (ðSection5.2.1.4,Page18)
3) Higher temperatures than indicated are possible. Contact KSB Support for more information.

5 Installation/ Commissioning
17 of 44
KSB Guard
4079.8/02-EN
5.2.1.3 Electrically connecting the gateway
Connection to a shockproof socket
1. Plug the existing power cable into the shockproof socket.
2. Check the status LED.
Make sure that at least 2 LEDs are lit. This indicates that the connection to the
mobile network is sufficiently strong.
ðIf applicable, an automatic firmware update for the device will be carried out
first. Depending on the reception quality of the accessible mobile network this
process can take 5-10minutes. When both status LEDs are permanently lit in
green and the level LEDs indicate sufficient signal strength, the device is ready
for use.
Alternative connection to customer’s own power supply
DANGER
Improper work on electrical connection
Electric shock!
▷The gateway may only be opened by a qualified electrical technician.
▷Electrical work may only be carried out by a qualified electrical technician.
Alternatively, the existing power cable can be replaced with the customer’s own
power cable:
1
Fig.8: Gateway
1 Screw terminals for power supply
1. Insert the customer’s own power cable into the device through the cable gland.
2. Connect the power cable to the appropriate screw terminals on the printed
circuit board.
When the customer’s own power cable is connected, the gateway starts
automatically and is ready for use.
3. Check status LED S1.
Make sure that at least 2 level LEDs are lit. This indicates that the connection to
the mobile network is sufficiently strong.
ðIf applicable, an automatic firmware update for the device will be carried out
first. Depending on the reception quality of the accessible mobile network this
process can take 5-10minutes. When both status LEDs are permanently lit in
green and the level LEDs indicate sufficient signal strength, the device is ready
for use.
NOTE
When connecting the cable ensure that the enclosure requirements (IP54) are met
again after installation.

5 Installation/ Commissioning
18 of 44 KSB Guard
4079.8/02-EN
5.2.1.4 Checking the signal strength of the gateway
The signal strength of the mobile data connection can be changed by positioning the
magnetic base antenna. The current signal strength is indicated by the corresponding
level LEDs (see Table: Description of LED indicators). (ðSection4.7,Page13)
▪Minimum sufficient signal strength is indicated by 2 level LEDs lighting up.
▪Good signal strength is indicated by 3 level LEDs lighting up.
▪Maximum signal strength is indicated by 4 level LEDs lighting up.
It is recommended that you position the magnetic base antenna such that 3 or 4 level
LEDs are lit during installation. (ðSection4.7,Page13)
1. Place the magnetic base antenna in a location that has sufficiently high mobile
network signal strength.
2. Check the level LEDs for mobile network signal strength.
3. If necessary, change the position of the magnetic base antenna and check again.
If this condition cannot be met, check whether a more powerful LTE antenna can be
installed, possibly also with a longer cable.
The antenna cable should not exceed 20 m in length.
NOTE
To improve data transmission between the gateway and the transmission and
battery unit, you can rotate and tilt the gateway antenna (data transmission of
transmission and battery unit). The gateway antenna acts in the plane
perpendicular to the antenna’s axis. The transmission and battery unit should be in
this plane. (ðSection5.2.1.2,Page16)
5.2.1.5 Commissioning the gateway
The device is delivered fully configured and is ready for operation after the power
supply has been connected. The current operating status is indicated by the LED for
the supply voltage. (ðSection4.7,Page13)
5.2.1.6 Fastening the gateway
1
2
Fig.9: Fastening the wall bracket
1 Wall bracket 2 Bolts/screws
üThe gateway antennas have been fitted.
üThe gateway is connected to the power supply.
üThe signal strength at the installation location has been checked and is sufficient.
1. Attach the wall mounting bracket supplied to a suitable wall using 2 screws.
2. Connect the rear adapter of the gateway to the wall bracket.

5 Installation/ Commissioning
19 of 44
KSB Guard
4079.8/02-EN
5.2.2 Positioning the transmission and battery unit
Set-up mode The Set-up mode helps find a suitable position for the transmission and battery unit.
The Setup mode can be repeated any number of times.
üThe gateway has been installed and the signal strength indicated is sufficient.
1. Press and hold the pushbutton (1) on the transmission and battery unit for 2-
3seconds. Release the pushbutton as soon as status LEDs A and B of the
transmission and battery unit briefly light up simultaneously.
2. Watch the signal strength of the gateway connection (see level LEDs) in order to
find a suitable position near the pump set.
ðAfter the Set-up mode has been activated, it remains active for 10minutes
and then stops automatically. The Set-up mode can be stopped at any time
by briefly pressing the pushbutton (<1s)
If a sensor unit has been connected, the device changes to the Automatic Measuring
Operation operating mode. (ðSection6.1,Page26)
If no sensor unit has been connected, the device reverts to its supplied condition.
(ðSection6.1,Page26)
5.2.3 Establishing a connection between the sensor unit and the transmission and
battery unit
NOTE
The adhesive bond between the sensor unit and bearing bracket or drive lantern
must be sufficiently cured before continuing to install the connecting cable to avoid
changing the position of the sensor unit.
1. Connect the connecting cable of the sensor unit to the transmission and battery
unit.
5.2.4 Installing the sensor unit
DANGER
Strong magnetic field
Danger of death for persons with pacemaker!
Interference with magnetic data carriers, electronic devices, components and
instruments!
Uncontrolled magnetic attraction forces between magnet-equipped components,
tools or similar!
▷Keep a safety distance of at least 0.3m.
WARNING
Hot surfaces of pump set
Risk of burns!
▷Observe the manufacturer’s safety instructions for fastening the sensor unit and
using the adhesive.
WARNING
Sensor unit takes on temperature of bearing bracket or drive lantern
Risk of burns!
▷Observe the operating manual of the pump set.
▷When the pump set is being operated, only touch the sensor unit using suitable
protective gloves.

5 Installation/ Commissioning
20 of 44 KSB Guard
4079.8/02-EN
WARNING
Work in the immediate vicinity of rotating parts
Risk of hand injury!
▷Always have this work performed by trained personnel.
▷Take particular caution when performing this work.
Positioning the sensor unit Observe the following information when positioning and fastening the sensor unit:
▪Mount the sensor unit in a suitable location on the bearing bracket or drive
lantern at a height of up to 2m.
Recommended mounting position (ðSection10.1,Page34)
▪Affix the sensor unit to magnetic material if possible (preferred).
▪The location on the bearing bracket or drive lantern where the sensor unit is
mounted should be level. Use the adhesive to compensate for minor uneven
spots or curvatures.
▪The sensor unit must also be glued in addition to the magnetic holders. The
adhesive surface should not be on top (with the unit upside down).
▪The adhesive should be processed at room temperature (18-25°C).
üThe operating manual for the pump set is accessible and has been observed.
üAll safety instructions for the adhesive have been read and observed.
1. Remove any coarse dirt from the mounting area.
2. Clean the back of the sensor unit using the supplied cleaning pad.
3. Clean the mounting area using the supplied cleaning pad.
4. Spread the supplied adhesive over the back of the sensor unit.
5. Position the sensor unit on the cleaned area of the bearing bracket or drive
lantern. The sensor unit is optimally aligned when the x-axis of the sensor unit is
parallel to the shaft and the y-axis of the sensor unit is horizontal to the shaft.
6. Firmly press down the sensor unit.
7. Allow the sensor unit to dry on the bearing bracket or drive lantern to ensure
that the position of the sensor unit is not unintentionally changed during
subsequent mounting. The adhesive bond must be able to withstand slight
vibrations at the sensor unit. The waiting time strongly depends on ambient
conditions.
NOTE
At an ambient temperature between +25 °C and +30 °C, the supplied adhesive will
have sufficiently cured after approximately 24 hours. After 3 days, the adhesive will
have fully cured. Increased temperatures (e.g. +60°C to +120°C) accelerate the
curing process.
8. Check that the sensor unit is firmly positioned on the bearing bracket or drive
lantern; re-glue the sensor unit if necessary.
5.2.5 Installing the transmission and battery unit
WARNING
Work in the immediate vicinity of rotating parts
Risk of hand injury!
▷Always have this work performed by trained personnel.
▷Take particular caution when performing this work.
