KSR Navara SF Select Assembly instructions

Ceiling mounted
Wall mounted
300mm 84mm
Drg No. KSRSF337-IS-B
KSR Lighting Ltd, Unit E Hazleton Interchange, Lakesmere Road, Horndean, Hampshire, PO8 9JU
08.11.2022-PJL
Installation Sheet KSRSF337
Read these instructions before commencing installation. Please give these instructions to the owner/occupier after
installation to retain for future reference/maintainence.
Navara SF Select
Available Rims: Various please visit www.ksrlighting.com for options
Multi Wattage Triple CCT Bulkhead
IP54 IK10 240V~50Hz 10W/14W/20W
These fittings are Class II and do not need an Earth, but Earth provision is provided.
Important Information
It is recommended that these luminaires are installed and fitted by a qualified electrician ensuring the installation
complies with current IEE wiring regulations & local building control. These products are designed for connection to
a 240V~50Hz supply.
Any faulty, broken or damaged luminaires should be replaced immediately.
KSR will not accept responsibility for any claims arising from a poor installation.
Please Note: The limited warranty shall be deemed null and void in the following circumstances: Failure by the
installer, end user or any third party to exercise caution to protect any covered product or part from outside damage,
adverse temperature (normal operating ambient temperature 0°C - +30°C), humidity conditions, fluctuations in the
electrical system or physical abuse as well as failure related to workmanship in the installation of the products or
parts.
Important User Advice
Always switch off mains supply before servicing.
Do not use Megger or similar high voltage instruments. Due to the fact this luminaire contains electronic
components that maybe damaged by high test voltages, they must be disconnected from the circuit before testing.
To prevent damage to the driver, do not mix with conventional magnetic ballasts on the same electrical circuit.
At the end of life the luminaire is classed as WEEE under directive 2014/30/EU and should be disposed of in
accordance with local legislation.
Installation Procedure
Isolate mains supply before installation.
Unscrew and retain the four screws and remove the diffuser.
Loosen the single LED tray screw as indicated in Fig.2 and lift the hinged tray to gain access to the wiring terminals.
Pass intended supply wires through grommet.
Ensure the fixing surface is flat and even.
Fix base to the wall, ceiling or besa box using adequate fixings with regard to the type of surface.
Ensure incoming cables are protected.
Terminate wiring as per Fig. 3, please note an Earth terminal is only supplied to aid the continuation of the Earth
circuit.
Please ensure battery is connected, this battery compartment can be accessed as shown overleaf.
Select LED colour and wattage required using the switches on the LED driver Note: Never change the LED colour
or wattage with the luminaire powered on as this can damage the luminaire. Fig. 4.
To set Photocell adjust the Lux level required via the adjuster (anti-clockwise = lowest, clockwise = highest)
and to test simply cover photocell when powered on in daylight and wait for the luminaire to Light up.
Proceed to Re-secure the LED tray.
Make sure the seal is in place in the diffuser and undamaged.
Replace the diffuser re-secure using the four retained screws.
Turn on the mains supply and test luminaire. If using an optional rim clip the rim over the fitting.
This fitting requires a 24 Hour initial charge period prior to any emergency testing, please see
overleaf for testing routine, write on the battery label in permanent ink the date of commissioning.
All results must be recorded and left with the end user.
The battery has a design life of at least 4 years but should be replaced if the duration of
operation is less than 3 hours after a 24hr charge time with no interrupted supply.
Fig. 1
Fig. 2
Gear Tray Retaining Screw
3000K
4000K
6000K
20W
14W
10W
Model: KSRSF330/331/332/333
KSRSF400/401/402/403
Input:220~240Vac 50/60Hz
Output:80-120VDC 175mA(Max)
Prated:20W Max Tc
Ta:40°C TC:85°C
V+ G- W- E+ Made in China
G-
G+
NL
Fig. 4
Wattage
LED Colour
Fig. 3
Mains Supply Luminaire
L- Brown
Permanent Live - Black
N - BlueNeutral - Blue
L N
L- Brown
Switch Live - Brown
'L
KSR Lighting Aftersales: 023 92 674343
E-mail: [email protected]
Lamp Details
Lamp: LED
Wattage: 10W, 14W, 20W
Colour: 3000K, 4000K and 6000K CCT
CRI: Ra>84
This product contains a light source of energy efficiency class F
Lumen output
CCT
10W
14W
20W
3000K 4000K
1145lm 1261lm
1658lm1457lm
2126lm1819lm
6000K
1212lm
1559lm
1947lm
PLEASE NOTE: If using an optional rim to ensure the photocell is
not obscured from ambient light. Measure 18mm from the back
of the rim and slowly drill a 10mm hole using a brad point drill bit.
Install rim to line up the hole with the sensor.
Turn on the mains supply and test luminaire.
Instruction when using Photocell with Optional Rim

All tests must be undertaken at times of least risk and in accordance with EN 50172:2004 as indicated below:
Daily:
LED charge indicators shall be visually inspected for correct operation.
Monthly:
(in addition to the daily check) If automatic testing devices are used, the results of the short duration tests shall be recorded.
Test shall be carried out as follows:
1. Switch the luminaire over to emergency mode to operate from the batteries by simulating a failure of supply
to the emergency circuit for a period sufficient to ensure correct luminaire operation.
Note: The period of simulation failure should be sufficient for the purpose of this clause whilst minimising
damage to the system components e.g lamps. During this period, all luminaires shall be
checked to ensure that they are present, clean and functioning correctly. At the end of this test period, the unswitched
supply should be restored and any indicator lamp or device should be checked to ensure that is showing that the supply
has been restored.
Annually:
If automatic testing devices are used, the results of the short duration tests shall be recorded. For all
other systems the monthly inspection shall be carried out and the following additional
tests made:
1. Each luminaire shall be tested monthly as above but for its full duration in accordance with the manufacturer’s
information.
2. The unswitched supply for the luminaire should be restored and any charge indicator lamp or device should be checked
to ensure that it shows the unswitched supply has been restored. The charging arrangements should be checked for
proper functioning.
3. The date of the test and its results shall be recorded in the system logbook.
A copy of this report must accompany any emergency luminaire returned to KSR Lighting for any reason.
Battery Maintenance (Removal and Replacement Procedure)
For battery servicing please refer to Fig 1. showing how to access the battery compartment, please ensure when changing the
battery that the circuit is isolated and that the battery replacement is compatible with the product description.
To access the battery compartment simply remove the locking screw with a screwdriver and proceed to remove cover by
releasing the holding tab located to the the left side of the compartment.
When cover is removed disconnect old battery and recycle in accordance with WEEE under directive 2014/30/EU, this should
be disposed of in accordance with local legislation.
Proceed to connect the new battery by clicking connectors back together and replace battery back into battery housing
With battery in place replace cover onto compartment and fasten in place with locking screw removed earlier
Turn on the mains supply and test luminaire
Any deviation from the battery specification may result in damage to the emergency circuit or failure to perform under
emergency conditions.
KSR Lighting Ltd, Unit E Hazleton Interchange, Lakesmere Road, Horndean, Hampshire, PO8 9JU
Emergency Range Routine Inspection/Test Navara SF Select Emergency Bulkhead
L
N
R+
R-
G+
G-
B+
B-
L
N
R+
R-
G+
G-
B+
B-
LifePO4 3.2V 1500mAh Battery
Release Tab
Fig. 1

Em No. Luminaire Location Luminaire Type Start Time Duration (Mins) *Pass/Fail Comments/Actions
Site Address:
Test Conducted By:
Date of Test Completion:
Comments/Actions
Emergency Lighting Periodic Test Schedule
√
All emergency lighting should be installed and tested in accordance to EN5266-1:2011. This test schedule should remain
onsite and be accessible to the relevant authorities on request.
