Code Blue CB 5 Series Service manual

800.205.7186 •www.codeblue.com
Administrator Guide
Installation | Configuration | Operation | Troubleshooting
CB 5 Series

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 2 of 50
CB 5 Series
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED ELECTRI-
CIAN MAY BE REQUIRED.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software described herein, in
whole or part, shall not be reproduced, translated or reduced to any machine-readable form without
prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DIS-
CLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICU-
LAR PURPOSE WITH REGARD TO THIS GUIDE, THE SOFTWARE OR SUCH OTHER INFORMA-
TION. IN NO EVENT SHALL CODE BLUE CORPORATION BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modications to this guide or the information
contained herein at any time without notice. The software described herein may also be governed
by the terms of a separate user license agreement.
Code Blue®is a registered trademark of Code Blue Corporation.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 3 of 50
CB 5 Series
Administrator Guide
Table of Contents
(NOTE: Phone programming instructions can be found in the IP5000 and IA4100 Guides.)
Section Page
2 Introduction........................................................................................... 5
3 Getting Started...................................................................................... 7
4 Spare Parts............................................................................................ 9
5 Power Requirements..............................................................................11
6 Legacy Power Requirements................................................................14
7 Software Conguration.........................................................................16
8 CB 5-s Low Voltage Exploded View.....................................................17
9 CB 5-s High Voltage Exploded View....................................................18
10 CB 5-p Low Voltage Exploded View.....................................................19
11 CB 5-p High Voltage Exploded View....................................................20
12 CB 5-s with Decorative Top Low Voltage Exploded View..................21
13 CB 5-s with Decorative Top High Voltage Exploded View.................22
14 How to Replace LED Light Connectors...............................................23
15 CB 5-s and CB 5-p Installation Instructions........................................25
16 CB 5 Series Tower Base Gasket Installation Instructions...................27
17 CB 5-s with Public Address Installation Instructions.........................29
18 CB 5-s with Decorative Top Installation Instructions.........................30
19 CB 5 Series Anchor Bolt Installation Instructions..............................32
20 CB 5 Overhead Camera Mount Installation Instructions....................33
21 S-1000/S-1050 Installation Instructions................................................35
22 PoE Installation Instructions..................................................................37
23 CB 5 Series Deck Mount Installation Instructions...............................38
24 CB 5-s and CB 5-p 24V or Multi-Tap Power Brick Wiring (prior to 2015)...39
25 CB 5-s and CB 5-p Standard Wiring (after 2015) (with 24V Fuse Block)...............40
26 CB 5-s and CB 5-p Standard Wiring (prior to 3/2013) (with Hammond Transformer).41
27 CB 5 Series Standard Wiring Diagram (after 2015) (with Triad Transformer)........42
28 CB 5 Series with Public Address Wiring...............................................43
29 Multi-Tap Transformer Wiring................................................................45
30 Maintenance Schedule...........................................................................46
31 Locating Unit Serial Numbers...............................................................48

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 4 of 50
CB 5 Series
Administrator Guide
32 Warranty...................................................................................................49
33 Download Information............................................................................50

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 5 of 50
CB 5 Series
Administrator Guide
2 Introduction
Thank you for choosing the CB 5 Series for your Code Blue application.
The CB 5 Series Help Points®are the original Code Blue pedestal units that set the industry
standard for rugged construction, full feature availability and high visibility. The CB 5 Series is
easily recognized throughout a full 360-degree area. The high output strobe is easily identiable by
security when activated.
The CB 5 Series is an excellent choice for walkways, parks, college and commercial campus areas,
open landscape areas and anywhere a freestanding pedestal unit is required.
The exclusive analog InterAct and VoIP speakerphones are designed for maximum reliability,
vandal resistance, auxiliary functions, mass notication control, and fault monitoring and reporting
capability. (See IA4100 or IP5000 guides for more information.)
Our unmistakable craftsmanship makes our Help Points® the most rugged on the market,
withstanding the punishment of natural and man-made disasters. With durable construction, our
pedestal units can meet any requirement or purpose. CB 5 Series units have a rugged steel
construction, industrial engineering grade reective graphics and weather, UV and grafti resistant
paint.
Other options include:
• IP and analog phones
• 360° Public Address Speaker (PAS)
• Overhead Camera Mount
• Strobe Cage

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 6 of 50
CB 5 Series
Administrator Guide
This guide contains all of the CB 5 Series information. This guide contains a general overview of the
CB 5 Series options and its applications, installation and wiring.
CB 5-s with
Decorative Top
CB 5-s CB 5-pCB 5-s with
Public Address

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 7 of 50
CB 5 Series
Administrator Guide
3 Getting Started
Basic Install Instructions
1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper
operation of Code Blue communication devices connected to copper or ber infrastructures.
Communications cable and electrical cable in the same conduit is not an acceptable instal-
lation and shall not be supported. Analog phones require a minimum of 23mA for proper
operation (26-29mA recommended).
2. Each analog speakerphone requires its own phone line or PBX extension. Multiple units
shall not be supported.
3. Speakerphones require programming before operation. Consult the User Guide or Admin-
istrator Guide enclosed with the unit or visit www.codeblue.com > Support > Downloads to
read or download manuals.
4. If you are installing IP speakerphones, please read the appropriate manuals and consult
with your Network Administrator.
5. Size electrical wiring based on length of run.
6. Consult the enclosed document packet for internal wiring instructions.
What’s Included
Quantity Part Description
1 Anchor Bolt Kit (3 L-Bolts, 6 Washers, 3 Hex Nuts, 1 Cardboard Template)
1 Security Bit
1 Enclosure
2 Access Door Screws
1 URL listing sheet of Installation, Programming, Wiring & Warranty locations
1 PAS Top (PAS Option Only)
1Dome Top Assembly (Solar not Available)
1Decorative Top Assembly w/Strobe

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 8 of 50
CB 5 Series
Administrator Guide
CB 5-s, CB 5-p Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts or Deck Mount Kits
4. Phillips head screwdriver and at head screwdriver
CB 5-s with Public Address Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone and
access door
3. 11/8 socket set and extension for installing anchor bolts
4. Phillips head screwdriver and at head screwdriver
5. 3/8 socket set to mount the mounting plate containing the new toroid transformer
6. 6mm Allen Wrench small black for adapter ring
7. 9/16 inch Wrench for painted ring bolts
CB 5-s with Decorative Top Tools Required
1. Ladder to reach the top of the units
2. Drill and security bit for removing and inserting security screws on phone, dome top and
access door
3. 11/8 socket set and extension for installing anchor bolts
4. Phillips head screwdriver and at head screwdriver

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 9 of 50
CB 5 Series
Administrator Guide
4 Spare Parts
CB 5-s
Part Part Number
LED Strobe Light 40159
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
CB 5-p
Part Part Number
LED Strobe Light 40159
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
Strobe Guard 44022
CB 5-s with Public Address
Part Part Number
LED Strobe Light 40159
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Access Door Screws 41545 (2pk)
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
PAS Toroid Transformer 41121
Dome Top Lens w/active vent 40007
PAS 120V Amp Assembly 40010

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 10 of 50
CB 5 Series
Administrator Guide
CB 5-s with Decorative Top
Part Part Number
LED Strobe Light 40159
LED Faceplate Light 40196
Faceplate Screws 41544 (6pk)
Access Door Screws 41545 (2pk)
Manifold R/B 5-way 40101
Analog Surge Suppressor 41471
IP Surge Suppressor 41421
CB 5 Series Additional Options
Part Part Number
Overhead Camera Mount Need Color for Part#
Multi Tap Transformer (powers accessories) 120V, 240V, 277V 40104
Blank Lexan Plate Assembly 40067
Service Plate - Lexan w/graphics (This Location Being Serviced) 40208
Deck Mount Kit 40063
Triad Transformer 40V A 120V (will not power accessories) 41246
S-1050 LED Strobe Photo Cell 40542
PoE Power Splitter Kit Assembly 41574
IP5000 Speakerphone FP1 50101
IP5000 Speakerphone FP2 50102
Keypad IP5000 Speakerphone 50103
IA4100 Speakerphone FP1 50001
IA4100 Speakerphone FP2 50002
Keypad IA4100 Speakerphone 50003

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 11 of 50
CB 5 Series
Administrator Guide
5 Power Requirements (2020)
(The following power requirements include the 5 Series and also ALL OTHER Code Blue units.)
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13
Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11
Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22
Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04
DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04
PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13
CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07
CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14
CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48
CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28 CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75 CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28 CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15 CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25 CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18 12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36 24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28 CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75 CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71 CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13 CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15 CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15 CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13 Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63 CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23 12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93 24V DC 1.13 27.10 0.65
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13
Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11
Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22
Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04
DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04
PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs
High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13
CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07
CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14
CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48
CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28 CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75 CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28 CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15 CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25 CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18 12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36 24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28 CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19 12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39 24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75 CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30 12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60 24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71 CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13 CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15 CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15 CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12 12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25 24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13 Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11 12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22 24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63 CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23 12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93 24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 12 of 50
CB 5 Series
Administrator Guide
Power Requirements continued
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13 Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11 Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22 Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04 DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04 PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13 CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07 CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14 CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48 CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs
Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28
CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75
CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28
CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15
CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25
CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18
12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36
24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28
CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75
CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71
CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13
CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15
CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15
CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13
Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63
CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23
12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93
24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 13 of 50
CB 5 Series
Administrator Guide
Power Requirements continued
Component Specs
Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Votage AC Components Voltage Current Watts KWHrs
IA4100 24V AC 0.40 9.60 0.22 5.28 0.13 Multi-Tap Power Supply 120V AC 1.75A/210VAC 210 5.04
12V DC 0.90 10.80 0.39 4.68 0.11 Din Rail Power Supply 120V AC 1.2A/115VAC 115 2.76
24V DC 0.90 21.60 0.39 9.36 0.22 Heater -AED 120V AC 1.6 192 4.61
IP5000 24V AC 0.10 2.40 0.07 1.68 0.04 DC - PS AED 120V AC 2.6 312 7.49
12V DC 0.19 2.28 0.15 1.8 0.04 PAS Amp 120V AC 3.83 459.6 11.03
24V DC 0.19 4.56 0.15 3.6 0.09
Centry®12V DC 0.50 6.00 0.38 4.56 0.11
Lights Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High Voltage Models Voltage Current Watts KWHrs
S-1000 LED Strobe 24V AC 2.80 67.20 0.22 5.28 0.13 CB 1 AED 120V AC 3.35 402 9.6
12V DC 0.26 3.12 0.24 2.88 0.07 CB 2 AED 120V AC 3.35 402 9.6
24V DC 0.26 6.24 0.24 5.76 0.14 CB 1 PAS 120V AC 3.83 460 11
A-700 Area Light 24 VAC 1.80 43.20 0.83 19.92 0.48 CB 5 PAS 120V AC 3.33 400 9.6
12V DC 2.68 32.16 0.38 4.56 0.11
CB 1-s w/ NightCharge®120V AC 2.5 300 2.4
24V DC 2.68 64.32 0.38 9.12 0.22
CB 4-u w/ NightCharge®120V AC 2.5 300 2.4
S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13
12V DC 2.68 32.16 0.38 4.56 0.11
24V DC 2.68 64.32 0.38 9.12 0.22
LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02
12V DC 0.04 0.48 0.04 0.48 0.01
24V DC 0.04 0.96 0.04 0.96 0.02
WM-180 PAS with LED Strobe 24V AC 7.30 175.20 2.10 50.4 1.21
Common Configurations
Models With IA4100 Faceplate Voltage Current Watts KWHrs
Models With IP5000 Faceplate Voltage Current Watts KWHrs
CB 1-e 24V AC 0.48 11.52 0.28
CB 1-e 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 1-s 24V AC 1.31 31.44 0.75
CB 1-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 5-s/5-p 24V AC 0.48 11.52 0.28
CB 5-s/5-p 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 9-s 24V AC 0.26 6.24 0.15
CB 9-s 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 2-e 24V AC 0.44 10.56 0.25
CB 2-e 24V AC 0.29 6.96 0.17
12V DC 0.63 7.56 0.18
12V DC 0.39 4.68 0.11
24V DC 0.63 15.12 0.36
24V DC 0.39 9.36 0.22
CB 2-a 24V AC 0.48 11.52 0.28
CB 2-a 24V AC 0.33 7.92 0.19
12V DC 0.67 8.04 0.19
12V DC 0.43 5.16 0.12
24V DC 0.67 16.08 0.39
24V DC 0.43 10.32 0.25
CB 2-s 24V AC 1.31 31.44 0.75
CB 2-s 24V AC 1.16 27.84 0.67
12V DC 1.05 12.60 0.30
12V DC 0.81 9.72 0.23
24V DC 1.05 25.20 0.60
24V DC 0.81 19.44 0.47
CB 2-e W/ PAS 24V AC 6.44 154.56 3.71
CB 2-e / PAS 24V AC 6.44 154.56 3.71
CB 4-s 24V AC 0.22 5.28 0.13
CB 4-s 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB 4-r 24V AC 0.26 6.24 0.15
CB 4-r 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
CB 4-u 24V AC 0.26 6.24 0.15
CB 4-u 24V AC 0.11 2.64 0.06
12V DC 0.43 5.16 0.12
12V DC 0.19 2.28 0.05
24V DC 0.43 10.32 0.25
24V DC 0.19 4.56 0.11
Surface Mount/Flush Mount 24V AC 0.22 5.28 0.13
Surface Mount/Flush Mount 24V AC 0.07 1.68 0.04
12V DC 0.39 4.68 0.11
12V DC 0.15 1.8 0.04
24V DC 0.39 9.36 0.22
24V DC 0.15 3.6 0.09
CB RT 24V AC 1.10 26.33 0.63
CB RT 24V AC 1.21 28.96 0.70
12V DC 0.81 9.75 0.23
12V DC 1.03 12.37 0.30
24V DC 1.61 38.57 0.93
24V DC 1.13 27.10 0.65

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 14 of 50
CB 5 Series
Administrator Guide
6 Legacy Power Requirements
(The following power requirements include the 5 Series and also ALL OTHER Code Blue units.)

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 15 of 50
CB 5 Series
Administrator Guide

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 16 of 50
CB 5 Series
Administrator Guide
7 Software Configuration
Blue Alert® MNS Software
Blue Alert MNS (Mass Notication Software) lls a need in the marketplace for an incident response
solution that is both comprehensive and cost-effective, while also providing an efcient way to detect
and respond. The advanced mass notication system allows responders to deliver multi-layered
emergency notications via a wide range of platforms, including email, text message (SMS), emer-
gency phones, public address speakers, social media, desktop alerts and more, quickly informing
and directing people in emergency situations.
Blue Alert® EMS
Blue Alert EMS is an advanced software solution that handles all incoming events effectively by re-
motely controlling emergency communication devices with an easy-to-use Graphical User Interface
(GUI). You also will have the ability to open gates and AED access doors, turn LED beacon/strobes
on or off, transfer calls to Public Address Systems to make area wide announcements and incor-
porate other ancillary devices and applications while the system securely archives data for future
reference.
ToolVox®
A sophisticated emergency management platform for your blue light phone network, ToolVox offers
unique real-time monitoring and provisioning options for emergency phones and public address
speakers, effectively acting as a hub for connecting Help Points®and other Code Blue devices. Us-
ing our proprietary incident response software, Blue Alert®MNS and EMS, you can send alerts via
outdoor platforms, such as blue light phones and public address speakers. It also provides connec-
tions to PBX, public telephone (PSTN) and Internet (ISP) networks, in addition to third party security
platforms.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 17 of 50
CB 5 Series
Administrator Guide
8 CB 5-s Low Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identi cation. Reference the model and serial number from the unit ID tag and contact manufacturer to con rm
replacement part version and availability.
2a
2b
1
8
4
7
9
6
3
5
BALL # PART # DESCRIPTION
1 CALL Standard / Custom Graphic
2a 40159 LED Beacon Strobe
2b 40115 Complete LED Beacon Strobe Replacement Kit
3 41471 Analog Surge Suppressor
3 41421 IP Surge Suppressor
4 41700 24V Fuse Block
5 41545 Access Door Security Screws (2 pk)
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 41548 LED Faceplate Light
9 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
9 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
9 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
9 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 18 of 50
CB 5 Series
Administrator Guide
9 CB 5-s High Voltage Exploded View
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and
is intended to assist in component identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm
replacement part version and availability.
2
1
8
4
7
9
6
5
2
3
BALL # PART # DESCRIPTION
1 CALL Standard Graphic
1 CALL Custom Graphic
2 40159 LED Beacon Strobe
2 40115 Complete LED Beacon Strobe Replacement Kit
3 41471 Analog Surge Suppressor
3 41421 IP Surge Suppressor
4 40100 Power Brick 120V, 240V, 277v, 347V
5 41545 Access Door Security Screws (2 pk)
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 41548 LED Faceplate Light
9 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
9 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
9 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
9 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 19 of 50
CB 5 Series
Administrator Guide
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and is intended to assist in component
identi cation. Reference the model and serial number from the unit ID tag and contact manufacturer to con rm replacement part version and availability.
10 CB 5-p Low Voltage Exploded View
2a
2b
1
8
4
7
9
6
3
5
2c
BALL # PART # DESCRIPTION
1 CALL Standard / Custom Graphic
2a 40159 LED Beacon Strobe
2b 40115 Complete LED Beacon Strobe Replacement Kit
2c 44022 Strobe Guard
3 41471 Analog Surge Suppressor
3 41421 IP Surge Suppressor
4 41700 24V Fuse Block
5 41545 Access Door Security Screws (2 pk)
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 41548 LED Faceplate Light
9 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
9 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
9 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
9 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-158-Mpage 20 of 50
CB 5 Series
Administrator Guide
DISCLAIMER: Product design and component use subject to change without notice. Product shown reasonably represents current offering and is intended to assist in component
identication. Reference the model and serial number from the unit ID tag and contact manufacturer to conrm replacement part version and availability.
11 CB 5-p High Voltage Exploded View
2b
2
1
8
4
7
9
6
5
2
3
BALL # PART # DESCRIPTION
1 CALL Standard Graphic
1 CALL Custom Graphic
2 40159 LED Beacon Strobe
2 40115 Complete LED Beacon Strobe Replacement Kit
2b 44022 Strobe Guard
3 41471 Analog Surge Suppressor
3 41421 IP Surge Suppressor
4 40100 Power Brick 120V, 240V, 277v, 347V
5 41545 Access Door Security Screws (2 pk)
6 50001 Single Button IA4100 Analog Phone – PUSH FOR HELP
6 50002 Double Button IA4100 Analog Phone – PUSH FOR HELP
6 50003 Keypad IA4100 Analog Phone – PUSH FOR HELP
6 50004 Single Button IA4100 Analog Phone – EMERGENCY
6 50005 Double Button IA4100 Analog Phone – EMERGENCY
6 50006 Keypad IA4100 Analog Phone – EMERGENCY
6 50101 Single Button IP5000 VoIP Phone – PUSH FOR HELP
6 50102 Double Button IP5000 VoIP Phone – PUSH FOR HELP
6 50103 Keypad IP5000 VoIP Phone – PUSH FOR HELP
6 50104 Single Button IP5000 VoIP Phone – EMERGENCY
6 50105 Double Button IP5000 VoIP Phone – EMERGENCY
6 50106 Keypad IP5000 VoIP Phone – EMERGENCY
7 41544 Faceplate Security Screw 10x24 (6 pk)
8 41548 LED Faceplate Light
9 40357 Bezel Assembly IA4100 Analog Phone – PUSH FOR HELP
9 40407 Bezel Assembly IA4100 Analog Phone – EMERGENCY
9 40313 Bezel Assembly IP5000 VoIP Phone – PUSH FOR HELP
9 40405 Bezel Assembly IP5000 VoIP Phone – EMERGENCY
