KTM 1290 SUPER DUKE GT 2023 User manual

OWNER'S MANUAL 2023
1290 SUPER DUKE GT
Art. no. 3214765en

DEAR KTM CUSTOMER
*3214765en*
3214765en
24.01.2023
DEAR KTM CUSTOMER
Congratulations on your decision to purchase a KTM motorcycle. You are now the owner of a state-of-the-art
sports vehicle which, with appropriate care, will bring you pleasure for a long time to come.
We wish you good and safe riding at all times!
Enter the serial numbers of your vehicle below.
Vehicle identification number ( p. 14) Dealer's stamp
Engine number ( p. 15)
Key number ( p. 14)
The Owner's Manual contained the latest information for this model series at the time of publication. However,
minor differences due to further developments in design cannot be ruled out completely.
All specifications contained herein are non-binding. KTM Sportmotorcycle GmbH specifically reserves the right
to modify or delete technical specifications, prices, colors, forms, materials, services, designs, equipment, etc.,
without prior notice and without specifying reasons, to adapt these to local conditions, as well as to stop produc-
tion of a particular model without prior notice. KTM accepts no liability for delivery options, deviations from fig-
ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that
does not belong to the regular scope of supply.
© 2023 KTM Sportmotorcycle GmbH, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission
of the copyright owner.
ISO 9001(12 100 6061)
KTM applies quality assurance processes that lead to the highest possible product quality as
defined in the ISO 9001 international quality management standard.
Issued by: TÜV Management Service
KTM Sportmotorcycle GmbH
Stallhofnerstraße 3
5230 Mattighofen, Austria
This document is valid for the following models:
1290 SUPER DUKE GT EU (F9903WF)
1290 SUPER DUKE GT JP (F9986WF)
1290 SUPER DUKE GT CN (F9987WF)

TABLE OF CONTENTS
2
TABLE OF CONTENTS
1 MEANS OF REPRESENTATION ...................... 6
1.1 Symbols used .................................... 6
1.2 Formats used..................................... 6
2 SAFETY ADVICE............................................ 7
2.1 Use definition –intended use.............. 7
2.2 Misuse.............................................. 7
2.3 Safety advice..................................... 7
2.4 Degrees of risk and symbols ................ 7
2.5 Tampering warning............................. 8
2.6 Safe operation ................................... 8
2.7 Protective clothing ............................. 9
2.8 Work rules......................................... 9
2.9 Environment...................................... 9
2.10 Owner's Manual ................................. 9
3 IMPORTANT NOTES.................................... 11
3.1 Manufacturer warranty, implied
warranty.......................................... 11
3.2 Fuel, auxiliary substances ................. 11
3.3 Spare parts, technical accessories ..... 11
3.4 Service ........................................... 11
3.5 Figures ........................................... 11
3.6 Customer service.............................. 11
4 VIEW OF VEHICLE ...................................... 12
4.1 View of vehicle, front left (example) ... 12
4.2 View of vehicle, rear right
(example)........................................ 13
5 SERIAL NUMBERS ..................................... 14
5.1 Vehicle identification number............ 14
5.2 Type label ....................................... 14
5.3 Key number..................................... 14
5.4 Engine number ................................ 15
5.5 Fork part number ............................. 15
5.6 Shock absorber article number .......... 15
5.7 Steering damper article number ........ 15
6 CONTROLS................................................. 16
6.1 Clutch lever..................................... 16
6.2 Hand brake lever.............................. 16
6.3 Throttle grip .................................... 16
6.4 Combination switch, left side ............ 16
6.5 Light switch .................................... 17
6.6 Menu button.................................... 17
6.7 Turn signal switch............................ 17
6.8 Horn button..................................... 18
6.9 Cruise control buttons ...................... 18
6.10 +RES/-SET button............................ 19
6.11 Combination switch, right ................. 19
6.12 Start button/emergency OFF switch ... 20
6.13 Hazard warning flasher switch........... 20
6.14 RACE-ON button.............................. 21
6.15 C1 and C2 switch ............................ 21
6.16 RACE-ON key .................................. 21
6.17 Steering lock (antenna)..................... 22
6.18 Immobilizer..................................... 22
6.19 Socket for electrical accessories ........ 22
6.20 USB socket ..................................... 23
6.21 Connecting the USB cable ................ 23
6.22 Disconnecting the USB cable............ 23
6.23 Opening the storage compartment on
the left............................................ 24
6.24 Opening the storage compartment on
the right.......................................... 24
6.25 Closing the storage compartment on
the left............................................ 25
6.26 Closing the storage compartment on
the right.......................................... 25
6.27 Opening fuel tank filler cap............... 25
6.28 Closing the fuel tank filler cap........... 26
6.29 Seat lock......................................... 26
6.30 Tool set........................................... 27
6.31 Grab handle .................................... 27
6.32 Case holders.................................... 27
6.33 Passenger foot pegs ......................... 27
6.34 Shift lever ....................................... 28
6.35 Foot brake lever ............................... 28
6.36 Side stand....................................... 28
7 COMBINATION INSTRUMENT ..................... 29
7.1 Combination instrument ................... 29
7.2 Activation and test ........................... 30
7.3 Warnings......................................... 30
7.4 Brake system, temperature warning ... 31
7.5 Ice warning ..................................... 31
7.6 Indicator lamps................................ 32
7.7 Display ........................................... 33
7.8 Track Display (optional) .................... 34
7.9 Performance Display (optional).......... 35
7.10 Engine speed................................... 36
7.11 Shift warning light ........................... 36
7.12 Cruise control indicator..................... 36
7.13 Speedometer ................................... 37
7.14 ABS display..................................... 37
7.15 MTC display .................................... 37
7.16 Damping display .............................. 37
7.17 Load display.................................... 38
7.18 Coolant temperature indicator ........... 38
7.19 Ride‑Mode display ........................... 38
7.20 Gear display .................................... 38
7.21 Heated grip (optional)....................... 39
7.22 Seat heating (optional) ..................... 39
7.23 Fuel level display ............................. 39
7.24 Favorites display .............................. 39
7.25 Navigation display (optional) ............. 40
7.26 Call display ..................................... 40

TABLE OF CONTENTS
3
7.27 Menu.............................................. 40
7.27.1 Bike Info..................................... 41
7.27.2 Bike Info .................................... 41
7.27.3 Trip ............................................ 41
7.27.4 Trip 1 ......................................... 42
7.27.5 Trip 2 ......................................... 42
7.27.6 Motorcycle .................................. 42
7.27.7 Ride Mode .................................. 43
7.27.8 ABS............................................ 44
7.27.9 MTC ........................................... 44
7.27.10 MTC+MSR (optional).................... 44
7.27.11 Throttle Response (optional) ......... 45
7.27.12 Slip Adjuster (optional)................. 45
7.27.13 Anti Wheelie Mode (optional) ........ 46
7.27.14 Launch Control (optional) ............. 46
7.27.15 Suspension ................................. 47
7.27.16 Damping ..................................... 47
7.27.17 Load........................................... 47
7.27.18 Navigation (optional).................... 47
7.27.19 Last search (optional)................... 48
7.27.20 Favorites (optional) ...................... 48
7.27.21 Skip Waypoint (optional)............... 49
7.27.22 Volume (optional) ........................ 49
7.27.23 Stop Navigation (optional) ............ 50
7.27.24 Heating (optional)........................ 50
7.27.25 Heating Grips (optional) ............... 50
7.27.26 Heating Rider Seat (optional)........ 51
7.27.27 Audio ......................................... 51
7.27.28 Audio ......................................... 51
7.27.29 Call out....................................... 52
7.27.30 Settings ...................................... 52
7.27.31 Custom Switch ............................ 52
7.27.32 C1 and C2 buttons....................... 53
7.27.33 Favorites ..................................... 53
7.27.34 Favorites indicator 1-4 ................. 53
7.27.35 Button Illumination...................... 54
7.27.36 DRL ........................................... 54
7.27.37 KTMconnect................................ 55
7.27.38 Bluetooth.................................... 55
7.27.39 Phone......................................... 55
7.27.40 Rider's Headset ........................... 56
7.27.41 Headset Type .............................. 57
7.27.42 Quickshifter + (optional)............... 57
7.27.43 Hill Hold Control (optional) ........... 58
7.27.44 Shift Light .................................. 58
7.27.45 Shift Light State .......................... 58
7.27.46 Shift Light RPM1......................... 58
7.27.47 Shift Light RPM2......................... 59
7.27.48 Cornering Light Test..................... 59
7.27.49 Clock & Date ............................... 59
7.27.50 Clock Format............................... 60
7.27.51 Date Format ................................ 60
7.27.52 Units .......................................... 60
7.27.53 Units Distance............................. 60
7.27.54 Units Temperature ....................... 61
7.27.55 Units Consumption ...................... 61
7.27.56 Units Pressure............................. 61
7.27.57 Language .................................... 61
7.27.58 Settings Heating.......................... 62
7.27.59 Settings Heating Grips ................. 62
7.27.60 Settings Heating Rider Seat.......... 62
7.27.61 Settings Heating Pillion Seat ........ 62
7.27.62 Extra Functions ........................... 63
7.27.63 Setting the time and date ............. 63
8 ERGONOMICS ............................................ 65
8.1 Handlebar position........................... 65
8.2 Adjusting the handlebar position .... 65
8.3 Adjusting the steering angle .......... 66
8.4 Adjusting the windshield .................. 67
8.5 Adjusting the basic position of the
clutch lever ..................................... 67
8.6 Adjusting the basic position of the
hand brake lever .............................. 68
8.7 Adjusting the basic position of the
foot brake lever ............................ 68
8.8 Setting the step plate of the foot
brake lever ...................................... 69
8.9 Checking the basic position of the
shift lever........................................ 69
8.10 Adjusting the basic position of the
shift lever .................................... 69
8.11 Setting the shift lever stub................ 70
9 PREPARING FOR USE................................. 71
9.1 Advice on preparing for first use ........ 71
9.2 Running in the engine ...................... 72
9.3 Loading the vehicle.......................... 72
10 RIDING INSTRUCTIONS.............................. 74
10.1 Checks and maintenance measures
when preparing for use ..................... 74
10.2 Starting the vehicle .......................... 74
10.3 Launch Control (optional) ................. 76
10.4 Starting off...................................... 76
10.5 Starting off with launch control
(optional) ........................................ 76
10.6 Start off with HHC (Option: Hill-start
assist)............................................. 77
10.7 Anti wheelie mode (optional)............. 77
10.8 Quickshifter + (optional)................... 78
10.9 Shifting, riding ................................ 78
10.10 MSR (optional) ................................ 81
10.11 Braking........................................... 81
10.12 Stopping, parking............................. 82
10.13 Transporting .................................... 83
10.14 Towing in the event of a breakdown ... 84
10.15 Refueling ........................................ 84

TABLE OF CONTENTS
4
11 SERVICE SCHEDULE .................................. 86
11.1 Additional information...................... 86
11.2 Service work.................................... 86
12 SUSPENSION SETTING............................... 88
12.1 Fork/shock absorber ......................... 88
12.2 "Load"............................................. 88
12.3 "Damping"....................................... 88
13 SERVICE WORK ON THE CHASSIS............... 89
13.1 Raising the motorcycle with the rear
lifting gear ...................................... 89
13.2 Removing the rear of motorcycle
from the lifting gear ......................... 89
13.3 Lifting the motorcycle with the front
lifting gear ...................................... 89
13.4 Taking the motorcycle off the front
lifting gear ...................................... 90
13.5 Removing the passenger seat ............ 90
13.6 Mounting the passenger seat............. 90
13.7 Removing the front rider's seat.......... 91
13.8 Mounting the front rider's seat........... 91
13.9 Removing the windshield.................. 91
13.10 Installing the windshield................... 92
13.11 Removing the main silencer .......... 92
13.12 Installing the main silencer ........... 93
13.13 Checking the chain for dirt................ 93
13.14 Cleaning the chain ........................... 94
13.15 Checking the chain tension ............... 94
13.16 Adjusting the chain tension............... 95
13.17 Checking the chain, rear sprocket,
engine sprocket, and chain guide ...... 96
13.18 Checking/correcting the fluid level of
the hydraulic clutch ......................... 98
13.19 Removing the fuel tank spoiler .......... 99
13.20 Installing the fuel tank spoiler......... 100
13.21 Removing front fender .................... 100
13.22 Installing front fender ................. 100
13.23 Cleaning the dust boots of the fork
legs ........................................... 101
14 BRAKE SYSTEM ....................................... 102
14.1 Anti-lock braking system (ABS) ....... 102
14.2 Rear brake temperature
monitoring (BTM)........................... 103
14.3 Checking the brake discs ................ 104
14.4 Checking the front brake fluid
level ............................................. 104
14.5 Adding front brake fluid .............. 105
14.6 Checking that the brake linings of
the front brake are secured ............. 106
14.7 Checking the rear brake fluid
level ............................................. 107
14.8 Adding rear brake fluid ............... 107
14.9 Checking that the brake linings of
the rear brake are secured............... 108
15 WHEELS, TIRES ....................................... 110
15.1 Removing the front wheel ............ 110
15.2 Installing the front wheel ............ 111
15.3 Removing the rear wheel ............. 112
15.4 Installing the rear wheel .............. 113
15.5 Checking the tire condition ............. 114
15.6 Checking tire pressure.................... 115
15.7 Using tire repair spray .................... 116
16 ELECTRICAL SYSTEM ............................... 117
16.1 Low beam ..................................... 117
16.2 High beam .................................... 117
16.3 Daytime running light (DRL)
(SUPER DUKE GT EU/JP)............... 117
16.4 Cornering light............................... 118
16.5 Socket for electrical accessories ...... 118
16.6 Removing the 12-V battery .......... 118
16.7 Installing the 12-V battery ........... 119
16.8 Charging the 12-V battery ........... 120
16.9 Changing the RACE-ON key
battery .......................................... 123
16.10 Changing the main fuse.................. 124
16.11 Changing the fuses in the fuse
box............................................... 125
16.12 Checking the setting of the lighting
system .......................................... 126
16.13 Adjusting the headlight range.......... 127
16.14 Adjusting the cornering light
range ............................................ 128
16.15 Diagnostics connector .................... 130
16.16 Front ACC1 and ACC2 .................... 130
16.17 ACC1 and ACC2 rear ...................... 130
17 COOLING SYSTEM .................................... 131
17.1 Checking the coolant level in the
compensating tank......................... 131
17.2 Correcting the coolant level in the
compensating tank......................... 131
18 ENGINE TUNING ...................................... 133
18.1 Ride Mode .................................... 133
18.2 Motorcycle traction control (MTC) .... 133
18.3 Slip adjustment (optional)............... 134
18.4 Throttle Response (optional) ........... 134
19 SERVICE WORK ON THE ENGINE .............. 135
19.1 Checking the engine oil level........... 135
19.2 Changing the engine oil and oil
filter, cleaning the oil screens ...... 135
19.3 Adding engine oil........................... 138

TABLE OF CONTENTS
5
20 CLEANING, CARE ..................................... 140
20.1 Cleaning the motorcycle ................. 140
20.2 Checks and maintenance steps for
winter operation............................. 141
21 STORAGE................................................. 142
21.1 Storage ......................................... 142
21.2 Preparing for use after storage......... 143
22 TROUBLESHOOTING ................................ 144
23 TECHNICAL SPECIFICATIONS ................... 146
23.1 engine .......................................... 146
23.2 Engine tightening torques ............... 147
23.3 Capacities ..................................... 149
23.3.1 Engine oil ................................. 149
23.3.2 Coolant ..................................... 149
23.3.3 Fuel ......................................... 150
23.4 Chassis ......................................... 150
23.5 Electrical system............................ 151
23.6 Tires............................................. 151
23.7 Fork.............................................. 151
23.8 Shock absorber.............................. 152
23.9 Chassis tightening torques .............. 152
24 DECLARATIONS OF CONFORMITY ............. 157
24.1 Declarations of conformity .............. 157
24.2 Country-specific declarations of
conformity..................................... 157
24.3 Country-specific declarations of
conformity (CCU‑2) ........................ 158
25 SUBSTANCES .......................................... 159
26 AUXILIARY SUBSTANCES ......................... 161
27 STANDARDS ............................................ 162
28 INDEX OF SPECIAL TERMS ....................... 163
29 LIST OF ABBREVIATIONS.......................... 164
30 LIST OF SYMBOLS.................................... 165
30.1 Red symbols.................................. 165
30.2 Yellow and orange symbols.............. 165
30.3 Green and blue symbols.................. 165
INDEX ............................................................. 166

1 MEANS OF REPRESENTATION
6
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g., of a work step or a function).
Indicates an unexpected reaction (e.g., of a work step or a function).
Indicates work that requires expert knowledge and technical understanding. In the interest of
your own safety, have these jobs performed by an authorized KTM workshop! Your motorcycle
will be cared for there to the highest degree by specially trained experts using the special tools
required.
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates the end of an activity, including potential reworking.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name®Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

SAFETY ADVICE 2
7
2.1 Use definition –intended use
The vehicle is designed and constructed to withstand the usual demands of regular traffic and use on race
courses. This vehicle is not suitable for offroad use.
Info
This vehicle is only authorized for operation on public roads in its homologated version.
2.2 Misuse
The vehicle must only be used as intended.
Dangers can arise for people, property and the environment through use not as intended.
Any use of the vehicle beyond the intended and defined use constitutes misuse.
Misuse also includes the use of operating and auxiliary fluids which do not meet the required specification for the
respective use.
2.3 Safety advice
A number of safety instructions need to be followed to operate the product described safely. Therefore read this
instruction and all further instructions included carefully. The safety instructions are highlighted in the text and
are referred to at the relevant passages.
Info
Various information and warning labels are attached in prominent locations on the product described. Do
not remove any information or warning labels. If they are missing, you or others may not recognize dangers
and may therefore be injured.
2.4 Degrees of risk and symbols
Danger
Identifies a danger that will immediately and invariably lead to fatal or serious permanent injury if the
appropriate measures are not taken.
Warning
Identifies a danger that is likely to lead to fatal or serious injury if the appropriate measures are not
taken.
Caution
Identifies a danger that may lead to minor injuries if the appropriate measures are not taken.
Note
Identifies a danger that will lead to considerable machine and material damage if the appropriate measures are
not taken.
Note
Indicates a danger that will lead to environmental damage if the appropriate measures are not taken.

2 SAFETY ADVICE
8
2.5 Tampering warning
Tampering with the noise control system is prohibited. Federal law prohibits the following acts or the causing
thereof:
1 The removal or rendering inoperative by any person other than for purposes of servicing, repair, or replace-
ment, of any device or element of design incorporated into any new vehicle for the purpose of noise control
prior to its sale or delivery to the ultimate purchaser or while it is in use, or
2 the use of the vehicle after such device or element of design has been removed or rendered inoperative by any
person.
Among those acts presumed to constitute tampering are the acts listed below:
1 Removal or puncturing of the main silencers, baffles, header pipes or any other components which conduct
exhaust gases.
2 Removal or puncturing of parts of the intake system.
3 Lack of proper maintenance.
4 Replacing moving parts of the vehicle, or parts of the exhaust system or intake system, with parts other than
those specified by the manufacturer.
2.6 Safe operation
Danger
Danger of accidents A rider who is not fit to ride poses a danger to him or herself and others.
–Do not operate the vehicle if you are not fit to ride due to alcohol, drugs or medication.
–Do not operate the vehicle if you are physically or mentally impaired.
Danger
Danger of poisoning Exhaust gases are toxic and inhaling them may result in unconsciousness and death.
–Always make sure there is sufficient ventilation when running the engine.
–Use effective exhaust extraction when starting or running the engine in an enclosed space.
Warning
Danger of burns Some vehicle components become very hot when the vehicle is operated.
–Do not touch any parts such as the exhaust system, radiator, engine, shock absorber, or brake system
before the vehicle parts have cooled down.
–Let the vehicle parts cool down before you perform any work on the vehicle.
Only operate the vehicle when it is in perfect technical condition, in accordance with its intended use, and in a
safe and environmentally compatible manner.
The vehicle should only be used by trained persons. An appropriate driver's license is needed to ride the vehicle
on public roads.
Have malfunctions that impair safety promptly eliminated by an authorized KTM workshop.
Adhere to the information and warning labels on the vehicle.
