MOTOR6 INSTRUCTION MANUAL
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USE
This manual provides important information on operation & maintenance. These instructions are not meant to cover every
possible condition and situation that may occur. We reserve the right to change this product at any time without prior notice.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE
OR UNSAFE, DO NOT OPERATE THIS PRODUCT!
DO NOT RETURN THIS PRODUCT TO THE RETAILER!
If you experience a problem, have questions or need parts for this product, call Customer Service at 1-888-287-6981,
Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales receipt is required.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE
WARRANTY FOR FUTURE REFERENCE.
Keep this manual onboard inawaterproof bagwhen boating. The manual should stay with the outboard motor if sold .
2 YEAR LIMITED EMISSION-RELATED WARRANTY
THIS ENGINE MEETS U.S. EPA EMISSION STANDARDS UNDER 40 CFR 1054.625 .The emission-related limited warranty is
valid for two (2) years. Keep the purchase receipt and mail in the product registration card for proof of purchase. Buffalo Corp
limits emission-related warranty repairs to authorized service centers for owners located within 100 miles of an authorized
service center. For owners located more than 100 miles from an authorized service center, Buffalo Corp will, in its sole
discretion, either pay for shipping costs to and from an authorized service center, provide for a service technician to come to the
owner to make the warranty repair, or pay for the repair to be made at a local non-authorized service center. The provisions of
this paragraph apply only for the contiguous states, excluding the states with high-altitude areas identified in 40 CFR part 1068,
Appendix III.
To exercise this warranty, DO NOT RETURN TO RETAILER. Instead, call Customer Service toll free at 1-888-287-6981 (email
address [email protected]) and you will be instructed on where to take the engine for warranty service. Take the engine and
proof of purchase (your receipt) to the repair facility recommended by the Customer Service Representative. The warranty does
not extend to products damaged or affected by fuel contamination, accidents, neglect, misuse, unauthorized alterations, use in
an application for which the product was not designed and any other modifications or abuse.
1 YEAR LIMITED WARRANTY (30 Day Limited Warranty for Commercial and Rental Purpose)
Engines are warranted to be free from defects in materials and workmanship for a period of 1 YEAR from date of original
purchase. Buffalo Corp. is not liable for any indirect, incidental or consequential damages from the sale or use of this product.
Any implied warranties are limited to 1 YEAR as stated, or as otherwise stated, in this written limited warranty. Some states do
not allow the exclusion or limitation of incidental or consequential damages. Some states do not allow limitation on the length of
an implied warranty. Buffalo Corp will repair or replace, at its discretion, any part that is proven to be defective in materials or
workmanship under normal use during the 1 YEAR warranty period. Warranty repairs or replacements will be made without
charge for parts or labor. Parts replaced during warranty repairs will be considered as part of the original product and will have
the same warranty period as the original product. This warranty gives you specific legal rights, and you may have other rights
that vary state to state.
CALIFORNIA PROPOSITION 65
This product may contain chemicals, including lead, known to the State of California to cause cancer and
birth defects or other reproductive harm. Wash hands after handling.
0201310

2
MOTOR6
6 HP OUTBOARD MOTOR
SPECIFICATIONS:
4-Stroke Outboard Motor
6 HP @ 5000 RPM
Adjustable Steering Friction
Full Throttle RPM Range: 4500-5500
Displacement: 139 cc
Engine type: 1 Cylinder
Bore & Stroke: 2.44" x 1.81"
Compression Ratio: 8.9:1
Fuel/Induction System: 1 OHV
Intake: Carburetor
Exhaust: Above Propeller
Cooling: Water / Thermostatic Control
Ignition System: CDI
Starting System: Manual
Lubrication: Wet Pump
Gear Ratio: (27:13) 2.08:1
Gear Shift: Forward, Neutral, Reverse
Short Shaft Length 17.1"
Tilt Up Angle: 69°
Degree of Trim: 5 Positions
Steering Angle: 90°
Oil Capacity: 20 ounces
Internal fuel tank capacity (built in type):
0.29 US gal (37 ounces)
External Fuel tank capacity:
3.0 US gal
EPA Approved

3
TABLE OF CONTENTS
Safety information .............................................1
Gasoline............................................................4
Gasoline exposure and spills ............................4
Carbon monoxide..............................................4
Boating safety ...................................................5
Personal flotation devices .................................5
Passengers .......................................................5
Overloading.......................................................5
Weather ............................................................6
Passenger training ............................................6
Boating safety publications ...............................6
Rules when encountering vessels ....................8
General information ..........................................11
Read manuals and labels .................................11
Requirements.................................................... 12
Boat horsepower rating.....................................13
Mounting the outboard motor............................13
Propeller selection ............................................13
Engine oil requirements ....................................14
Fuel requirements .............................................14
Ring Free Fuel Additive ....................................15
Emergency equipment ......................................15
Components......................................................16
Fuel cock...........................................................17
Tiller handle ......................................................18
Gear shift lever..................................................18
Throttle grip.......................................................18
Engine stop button ............................................20
Installation .........................................................23
Mounting the outboard motor............................23
Clamping the outboard motor ...........................25
Operation ..........................................................26
Fill engine oil .....................................................26
Fuel level...........................................................26
Removing top cowling....................................... 27
Controls.............................................................27
Engine oil. .........................................................28
Installing top cowling .........................................29
Operating engine ..............................................30
Starting engine..................................................35
Warming up.......................................................35
Stopping boat....................................................37
Stopping engine ................................................37
Cruising.............................................................42
Maintenance .....................................................44
Cleaning the outboard motor ............................52
Periodic maintenance .......................................53
Replacement parts............................................53
Maintenance interval guidelines........................53
Maintenance chart ............................................54
Cleaning and adjusting spark plug.................... 57
Checking fuel filter ............................................57
Changing engine oil. .........................................59
Propeller............................................................60
Installing propeller .............................................60
Troubleshooting ................................................64

4
Safety Information
Observe these precautions at all times.
Propeller
People can be injured or killed if they come in
contact with the propeller. The propeller can keep
moving even when the motor is in
neutral, and sharp edges of the propeller can cut
even when stationary.
Stop the engine when a person is in the
water near you.
Keep people out of reach of the propeller, even
when the engine is off.
Rotating parts
Hands, feet, hair, jewelry, clothing, straps, etc.
can become entangled with internal rotating parts of
the engine, resulting in serious injury or death.
Keep the top cowling in place whenever
possible. Do not remove or replace the cowling
with the engine running.
Only operate the engine with the cowling
removed according to the specific instructions in the
manual. Keep hands, feet, hair, jewelry, clothing,
straps, etc. away from any exposed moving parts.
Hot parts
During and after operation, engine parts are hot
enough to cause burns. Avoid touching any parts
under the top cowling until the
engine has cooled.
Electric shock
Do not touch any electrical parts while starting or
operating the engine. They can cause shock or
electrocution.
Engine shut-off cord (lanyard)
Attach the engine shut-off cord so that the
engine stops if the operator falls overboard or
leaves the helm. This prevents the boat from
running away under power and leaving people
stranded, or running over people or objects.
Always attach the engine shut-off cord to a
secure place on your clothing or your arm or leg
while operating. Do not remove it to leave the
helm while the boat is moving. Do not attach the
cord to clothing that could tear loose, or route the
cord where it could become entangled,
preventing it from functioning.
Do not route the cord where it is likely to be
accidentally pulled out. If the cord is pulled
during operation, the engine will shut off and you
will lose most steering control. The boat could
slow rapidly, throwing people and objects
forward.
Gasoline
Gasoline and its vapors are highly flammable
and explosive.
Gasoline exposure and spills
Take care not to spill gasoline. If gasoline
spills, wipe it up immediately with dry rags.
Dispose of rags properly.
If any gasoline spills onto your skin, immediately
wash with soap and water. Change clothing if
gasoline spills on it.
If you swallow gasoline, inhale a lot of gasoline
vapor, or get gasoline in your eyes, get
immediate medical attention. Never siphon fuel
by mouth.
Carbon monoxide
This product emits exhaust gases which contain
carbon monoxide, a colorless, odorless gas
which may cause brain damage or death when
inhaled. Symptoms include nausea, dizziness,
and drowsiness. Keep cockpit and cabin areas
well ventilated. Avoid blocking exhaust outlets.

5
Safety Information
Modifications
Do not attempt to modify this outboard motor.
Modifications to your outboard motor may re duce
safety and reliability, and render the out board
unsafe or illegal to use.
Boating safety
This section includes a few of the many
important safety precautions that you should
follow when boating.
Alcohol and drugs
Never operate after drinking alcohol or taking
drugs. Intoxication is one of the most common
factors contributing to boating fatalities.
Personal flotation devices
Have an approved personal flotation device
(PFD) on board for every occupant. You must
wear a PFD whenever boating. At a minimum,
children and non-swimmers should always
wear PFDs, and everyone should wear PFDs
when there are potentially hazardous boating
conditions.
People in the water
Always watch carefully for people in the water,
such as swimmers, skiers, or divers, whenever
the engine is running. When someone is in the
water near the boat, shift into neutral and stop
the engine.
Stay away from swimming areas. Swimmers
can be hard to see.
The propeller can keep moving even when the
motor is in neutral. Stop the engine when a
person is in the water near you.
Passengers
Consult your boat manufacturer's instructions for
details about appropriate passenger locations in
your boat and be sure all passengers are
positioned properly before accelerating
and when operating above an idle speed.
Standing or sitting in non-designated locations
may result in being thrown either overboard or
within the boat due to waves, wakes, or sudden
changes in speed or direction. Even when people
are positioned properly, alert your passengers if
you must make any unusual maneuver. Always
avoid jumping waves or wakes.
Overloading
Do not overload the boat. Consult the boat
capacity plate or boat manufacturer for maxi-
mum weight and number of passengers. Be
sure that weight is properly distributed
according to the boat manufacturers
instructions. Overloading or incorrect weight
distribution can compromise the boats handling
and lead to an accident, capsizing or swamping.
Avoid collisions
Scan constantly for people, objects, and other
boats. Be alert for conditions that limit your
visibility or block your vision of others.
Operate defensively at safe speeds and keep a
safe distance away from people, objects, and
other boats.
• Do not follow directly behind other boats or
water skiers.

Safety Information
Avoid sharp turns or other maneuvers that make it
hard for others to avoid you or understand where you
are going.
Avoid areas with submerged objects or shallow
water.
Ride within your limits and avoid aggressive
maneuvers to reduce the risk of loss of control, ejection
and collision.
Take early action to avoid collisions. Remember,
boats do not have brakes, and stopping the engine
or reducing throttle can reduce the ability to steer. If
you are not sure that you can stop in time before
hitting an obstacle, apply throttle and turn in another
direction.
Weather
Stay informed about the weather. Check weather
forecasts before boating. Avoid boating in hazardous
weather.
Accident reporting
Boat operators are required by law to file a Boating
Accident Report with their state boating law
enforcement agency if the boat is involved in any of the
following accidents:
1. There is loss of life or probable loss of life.
2. There is personal injury that requires
medical attention beyond first aid.
3. There is property damage to boats or other
property over a certain amount.
4. There is complete loss of a boat. Contact local
law enforcement personnel if a report is necessary.
Boat education and training
Operators should take boating safety course. This
may be required in your state. Many of the
organizations listed in the next section can provide
information about courses in your area.
You may also want to consider an Internet-
based program for basic boater education. The
Online Boating Safety Course provided by the
Boat U.S. Foundation, is approved by the
National Association of State Boating Law
Administrators (NASBLA) and recognized by the
United States Coast Guard. Most, but not all,
states accept this course to meet their
minimum requirements. While it cannot re-
place an in-depth course such as one offered by
the U.S. Coast Guard, U.S. Power Squadron, or
other organization, this online course does
provide a general overview of the basics in
boating safety, requirements, navigation, and
operation. Upon successful completion of the
course, the user can download a certificate of
completion immediately or, for a small charge,
request one by mail. To take this free course, go
to boatus.org.
Passenger training
Make sure at least one other passenger is
trained to operate the boat in the event of an
emergency.
Boating safety publications
Be informed about boating safety. Additional
publications and information can be obtained
from many boating organizations.
Laws and regulations
Know the marine laws and regulations where you
will be boating and obey them. Several sets of
rules prevail according to geographic location,
but all are basically the same as the International
Rules of the Road. The rules presented in the
following section are condensed and have
been provided for your convenience.
6

Safety information
Contact the U.S. Coast Guard, the National
Association of State Boating Law Administrators,
or your local Power Squadron for a complete set
of rules governing the waters in which you will
be using your boat.
Boating organizations
The following organizations provide boating
safety training and information about boating
safety and laws:
United States Coast Guard
Consumer Affairs Staff (G-BC)
Office of Boating, Public, and Consumer Affairs
U.S. Coast Guard Headquarters Washington, D.C.
20593-0001
http://www.uscgboating.org/
United States Power Squadrons
1-888-FOR-USPS (1-888-367-8777)
http://www.usps.org/
Boat Owners Association of The United
States
1-800-336-BOAT (1-800-336-2628)
http://www.boatus.com/
National Association of State Boating Law
Administrators (NASBLA)
1500 Leestown Road, Suite 330
Lexington, KY 40511
859-225-9497
http://www.nasbla.org/
National Marine Manufacturers Association
(NMMA)
200 East Randolph Drive Suite 5100
Chicago, IL 60601
http://www.nmma.org/
Marine Retailers Association of America
155 N. Michigan Ave. Chicago, IL
60304
http://www.mraa.com/
Basic boating rules (Rules of the road)
Just as there are rules that apply when you are
driving on streets and highways, there are
waterway rules that apply when you are driving
your boat. These rules are used internationally.
(For U.S.A.: and are also enforced by the United
States Coast Guard and local agencies.) You
should be aware of these rules, and follow them
whenever you encounter another vessel on the
water.
Steering and sailing rules and sound signals
Whenever two vessels on the water meet one
another, one vessel has the right-of-way; it is
called the “stand-on” vessel. The vessel that does
not have the right-of-way is called the “give-way”
or “burdened” vessel. These rules determine
which vessel has the right-of-way, and what each
vessel should do.
Stand-on vessel
The vessel with the right-of-way has the duty to
continue its course and speed, except to avoid
an immediate collision. When you maintain your
direction and speed, the other vessel will be able to
determine how best to avoid you.
Give-way vessel
The vessel that does NOT have the right-of-way
has the duty to take positive and timely action to
stay out of the way of the Stand-On vessel.
Normally, you should not cross in front of the vessel
with the right-of-way.
7

Safety Information
You should slow down or change directions briefly
and pass behind the other vessel. You should
always move in such a way that the operator of the
other vessel can see what you are doing.
“The general prudential rule”
This rule is called Rule 2 in the International
Rules and says,
“In obeying and construing these rules due regard
shall be had to all dangers of navigation and
collision, and to any special circumstances, which
may render a departure from the above rules
necessary in order to avoid immediate danger.”
In other words, follow the standard rules except
when a collision will occur unless both vessels try
to avoid each other. If that is the case, both vessels
become “ Give-Way ” vessels.
Rules when encountering vessels There are three
main situations that you may encounter with other
vessels which could lead to a collision unless the
Steering Rules are followed:
Meeting: (you are approaching another vessel
head-on)
Crossing: (you are traveling across the other
vessel’s path)
Overtaking: (you are passing or being passed by
another vessel)
In the following illustration, your boat is in the center.
You should give the right-of-way to any vessels
shown in white area (you are the Give-Way vessel).
Any vessels in the shaded area must yield to you
(they are the Give-Way vessels). Both you and the
meeting vessel must alter course to avoid each
other.
Meeting
If you are meeting another power vessel head
on, and are close enough to run the risk of
collision, neither of you has the right-of-way Both
of you should alter course to avoid an
accident. You should keep the other vessel
on your port (left) side. This rule doesn’t apply if
both of you will clear one another if you continue
on your set course and speed.
Crossing
When two power driven vessels are crossing
each other’s path close enough to run the risk of
collision, the vessel which has the other on the
starboard (right) side must keep out of the way of
the other. If the other vessel is on your right, you
must keep out of its way; you are the Give-Way
vessel. If the other vessel is on your port
(left) side, remember that you should maintain
course and direction, provided the other vessel
gives you the right-of-way as it should.
8

Safety information
Overtaking
If you are passing another vessel, you are the “Give-
Way” vessel. This means that the other vessel is
expected to maintain its course and speed. You
must stay out of its way until you are clear of it.
Likewise, if another vessel is passing you, you
should maintain your speed and direction so that
the other vessel can steer itself around you.
Narrow channels and bends
When navigating in narrow channels, you should
keep to the right when it is safe and practical to
do so. If the operator of a power- driven vessel is
preparing to go around a bend that may obstruct
the view of other water vessels, the operator
should sound a pro- longed blast on the whistle
(4 - 6 seconds). If another vessel is around the
bend, it too should sound the whistle. Even if no
reply is heard, however, the vessel should still
proceed around the bend with caution. If you navigate
such waters with your boat, you will need to
carry a portable air horn.
Fishing vessel right-of-way
All vessels that are fishing with nets, lines or
trawls are considered to be “fishing vessels”
under the International Rules. Vessels with
trolling lines are not considered fishing vessels.
Fishing vessels have the right-of-way regardless of
position. Fishing vessels cannot, however, impede
the passage of other vessels in narrow channels.
Sailing vessel right-of-way
Sailing vessels should normally be given the right-
of-way. The exceptions to this are:
1. When the sailing vessel is overtaking the
power-driven vessel, the power-driven vessel has
the right-of-way.
2. Sailing vessels should keep clear of any
fishing vessel.
3. In a narrow channel, a sailing vessel should
not hamper the safe passage of a power-driven
vessel that can navigate only in such a channel.
Reading buoys and other markers
The waters of the United States are marked for
safe navigation by the lateral system of
buoyage. Simply put, buoys and markers have an
arrangement of shapes, colors, numbers and lights
to show which side of the buoy a boater should
pass on when navigating in a particular direction.
The markings on these buoys are oriented from
the perspective of being entered from seaward (the
boater is going towards the port). This means that
red buoys are passed on the starboard (right) side
when proceeding from open water into port,
and black buoys are to port (left) side. When
navigating out of port, your position with respect to
the buoys should be reversed; red buoys should
be to port and black buoys to starboard.
9

Safety Information
Many bodies of water used by boaters are entirely
within the boundaries of a particular state. The
Uniform State Waterway Marking System has been
devised for these waters. This system uses buoys
and signs with distinctive shapes and colors to show
regulatory or advisory information. These markers
are white with black letters and orange boarders.
They signify speed zones, restricted areas,
danger areas, and general information.
Remember, markings may vary by geographic
location. Always consult local boating authorities
before driving your boat in unfamiliar waters.
10

11
1 2
3 4
Symbols
The following symbols mean as follows.
Notice/Warning
Electrical hazard
Read Owner’s Manual
Hazard caused by
continuous rotation

12
Specifications and Requirements
TIP:
Specifications Engine:
“(AL)” stated in the specification data below
represents the numerical value for the aluminum
propeller installed.
TIP:
“*” means: select the engine oil referring to the
chart of engine oil paragraph.
Dimension:
Overall length:
557 mm (21.9 in)
Overall width:
329 mm (13.0 in)
Overall height S:
1039 mm (40.9 in)
Overall height L:
1166 mm (45.9 in)
Transom height S:
435 mm (17.1 in)
Transom height L:
562 mm (22.1 in)
Weight (AL) S:
27.0 kg (60 lb) Weight (AL)
L: 28.0 kg (62 lb)
Performance:
Full throttle operating range: FP4A
4000–5000 r/min
FP6A 4500–5500 r/min
Maximum output:
F4MHA 2.9 kW@4500 r/min
(4 HP@4500 r/min)
FP6A 4.4 kW@5000 r/min (6
HP@5000 r/min)
Idle speed (in neutral):
1500 ±50 r/min
Type: 4-stroke S
Displacement: 139.0 cm³
Bore ⋅stroke:
62.0 ⋅46.0 mm (2.44 ⋅1.81 in)
Ignition system: CDI
Spark plug (NGK):
CR6HSB
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Control system:
Tiller handle
Starting system:
Manual starter
Starting carburetion system:
Choke valve
Valve clearance (cold engine) IN: 0.08–0.12 mm
(0.0032–0.0047 in)
Valve clearance (cold engine) EX: 0.08–0.12 mm
(0.0032–0.0047 in)
Drive unit:
Gear positions:
Forward-neutral-reverse Gear ratio:
2.08(27/13)
Trim and tilt system: Manual tilt
Propeller mark: BA
Fuel and oil:
Recommended fuel:
Regular gasoline min. octane: 86
Internal Fuel tank capacity:
0.29 US gal (37 ounces)
External Fuel tank capacity:
3.0 US gal
Recommended engine oil
4-stroke outboard motor oil
Oil Capacity: 20 ounces

13
13
Specifications and Requirements
Recommended engine oil:
SAE 10W-30/10W-40/5W-30
API SE/SF/SG/SH/SJ/SL
Engine oil quantity: 20 ounces
Lubrication:
Wet sump
Recommended gear oil:
Hypoid gear oil SAE#90
Gear oil quantity: 3.3 ounces
Tightening torque for engine:
Spark plug:
13.0 Nm (1.33 kgf-m, 9.6 ft-lb)
Engine oil drain bolt:
18.0 Nm (1.84 kgf-m, 13.3 ft-lb)
Installation Requirements
Boat Horsepower Rating
WARNING
Overpowering a boat can cause severe
instability.
To lift and mount the outboard motor, two people
are necessary. TEAM LIFT REQUIRED
Propeller selection
Next to selecting an outboard motor, selecting the
right propeller is one of the most important
purchasing decisions a boater can make. The
type, size, and design of your propeller have a
direct impact on acceleration, top speed, fuel
economy , and even engine life.
Your outboard motor came with a propeller
selected to perform well over a range of
applications, but there may be uses where a
different propeller would be more appropriate.
Select a propeller that will allow the engine to
reach the middle or upper half of the operating
range at full throttle with the maximum boatload.
Generally, select a larger pitch propeller for a
smaller operating load and a smaller pitch
propeller for a heavier load. If you carry loads
that vary widely, select the propeller that lets the
engine run in the proper range for your maximum
load but remember that you may need to
reduce your throttle setting to stay within the
recommended engine speed range when
carrying lighter loads.
Before installing the outboard motor(s), confirm
that the total horsepower of your motor(s) does
not exceed the boats maximum horsepower
rating. See the boat's capacity plate.
Mounting the Outboard Motor
WARNING
Improper mounting of the outboard motor
could result in hazardous conditions, such as
poor handling, loss of control, or fire hazards.
If you are not able to mount the outboard
motor properly, consult customer service.

14

15
Specifications and Requirements
• Avoid getting water and contaminants in
the fuel tank. Contaminated fuel can cause
poor performance or engine damage. Use
only fresh gasoline that has been stored in
clean containers.
Gasohol
There are two types of gasohol: gasohol
containing ethanol (E10) and that containing
methanol. Ethanol can be used if the ethanol
content does not exceed 10% and the fuel
meets the minimum octane ratings. E85 is a
fuel containing 85% ethanol and must not be
used in your outboard motor. All ethanol
blends containing more than 10% ethanol can
cause fuel system damage or cause engine
starting and running problems. We do not
recommend gasohol containing methanol
because it can cause fuel system damage or
engine performance problems.
It is recommended that you install a water-
separating marine fuel filter assembly (10
micron minimum) between your boat's fuel tank
and outboard motor when using ethanol.
Ethanol is known to allow moisture to be
absorbed into boat fuel tanks and systems.
Moisture in the fuel can cause corrosion of
metallic fuel system components, starting and
running complaints and require additional fuel
system maintenance.
Ring Free Fuel Additive
Gasoline is a precise blend of many different
substances, each chosen to give certain
characteristics. Gasoline blends have been
changing in recent years in response to
concerns about pollution and resulting
emissions regulations. One of the most obvious
changes has been the elimination of lead from
most fuels.
As gasoline has changed, the amount of additives
such as aromatics and oxygenates has
increased. These additives are important for the
engines in passenger cars, but they can have
detrimental effects in marine engines, because of
increased deposits in the combustion chamber.
When enough deposits collect, piston rings begin
sticking. Performance drops and engine wear
increases dramatically.
While many additives available may reduce
deposits, we recommend the use of Ring Free
Fuel Additive.It has repeatedly proven its ability to
clean combustion deposits from inside the engine,
notably the critical piston-ring-land area, and fuel
system components. Follow product labeling for
use instructions.
Anti-fouling paint
A clean hull improves boat performance. The
boat bottom should be kept as clean of marine
growth as possible. If necessary, the boat bottom
can be coated with an anti-fouling paint
approved for your area to inhibit marine growth.
Do not use anti-fouling paint which includes
copper or graphite. These paints can cause
more rapid engine corrosion.
Motor disposal requirements
Never illegally discard (dump) the motor.
Emergency equipment
Keep the following items onboard in case there is
trouble with the motor.
• A tool kit with assorted screwdrivers, pliers,
wrenches (including metric sizes), and electrical
tape.

16

15
17
Components

18

19

20
Components
Engine shut-off cord (lanyard) and clip
The clip must be attached to the engine shut-
off switch for the engine to run. The cord
should be attached to a secure place on the
operator’s clothing, or arm or leg. Should the
operator fall overboard or leave the helm, the
cord will pull out the clip, stopping ignition to
the engine. This will prevent the boat from
running away under power. WARNING!
Attach the engine shut-off cord to a
secure place on your clothing, or your arm
or leg while operating. Do not attach the
cord to clothing that could tear loose. Do
not route the cord where it could become
entangled, preventing it from functioning.
Avoid accidentally pulling the cord
during normal operation. Loss of engine
power means the loss of most steering
control. Also, without engine power, the
boat could slow rapidly. This could cause
people and objects in the boat to be
thrown forward.
1
1. Engine stop button
Choke knob for pull type
To supply the engine with the rich fuel mixture
required to start, pull out this knob.
1
1. Choke knob
3
1. Engine shut-off 2. Cord 3. Clip
Engine stop button
The engine stop button stops the
engine when the button is pushed.
