Kudux ARTNET 150 User manual

ARTNET CONTROLLER
150
User manual
! Please read the manual before installing and using this
lighting
Keep it for future reference

WWW.KUDUX.COM 2
Thank you for purchasing our device.
We make every effort to ensure the best
quality of our products and to meet your
expectations.
If you have any remarks or comments,
please share them with us.
We will be grateful for any suggestions
that will help us make products that are
even better and devices that satisfy your
needs.
R&D Team

WWW.KUDUX.COM 3
Table of contents
Statement.................................................................................................................................. 4
Safety information..................................................................................................................... 4
1. Summary：........................................................................................................................ 4
2. Application area: ............................................................................................................... 4
3. Characteristic description：.............................................................................................. 4
4. Product advantages：....................................................................................................... 5
5. Artnet Controller usage:.................................................................................................... 5
5.1. Display screen display after connecting power supply ................................................. 5
5.2. IP Address Setting mode：............................................................................................ 6
5.3. Universe Setting mode：.............................................................................................. 6
5.4. DMX Addr Setting mode：............................................................................................ 7
5.5. Play Set Setting mode：................................................................................................ 7
5.6. IC Select Setting mode：............................................................................................... 7
5.7. Pixel Setting mode：..................................................................................................... 8
5.8. LED/Pixel Setting mode：............................................................................................. 8
5.9. Channels Setting mode：.............................................................................................. 8
5.10. SD Record Setting mode：........................................................................................ 9
6. Madrix software configuration........................................................................................ 10
7. Contact: ........................................................................................................................... 11

WWW.KUDUX.COM 4
Statement
The product is good packing when ship out the factory. All users should strictly abide by the
warnings and instructions stated in this manual, any damage and results due to misuse and the
neglect of this operating manual will be excluded from the deal responsibility this manual will not
informed in additionally if have technical changes.
Safety information
Safety warning:
This product is only suitable for professional use, and does not apply to security for other
purposes.
After you got the lights, please check the package whether have any damage caused by
transportation. If there is any damage, do not use this fixture, and please contact the dealer or
manufacturer as soon as possible. This product is only suitable for indoor, IP20 protection class.
1. Summary：
Art-Net Controller is an Ethernet driver based on Artnet protocol. It can convert
network pa cket s in Artnet protocol into standard DMX512 data or SPI data controller.
Single port output, up to 6000 pixels can be output. And can record on the line effect,
can record up to 31 effects, can call play effect, speed, brightness and so on through
DMX.
2. Application area:
It is widely used in LED lattice and stage lighting control network which needs a lot
of DMX512 data.
3. Characteristic description：
Input: AC110—220V
Output: DC5V，DC12V，DC24V
Dimensional:
Length: 320m
Wide:62mm
High:50mm
Notice：All sizes are in mm, In the absence of a clear label, the tolerances
are±0.15mm

WWW.KUDUX.COM 5
Signal input:
100m Ethernet interface, can be used with both ARTNET signal and DMX signal (the
initial interface displays ">" when there is a signal in ARTNET mode, and flashes if
there is no signal. In SD card mode, the file name and playback speed currently played
are displayed)
Signal output:
4 core Canon head interface:
Pin1:GND
Pin2:B
Pin3:A/DAT
Pin4:VCC
Can be cascade use, can be cascade up to 64 sets.
4. Product advantages：
1. Ethernet port can input ARTNET signal and DMX signal at the same time。
2. The recording effect can be used offline. Up to 31 effects can be recorded。
3. Playback effect, playback speed, brightness, R, G, B mask, stroboscopic and
recording can be recorded
through the 8 channel controllers of the DMX console。
4. DMX address can be set, one controller occupies 8 DMX channels
5. Can be set to control the IC model,
CL05,DMX512,WS2811,UCS1903,GS8208,UCS9812
6. Single port output, three channels can be set output 170 Pixel, 340 Pixel, 510 Pixel,
680 Pixel.
Four-channel maximum output 512Pixel
7. Can set one lamp one pixel point, two lights one pixel point, three lights one pixel
point, four lights
one pixel point.
8. The output channel can be set: RGB,RBG,GRB,GBR,BRG,BGR,RGBW.
5. Artnet Controller usage:
5.1. Display screen display after connecting power supply
•The first column shows the indication signal, the signal moves ">" when the signal
is normal, and the NO Signal flashes when the signal is abnormal.

WWW.KUDUX.COM 6
•If in SD mode, the file currently played and the speed at which it is played is
displayed
•The second column Output DMX is shown as the control IC type.
•The third column shows 192 171.001.010 as the controller IP address
•The fourth column shows www.kudux.com as the company's Web site.
5.2. IP Address Setting mode：
Press the MODE button long to enter the settings page and select IP Address.
Press the MODE key to enter the IP modification interface, press the MODE key to
select the IP bit to be set, the DOWM and UP keys to increase or decrease the value,
and then press the SET key to save and return.
5.3. Universe Setting mode：
Press DOWM or UP to select Universe, click the MODE button to enter the page
Press DOWM or UP to select the desired Universe range and click the SET button
to exit

WWW.KUDUX.COM 7
5.4. DMX Addr Setting mode：
Press DOWM or UP to select DMX Addr, click the MODE button to enter the page
Press DOWM or UP to select the desired range DMX Addr, click the SET button to exit
5.5. Play Set Setting mode：
Click the MODE button to enter the page, press DOWM or UP to select Play Set
5.6. IC Select Setting mode：
Click the MODE button to enter the page, press DOWM or UP to select IC Select
Can be set to select IC：CL05，DMX，WS2811，UCS1903，GS8208,，UCS9812.

WWW.KUDUX.COM 8
5.7. Pixel Setting mode：
Click the MODE button to enter the page, press DOWM or UP to select Pixel.
The number of pixels output by the controller can be set：170Pixel，
340Pixel, 510Pixel，680Pixel
5.8. LED/Pixel Setting mode：
Click the MODE button to enter the page and press the DOWM or UP key to select
the LED/ Pixel
Can set one lamp one pixel point, two lights one pixel point, three lights one pixel
point, four lights one pixel point.
5.9. Channels Setting mode：
Click the MODE button to enter the page, press DOWM or UP to select Channels.

WWW.KUDUX.COM 9
The output channel order can be set：RGB，RBG，GRB，GBR，BRG，BGR，RGBW
5.10. SD Record Setting mode：
Click the MODE button to enter the page, press DOWM or UP to select SD Record.
For manual recording, press MODE to enter, select the current file to be
recorded through DOWM or UP, press MODE to enter into the recording
interface, select Record, click MODE, and then click MODE again to exit
recording, and the original effect in the current file will be overwritten.
Play: looks at the effect of the current recording.
When the setting is complete, press the button to exit the
setting area and return to the main menu.

WWW.KUDUX.COM 10
6. Madrix software configuration.
Computer operation Usage steps (the controller is used in ARTNET mode):
After the controller is connected to the computer, set the
IP and subnet mask of the computer, and notice that the
IP address of the PC side is in the same network
segment as the IP address of the controller (for example,
if the controller IP is 192.168.1.10, the IP of the PC side
should be set to 192.168.1.X, when X is 0 ≤255and not
10). The IP address of the controller can also be set by
the controller to adapt to the network segment on the
PC side. The PC subnet mask is fixed to 255.255.255.0.
Open the MADRIX software, click Devices Manager in preferences to select the
Art-Net option, and click the icon Search for the device, as shown in the figure to
search for a controller called CLEN-Artnet.
Select the DMX device option, select all output ports, select enable and apply.

WWW.KUDUX.COM 11
7. Contact:
Please check who is our dealer in your country at our website
www.kudux.com
or write direct to us by email: [e-mail]
