Kuppersbusch KCT906.2 User manual

Installation instructions
Important - Save for the local electrical inspector’s use.
KC 906.2
072445 I31

2Installation instructions KC 906.2 USA
For your information...
Be sure to read the information in this manual carefully before you install the
cook top.
Please keep this manual in a safe place and pass it on to future owners for
their information and safety.
The following symbols are used in this operating manual:
[The warning triangle will alert you about possible health risks or things
that can cause potential damage to your appliance.
FYou’ll find useful hints and information when you see this symbol.
Warranty
This warranty is extended to the original purchaser and succeeding owners for
products purchased for ordinary home use. It does not cover its use in com-
mercial situation. Should the appliance be sold by the original purchaser during
the warranty period, the new owner continued to be protected until the expi-
ration date of the original purchaser’s warranty period. Save your dated receipt
or other evidence of the installation/occupancy date. Proof of original purchase
date is needed to obtain service under warranty. The warranty applies even if
the owner should move during the warranty period.
Küppersbusch does not assume any responsibility for consequential or inci-
dental damages. This warranty provides you with certain legal rights. You may
also have other rights which may vary from state to state.
What Is Covered
For one full year from the date of the original purchase, we will provide parts,
service and labor in your home to repair or replace any part of the cook top
that fails because of a defect in materials or workmanship. This service is pro-
vided free of charge. All warranty service will be provided by an authorized
technician during normal business hours.
What Isn’t Covered
■ Service by an unauthorized agency will not be reimbursed. Likewise, the
warranty doesn’t cover any damage or repairs due to service performed by
an unauthorized agency, or by the use of unauthorized parts.
■ Service visits to teach you how to use the appliance.
■ Service visits to correct the installation. You are responsible for providing
electrical wiring and other connecting facilities.
■ Reset circuit breakers or replace home fuses.
■ Damage resulting from accident, alteration, misuse, improper installation,
abuse or installation not in accordance with local electrical codes, or im-
proper storage of the appliance.
■ Repairs due to other than normal household use.
Disposing of the packaging and
the old appliance
Be sure to dispose of the transport packaging properly. Disposal should not
have a negative impact on the environment. Recycling the packaging saves
raw materials and reduces the amount of waste.
Be sure to dispose of your old appliance properly, as well. Even if it can no
longer be used, it still contains useful materials. Before discarding an old ap-
pliance, disconnect the power cord and remove the door to prevent it from
becoming a hazard.
Contents
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation conditions . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 3
Distances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation above the oven EEB 9600.0 . . . . . . . . . . . . . . 4
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the cooking center . . . . . . . . . . . . . . . . . . . . . 5
Installing accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the acc. no. 451 and 452
Installing the acc. no. 439
Installing the acc. no. 442
For technical information and/or
replacement parts, please contact the
Küppersbusch Customer Care line
at
1-800-459-0844
For the most efficient assistance,
please have the Model and Serial
numbers for the appliance available.

Installation instructions KC 906.2 USA 3
The following symbols are used in this installation manual:
[The warning triangle will alert you about possible health risks or things
that can cause potential damage to your appliance.
FYou’ll find useful hints and information when you see this symbol.
Safety instructions
■ Turn off the power source before installing the cooking surface.
■ Don’t operate the appliance until it has been properly installed within
cabinetry or into an opening in the countertop!
■ Only qualified personnel should perform installations and repairs on
electrical appliances. Do not repair or replace any part of the appliance
unless specifically recommended in this manual. Do not put your safety
at risk.
■ The glass ceramic surface is very tough and can easily withstand
light to medium blows and loads distributed over large areas. You
should avoid dropping concentrated loads like spice bottles onto the
surface. The impact of such items can damage the cooking surface.
■ If the cooking surface becomes fractured or cracked, quit using it
immediately. Disconnect the power source and call Customer
Service.
■ The connecting cable must not come in contact with the hot cooking
surface.
■ If the cooking center is not installed properly, there is a risk of tipping
it over! Be sure it is fastened to the supporting rails.
■ WARNING! The adjacent side walls must be secured so the installed
cooking center can’t tilt.
Installation conditions
■ Make sure the plastic finish or the veneer of the built-in kitchen furniture
has a heat-resistant adhesive (100 °C/210 °F).
■ The appliance must be perfectly horizontal.
■ The cooking center must be installed between two side cabinets.
■ Make sure all components surrounding the oven can resist temperatures of
at least 100 °C/210 °F. These include varnishes, edge bands, plastic
surfaces, adhesives and paints. The adjacent cabinet fronts should be able
to resist temperatures up to 70 °C/160 °F.
■ To eliminate the risk of burns or fire by reaching above heated surface units,
do not put cabinet storage space above the surface units. If you do decide
to put cabinet storage above the surface units, install a range hood that
projects at least 5" horizontally beyond the bottom of the cabinets.
Installation dimensions
Distances
Concerning A*: A = 30" minimum clearance between the top of the cooking
suface and the bottom of an unprotected wood or metal cabinet or A = 24"
minimum when bottom of wood or metal cabinet is protected by not less than
1/4-inch-thick flame-retardant millboard covered with not less than No. 28
MSG sheet steel, 0.015-inch-thick stainless steel, 0.024-inch-thick
aluminium, or 0.020-inch-thick copper.
Hoods above the cook top should be at least 650 mm (26") above the cook
top.
Concerning B*: Minimum distance corresponds to the width of the
appliance.
To eliminate the risk of burns or fire by reaching over heated surface units,
do not put cabinet storage space above the surface units. If you do decide
to put cabinet storage above the surface untis, install a range hood that
projects at least 5" horizontally beyond the bottom of the cabinets.
Concerning C*:This appliance can be mounted with two sides to a wall or
the side of a cabinet with a distance of at least 40 mm (1-9/16"). The third
side may only be positioned next to an appliance of equal height.
There should be a horizontal distance between the appliance and mounted
cupboards of at least 300 mm (12") for ergonomical reasons.

4Installation instructions KC 906.2 USA
Installation above the oven
EEB 9600.0
The oven must be positioned on a secured shelf be-
tween two cabinets. Shelves (approximately 19mm/
9/16" thick) must be attached to the adjacent cabi-
nets on both sides so the oven can be clipped in at
the sides.
Please review the installation instructions for the
model EEB 9600 for installation dimensions and in-
stallation.
Be sure to install a
stainless steel filler panel
(acc. No. 454) between the
Cook-Center and the oven.
The stainless steel filler
panel is required and sold
separately.
Electrical connection
■ Observe all guidelines and regulations from your local electric code.
■ You should not be able to touch insulated components when operating the
appliance.
■ The power supply should be a 240 volts system, 2-wire with ground, or a
120/240 volts system, 3-wire with ground.
Electrical diagram
for a 240 volts system,
2-wire with ground:
Electrical diagram
for a 120 / 240 volts system,
3-wire with ground:
■ Be sure to install an appropriate conduit box (not furnished) to connect the
cook top. Only a professional electrician or certified technician should install
a conduit-box or replace the connection cable.
■ Don’t shorten the conduit to facilitate service! The conduit should be routed
to permit the removal of the cooking surface.
■ A circuit breaker or fuse is recommend, having amperage as noted in this
chapter. Fuse both sides of the line!
■ The conduit-box can be mounted under the countertop below the cooking
surface or in a side cabinet in the wall. Do not mount it above the cooking
surface!
■ Be sure the conduit and the conduit box cannot be touched or damaged
after installation!
Connection to a conduit-box (not supplied accessory!)
Total rating 8.3 kW, fuse current: 40 A
Electrical connection 240 V, 60 Hz

Installation instructions KC 906.2 USA 5
Installing the cooking center
– Using 4.2 x16 mm screws, install the supporting rails in horizontal position
on the right side. Install the supporting rails on the left onto the sides of
the cabinets, using the following measurements.
– Connect the conduit to the conduit box.
– Fit the appliance in.
– Fasten the appliance onto the supporting rails using 4.2 x 7 mm screws.
– Use silicon to seal the appliance on the back and on the two sides.
Installing accessories
Installing the acc. no. 451 and 452
Dimensions of the drawers:
Model acc.
no. 451:
Model acc.
no 452:
For both models:
Measurements for the screws of the supporting rails for the drawers
– Screw on the supporting rails:
For model 451 A ≥ 129 mm (≥ 5-1/16")
for model 452 A ≥ 90 mm (≥ 3-9/16")
1.
2.

6Installation instructions KC 906.2 USA
– Insert the drawer in the supporting rails.
Installing the acc. no. 439
– Screw on the supporting rails.
Adapt the pot grid width, if necessary:
IIf the slide-out grid doesn’t fit
into the corner because it’s too
wide or if there’s too much
space after it’s been inserted,
the slide-out grid width can be
adjusted up to a max. of ± 2
mm (± 1/16") by loosening the
fixing screw E. Tighten the
screw E again after making the
adjustment!

Installation instructions KC 906.2 USA 7
Installing the acc. no. 442
FInstall this accessory only with a stainless steel filler panel (acc.no 454)!
The installation instructions will be provided with the filler panel.
– First, install the stainless steel filler panel (acc. no. 454).
– Mark the screw positions for the cabinet floor and the door hinges.
A must be the same height as B.
– When screwing in the screws, leave space for the floor of the cabinet to be
inserted.
– Insert the floor from above, align it and adjust it by fastening the front
fastening screws.
– Fasten the hinges to the revolving doors.
– Fasten the the revolving doors according to the above illustration.

KÜPPERSBUSCH
112 N. East Street, Suite C
Tampa, Florida 33602
Telephone: [phone] Fax: [phone]
Customer Care line: 1 - 800 - 459 - 0844
www.kuppersbuschusa.com
KÜPPERSBUSCH is a brand of Teka USA, Inc.
