Kuppersbusch TD 1458.0W-CN User manual

User manual
Tumble Dryer
TD1458.0W-CN

Contents
Important safety information 2
Environment 4
Installation 4
Product description 6
Control panel 6
Before first use 6
Programme chart 7
Sorting and preparing laundry 8
Daily use 9
Cleaning and maintenance 10
What to do if ... 11
Technical data 12
Machine settings 13
Hints for test institutes 13
Subject to change without notice
Important safety information
Important! In the interest of your safety
and to ensure the correct use, before
installing and first using the appliance,
read this user manual carefully,
including its hints and warnings. To
avoid unnecessary mistakes and
accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation
and safety features. Save these
instructions and make sure that they
remain with the appliance if it is moved
or sold, so that everyone using it
through its life will be properly
informed on appliance use and safety.
- Please read the instruction book
before using this appliance.
General safety
• It is dangerous to alter the specifications
or attempt to modify this product in any
way.
• This appliance is not intended for use by
persons (including children) with reduced
physical and sensory conditions or lack
of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
• Make sure that small children and pets
do not climb inside the drum. To avoid
this, please check into the drum before
using.
• Any objects such as coins, safety pins,
nails, screws, stones or any other hard,
sharp material can cause extensive dam-
age and must not be placed into the ma-
chine.
• In order to avoid danger of fires caused
by excessive drying, do not use appli-
ance to dry the following items: Cush-
ions, quilts etc. (these items accumulate
heat).
• Items such as foam rubber (latex foam),
shower caps, waterproof textiles, rubber
backed articles and clothes or pillows fit-
ted with foam rubber pads should not be
dried in the tumble dryer.
• Always unplug the appliance after use,
cleaning and maintenance.
• Under no circumstances should you at-
tempt to repair the machine yourself. Re-
pairs carried out by inexperienced per-
sons may cause injury or serious mal-
functioning. Contact your local Service
Centre. Always insist on genuine spare
parts.
• Items that have been soiled with sub-
stances such as cooking oil acetone,
petrol, kerosene, spot removers, turpen-
tine, waxes and wax removers should be
washed in hot water with an extra
amount of detergent before being dried in
the tumble dryer.
•Danger of explosion: Never tumble dry
items that have been in contact with in-
flammable solvents (petrol, methylated
spirits, dry cleaning fluid and the like). As
these substances are volatile, they could
cause an explosion. Only tumble dry
items washed with water.
•Risk of fire: items that have been spot-
ted or soaked with vegetable or cooking
oil constitute a fire hazard and should not
be placed in the tumble dryer.
• If you have washed your laundry with
stain remover you must execute an extra
rinse cycle before loading your tumble
dryer.
• Please make sure that no gas lighters or
matches have accidentally been left in
2

pockets of garments incase they are loa-
ded into appliance
Warning!
•Risk of fire! Never stop a tumble
dry before the end of the drying
cycle unless all items are quickly
removed and spread out so that
the heat is dissipated.
•Lint must not be allowed to accu-
mulate around the tumble dryer.
•Risk of electric shock! Do not spray
down the appliance with jets of water.
• The final part of a tumble dryer cycle oc-
curs without heat ( cool down cycle ) to
ensure that the items are left at a temper-
ature that ensures that items will not be
damaged.
• The tumble dryer is not to be used if in-
dustrial chemicals have been used for
cleaning.
• Ensure you have good ventilation in the
installation room to avoid the back flow of
gases into the room from appliances
burning other fuels, including open fires.
Installation
• This appliance is heavy. Care should be
taken when moving it.
• When unpacking the appliance, check
that it is not damaged. If in doubt, do not
use it and contact the Service Centre.
• All packaging must be removed before
use. Serious damage can occur to the
product and to property if this is not ad-
hered to. See relevant section in the user
manual.
• Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
• If the machine is situated on a carpeted
floor, please adjust the feet in order to al-
low air to circulate freely under the appli-
ance.
• After having installed the appliance,
check that it is not pressing or standing
on its electrical supply cable.
• If the tumble dryer is placed on top of a
washing machine, it is compulsory to use
the stacking kit (optional accessory).
Use
• This appliance is designed for domestic
use. It must not be used for purposes
other than those for which it was de-
signed.
• Only wash fabrics which are designed to
be machine dried. Follow the instructions
on each garment label.
• Do not dry unwashed items in the tumble
dryer.
• Do not overload the appliance. See the
relevant section in the user manual.
• Clothes which are dripping wet should
not be placed in the dryer.
• Garments which have been in contact
with volatile petroleum products should
not be machine dried. If volatile cleaning
fluids are used, care should be taken to
ensure that the fluid is removed from the
garment before placing in the machine.
• Never pull the power supply cable to re-
move the plug from the socket; always
take hold of the plug itself.
• Never use the tumble dryer if the power
supply cable, the control panel, the work-
ing surface or the base are damaged so
that the inside of the tumble dryer is ac-
cessible.
• Fabric softeners, or similar products
should be used as specified by the fabric
softener instructions.
•Caution - hot surface : Do not touch
the door light cover surface when the
light is switched on.
(Only dryers equipped with internal drum
light)
Child safety
• This machine is not intended for use by
young children or infirm persons without
supervision.
• Children often do not recognise the haz-
ards associated with electrical applian-
ces. Children should be supervised to
ensure that they do not play with the ap-
pliance.
Warning!
• Danger of suffocation! The packag-
ing components (e.g. plastic film,
polystyrene) can be dangerous to
children - Keep them out of chil-
dren’s reach.
3

• Keep all detergents in a safe place out of
children’s reach.
• Make sure that children or pets do not
climb inside the drum.
Environment
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will
help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling of
this product. For more detailed information
about recycling of this product, please
contact your local council, your household
waste disposal service or the shop where
you purchased the product.
Old appliance
Warning!
Remove mains plug from socket when you
have no further use for the machine. Cut off
mains cable and dispose of together with
plug. Destroy loading door hook. Children
cannot then lock themselves in the machine
and put their lives at risk.
Packaging material
The packaging materials are environmental-
ly friendly and can be recycled. The plastic
components are identified by markings, e.g.
>PE<, >PS<, etc. Please dispose of the
packaging materials in the appropriate con-
tainer at the community waste disposal fa-
cilities.
Environmental tips
• In the dryer, laundry becomes fluffy and
soft. Fabric softeners are not therefore
needed when washing.
• Your dryer will function most economical-
ly if you:
– always keep the ventilation slots on the
base of the dryer unobstructed;
– use the loading volumes specified in
the programme overview;
– ensure you have good ventilation in the
installation room;
– clean the micro-fine filter and fine
strainer after each drying cycle;
– spin the laundry well before drying.
Energy consumption depends on spin-
ning speed set in washing machine.
Higher spinning speed - lower energy
consumption.
Installation
Appliance positioning
• It is recommended that, for your conven-
ience, the machine is positioned close to
your washing machine.
• The tumble dryer must be installed in a
clean place, where dirt does not build up.
• Air must be able to circulate freely all
round the appliance. Do not obstruct the
front ventilation grille or the air intake
grilles at the back of the machine.
• To keep vibration and noise to a mini-
mum when the dryer is in use, it should
be placed on a firm, level surface.
• Once in its permanent operating position,
check that the dryer is absolutely level
with the aid of a spirit level. If it is not,
raise or lower the feet until it is.
• The feet must never be removed. Do not
restrict the floor clearance through deep-
pile carpets, strips of wood or similar.
This might cause heat built-up which
would interfere with the operation of the
appliance.
4

Important!
• The hot air emitted by the tumble dryer
can reach temperatures of up to 60°C.
The appliance must therefore not be in-
stalled on floors which are not resistant to
high temperatures.
• When operating the tumble dryer, the
room temperature must not be lower
than +5°C and higher than +35°C, as it
may affect the performance of the appli-
ance.
• Should the appliance be moved, it must
be transported vertically.
• The appliance must not be installed be-
hind the lockable door, a sliding door a
door with a hinge on the opposite side to
that of the appliance in such a way that a
full opening of the dryer is restricted.
Removing transport safety packaging
Caution!
Before use all parts of the transport pack-
aging must be removed.
1
1. Open loading door
2. Pull off adhesive strips from inside ma-
chine on top of drum.
3. Remove foil hose and polystyrene pad-
ding from the machine.
Electrical connection
Details on mains voltage, type of current
and the fuses required should be taken
from the type plate. The type plate is fitted
near the loading aperture (see “Product de-
scription” chapter).
Connect the machine to an earthed
socket, in accordance with current wir-
ing regulations.
Warning! The manufacturer
declines any responsibility for
damage or injury through failure to
comply with the above safety
precautions.
Should the appliance power supply
cable need to be replaced, this
must be carried out by our Service
Center.
Warning! The plug must be
accessible after installing the
machine.
Door reversal
To make it easier to load or unload the
laundry, the door can be reversed.
Warning! The door must only be
reversed by an authorised service
engineer.
Please contact your local Service Force
Centre. The engineer will carry out the door
reversal at your cost.
Special accessories
•Stacking kit
These intermediate installation kits can
be used to arrange the dryer and a wash-
ing machine (60 cm wide, front loaded)
as a space-saving washer/dryer stack.
The washing machine is at the bottom
and the dryer is at the top.
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
•Draining kit
Installation kit for direct draining of the
condensed water into a basin, siphon,
gully, etc. The water reservoir then no
longer has to be drained, it must however
remain in its intended position in the ma-
chine.
Fixed hose has to be on the suitable
height from minimum of 50 cm to maxi-
mum of 1 m from floor level and cannot
be looped. If possible shorten the drain-
ing hose.
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
•Pedestal with the drawer
5

To situate the dryer at the optimal height
and have some additional space to store
(e.g. laundry).
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
Product description
1
2
3
5
6
8
10
11
4
7
9
1Worktop
2Water reservoir
3Drum light
4Rating Plate
5Heat exchanger
6Heat exchanger door
7Control panel
8Fluff filters
9Loading door
10 Ventilation grille
11 Adjustable feet
Control panel
1234 5 6 7 8 9 10
1Programme knob and On/Off switch
2Display
3INTENSIVE button
4DELICATE button
5LONG ANTICREASE button
6BUZZER button
7TIME button
8START/PAUSE button
9Maintenance displays
–Condenser
–Filters
–Full Tank
10 DELAY button
What is shown in the display
SYMBOL DESCRIPTION
Time to end (time of time pro-
gramm, time of start delay)
Child lock
Anticrease guard phase
Error, wrong selection
Before first use
In order to remove any residues which may
have been produced during production,
wipe the dryer drum with a damp cloth or
carry out a brief drying cycle (30 MIN) with
damp cloths in the machine.
1. Turn the programme knob to TIME .
6

2. Press the START/PAUSE button.
Programme chart
Programmes
max. load
(weight when dry)
Additional
functions/
options
Application/properties
Care mark
COTTON
EXTRA DRY 6 kg all
1)
except Thorough drying of thick or multi- layered fab-
rics, e.g. terry towelling items, bathrobes.
COTTON
STRONG DRY 6 kg all
1)
except Thorough drying of thick or multi- layered fab-
rics, e.g. terry towelling items, bathrobes.
COTTON
STORAGE DRY
2)
6 kg all
1)
except Thorough drying of fabrics of even thicknesses,
e.g. terry towelling items, knitwear, towels.
COTTON
DAMP
2)
6 kg all
1)
except
For thin textiles which are still to be ironed, e.g.
knitted items, cotton shirts.
COTTON
IRON DRY
2)
6 kg all
1)
except For thin fabrics which are also to be ironed, e.g.
knitwear, cotton shirts.
SYNTHETICS
EXTRA DRY 3 kg all
1)
except Thorough drying of thick or multi-layered fabrics,
e.g. pullovers, bedding, table linen.
3)
SYNTHETICS
STORAGE DRY
2)
3 kg all
1)
except For thin fabrics which are not ironed, e.g. easy
care shirts, table linen, baby clothes, socks, lin-
gerie with bones or wires.
3)
SYNTHETICS
IRON DRY 3 kg all
1)
except For thin fabrics which are also to be ironed, e.g.
knitwear, cotton shirts.
3)
TIME 6 kg
For further drying of individual items of laundry.
EASY IRON
1 kg
(or
5
shirt
s)
Special program with anti-crease mechanism
for easy care fabrics such shirts and blouses; for
minimum ironing effort. The results depends on
the type of fabric and its finish. Place fabrics in
the dryer straight after spinning; once dried, im-
mediately remove fabrics and place on a clothes
hanger.
MIXED 3 kg
4)
For drying cotton and synthetic fabrics, uses
low temperature.
7

Programmes
max. load
(weight when dry)
Additional
functions/
options
Application/properties
Care mark
CURTAINS 2 kg
4)
Special programe for curtains to be drieded
"STORE DRY"
BABY 2 kg
Baby cycle is a special programme for jumpers
to be dried “ready to wear”.
REFRESH 1 kg For refreshing or gently cleaning textiles with
commercially available dry cleaning products.
1) The DELICATE cannot be selected with INTENSIVE
2) In accordance with IEC61121
3) select DELICATE option
4) auto
Sorting and preparing laundry
Sorting laundry
• Sort by fabric type:
–Cotton/linen for programmes in
COTTONS programme group.
– Mixed fibres and synthetics for pro-
grammes in the SYNTHETICS pro-
gramme group.
• Sorting by care label. The care labels
mean:
Drying in the tumble dryer possible in prin-
ciple
Dry at normal temperature
Dry at reduced temperature (press
DELICATE button!)
Drying in the tumble dryer not possible
Important! Do not place in the appliance
any wet laundry which is not specified on
the care label as being suitable for tumble-
drying.
This appliance can be used for all wet laun-
dry items which are labelled as suitable for
tumble-drying.
• Do not dry new, coloured textiles togeth-
er with light-coloured laundry items. Tex-
tile colours may bleed.
• Do not dry cotton jersey and knitwear
with the EXTRA DRY programme.
Items may shrink!
Preparing laundry
• To avoid laundry becoming tangled:
close zips, button up duvet covers and
tie loose ties or ribbons (e.g. of aprons).
• Empty pockets. Remove metal items (pa-
per clips, safety pins, etc).
• Turn items with double-layered fabrics in-
side out (e.g. with cotton-lined anoraks,
the cotton layer should be outermost).
These fabrics will then dry better.
Important! Do not overload the appliance.
Observe max. loading volume.
Laundry weights
Type of laundry Weight
Bathrobe 1200 g
Napkin 100 g
Quilt cover 700 g
Sheet 500 g
Pillow case 200 g
Tablecloth 250 g
Towelling towel 200 g
8

Type of laundry Weight
Tea cloth 100 g
Night dress 200 g
Ladies' briefs 100 g
Man's work shirt 600 g
Type of laundry Weight
Man's work shirt 200 g
Man's pyjamas 500 g
Blouse 100 g
Men's underpants 100 g
Daily use
Switching machine on
Turn the programme selector to any pro-
gramme. The machine switches on. When
the loading door is open, the internal lamp
illuminates the drum.
Operating
1
45
2
3
INTENSIVE
If the laundry is still damp after a standard dry-
ing programme, you can increase the drying
result by using the Intensive function.
DELICATE
gentle drying with reduced heat of sensitive
fabrics and temperature-sensitive textiles (e.g.
acrylic, viscose) marked on care label with:
LONG ANTI-CREASE
prolongs the anti-crease phase to 90 mins in
total. The laundry remains relaxed and free of
creases.
BUZZER
audible confirmation of:
•cycleend
• anti-crease phase start and end
• cycle interruption
• error
TIME
after setting the TIME programme. You can
select a programme duration from 10 mins to 2
hrs in 10-minute steps.
DELAY START
allows to delay the start of a drying programme
from minimum of 30 min. to maximum of 20
hours. Press the DELAY START button repeat-
edly until the desired delay start is shown on
the display
Setting child lock
The child lock can be set to prevent a pro-
gramme being accidentally started or a pro-
gramme in operation being accidentally
changed. The child lock function locks all
buttons and the programme selector. The
child lock can be activated or deactivated
by holding down the INTENSIVE and
DELICATE buttons simultaneously for 5
seconds.
The icon appears in the display to indi-
cate that the child safety device is activa-
ted.
Any changes of drying parameters re-
quire child lock deactivation.
The child lock cannot be deactivated in the
last phase of the drying cycle.
Starting the programme
Press the Start/Pause button. The pro-
gramme starts.
The programme progress is shown by
elapsing dry time on the LCD.
Changing programme
To change a programme which is running,
first cancel it by turning the programme se-
lector dial to OFF. Select the new pro-
gramme and press the START/PAUSE
button.
9

The programme can no longer be
changed directly once the programme
has started. If nevertheless there is an
attempt to change the programme on
the programme knob, the programme
progress display and the maintenance
indicators flash. If an option button (ex-
cluding the BUZZER button) is
pressed, appears on the display.
The drying programme is not however
affected by this (laundry protection).
Drying cycle complete / removing
laundry
Once the drying cycle is complete, the dis-
play shows the anti-crease icon and
flashing as well as warning lamps: FIL-
TER and FULL TANK . If the BUZ-
ZER button has been pressed, an acoustic
signal sounds intermittently for about one
minute.
The drying cycles are automatically fol-
lowed by an anti-crease phase which
lasts around 30 minutes. The drum ro-
tates at intervals during this phase. This
keeps the laundry loose and free of
creases. The laundry can be removed
at any time during the anti-crease
phase. (The laundry should be taken
out towards the end of the anti-crease
phase at the latest to prevent creases
from forming.)
1. Open door.
2. Before removing the laundry, remove
fluff from the micro-fine filter. It is best to
use a damp hand for this purpose. (See
“Cleaning and maintenance” chapter.)
3. Remove laundry.
4. Turn the programme selector to off.
5. Close the door.
After each use
• Clean the filters.
• Empty the water reservoir.
Cleaning and maintenance
Cleaning fluff filters
The filters collect all the fluff which accumu-
lates during drying. To ensure that the dryer
works perfectly, the fluff filters (fine filters
and fluff filters) must be cleaned after each
drying cycle.
Caution! Never operate the dryer
without fluff filters or with damaged or
blocked fluff filters.
65
2 3
1
4
7II
I
II
I
Clean the door seal
Wipe the door seal with a damp cloth im-
mediately after the drying cycle has finish-
ed.
Emptying the water reservoir
Empty the water reservoir after every drying
cycle.
10

Caution! The condensed water is not
suitable for drinking or for preparing
foodstuffs.
If the programme has been interrupted
as a result of the water reservoir being
full: Press the START/PAUSE button to
continue the drying cycle.
Cleaning condenser
Important!
• Never operate the dryer without con-
denser.
• Clogged condenser cause higher energy
consumption (drying cycle elongation)
and dryer damage.
• Do not use sharp objects to clean.
6 7
Cleaning the drum
Caution! Do not use abrasives or steel
wool to clean the drum.
Lime in the water or cleaning agents
may form a barely visible lining on the
inside of the drum. The degree to
which the laundry has been dried is
then no longer detected reliably. The
laundry is damper than expected when
removed from the appliance.
Use a standard domestic cleaner (e.g. vine-
gar-based cleaner) to wipe down the inside
of the drum and drum ribs.
Clean control panel and housing
Caution! Do not use furniture cleaners
or aggressive cleaning agents to clean
the machine.
Use a damp cloth to wipe down the control
panel and housing.
What to do if ...
Troubleshooting by yourself
Problem
1)
Possible cause Remedy
Dryer does
not work.
Dryer not connected to mains supply. Plug in at mains socket. Check fuse in
fuse box (domestic installation).
Loading door opened. Close loading door
The START PAUSE button not pressed. Press the START PAUSE button.
Unsatisfactory
drying results.
Incorrect programme set. Set suitable programme.
2)
Fluff filters clogged. Clean fluff filters.
3)
Heat exchanger clogged. Clean heat exchanger.
3)
Max. loading exceeded. Respect max. loading volume.
Covered ventilation grill. Uncover ventilation grill in base area.
11

Residue inside the drum. Clean the drum inside.
High water hardness. Set suitable water hardness
4)
.
Loading door
does not
close
Filters not locked in place. Install fine filter and/or snap course filter
into place.
Err ( Error )
on the LCD.
5)
Attempt to change parameters after
start of the programme.
Turn the dryer off and on. Set requested
parameters.
No drum light Programme selector in OFF position. Turn it to DRUM LIGHT (if available) or
to any programme.
Defective light bulb. Replace light bulb (see next section).
Abnormally
elapsing time
on the LCD
5)
Time to end is calculated on the basis
of: type, volume and dampness of laun-
dry.
Automatic process; this is not a ma-
chine fault.
Programme
inactive Full water reservoir. Empty water reservoir
3)
, press START
PAUSE button.
Drying cycle
to short
Small laundry volume./Too dry laundry
for selected programme.
Select time programme or higher drying
level (e.g. EXTRA DRY ).
Drying cycle
to long
6)
Fluff filters clogged. Clean fluff filters.
To high loading volume. Respect max. loading volume.
Laundry insufficiently spun. Spun adequately the laundry.
Particularly high room temperature - no
machine fault. Lower the room temperature if possible.
1) In case of error message on the LCD (e.g. E51 - only dryers with the LCD): Switch the dryer off and on. Set
programme. Press the START PAUSE button. Does not work? - inform local service and quote the error code.
2) follow program recommendation - see Programme overview chapter
3) see Care and cleaning chapter
4) see Machine settings chapter
5) only dryers with the LCD
6) Note: After around 5 hours the drying cycle ends automatically (see Drying cycle complete section).
Technical data
Parameter Value
Height x width x depth 85 x 60 x 58 cm
Drum volume 108 l
Depth with loading door open 109 cm
Height can be adjusted by 1.5 cm
Weight when empty approx. 40 kg
Loading volume (depends on programme)
1)
max. 6kg
Voltage 230 V
Required fuse 10 A
Total power 2350 W
Energy efficiency class C
Energy consumption (6 kg of cotton, pre-drained
at 1000 rpm)
2)
3.8 kWh
12

Parameter Value
Average annual energy consumption 302.5 kWh
Use Domestic
Permissible ambient temperature + 5°C to + 35°C
Consumption values
The consumption values have been established under standard conditions. They may deviate when
the machine is operated in domestic circumstances.
Programme Energy consumption in kWh / average dry-
ing time in min.
COTTON CUPBOARD DRY
3)
3.8 / 125 (6 kg load pre-drained at 1000 rpm)
3,40 (6 kg load pre-drained at 1200 rpm)
3,30 (6 kg load pre-drained at 1400 rpm)
2,50 (6 kg load pre-drained at 1800 rpm)
COTTON IRON DRY
3)
3.0 / 100 (6 kg load pre-drained at 1000 rpm)
SYNTHETICS CUPBOARD DRY
3)
1.35 / 50 (3 kg load pre-drained at 1200 rpm)
1) different loading volume data may be needed in some countries as a result of different measuring methods
2) in accordance to EN 61121
3) hints for test institutes: cycle has to be checked in accordance to EN 61121
Machine settings
Setting Implementation
BUZZER permanent off 1. Turn the programme selector to any programme.
2. Press simultaneously the DELICATE and LONG
ANTI-CREASE buttons and hold down for approx. 5 seconds.
3. The buzzer is by default always off.
Water hardness
Water contains, a variable
quantity of limestone and min-
eral salts of which quantities
vary according to geographi-
cal locations thus varying its
conductivity values.
Relevant variations of the con-
ductivity of the water com-
pared to those prefixed by the
factory could slightly influence
the residual humidity of the
laundry at the end of the cy-
cle. Your dryer allows you to
regulate the sensitivity of the
drying sensor based on con-
ductivity values of the water.
1. Turn the programme selector to any programme.
2. Press simultaneously the LONG ANTI-CREASE and
START/PAUSE buttons and hold down for approx. 5 sec-
onds. The current setting is on the display:
–low conductivity <300 micro S/cm
–medium conductivity 300-600 micro S/cm
–high conductivity >600 micro S/cm
3. Press the START/PAUSE button sequentially until you set
desired level.
4. To memorize setting press simultaneously the LONG
ANTI-CREASE and START/PAUSE buttons or turn knob
to Ooff position
Hints for test institutes
Parameters possible to checked by the
Test Institutes:
• Energy consumption (corrected with final
humidity) during the cupboard dry cotton
cycle with nominal load.
• Energy consumption (corrected with final
humidity) during the cupboard dry cotton
cycle with half load.
• Final humidity (during cupboard dry cot-
ton, iron dry cotton and cupboard dry
easy care)
13

• Condensation efficiency (corrected with
final humidity) during cupboard dry cot-
ton cycle with nominal and half load
All the cycles have to be checked in ac-
cordance with EN 61121 (Tumble dryers for
household use – Methods for measuring
the performance).
14

15

136914590-B-332010
