Kuppersbusch CMB6750.0S Operation manual

BEDIENUNGSANWEISUNG
mit Montageanweisungen
INSTRUCTIONS FOR USE
and installation
Lesen Sie unbedingt die Gebrauchsanleitung
und den Montageplan vor Aufstellung,
Installation sowie Inbetriebnahme.
Please read the users and installation
instructions carefully before installation
of the appliance and before starting to use it.
Service und Kundendienst
Telefon: 0209 – 401 631
Email: [email protected]
CMB6750.0S
EN

CONTENTS
Safety information 2
Safety instructions 4
Product description 7
Control panel 8
Before first use 10
Daily use 10
Clock functions 14
Automatic programmes 15
Using the accessories 16
Additional functions 16
Hints and tips 18
Care and cleaning 35
Troubleshooting 36
Installation 38
Energy efficiency 41
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts may
become hot during use.
•If the appliance has a child safety device, it should be
activated.
2

•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
•Always use oven gloves to remove or put in accessories or
ovenware.
•Before carrying out any maintenance, disconnect the
appliance from the power supply.
•WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of electric
shock.
•Do not use the appliance before installing it in the built-in
structure.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch the
surface, which may result in shattering of the glass.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an electrical
hazard.
•Do not activate the appliance when it is empty. Metal parts
inside the cavity can create electric arcing.
•Metallic containers for food and beverages are not allowed
during microwave cooking. This requirement is not
applicable if the manufacturer specifies size and shape of
metallic containers suitable for microwave cooking.
•If the door or door seals are damaged, the appliance must
not be operated until it has been repaired by a qualified
person.
3

•Only a qualified person can carry out any service or repair
operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
•Do not heat liquids and other foods in sealed containers.
They are liable to explode.
•Use only utensils that are suitable for use in microwave
ovens.
•When heating food in plastic or paper containers, keep an
eye on the appliance due to the possibility of ignition.
•The appliance is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads,
slippers, sponges, damp cloth and similar may lead to risk
of injury, ignition or fire.
•If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
•Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling the
container.
•The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
•Eggs in their shell and whole hard-boiled eggs should not
be heated in the appliance since they may explode, even
after microwave heating has ended.
•The appliance should be cleaned regularly and any food
deposits removed.
•Failure to maintain the appliance in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
4

• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Keep the minimum distance from other
appliances and units.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power supply.
• The built-in unit must meet the stability
requirements of DIN 68930.
Cabinet minimum
height (Cabinet un‐
der the worktop mini‐
mum height)
444 (460) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of
the appliance
455 mm
Height of the back of
the appliance
440 mm
Width of the front of
the appliance
595 mm
Width of the back of
the appliance
559 mm
Depth of the appli‐
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
882 mm
Ventilation opening
minimum size. Open‐
ing placed on the
bottom rear side
560x20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 3.5x25 mm
Electrical connection
WARNING! Risk of fire and
electric shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door or the niche
below the appliance, especially when it
operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
5

• This appliance is supplied with a main
plug and a main cable.
Use
WARNING! Risk of injury,
burns and electric shock or
explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is in
operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can
cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not use microwave function to
preheat the oven.
WARNING! Risk of damage to
the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put aluminium foil directly on
the bottom of cavity of the
appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance
of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
Care and cleaning
WARNING! Risk of injury, fire,
or damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Make sure the cavity and the door are
wiped dry after each use. Steam
produced during the operation of the
appliance condensates on cavity walls
and can cause corrosion.
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
6

• Fat and food remaining in the appliance
can cause fire and electric arcing when
the microwave function operates.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
Internal lighting
WARNING! Risk of electric
shock.
• The type of light bulb or halogen lamp
used for this appliance is for household
appliances only. Do not use it for house
lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming trapped
in the appliance.
PRODUCT DESCRIPTION
General overview
1 2
3
4
5
6
7
1
2
3
4
1Control panel
2Electronic programmer
3Heating element
4Lamp
5Fan
6Shelf support, removable
7Shelf positions
7

Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
CONTROL PANEL
Electronic programmer
1110987654321
Use the sensor fields to operate the oven.
Sensor
field
Function Comment
1- Display Shows the current settings of the oven.
2ON / OFF To turn on and off the oven.
3
Heating Func‐
tions / Assisted
Cooking
Press the sensor field once to choose a heating
function or the menu: Assisted Cooking. Press the
sensor field again to switch between the menus:
Heating Functions, Assisted Cooking. To turn on or
off the light, press the field for 3 seconds.
4
Microwave func‐
tion
To turn on the: Microwave function. You can use it
when the oven is off. When you use the: Microwave
function with the function: Duration for more than 7
minutes and in Combi mode, the Microwave power
cannot be more than 600 W.
8

Sensor
field
Function Comment
5
Temperature se‐
lection / Fast
Heat Up
To set the temperature or show the current temper‐
ature in the oven. Press the field for 3 seconds to
turn on or off the function: Fast Heat Up.
6Down To move down in the menu.
7Up To move up in the menu.
8
OK / Microwave
Quick Start
To confirm the selection or settings. To turn on the:
Microwave function. You can use it when the oven
is off.
9Back To go back one level in the menu. To show the main
menu, press the field for 3 seconds.
10
Time and addi‐
tional functions
To set different functions. When a heating function
works, press the sensor field to set the timer or the
functions: Function Lock, Favourites, Heat + Hold,
Set + Go.
11 Minute Minder To set the function: Minute Minder.
Display
A
DE
B C
A. Heating function or Microwave function
B. Time of day
C. Heat-up indicator
D. Temperature or power of the
microwave
E. Duration time or end time of a function
Other indicators of the display:
Symbol Function
Minute Minder The function works.
Time of day The display shows the current time.
Duration The display shows the necessary time
for cooking.
End Time The display shows when the cooking
time is complete.
9

Symbol Function
Temperature The display shows the temperature.
Time Indication The display shows how long the heat‐
ing function works. Press and
at the same time to reset the time.
Heat-up Indicator The display shows the temperature in
the oven.
Fast Heat Up The function is on. It decreases the
heat up time.
Weight Automatic The display shows that the automatic
weight system is on or that weight can
be changed.
Heat + Hold The function is on.
BEFORE FIRST USE
WARNING! Refer to Safety
chapters.
Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial position.
First Connection
When you connect the oven to the mains
or after the power cut, you have to set the
language, the display contrast, the display
brightness and the time of the day.
1. Press or to set the value.
2. Press to confirm.
DAILY USE
WARNING! Refer to Safety
chapters.
Navigating the menus
1. Turn on the oven.
2. Press or to select the menu
option.
3. Press to move to the submenu or
accept the setting.
At each point you can go back
to the main menu with .
The menus in overview
Main menu
Symbol / Menu
item
Application
Heating Func‐
tions
Contains a list of heat‐
ing functions.
Assisted Cook‐
ing
Contains a list of auto‐
matic programmes.
10
