1 About this manual
This manual is intended for Kvaser Mini PCI Express HS users. This document contains a
description of the hardware’s properties and general instructions for connecting the device to
a computer.
2 Introduction
This section will describe the functions and features of the Kvaser Mini PCI Express HS.
2.1 Welcome to Kvaser Mini PCI Express HS
Figure 1. Kvaser Mini PCI Express HS.
The Kvaser Mini PCI Express HS is a small, yet advanced, CAN interface.
Table 1: Device and EAN Number.
Device
Product Number
Kvaser Mini PCI Express HS
73-30130-00688-1

Kvaser Mini PCI Express HS User's Guide 5(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
2.2 Major features
Mini PCI Express CAN interface.
Quick and easy plug-and-play installation.
Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
100% compatible with applications written for other Kvaser CAN hardware with
Kvaser CANLib.
High-speed CAN connection (compliant with ISO 11898-2), up to 1 Mbit/s.
Fully compatible with J1939, CANopen, NMEA 2000® and DeviceNet.
Supports silent mode for analysis tools –listen to the bus without interfering.
Simultaneous operation of multiple devices.
2.3 Additional software and documentation
Kvaser CANLIB SDK, which includes everything you need to develop software for the
Kvaser CAN hardware. Includes full documentation and many sample programs,
written in C, C++, C#, Delphi, and Visual Basic. All Kvaser CAN interface hardware
shares a common software API. Programs written for one device type will run without
modification on other device types!
On-line documentation in Windows® HTML Help and Adobe Acrobat format.
The latest versions of documentation, software and drivers can be downloaded for
free at www.kvaser.com or purchased separately on CD.

Kvaser Mini PCI Express HS User's Guide 6(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
3 Kvaser Mini PCI Express HS hardware
In this section you can read more about the CAN channels, power supply and led indicators.
3.1 Hardware installation
The Kvaser Mini PCI Express HS may be inserted in any free Mini PCI Express slot on the
host computer that supports USB. You do need to switch the power off before inserting or
removing the device. For the Kvaser Mini PCI Express HS to communicate with the host
computer, compatible versions of the Kvaser driver and firmware must be installed. The
firmware is downloaded and installed directly on the Kvaser Mini PCI Express HS. The driver
is installed on the host computer.
To communicate with the host computer, the correct version of the Kvaser driver must be
installed. The installation file, kvaser_drivers_setup.exe, and instructions can be found on the
attached CD but it is recommended that the latest version is downloaded from
http://www.kvaser.com/download/.
3.2 Firmware Update
Firmware updates and upgrade instructions can be found at
http://www.kvaser.com/download/. Use “Kvaser Hardware” to see the current firmware
version of your Kvaser Mini PCI Express HS.
3.3 Kvaser Mini PCI Express HS connection
The Kvaser Mini PCI Express HS is a Card of type F2 (Full-Mini with bottom side keep outs).
3.4 CAN channels
The standard Kvaser Mini PCI Express HS has one CAN channel and has a 4-pin Molex
connector (see chapter 4.2 CAN connectors).
3.5 Power supply
The Kvaser Mini PCI Express HS is powered from the Mini PCI Express connector.

Kvaser Mini PCI Express HS User's Guide 7(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
3.6 LED Indicators
The Kvaser Mini PCI Express HS has one LED, it's functionality is shown in Table 2.
Table 2 LED configuration
LED
Function
Description
Green
Power
Steady light when unit is powered and working.
USB configuration
Blinking once every three seconds when something is
wrong with the USB connection
Firmware
2 Hz flash if something is wrong with the firmware or
configuration.
3.7 Troubleshooting
Use “Kvaser Hardware” in the Control Panel to verify that the computer
really can talk to the Kvaser Mini PCI Express HS. If the firmware
version shown is all zeroes, there are communication problems.

Kvaser Mini PCI Express HS User's Guide 8(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
4 Appendices
In this section you will find technical information about the Kvaser Mini PCI Express HS and
its connectors.
4.1 Technical data
In Table 3 below you will find the Kvaser Mini PCI Express HS’s technical specifications.
Table 3: Kvaser Mini PCI Express HS Technical Specifications.
CAN Channels
1
CAN Transceivers
TJA1051T (Compliant with ISO 11898-2)
CAN Controller
Built into the processor
CAN Bit Rate
40 to 1000 kbit/s
Time stamp resolution
25 μs
Error Frame Detection
Yes
Error Frame Generation
No
Silent mode
Yes
PC interface
Mini PCI Express with USB 2.0.
Power consumption
Typical values are:
180mA @ 3.3V from Mini PCI Express slot.
Hardware configuration
Done by software (Plug & Play).
Software requirements
Windows XP or later.
(For other operating systems, see Kvaser web or contact Kvaser
support.)
Weight
6g excluding cables and connectors.
Operating temperature
-40 ºC ... +85 ºC
Storage temperature
-55 ºC ... +90 ºC
Relative Humidity
0% ... 85% (non-condensing.)

Kvaser Mini PCI Express HS User's Guide 9(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
4.2 CAN connectors
The Kvaser Mini PCI Express HS has one high-speed CAN channel with a 4-pin Molex
connector (53780-0470) with the pinning described in Table 4.
Table 4: Molex pin configuration.
pin number
Function
1
GND
2
CAN_H
3
CAN_L
4
Shield

Kvaser Mini PCI Express HS User's Guide 10(12)
Kvaser AB, Mölndal, Sweden —www.kvaser.com
5 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it according to your
local environmental laws and guidelines.
