KYARA LTK730 User manual
MA LTK730_LTK740_LTK750 01 B_EN_12-2018
HEATING CAPES -
3 TEMPERATURES
INSTRUCTION MANUAL
ENGLISH
MA LTK730_LTK740_LTK750 01 B_EN.indd 1 10/01/19 16:30
2
ENGLISH
INDEX
1. CODES .............................................................................................................................. pag.3
2. INTRODUCTION .............................................................................................................. pag.3
3. SAFETY WARNINGS ....................................................................................................... pag.3
4. SYMBOLS ......................................................................................................................... pag.4
5. GENERAL DESCRIPTION .............................................................................................. .pag.5
6. INSTRUCTION OF USE ................................................................................................... pag.5
6.1 Automatic switch-off function .......................................................................................pag.6
6.2 Switch-off .........................................................................................................................pag.6
7. CLEANING AND MAINTEINANCE................................................................................. pag.6
8. GENERAL CONDITIONS OF DISPOSAL ....................................................................... pag.6
9. TECHNICAL FEATURES ..................................................................................................pag.7
10. TROUBLESHOOTING .......................................................................................................pag.7
11. WARRANTY ..................................................................................................................... pag.8
11.1 Exempt clauses .................................................................................................................. pag.8
MA LTK730_LTK740_LTK750 01 B_EN.indd 2 10/01/19 16:30
3
ENGLISH
1. CODES
LTK730 HEATING PAD FOR NECK AND SHOULDERS - 3 TEMPERATURES
LTK740 HEATING CAPE FOR NECK AND BACK - 3 TEMPERATURES
LTK750 HEATING CAPE - 3 TEMPERATURES
2. INTRODUCTION
Thank you for choosing the heating pad of the Kyara line by Moretti. Please read the operating
instructions and safety warnings in particular before using the appliance and follow these at all
times. Keep this manual and illustrative guide with the appliance for future consultation. Should
you pass the device on to another user, make sure to also include this documentation. This manual
includes suggestions for a correct use of the appliance and precious advices for your safety. If you
have any doubts, please contact the retailer, who will be able to help you and advise you correctly.
NOTE Check that all parts of the product have not been damaged during the shipment. In
case of damage do not use the product and contact the retailer for further instructions.
3. SAFETY WARNINGS
• After having removed the appliance from its packaging, verify its integrity based on the
drawing and check for any damage caused during transport. If in doubt, do not use the
appliance and contact the local retailer. Do not let children play with the packaging!
Keep the plastic wrapping out of the reach of children; risk of suffocation!
• Before connecting the appliance, check that the mains voltage data reported on the
identification plate corresponds to that of the available electric mains. The identification
plate is attached to the appliance.
• This appliance is intended exclusively as a heating pad for home use. Any other use is
improper and potentially dangerous.
• When using for the first time, you may notice a nasty odour due to the synthetic materials.
• Checking the heating pad outside with your hands must not be taken into account as
this may give a misleading result of the heat emitted.
• The appliance is not to be used by persons (including children) with reduced physical,
sensorial or mental abilities, or with no experience or knowledge, unless supervised by
a person responsible for their safety, supervision or after having received instructions
regarding its use. Children must be supervised to ensure they do not play with the
appliance. Do not use the appliance for ill people, for infants or for persons who are
insensitive to heat. This appliance must not be used by children if the control devices
have not been set beforehand by a parent or guardian or if the child has not been
properly instructed on how to use the device safely.
• AVWARNING – NOT suitable for children under the age of 3. Children under the
age of 3 must not use the appliance as they are unable to react in the event of overheating.
• DO NOT activate the temperature control with wet hands.
• DO NOT pull the power cord or the appliance itself to remove the plug from the socket.
• DO NOT immerse the power cord and the remote control.
• Always disconnect the appliance from the mains before cleaning or performing
maintenance and when the appliance is not in use.
• In case of a fault or malfunctioning of the appliance, switch it off and do not tamper with it.
If the appliance needs to be repaired, contact an authorised technical service centre.
• If the power cord is damaged, it must be replaced by an authorised technical
service centre, so as to prevent all risks.
MA LTK730_LTK740_LTK750 01 B_EN.indd 3 10/01/19 16:30
4
ENGLISH
• The appliance must be used solely with the types of control indicated on the label.
• DO NOT place the remote control (1) or the power cable underneath or on top of
the heating pad when the appliance is turned on.
• DO NOT use the folded appliance.
• Before storage, let the appliance cool before folding it.
• DO NOT leave clothes inside the appliance if folded.
• Inspect the appliance frequently to check for signs of wear and tear. If such signs
are found or if the appliance has been used incorrectly, contact an authorised technical
assistance centre before continuing to use it.
• Persons with pacemakers must not use the appliance.
• This appliance is not intended for medical use inside of hospitals.
• DO NOT use the appliance if it is wet or in locations with an high level of humidity
(e.g., bathroom).
• DO NOT use the appliance to keep animals warm.
• DO NOT leave the appliance running while you sleep.
• If the device is used for an extended period, the selector should be placed
on the level 1-2 (minimun heat).
• DO NOT use the appliance on swollen or painful parts of the body.
• Immediately switch the device off if you feel pain during the use.
• DO NOT use the device if highly flammable gases are present in the air.
• NEVER use the device near to a gas source.
• DO NOT place on the device flammable materials or materials that easily deteriorate
due to the heat (e.g., carton, plastic, paper, candles).
• NEVER expose the appliance to other heat sources (such as burners or ovens),
sub-zero temperatures, direct sunlight, humidity.
• DO NOT INSERT PINS OR NEEDLES.
• Application of the appliance for a long time at high temperature can burn the skin.
WARNING!
In case of improper use, exist the risk of possible injuries.
4. SYMBOLS
Product code
Month and year of production
CE mark
Instruction manual
Disposal
Insulation class II
MA LTK730_LTK740_LTK750 01 B_EN.indd 4 10/01/19 16:30
5
ENGLISH
5. GENERAL DESCRIPTION
1
2
3
4
5
MAIN COMPONENTS
1. Remote control
2. Temperature selector
3. Display
4. Connector
5. Connector base
6. INSTRUCTION OF USE
The heating pad is designed to warm the human body. It allows for targeted application of
heat. The heating pad can be placed on parts of the body, such as: neck, shoulders, back,
abdomen and joints, depending on the relative model.
ATTENTION!
The heating pad can only be used with the control supplied. The relative model
is specified on the label sewn on the panel.
• Insert the connector (4) into the connector base (5) to connect the temperature
selector to the heating pad.
• Insert the plug in the socket and select the maximum temperature for a short time, in order
to warm up the heating pad faster, then select a temperature level from 1 to 3
- LTK730*: Level 1 = 53°C; Level 2 = 59°C; Level 3 = 65°C
- LTK740*: Level 1 = 50°C; Level 2 = 55°C; Level 3 = 60°C
- LTK750*: Level 1 = 35°C; Level 2 = 40°C; Level 3 = 45°C
* Tolerance for each temperature level ± 5°C
MA LTK730_LTK740_LTK750 01 B_EN.indd 5 10/01/19 16:30
6
ENGLISH
• Place the heating pad on the part of the body that is to be heated.
6.1 Automatic switch-off function
• The heating pad is provided with an automatic switch-off system. After 90 minutes of
functioning it automatically turns off.
• To turn the device on once again, place the temperature selector in position “0”, wait a few
seconds, then select the desired temperature once again.
6.2 Switch-off
• Switch the heating pad off by placing the temperature selector in position “0”.
• Remove the plug from the socket.
7. CLEANING AND MAINTEINANCE
Do not use bleach
Hand wash at a temperature not higher than 30°
Do not dry-clean
Do not dry the heating pad in the dryer
Do not iron
• Before cleaning make sure that the heating pad is not connected to the electric
main and that it’s cold.
• Before cleaning make sure the connection cable is detached.
• The heating pad can be hand-washed (DO NOT USE THE WASHING MACHINE) at a
temperature not higher than 30°.
• Use a neutral cleanser.
• DO NOT use bleach.
• DO NOT dry in the dryer, leave the heating pad dry to the air. DO NOT place
it on radiators or other heating systems.
• DO NOT iron.
• Make sure that the heating pad is completely dried, before using it again.
• While cleaning do not use chemical or abrasive products.
8. GENERAL CONDITIONS OF DISPOSAL
The product is packaged in recyclable materials. Dispose of it in compliance with the
environmental protection standards.
The product must be disposed of appropriately, in compliance with European
standard 2002/96/EC. The recyclable materials contained in the appliance must be
recovered so as to prevent environmental pollution. For further information, contact
the local disposal body or the appliance dealer.
MA LTK730_LTK740_LTK750 01 B_EN.indd 6 10/01/19 16:30
7
ENGLISH
9. TECHNICAL FEATURES
www.morettispa.com
Voltage: 220-240 ~ 50Hz
Rated power input: 100W
IMPORTED AND DISTRIBUTED BY MORETTI S.P.A. Cavriglia (AR) Italy. MADE IN P. R.C.
Model:
IT – USARE SOLO CON IL COMANDO SS03. UN’APPLICAZIONE PROLUNGATA CON REGOLAZIONE ELEVATA PUò
CAUSARE BRUCIATURE ALLA PELLE. NON UTILIZZARE CON INVALIDI, INFANTI E PERSONE INSENSIBILI AL CALORE.
NON UTILIZZARE SE BAGNATO.
EN – USED ONLY WITH DETACHABLE CONTROLLER SS03. A TOO LONG APPLICATION CAN RESULT IN SKIN BURNS. DO
NOT DRY CLEAN. DO NOT USE WITH INFANTS, A HELPLESS PERSON OR A PERSON INSENSITIVE TO HEAT. HAND WASH
ONLY. DO NOT USE IF WET.
ES – USE EL APARATO SOLO CON EL MANDO TIPO SSO3. UNA APLICACIÓN PROLONGADA CON REGULACIÓN ELEVADA
PUEDE CAUSAR QUEMADURAS EN LA PIEL. NO UTILICE CON PERSONAS INVÁLIDAS, NINOS Y PERSONAS
INSENSIBLES AL CALOR. NO UTILICE SI ESTÁ HÚMEDA.
PT – USAR SOMENTE COM O COMANDO TIPO SSO3. UMA APLICAÇÃO PROLONGADA COM REGULAÇÃO ELEVADA PODE
CAUSAR QUEIMADURAS À PELE. NÃO UTILIZAR COM INVÁLIDOS, CRIANÇAS E PESSOAS INSENSÍVEIS AO CALOR. NÃO
UTILIZAR SE HÚMIDO.
FR – N’UTILISEZ LA COUVERTURE OU’AVEC L’INTERRUPTEUR TYPE SSO3. UNE APPLICATION PROLONGEE AVEC UNE
HAUTE TEMPERATURE PEUT CAUSERDES BRULURES A LA PEAU. NE PAS UTILISER AVEC LES INVALIDES, LES PETITS
ENFANTS ET LES PERSONNES INSENSIBLES A LA CHALEUR. NE PAS UTILISER S’IL EST HUMIDE.
(Image for illustrative purpose only)
• Measure 60x62 cm (cod.LTK730)
• Measure 60x90 cm (cod.LTK740)
• Measure 150x100 cm (cod.LTK750)
• Power 100W (LTK730 - LTK740); 120W (LTK750) - Voltage 220-240V
• Material 100% poliester
10. TROUBLESHOOTING
ATTENTION!
If the electrical device does not work properly and it is defective, do not
attempt to repair it by yourself.
PROBLEM POSSIBLE CAUSE SOLUTION
The device
does not
work.
The device does not receive
the power source.
Verify if:
a. the power cable is connected
to the connecting socket;
b. the plug is insert in the socket;
c. the socket is defective;
d. the fuse of your mains
connection has been activated.
Any temperature level
has been selected.
The temperature selector
is in position 0.
Move the temperature
selector to position 1, 2 or 3.
The protection against
overheating has been activated.
Have the device checked
by the manufacturer.
MA LTK730_LTK740_LTK750 01 B_EN.indd 7 10/01/19 16:30
8
ENGLISH
11. WARRANTY
Every Moretti product is guaranteed for 2 (two) YEARS from the purchase date, except
the restrictions specified below. The warranty shall not apply in case of damage caused
by improper use, abuse, alterations of the product or any other use not in compliance with
the user manual.
The proper use of the product is indicated in the user manual. Moretti S.p.A. shall not be
liable for any damages or personal injuries due to incorrect assembly/improper use of the
device, not compliant with the user manual.
Moretti does not guarantee its products against damages or faults in the following
cases: natural disasters, non authorized maintenance or reparations, damages caused
by electrical supply problems (if provided), use of parts or components not provided by
Moretti, failure in accomplishing the guidelines and instructions for use, non authorized
alterations, damages due to the transport (different from Moretti original delivery) or
failure in maintaining the device as indicated in the manual.
The components subject to wear are not covered by this warranty if the damage is due to
the normal use of the product.
11.1 Exempt clauses
Except what clearly specified in this warranty and in accordance with the law, Moretti
S.p.A. does not offer its customers any other declaration, warranty or condition, expressed
or implicit, including any declaration, warranty or condition of merchantability, of non
violation or non interference, of suitability for a specific aim. Moretti S.p.A. does not
guarantee that the use of Moretti products will be continuous and faultless. The duration
of possible implicit warranties that may be applied in accordance with the law is limited
to the warranty period.
Some states or countries do not allow limitations to the duration of an implicit warranty,
or the exoneration, or the limitations of accidental or indirect damages related to
products for consumers. In such states or countries some exonerations or limitation of
this warranty may not be applied to the user. This warranty is subject to modifications
without any prior notice.
MA LTK730_LTK740_LTK750 01 B_EN.indd 8 10/01/19 16:30
9
ENGLISH
MORETTI S.P.A.
Via Bruxelles, 3 - Meleto 52022 Cavriglia (Arezzo) Tel. +39 055 96 21 11
www.morettispa.com email: info@morettispa.com
MADE IN P.R.C.
WARRANTY CERTIFICATE
Product _________________________________________________________________
Purchased on (date) ______________________________________________________
Retailer ________________________________________________________________
Address _______________________ Town/city ________________________________
Sold to __________________________________________________________________
Address __________________________ Town/city _____________________________
MA LTK730_LTK740_LTK750 01 B_EN.indd 9 10/01/19 16:30
10
ENGLISH
Notes
MA LTK730_LTK740_LTK750 01 B_EN.indd 10 10/01/19 16:30
11
ENGLISH
Notes
MA LTK730_LTK740_LTK750 01 B_EN.indd 11 10/01/19 16:30
MORETTI S.P.A.
Via Bruxelles, 3 - Meleto
52022 Cavriglia (Arezzo)
Tel. +39 055 96 21 11
Fax. +39 055 96 21 200
www.morettispa.com
info@morettispa.com
MA LTK730_LTK740_LTK750 01 B_EN.indd 12 10/01/19 16:30
This manual suits for next models
2
Table of contents
