KYE Systems Corp. SP-HF1800A User manual

ServiceGuide SP-HF1800A
Version : 1.0 Page 1 of 16
SERVICE GUIDE
KYE SYSTEMS CORP.
SP-HF1800A
Version : 1.0

ServiceGuide SP-HF1800A
Version : 1.0 Page 2 of 16
RevisionHistory
Version Date Change
1.0 7/16/2009

ServiceGuide SP-HF1800A
Version : 1.0 Page 3 of 16
Table of Contents
Revision History …………………………………………………………………….2
Table of Contents ……………………………………………………………………3
Getting Started ………………………………………………………………………4
Conventions Used in this Guide ……………………………………….4
Safety Precautions ……………………………………………………..4
Chapter 1. How to Handle Defective Returns……………………………………..5
1.1 Overview …………………………………………………………..5
1.2 Problems …………………………………………………………...6
1.2.1 One or more channels no sound ………………..…7
1.2.2 Power LED (indicator) no light………………....…8
1.2.3 Volume , Treble, Bass no function……..…………..8
Chapter 2. Specifications ………………………………………………..…………9
Chapter 3. Block Diagram ……………………………………………….……….10
Chapter 4. Exploded View ……………………………………………….……….11
Chapter 5. Part List …………………………………………………….…………13
Chapter 6. Schematic Diagram ……………………………………….………..14-15
Chapter 7. Important Notes …………………………………………….…………16
7.1 Packing Requirement for Sending the PCB Assembly by Post …...16
7.2 Short of Spare Parts while Repairing a Speaker System ……….…16

ServiceGuide SP-HF1800A
Version : 1.0 Page 4 of 16
Getting Started
Conventions Used in this Guide
Pay Special Attention : Instructions that are important to remember and
may prevent mistakes .
Caution : Information that, if not followed, may result in damage to the
product .
Safety Precautions
The following precautions should be observed in handling the speaker
Described in this guide :
Place the speakers on a flat, level and stable surface.
Do not place the speakers in environments subject to mist, smoke,
vibration, excessive dust, salty or greasy air, or other corrosive gases
and fumes.
Do not drop or jolt the speakers.
Do not allow anything to drop into the subwoofer case through its
ventilator, as it could result in fatal electric shock or fire .
Place the unit far enough from other equipments for good heat
dissipation .
Disconnect the AC power cord from the AC outlet before performing
any maintenance on the speakers .
Do not perform any maintenance with wet hand .
Prevent foreign substances, such as water, other liquids or chemicals ,
From entering the speakers while performing maintenance procedures
on the speakers .

ServiceGuide SP-HF1800A
Version : 1.0 Page 5 of 16
Chapter 1. How to Handle Defective Returns
1.1 Overview
Verifying problems
Proceeding necessary tests
Receiving Defective speakers form
Customers
Analyzing possible malfunction
causes
Deciding & proceeding the
rectification methods
Replace necessary defective parts
Proceeding tests to
Ver if
y
if the s
p
eaker is
functionin
g
normall
y
R
etu
rn
t
h
e
spea
k
e
r
s
w
i
t
h
p
r
ope
r
repackaging to customers
Function NG
Function OK
Function OK
Function NG

ServiceGuide SP-HF1800A
Version : 1.0 Page 6 of 16
1.2 Problems
Item Problem Description
1.2.1 Oneormorechannelsnosound
1.2.2 PowerLED(indicator)nolight
1.2.3 Volume,Treble,Bassnofunction

ServiceGuide SP-HF1800A
Version : 1.0 Page 7 of 16
Attention
1.2.1 One or more channels no sound
Problem
Solutions
Please follow the numbered sequence marked within parenthesis given in individual
Flow chat, in that this is the best-recommended sequence to rectify the problems .
One or more channels no sound
Broken or short circuit Defective IC50,
IC1, IC2, CON3,
CON5
Speaker cable
dis-connect or speaker
damaged
Check solder points on
PCB
Check and Replace
defective IC
Re-connect speaker
cable or replace
defective speaker(s)
Analyzer and
Identify the Causes

ServiceGuide SP-HF1800A
Version : 1.0 Page 8 of 16
1.2.2 Power LED (indicator) no light
Problem
Solutions
1.2.3 Volume , Treble , Bass no function
Problem
Solutions
Power LED (indicator) no light
Power switch or LED
Defective JK2,
Q101, R6, Z101,
CON4
AC cord of transformer
disconnected or
defective
Re-solder or replace
defective component(s)
Analyzer and
Identify the Causes
Volume, Treble, Bass no function
Broken or short circuit Defective VR1, VR2, VR3,
C13, C23, C14, C24, C15,
C25, R15, R25
Check solder points on PCB
Analyzer and
Identify the Causes
Check and Replace defective
components

ServiceGuide SP-HF1800A
Version : 1.0 Page 9 of 16
Chapter 2. Specifications
NO. Description Unit Specifications
1 Out Power at THD 10% W ≧25
2 Sensitivity mV 600 ±60
3 Freq. Response (Ref:-3dB) Hz 20Hz~20KHz ±10%
4 Separation dB ≧40
5 S/N ratio dB ≧70
6 Hum & Noise Vol:max mV ≦ 2

ServiceGuide SP-HF1800A
Version : 1.0 Page 10 of 16
Chapter 3. Block Diagram
AUDIO IN
Bass
Control
Power
Amplifier
R.CH Speaker
AC IN
L.CH Speaker
Treble
Control
Vo l u m e
Control
Transformer Filter

ServiceGuide SP-HF1800A
Version : 1.0 Page 11 of 16
Chapter 4. Exploded View
Host

ServiceGuide SP-HF1800A
Version : 1.0 Page 12 of 16
Satellite

ServiceGuide SP-HF1800A
Version : 1.0 Page 13 of 16
Chapter 5. Part List
No. DESCRIPTION Qty UNIT Part No.
1 SP-HF1800A/Body/Satellite 1 PC 30-101-01
2 Woofer Speaker, 4” 8 ohm 20W 2 PC E1049-45
3 Midrange Speaker, 4” 8 ohm 20W 2 PC E1049-44
4 Tweeter Speaker, 52mm 4 ohm 3W 2 PC E1049-43
5 Rubber pad (SP-HF1800A) 8 PC 30-100-01
6 SP-HF1800A/Body/Host-120V-US 30-101-02
7 SP-HF1800A/Body/Host-220V-AR 30-101-03
8 SP-HF1800A/Body/Host-230V-EU 30-101-04
9 SP-HF1800A/Body/Host-240V-AU 30-101-05
10 SP-HF1800A/Body/Host-240V-UK
1 PC
30-101-06
11 PCBA, SP-HF1800A 1 PC 30-101-07
12 IC, STA540SA 1 PC E1065-48
13 IC, (YW)UTC4558 2 PC 25-100-05
14 Transformer, 120V:15VAC & 2.5A E1074-148
15 Transformer, 230V:15VAC & 2.5A E1074-149
16 Transformer, 240V:15VAC & 2.5A
1 PC
E1074-150
17 Audio Cable, 3.5mm Male(Green) to RCA
(Red/White), SP-HF18000A
1 PC E1066-31
18 Gift Box, SP-HF1800A 1 PC 12000504100-A
19 Manual, SP-HF1800A 1 PC 12030420100-A
20 Cushion(Top/Bottom), SP-HF1800A 1 SET 30-102-01
21 S/N Label ( on Host & Gift Box ), SP-HF1800A 2 PC 30-102-02
22 Carton, SP-HF1800A 1/2 PC 12100393100-A

ServiceGuide SP-HF1800A
Version : 1.0 Page 14 of 16
Chapter 6. Schematic Diagram

ServiceGuide SP-HF1800A
Version : 1.0 Page 15 of 16

ServiceGuide SP-HF1800A
Version : 1.0 Page 16 of 16
Chapter 7. Important Notes
7.1 Packing Requirement for Sending the PCB Assembly by Post
PCB assembly is a kind of sophisticated electronic circuit board. Well
packing will be required when sending them by post.
* Some sophisticated IC components are mounted on the PCB assembly,
hence it is necessary to pack each PCB assembly with a separate static
protecting bag, in order to avoid static electricity.
* Reliable external packing is also very important when sending PCB
assembly by post, in that it would avoid unnecessarily lost or damage.
7.2 Short of Spare Parts while Repairing a Speaker System
If you are short of spare parts when you have some speaker systems waiting
to be repaired, it would be recommended to take the necessary parts form
one speaker system, so that you may have the as many speaker systems.
