KYLAND Technology PTS-10A User manual

PTS-10A
Time Server
Operation Manual
Kyland Technology (Shanghai) Co., Ltd.
Version Copyright
R7

Kyland Technology (Shanghai) Co., Ltd.
Room 802, Building 5, No.3000 Longdong Avenue
Pudong District, Shanghai, China
Tel: [phone]
Fax: [phone]

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
Contents
1. Basic Features ............................................................................................................ 2
1.1. Introduction................................................................................................. 2
2. LCD ............................................................................................................................. 3
2.1. Main Screen................................................................................................. 3
2.1.1. Time Infomation................................................................................... 3
2.1.2. Status Infomation ................................................................................. 3
2.2. Indicator Light and Keys .............................................................................. 3
2.3. Status Indication.......................................................................................... 4
2.3.1. Time Information ................................................................................. 4
2.3.2. PTP Information.................................................................................... 4
2.3.3. Source Information............................................................................... 5
2.3.4. Clock Information ................................................................................. 7
2.3.5. Position Information............................................................................. 8
2.3.6. Version Information.............................................................................. 8
3. Operations ................................................................................................................. 9
3.1. Settings ........................................................................................................ 9
3.1.1. Setting Options..................................................................................... 9
3.1.2. Setting Confirmation ............................................................................ 9
3.2. Source Settings .......................................................................................... 10
3.3. Clock Settings ............................................................................................ 12
3.4. NTP Settings............................................................................................... 13
3.5. PTP Settings ............................................................................................... 14
3.6. Output Settings.......................................................................................... 15
3.6.1. SO Output........................................................................................... 15
3.6.2. O1-O5 Output..................................................................................... 16
3.6.3. IRIG-B-AC Output................................................................................ 16
3.7. Network Settings ....................................................................................... 17
3.8. Default Settings ......................................................................................... 18
3.9. System Settings.......................................................................................... 18
Figure Index .................................................................................................................... 19
- 1 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
1. Basic Features
1.1. Introduction
[Figure 1-1] PTS-10A Time Server
The PTS-10A Time Server is a standard time server. It supports high precision
reference clock, which can be synchronized to absolute time such as GPS, BDS, and
GLONASS etc. Built-in TCXO, OCXO, Rubidium clock helps to provide stable reference
frequency source. System supports multiple sources time sync auto selection
algorithm which can perform stable switch between GPS, BDS, GLONASS, IRIG-B, PTP
and local clock, and sky/ground and master/slave clock backup. PTS-10A time server
provides flexible time output channels and signals. The output timing signals include
PPS, PPM, PPH, IRIG-B (Demodulated), IRIG-B (Modulated), Serial Time Signal (TOD
etc.) etc. Plus, PTS-10A supports network sync time protocols NTP/SNTP and PTP
(IEEE1588 v2). IEEE1588 can works in several modes by the software configuration
including grandmaster clock, slave clock and boundary clock. PTS-10A has LCD to show
any status and do configuration by keyboard. Meanwhile, PTS-10A is designed to send
timing source status and clock status to control center by IEC61850 MMS, IEC60870-
T104, DNP3.0, Modbus etc. PTS-10A also supports WEB and SNMP to manage system.
- 2 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
2. LCD
2.1. Main Screen
The default main screen is shown as below:
2014-01-01 09:00:00 M
GPS 08-OK-3D LOCK
[Figure 2-1] PTS-10A Main Screen
The screen has two line characters. The top line always shows the time information
and PTP clock information. The bottom line shows time server status including time
source status, clock status, position information and version information.
2.1.1. Time Infomation
It lies in the top line of screen. Time information includes time as the following format yyyy-mm-
dd hh:mm:ss and PTP clock information as M (Master), S (Slave) and B (Boundary).
2014-01-01 09:00:00 M
[Figure 2-2] PTS-10A Time Information
2.1.2. Status Infomation
Time server shows the current time source status, clock status, position information and version
information. The detail information please refers to section 2.3.
GPS 08-OK-3D LOCK
[Figure 2-3] PTS-10A Status Information
2.2. Indicator Light and Keys
Press any key of front panel to view information and change parameters.
Name Description
LEFT Show Information as left direction.
RIGHT Show information as right direction.
Enter Confirm operation.
ESC Cancel operation or Back to high level
- 3 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
Indicator light of front panel shows time server status.
Name Description
PSW On: Power On; Off: Power Off
SAT On: Satellite Number >=4; Off: Satellite Number <4
ANT On: Antenna is normal; Off: Antenna is abnormal
LOCK
Flash(1 second): Clock is locked;
Flash(3 seconds):Clock is holded;
Off: Clock is unlocked
NOTE: When screen backlight is off, press any key will ative screen again.
2.3. Status Indication
Time server will be shown as the following information.
All information screens can be shown by LEFT or RIGHT key at the main screen.
2.3.1. Time Information
The system time is shown at the first part of top line. This line is fixed.
The time format is YYYY-MM-DD HH:MM:SS.mmm.
2014-01-01 09:00:00 M
GPS 08-OK-3D LOCK
[Figure 2-4] System Time (LOCAL)
This is a local time display with local time zone.
The daylight saving time (DST) will show ‘*’ at the end of system reference time.
2014-01-01 09:00:00 * M
GPS 08-OK-3D LOCK
[Figure 2-5] System Time (DST)
2.3.2. PTP Information
The PTP clock status is shown at last part of top line. This line is fixed.
The PTS-10A might work in one of the following modes:
Master PTP Grandmaster Clock
Slave PTP Slave Clock
Boundary PTP Boundary Clock
2014-01-01 09:00:00 M
PTP 000-000-P2P LOCK
2014-01-01 09:00:00 S
PTP 000-000-P2P LOCK
- 4 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
2014-01-01 09:00:00 B
PTP 000-000-P2P LOCK
[Figure 2-6] PTP Information
2.3.3. Source Information
The time source status is shown at bottom line.
The display contents will be changed by LEFT or RIGHT key.
Use GPS as sync source, the display format is shown below:
GPS xx-xx-xx
xx (1st) The amount of locked GPS satellites at present.
xx (2nd) GPS antenna status. Following is the status introduction:
OK: antenna normal
UV: low antenna power supply voltage
NV: no antenna power supply voltage
OC: antenna over current
xx (3rd) GPS fix mode. Following is the mode introduction:
3D: The best fix mode.
2D: 2D fix mode. Not enough tracked satellites
HD: Hold over. Just lost the tracking to satellites, but time
accuracy should be OK.
No: No fix. No satellites are tracked.
2014-01-01 09:00:00 M
GPS 08-OK-3D LOCK
[Figure 2-7] Sync Source: GPS
Use BDS as sync source, the display format is shown below:
BDS xx-xx-xx
xx (1st) The amount of locked BDS satellites at present.
xx (2nd) BDS antenna status. Following is the status introduction:
OK: antenna normal
UV: low antenna power supply voltage
NV: no antenna power supply voltage
OC:antenna over current
xx (3rd) BDS fix mode. Following is the mode introduction:
3D: The best fix mode.
2D: 2D fix mode. Not enough tracked satellites
- 5 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
HD: Hold over. Just lost the tracking to satellites, but time
accuracy should be OK.
No: No fix. No satellites are tracked.
2014-01-01 09:00:00 M
BDS 08-OK-3D LOCK
[Figure 2-8] Sync Source: BDS
Use GLONASS as sync source, the display format is shown below:
GLN xx-xx-xx
xx (1st) The amount of locked GLONASS satellites at present.
xx (2nd) GLONASS antenna status. Following is the status introduction:
OK: antenna normal
UV: low antenna power supply voltage
NV: no antenna power supply voltage
OC:antenna over current
xx (3rd) GLONASS fix mode. Following is the mode introduction:
3D: The best fix mode.
2D: 2D fix mode. Not enough tracked satellites
HD: Hold over. Just lost the tracking to satellites, but time
accuracy should be OK.
No: No fix. No satellites are tracked.
2014-01-01 09:00:00 M
GLN 08-OK-3D LOCK
[Figure 2-9] Sync Source: GLONASS
Use IRIG-B as sync source, the display format is shown below:
IRIG-B xx-xx-xxx
xx (1st) IRIG-B input format. Following is the format introduction:
DC: IRIG-B Demodulated
AC: IRIG-B Modulated
xx (2nd) IRIG-B input interface. Following is the interface introduction:
FI1: IRIG-B input interface named FI1 on the rear panel.
FI2: IRIG-B input interface named FI2 on the rear panel.
xxx (3rd) The number of IRIG-B input frame from 0 to 999. It means
when count number over 999, it will start from 0 again.
2014-01-01 09:00:00 M
IRIG DC-FI1-255 LOCK
- 6 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
[Figure 2-10] Sync Source: IRIG-B-DC
Use PTP as sync source (i.e., the PTS-10A can work as PTP Slave Clock or Boundary
Clock), the display format is shown below:
PTP xxxx xxxxx xxx
xxxx(1st) PTP Offset value, the unit is ns.
The value range is between -999 to +999.
If out of this range, it will use ‘*’ instead.
xxxxx(2nd) PTP Delay Measurment value, the unit is ns.
The value range is between -9999 to +9999.
If out of this range, it will use ‘*’ instead.
xxx(3rd) PTP Mode, E2E or P2P
2014-01-01 09:00:00 S
PTP 000-000-P2P LOCK
[Figure 2-11] Sync Source (PTP-P2P-Slave)
2014-01-01 09:00:00 B
PTP 000-000-E2E LOCK
[Figure 2-12] Sync Source (PTP-E2E-Boundary)
2.3.4. Clock Information
For any kind of time reference source, the lastpart of line always shows clock status.
For seeking status, ‘SEEK’ is displayed; for initial status, ‘INIT’ is displayed; for sync
status, ‘SYNC’ is displayed; for lock status, ‘LOCK’ is displayed; for time adjust status,
‘RCRV’ is displayed; for hold status, ‘HOLD’ is displayed.
2014-01-01 09:00:00 M
LOCAL No Source SEEK
[Figure 2-13] Sync Lock Mode (SEEK)
2014-01-01 09:00:00 M
LOCAL No Source INIT
[Figure 2-14] Sync Lock Mode (INIT)
2014-01-01 09:00:00 M
GPS 08-OK-3D SYNC
[Figure 2-15] Sync Lock Mode (SYNC)
2014-01-01 09:00:00 M
GPS 08-OK-3D LOCK
[Figure 2-16] Sync Lock Mode (LOCK)
- 7 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
2014-01-01 09:00:00 M
GPS 08-OK-3D RCVR
[Figure 2-17] Time Setting Mode (RCVR)
2014-01-01 09:00:00 M
LOCAL No Source HOLD
[Figure 2-18] Hold Mode (HOLD)
2.3.5. Position Information
When get the satellite information from satellite source, system will show the position
information including longitude, latitude and height.
2014-01-01 09:00:00 M
Longitude: 0.0000000 E
[Figure 2-19] Longitude
2014-01-01 09:00:00 M
Latitude: 0.0000000 N
[Figure 2-20] Latitude
2014-01-01 09:00:00 M
Height: 0.000 M
[Figure 2-21] Height
2.3.6. Version Information
View the version information of software from screen. The version will show detailed
version information and compile date and time of software.
2014-01-01 09:00:00 M
VER: R7.40
[Figure 2-22] Version
2014-01-01 09:00:00 M
VER:Feb 22 2016 16:42:02
[Figure 2-23] Compile Date & Time
- 8 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
3. Operations
3.1. Settings
LCD screen might show data by ‘LEFT/RIGHT’ key. Press‘Enter’key on any screen might
enter setting screen to change setting. When change any options in the setting screen,
user can use the navigation button ‘LEFT’ and ‘RIGHT’ key to switch the settings page.
Press ‘Enter’ key to set parameters. According to screen tips, select or type the correct
settings.
3.1.1. Setting Options
On main screen, select ‘Enter’ key to enter to setting configuration screen.
SYN CLK NTP | DEF
PTP OUT NET | SYS
[Figure 3-1] Configuration Screen
Name Description Note
SYN Source settings
Set the external clock source including GPS, BDS, GLONASS,
IRIG-B, and PTP. Here we can set the priority of source, IRIG-B
time service and antenna time delay compensation, etc.
CLK Clock settings Set reference time as UTC or TAI time tag, time zone offset,
output modes and Daylight Saving Time(DST) etc.
NTP NTP settings Set NTP time service and offset between UTC and NTP.
PTP PTP settings Set PTP time service including work modes, sync time interval,
delay time interval, priority and vLAN etc.
OUT Output settings Set programmable output channel SO,O1~O5 including output
signal, time format, signal delay compensation, polarity, etc.
NET Network settings Set network IP address, subnet mask and operating modes.
DEF Default setting Load default parameter when need it.
SYS System setting System management including change password etc.
3.1.2. Setting Confirmation
Any modified settings should be accepted password confirm. If wrong password, the
new configuration will not work.
As the following steps to finish password confirm:
- 9 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
Password Check Screen
Use ‘LEFT/RIGHT’ key to select password, then press ‘Enter’key to confirm.
NOTE: The default password is 8.
Enter Password :
0123456789
[Figure 3-2] Enter Password Screen
Password Invalid Screen
Input wrong password, the following tips will be shown:
Failed! Password Invalid!
[Figure 3-3] Invalid Password Screen
Password Valid Screen
Input correct password, the following tips will be shown:
Password OK!
[Figure 3-4] Valid Password Screen
3.2. Source Settings
In main screen, press ‘SYNC’ button to modify sync source settings. Various sync
source settings are provided by the page switch buttons. There are totally 3 pages
available.
WORK-MODE
WORK-MODE: Single
[Figure 3-5] Source Setting: Page 1
Name Description
Parameter Note
WORK
MODE Working Mode Single /Multple
Single source enabled(only one good
external source can make clock
work)/multi-source enabled(compare
with multiple good time sources in
order to select best one as the
reference source)
SAT1-T SAT1-M SAT1-A
SAT1-T: UBLOX5
- 10 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
SAT2-T SAT2-M SAT2-A
SAT2-T: UBLOX5
[Figure 3-6] Source Setting: Page 2, 3
Name Description
Parameter Note
SAT1-T
SAT2-T SatelliteType
UBLOX5/UBLOX8/AT
3340/HWA210B/HW
A210L
Set satellite receiver model.
SAT1-M
SAT2-M SatelliteMode
Auto/A-BDS/A-
GPS/A-GLN/F-
BDS/F-GPS/F-GLN
Set satellite receiver working mode.
SAT1-A
SAT2-A
SatelliteAntenna
Compensation 0ns
According to different antenna types
and lengths, system implements time
delay compensation.
SAT1-P SAT1-P
SAT1-P: 1
B01-P B02-P PTP-P
B01-P : 1
[Figure 3-7] Source Setting: Page 4, 5
Name Description Parameter Note
SAT1-P SAT1 Priority
1~10
Set the priority for external signal
source. 1 is highest source and 10 is
lowest source.
SAT2-P SAT2 Priority
B01-P IRIG-B1 Priority
B02-P IRIG-B2 Priority
PTP-P PTP Priority
SAT1-W SAT2-W
SAT1-W: SYNC
B01-W B02-W PTP-W
B01-W : SYNC
[Figure 3-8] Source Setting: Page 6, 7
Name Description
Parameter Note
SAT1-W SAT1 Mode
SYNC/PEER/NONE
To set source working mode. SYNC is
individual sync source, PEER is
redundancy sync source and NONE is
anything to do.
SAT2-W SAT2 Mode
B01-W IRIG-B1 Mode
B02-W IRIG-B2 Mode
PTP-W PTP Mode
B1CHA B1FOR B1OFF
B1CHA: FI1
- 11 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
B2CHA B2FOR B2OFF
B2CHA: FI2
[Figure 3-9] Source Setting: Page 8, 9
Name Description
Parameter Note
B1CHA
B2CHA IRIG-B1/2 Input FI1/FI2 To set IRIG-B1/B2 input time signal.
B1FOR
B2FOR IRIG-B 1/2 F o r m a t DC+/DC-/MC/AC
To set IRIG-B1/B2 input format,
including DC+ (positive polarity
demodulated), DC-(negative polarity
demodulated), MC (Manchester) and
AC (modulated) IRIG-B signal.
B1OFF
B2OFF IRIG-B1/B2 UTC 0.00H Set time offset between IRIG-B and
UTC.
3.3. Clock Settings
USE OUT ZONE TAIOFF
USE: UTC
[Figure 3-10] Clock Setting: Page 1
Name Description Parameter Note
USE Use UTC UTC / TAI Set UTC time or TAI time as required.
OUT Output Mode Always/Lock
Always means time server always has
output signals in any time. Lock means
time server only has output signals after
timer server is locked by external time
source.
ZONE Time Zone 0.00H Set time zone offset to ensure required
time zone display.
TAIOFF TAI and UTC Offset 35s Set time zone offset between TAI and
UTC.
DSTOFF DSTMODE
DSTOFF: 0.00H
[Figure 3-11] Clock Setting: Page 2
Name Description Parameter Note
DSTOFF DST Offset 0.00H Set how many hours need to adjust at
DST period.
DSTMODE DST Mode UTC/LOCAL Set use which reference time to convert
DST time.
- 12 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
Start : 1
st
MON MAR 02:00
Start Index: 1
st
Stop : 1
st
MON MAR 02:00
Stop Index: 1
st
[Figure 3-12] Clock Setting: Page 3
Name Description
Parameter Note
Start DST
Index 1
st
/2
nd
/3
rd
/4
th
/5
th
/L
ast
Set start date of DST.
Weekday
MON/TUE/WEN/
THU
/FRI/SAT/SUN
Month
JAN/FEB/MAR/AP
R/MAY/JUN/JUL/A
UG/SEP/OCT/NOV
/DEC
Time 00:00~24:00
Stop DST
Index 1
st
/2
nd
/3
rd
/4
th
/5
th
/L
ast
Set start date of DST.
Weekday
MON/TUE/WEN/
THU
/FRI/SAT/SUN
Month
JAN/FEB/MAR/AP
R/MAY/JUN/JUL/A
UG/SEP/OCT/NOV
/DEC
Time 00:00~24:00
3.4. NTP Settings
NTP-S NTPOFF
NTP-S: Enable
[Figure 3-13] NTP Setting: Page 1
Name Description
Parameter Note
NTP-S NTP Server Enable/Disable Set NTP to enable time service.
NTPOFF NTP and UTC
Offset 0.00H Set time offset between NTP and UTC.
- 13 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
3.5. PTP Settings
MODE DELAY LOG-S LOG-D
MODE: Master
[Figure 3-14] PTP Setting: Page 1
Name Description
Parameter Note
MODE PTP Mode Master/Slave
/Boundary
Set PTP working mode.
PATH
Delay
Measurement
Mode
E2E / P2P / Disable Set clock delay measurement mode or
disable this function.
LOG-S Sync Interval -8~4 / Stop
Set the PTP sync message rate of PTP
master clock. Setting value is n, actual
interval is 2nseconds. Valid range is
from -8 to 4 and Stop. Default value is
Stop.
LOG-D
Delay
Measurement
Interval
-8~4 / Stop
Set delay measurement rate. Setting
value is n, actual interval is 2nseconds.
Valid range is from -8 to 4 and Stop.
Default value is Stop.
DOM1 DOM2 PRI1 PRI2
DOM1: 0
[Figure 3-15] PTP Setting: Page 2
Name Description
Parameter Note
DOM1/2 Domain1/2 0~3 Set the working domain name for PTP
message.
P R I 1/2 Priority1/2 0~255 Set working priority for PTP message.
MEDIA INDELAY OUTDELAY
MEDIA: 802.3
[Figure 3-16] PTP Setting: Page 3
Name Description Parameter Note
MEDIA Over Media 802.3 / IPv4 Set the transmission protocol for
PTP.IEEE802.3 and IPv4 are supported.
INDELAY Receive Delay 0ns Set the time delay for receiving PTP
message.
OUTDELAY Send Delay 0ns Set the time delay for sending PTP
message.
- 14 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
VLAN VLAN-P VLAN-CFI
VLAN: No
[Figure 3-17] PTP Setting: Page 4
Name Description Parameter Note
VLAN Enable Vlan Yes / No Set whether to send vLan information.
VLAN-P vLan Priority 0~7 Set vLan priority.
VLAN-CFI vLan CFI 0~1 Set vLan CFI information.
VLAN-ID MasterCoord
VLAN_ID: 0
[Figure 3-18] PTP Setting: Page 5
Name Description Parameter Note
VLAN-ID vLan ID 0~4095 Set vLan ID information.
MasterCoord Master
Coordination Yes,No Set PTP to enable master coordination.
3.6. Output Settings
SO O1 O2 O3 O4 O5 AC
[Figure 3-19] Output Setting
Name Description
SO Config serial output time signals.
O1 Config channel 1 output time signals.
O2 Config channel 2output time signals.
O3 Config channel 3 output time signals.
O4 Config channel 4 output time signals.
O5 Config channel 5 output time signals.
AC Config IRIG-B modulated time signals.
3.6.1. SO Output
PPS TXD TIME TYPE BAUD
PPS: PPS
[Figure 3-20] SO Output Setting: Page 1
Name Description Parameter Note
PPS SO-PPS signal PPS/IRIG/PPM/PPH Set the signal type for the SO-PPS.
TXD SO-TxD Signal TOD Set the signal type for SO-TxD.
TIME SO Time Format UTC / TAI / Local Set SO output time format which can be
- 15 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
set to UTC/TAI/Localtime.
TYPE SO Message RMC,ZDA,DL/T1100,
CM-TOD,CMBB
Set the coding format for serial port
message.
BAUD SOBaudRate 300~115200 Set the working baud rate for serial
port, ranging from 300 to 115200.
S-OFF PPS-OFF
S-OFF: 0s
[Figure 3-21] SO Output Setting: Page 2
Name Description Parameter Note
S-OFF SO Offset 0s Set SO second offset.
PPS-OFF SO-PPS Offset 0ns Set SO-PPS offset.
3.6.2. O1-O5 Output
O1 S-OFF PPS-OFF
O1: PPS
[Figure 3-22] O1~O5 Output Setting: Page 1
Name Description Parameter Note
O1~O5 O1~O5 time
signals PPS/IRIG/PPM/PPH Set the signal type for the O1~05. The
BDC means IRIG-B-DC signal.
S-OFF IRIG-B Offset 0s Set second offset for IRIG-B.
PPS-OFF IRIG-B PPS Offset 0ns Set PPS offset for PPS1~5.
IRIG-C IRIG-P IRIG-T
IRIG-C : Even
[Figure 3-23] O1~O5 Output Setting: Page 2
Name Description Parameter Note
IRIG-C IRIG-B Check Bit Even /Odd Set IRIG-B check code: even check, odd
check.
IRIG-P IRIG-B Polarity +/-Set IRIG-B output signal polarity.
IRIG-T IRIG-B Time UTC/TAI/Local Set IRIG-B output time format which
can be set to UTC/TAI/Localtime.
3.6.3. IRIG-B-AC Output
AC-PEAK AC-RATIO
AC-PEAK : 3.0V
[Figure 3-24] AC Output Setting: Page 1
Name Description Parameter Note
- 16 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
AC-PEAK IRIG-AC
Output P-P 3.OV~12.0V
Set the peak-to-peak value for IRIG-B-
AC, ranging from 3.0V to 12.0V,
adjusting step length is 0.5V, default
value is 12.0V.
AC-Ratio IRIG –AC
Output Ratio 3.0:1~6.0:1
Set the modulation ratio for IRIG-B-AC,
ranging from 3.0:1~6.0:1, adjusting step
length is 0.5:1; default value is 3.0:1.
3.7. Network Settings
IP0 MS0 MO0
IP0 :192.168.0.111
[Figure 3-25] Network Setting: Page 1
Name Description Parameter Note
IP0 IP Address 192.168.0.111 Set ETH0 IP address, the default is
192.168.0.111.
MS0 Mask Address 255.255.255.0 Set ETH0 Subnet mask address, the
default is 255.255.255.0.
MO0 Network Mode
Auto,
100M-FX FDX,
100M-FX-HDX,
1000M-X FDX,
1000M-X HDX
Set ETH0 mode.It can be set to fiber
mode with 100M and 1000M.
IP1 MS1 MO1
IP1 :192.168.1.111
[Figure 3-26] Network Setting: Page 2
Name Description Parameter Note
IP1 IP Address 192.168.1.111 Set ETH1 IP address, the default is
192.168.1.111.
MS1 Mask Address 255.255.255.0 Set ETH1 Subnet mask address, the
default is 255.255.255.0.
MO1 Network Mode
Auto,
100M-FX FDX,
100M-FX-HDX,
1000M-X FDX,
1000M-X HDX
Set ETH1 mode.It can be set to fiber
mode with 100M and 1000M.
IP2 MS2
IP1 :192.168.2.111
- 17 -

Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server
[Figure 3-27] Network Setting: Page 3
Name Description Parameter Note
IP2 IP Address 192.168.2.111 Set ETH2 IP address, the default is
192.168.2.111.
MS2 Mask Address 255.255.255.0 Set ETH2 Subnet mask address, the
default is 255.255.255.0.
IP3 MS3
IP1 :192.168.3.111
[Figure 3-28] Network Setting: Page 4
Name Description Parameter Note
IP3 IP Address 192.168.3.111 Set ETH3 IP address, the default is
192.168.3.111.
MS3 Mask Address 255.255.255.0 Set ETH3 Subnet mask address, the
default is 255.255.255.0.
3.8. Default Settings
Load default parameter via ‘DEF’ entrance.
SYN CLK NTP | DEF
PTP OUT NET | SYS
Load default parameters?
[Figure 3-29] Default Setting: Page 1
Press ‘ENTER key to confirm this operation and make system load default parameters.
3.9. System Settings
Change password via ‘SYS’ entrance.
SYN CLK NTP | DEF
PTP OUT NET | SYS
New Password: 0000
[Figure 3-30] System Setting: Page 1
Press ‘ENTER’ key to set new password and confirm password. If want to cancel this
operation, please press ‘ESC’ key to cancel this operation.
Notes: The password is made up of four digital.
- 18 -
