Kyocera ECOSYS FS-4000DN User manual

Up to 45 pages per minute
with 1,200 dpi
128 MB memory standard,
upgradeable to 640 MB
PDF direct printing from
USB Flash Memory devices
Eco-friendly, ozone-free
technology
Long-life components and
easy maintenance
Network connectivity and
powerful CPU as standard
Add up to 3 additional
paper cassettes to
upgrade input capacity
to 2,100 sheets.
Take the guess-work out
of how much toner is
left with an intelligent
toner level monitor.
Space to think at
High Speed
FS-4000DTN shown
FS-4000DN
This extremely fast new generation A4 printer allows
larger workgroups to increase productivity with ease
and accommodates additional memory for improved
performance with large print files. A space saving
internal duplex unit and network connectivity are
standard. Low noise, compact design and cost-effective
ECOSYS technology give you space to think faster than
the competition.
Print Copy Scan Fax Publish
POSITIONAL ONLY

General
Technology:
Kyocera ECOSYS, Laser
Engine speed:
Up to 45 pages per minute A4 simplex Up to 32.5 pages
per minute A4 duplex
Resolution:
Fine1200, Fast1200, 600x600, 300x300
Time to first page:
9 seconds or less
Warm-up time:
17 seconds or less from power on Duty cycle:
Max. 250,000 pages per month, max. average 30,000
pages per month
Power source:
AC 220 ~240 V, 50/60 Hz
Power consumption:
Printing: 510 W, Stand-by: 10 W,
Power-Saving (ECOpower): 5.5 W
Noise (ISO 7779):
Printing: 56 dB(A),
Stand-by: 40 dB(A),
Power-Saving (ECOpower): Immeasurably low
Dimensions (W x D x H):
Main unit: 382 x 394 x 320 mm
Weight: Main unit: Approx. 16.8 kg
Certifications:
TÜV/GS, CE, PTS
This product is manufactured according to ISO 9001
quality standard and ISO 14001 environmental standard.
Paper handling
All paper capacities quoted are based on a
paper thickness of max. 0.11 mm. Please use
paper recommended by Kyocera under normal
environmental conditions.
Input capacity:
500-sheet universal paper cassette, 60-120
g/m2, A4, A5, A6, B5, Letter, Legal, Custom (148
x 210 mm to 216 x 356 mm)
100-sheet multi-purpose tray, 60-220 g/m2,
A4, A5, A6, B5, Letter, Legal, Custom (70 x 148
mm to 216 x 356 mm) Max. input capacity with
optional paper feeder PF-315: 2,500 sheets
Duplex as standard supports A4, A5, B5, Letter,
Legal, 60-120 g/m2
Output capacity:
500 sheets face-down with paper full sensor and
optional 250 sheets face-up with PT-310
Controller
Processor:
PowerPC 750 / 500 MHz
Memory:
Standard 128 MB + ECOmemory, max. 640 MB
Emulations: PCL6/PCL5e incl. PJL, KPDL 3 (PostScript 3
compatible), PDF direct print, Line Printer,
IBM Proprinter X24E, Epson LQ-850, Diablo 630
Controller language:
PRESCRIBE IIe
Fonts:
80 outline fonts accessible in all emulations,
1 bitmap font, 45 types of one-dimensional barcodes
plus two-dimensional barcode PDF-417,
Downloadable fonts:
Kyocera, PCL + TrueType format, Type 1 + 3 format
Print features:
Duplex, Accounting, PDF direct printing, eMPS, low noise,
no Ozone, USB-Host
Interfaces
Standard interface:
High speed bi-directional parallel (IEEE 1284), USB 2.0
(Hi-Speed), Fast Ethernet 10Base-T/100Base-TX, USB Host
Interface dedicated for USB Flash Memory device, KUIO-
LV option interface slot
Multiple interface connection (MIC):
Allows simultaneous data transfer via up to four inter-
faces, with each interface having its own virtual printer.
Options
Paper handling
PF-310 Paper feeder (max. 3 units): 500 sheets, 60-120
g/m2, A4, A5, B5, Letter, Legal, Custom (148 x 210 mm
to 216 x 356 mm)
PT-310 Paper tray: 250 sheets face-up output tray
PF-315 Bulk paper feeder: 2,000 sheets (requires PB-
315), not to be combined with PF-310 or EF-310
PB-315 Printer base: For use with PF-315
EF-310 Envelope feeder: For max. 70 normal envelopes
or max. 100 air mail envelopes up to A6 size
Memory
Printer memory:
1 DDR SDRAM DIMM slot (64, 128, 256 or 512 MB)
Storage memory:
1 slot for either CompactFlash® memory card type 1
(up to 2 GB) for forms, fonts, logos, macro storage or
MicrodriveTM (up to 4 GB) for forms, fonts, logos, macro
storage as well as document management with eMPS
functions such as quick copy, proof and hold, private
print and job storage.
1 USB Host Interface (USB 1.1) for USB Flash Memory
device supports PDF direct printing
Optional interface
IB-21E Network card: 10Base-T/100Base-TX
IB-11 Serial interface: RS-232C serial interface
(max. 115.2 kbps)
IC159-WLAN: KUIO PORT 802.11b Wireless Lan Card
Consumables
TK-330 Toner-kit: Microfine toner for 20,000 pages with
5% coverage (ISO/IEC 19752)
Capacity of starter toner is 10,000 pages with 5% cover-
age (ISO/IEC 19752)
TK-310 Toner Kit (12,000 pages @ 5% A4 coverage) for
FS-2000D/FS-3900DN/FS-4000DN (ISO/IEC 19752)
TK-320 Toner Kit (15,000 pages @ 5% A4 coverage) for
FS-3900DN/FS-4000DN (ISO/IEC 19752)
TK-310 Yield based on usage in FS-2000D, TK-320 Yield
based on usage in FS-3900DN, TK-330 yield based on
usage in FS-4000DN
When Using toner based on usage from an alternative
machine yield may vary.
MK-320 Maintenance Kit: Due for installation at each
300,000 pages.
Warranty
Standard Warranty
2-year onsite warranty as standard.
Kyocera guarantees the drum and developer for 2 years
or 300,000 pages (whichever occurs sooner), provided
each printer is used , cleaned and maintained in
accordance with the service instructions.
Extended Warranty Options
ECO-FS-3003:
Optional Upgrade to 3rd year onsite
warranty
ECO-FS-3004:
Optional Upgrade to 4th year onsite
warranty
Model Configurations
FS-4000DN
FS-4000DTN (FS-4000DN + PF-310)
FS-4000DN A4 Monochrome Workgroup Laser Printer
Disclaimer
Kyocera does not warrant that any specifications mentioned will be error-free. Specifications are subject to change without notice. Information
is correct at time of going to print. All other brand and product names may be registered trademarks or trademarks of their respective holders
and are hereby acknowledged.
Australia Sales Enquiries
1300 364 429
Australia Web Address
www.kyoceramita.com.au
New Zealand Web Address
www.kyoceramita.co.nz
Sydney Head Office
6-10 Talavera Road
North Ryde NSW 2113
Phone: [phone]
Fax: [phone]
Melbourne Office
Unit 2, 993 North Road
Murrumbeena VIC 3163
Phone: [phone]
Fax: [phone]
Brisbane Office
Cnr Forbes St & Riverside Drive
West End QLD 4101
Phone: [phone]
Fax: [phone]
Perth Office
104 Walters Drive
Osborne Park WA 6017
Phone: [phone]
Fax: [phone]
Adelaide Office
53 Rundle Street,
Kent Town SA 5067
Phone: [phone]
Fax: [phone]
Canberra Office
Epicorp Centre
401 Clunies Ross Street
Acton ACT 2601
Phone: [phone]
Fax: [phone]
New Zealand Office
1-3 Parkhead Place
Albany New Zealand
Phone: [phone]
Fax: [phone]
ABN 77 003 852 444
Kyocera is the
Official Supporter of
Business Clean Up Day
A SMART
ENVIRONMENTAL
CHOICE
Protection of the environment
is integral to Kyocera’s
day-to-day operations. Research
over the last few decades has been
focused, not only
developing the most advanced
documentmanagementdevices,but
also doing so in harmony
with the environment.
ECOSYS devices are designed to minimise both direct costs
and indirect costs, such as maintenance, administration and
consumables. The cartridge-free system requires only the toner
to be replaced. The modular design concept allows you to add
workflow-enhancing functions and a wide variety of paper
handling capabilities as required. Integrated system software
provides long-term cross-network compatibility. Kyocera’s long-
life components cost you and the environment less.
System platform:
The FS-4000DN offers USB, parallel and network connectivity as
standard and delivers problem-free system administration. Kyocera’s
single platform technology means that the same driver can be used
for every Kyocera PCL/PostScript print device on the network; from
single-user desktop printers to high-end multifunctional systems. Only
Kyocera offers this effortless combination of IT sophistication and
high-performance paper handling expertise.
PRESCRIBE IIe:
With the Kyocera page design and control language PRESCRIBE IIe,
even complex graphics, logos and forms (even multipart forms) can
be created independently of the system and saved and updated in the
printer. Consequently, integration into print files no longer applies.
They are only accessed as required and therefore relieve the load on
the network.
KM-NET for Client/KM-NET Viewer:
The settings of all printers on the network can be checked visually
and amended from any Windows® PC. KM-NET for Client enables easy
setup and monitoring of the printer status via parallel, USB or network
connection. KM-NET Viewer is an advanced printer management
software tool using the standardized protocol SNMP.
In an effort to reduce future landfill pollution
Kyocera has removed 6 hazardous materials from
our latest products. Kyocera has implemented a
totally lead free manufacturing process using lead
free solder and components.
