Basic Manual

Preface
Thank you for buying the "GRATINA" (simply
called the "product" or "main unit" from here on).
Before using the product, be sure to read
"Basic Manual" (this manual) and "Setting
Guide" to ensure correct use.
List of Packaged Items
Before you start using the product, make sure
that you have all the following packaged items
with the product.
Main Unit
Battery Pack
(KYF36UAA)
•取扱説明書 (Basic Manual) (Japanese)
•設定ガイド (Setting Guide) (Japanese)
ii

The following items are not included in the
package.
•Desktop holder (KYF37PUA)
•microSD memory card
•AC adapter
•Earphone
•3.5 φ-microUSB conversion adapter 01
(0301QNA)
•microUSB cable
◎ Purchase a specified charger (sold separately).
◎ Illustrations of cell phones in this manual are only
for reference. They may look different from the
actual product.
Operating Instructions
■"Setting Guide" and "Basic
Manual" (This manual)
Handles only basic operations for main
features.
■“取扱説明書 詳細版”(Full Instruction
Manual)
For detailed descriptions of various functions,
refer to the “取扱説明書 詳細版（Full Instruction
Manual）” (Japanese) available on the au
homepage:
https://www.au.com/support/service/mobile/
guide/manual/
1

■GRATINA guide
You can check detailed explanations of this
product with images by the following operation.
Press l in the standby screen → [GRATINA
guide]
Illustrations and
Descriptions in This Manual
■Note on Key Illustrations
In this manual, the key illustrations are
simplified as shown below.
uo
jl
m,.
123
456
789
-0^
qaz
v
k
e
c
s f
Pressing e or c..............w
Pressing s or f..............x
Pressing e, c, s, f....d
2

■Description of Operations for
Selecting Item/Icon/Button, etc.
In this manual, step descriptions for selecting a
menu item/icon/on-screen button, etc. with w
or d and then pressing k (OK/Check/Set/
Commit/Done) are abbreviated as [Operation].
Example: To edit phone book contacts
1 When the standby screen is
displayed, press u → u (Menu) →
[Edit]
Indicates to select "Edit" with w and commit
with k.
◎ For details on key operation, refer to "Learn Basic
Key Operations" (▶P. 71).
■Notes on Illustrations/Screenshots
Screenshots and operation instructions in this
manual are based on the product with an au
Nano IC Card 04 LE is inserted.
The illustrations and screenshots in this
manual may look different from the actual
product or screens. Note that part of the
screen may be omitted.
Notations used in
this manual
Actual screen
In this manual, part of the
screen such as icons are
omitted.
◎ In this manual, keys, screenshots and icons are
described based on default settings of the product
with the body color "GREEN". However, actual keys,
screenshots and icons may differ or be partially
omitted .
3

◎ Contents at the bottom of the screen that can be
operated by pressing k/u/o/j/l are indicated
in parentheses, such as u (Menu).
* However, k (OK)/k (Check)/k (Set)/k (Commit)/k (Done)
are abbreviated as k only.
◎ Menu items, layers and icons described in this
manual may be different according to functions and
conditions to use.
◎ In this manual, "au Nano IC Card 04 LE" is
abbreviated as "au IC card".
◎ In this manual, "microSD™ memory card
(commercially available)" and "microSDHC™ memory
card (commercially available)" are abbreviated as
"microSD memory card" or "microSD".
◎ All of the indicated amounts exclude tax unless
otherwise specified.
◎
Company names and product names referred to in
this manual are trademarks or registered trademarks
of the respective companies. The TM, ® marks may
be omitted in this manual.
4
