Kzyee WiFi940Pro User manual

WiFi
Bluetooth
0.2s
MAX 256G
B
36MP
4K
WiFi Trail Camera
Model：WiFi940Pro
User Manual EN

-1-
!
TIPS:
Slide the battery latch to ON,
then remove the battery.
Step 1
EN
Slide the battery latch to ON ,
then insert the battery from
right to left and lay it flat.
Slide the battery latch to OFF to
lock the battery in place.
INSTALLATION
01
02

-2-
Step 2
Insert the SD card (not included) into the trail camera.
EN
Step 3
①Slide the mode switch
from OFF to TEST to activate
the camera and display the
user setting screen.
②then slide the mode switch from TEST to ON.
③The camera will begin to operate after a 10 -seconds
countdown, during which the red indicator light will flash

-3-
Step 5
Step 4
Scan the QR codes below or search for "WiFiCameraSum" in the
Appstore and "WiFiCamera" in Google Play to download the app.
EN
IOS Android
Open APP on your cell phone
and tap “Connect Bluetooth”
In the lower left corner
Select “GCBT40” and then tap “ ” to connect
your phone and camera via Bluetooth.
You can see the camera flashing yellow once and
then blue.
1
2

-4-
Step 6
However, you can also choose another
way to turn on WiFi
1. Slide the mode switch from OFF to TEST.
2. Press WiFi button tocontrol panel
Your WiFi turns on.
EN
Return to the main page of APP, then tap "Connect WiFi."
Go to WiFi settings on your phone, select "CAM
_XXXXXXXXXX" and enter password "12345678". (WiFi
name and password can be changed when connecting on
APP ).
3
1
2
3

Night
EN
Day
- 5 -
GETTING START


!
!
(;7(51$/ 32:(5 6833/<
8VH D 9 '& SRZHU VRXUFH QRW LQFOXGHG
(1
23(5$725¶6 %87721
0(18
0HQX %XWWRQ  0HQX 6HWWLQJ
:,),
:L)L %XWWRQ  212)) :L)L
9LGHR %XWWRQ  9LGHR 5HFRUGLQJ 0RGH
&DPHUD %XWWRQ  3KRWR0RGH
5HSOD\ %XWWRQ  5HSOD\0RGH
2. 2. %XWWRQ  2.  6WDUW(QG 9LGHR 5HFRUGLQJ RU 3KRWR7DNLQJ
7LSV φ2Q WKH SOD\EDFN SDJH VOLGH WKH  DQG  EXWWRQ WR VFUROO
3UHVV WKH 
2.  EXWWRQ WR H[LW WKH SOD\EDFN SDJH
!
!
Tips: On the playback page, slide the and button to scroll.
Press the "OK "button to exit the playback page.

-7-
EN
Setup Sub Menu Description
Mode Camera,video,camera
＆video,Time-lapse
Image,video,image
and video, regular
recording.
Resolution 4K,2K,1080P,720P,VGA Video Resolution
Video Length 5/10/30/60/90 Seconds Each Video max 90
secs, default 10 secs.
Record Audio On / Off Video With Sound
Image Size 36 / 24 / 20 / 16 / 12MP Image resolution
SETUP MENU

-8-
EN
Setup Sub Menu Description
Interval 1/10secs,1/3/5/10/15/30mins Max 30 minutes delay
Time-lapse 5/30minutes,
1/2/3/6/12/24hour Take pics every 5min
Sequence 1/3/6/9 pictures Max 9 pics one shot
ISO Auto/100/200/400 Exposure level
Over write On / Off Cycle Recording
PIR Sensitivity High/Medium/Low Adjust PIR sensitivity
Language UK/FR/ES/RU/POR/IT/DE Adjust PIR sensitivity
Frequency 50HZ / 60HZ Screen refresh rate
TV Mode NTSL , PAL Camera support AV-out
Camera ID CAM000 6 numbers or letters
Password On / Off 4 numbers
Working
Timer
00:00:00 to 23:59:59 N/L
Date / Time DD/MM/YY N/L
Format OK / Cancel Format memory card
Default Setting OK / Cancel Back to default
Version
Camera firmware version

-9-
Q: What is the range of WiFi and Bluetooth?
Q: Can you change the WiFi name and password of the camera?
Q: Can you connect to your in-home WiFi and the internet provided the camera
Q: Is the app available for the iPhone?
TROUBLE SHOOTING
A: The range of the WiFi camera is about 98 feet in a forest or indoors and
328 feet outdoors. The Bluetooth camera is between 16 and 26 feet.
EN
A: Yes, this camera can be powered by 12V DC. In the gift box there is a power
connector designed for external power supply.
There is a 10000mah lithium battery in the camera, which can be recharged
by external power supply.
A: Yes, you can change the WiFi name and your own password via app on the
phone.
A: WiFi trail camera connects with the phone's WiFi, not in-home
WiFi/Internet. Download the APP on your phone and then connect with WiFi.
You can adjust the setting and check the photo /video on the phone directly.
A: Yes, Trail Camera uses "WiFi Camera Sum" APP for Apple Store
and “WiFi Camera” APP for Google Play, it is available for Android
and IOS system phones.
Q: Can it be connected to the internal battery with 12V DC?
