L.A. Spas 2010 North American User manual

2010 North American
L.A. Spas
Entry-Level
Owner’s Manual

1
TABLE OF CONTENTS
WATER TREATMENT.....................................17
Sanitizers.........................................................17
Bromine ...........................................................17
Chlorine ...........................................................17
Super Chlorination...........................................17
Shock Treatments (Potassium
Peroxymonosulfate).........................................18
Water Testing ..................................................18
Stain and Scale Inhibitor..................................18
Foam Inhibitor..................................................18
Keeping Your Water Clean and Safe...............18
SPA CARE......................................................19
Filter Cleaning..................................................19
Care for Spa Surface.......................................19
Spa Cover........................................................19
Care of Spa Cabinet (ThermoGuard Cabinet) .19
Care for Spa Cover..........................................19
Draining the Spa..............................................20
Special Cold Weather Instructions
(Winterizing).....................................................20
Warranty Service Information ..........................20
TROUBLESHOOTING ....................................21
LETTER OF INTRODUCTION...........................2
SPA RECORD KEEPING INFORMATION........3
IMPORTANT SAFETY INSTRUCTIONS...........4
HYPERTHERMIA INFORMATION....................6
SAFETY PRECAUTIONS..................................6
SAFETY SIGN...................................................7
SPA CAUTIONS................................................7
SPA EQUIPPED SAFETY DEVICES ................8
IMPORTANT SAFETY INSTRUCTIONS FOR
CANADA ...........................................................9
INSTALLATION INSTRUCTIONS...................11
Surface and Pad Requirements.......................11
Electrical Installation Requirements.................11
Electrical Connection .......................................12
INITIAL START-UP INSTRUCTIONS..............13
OPERATING INSTRUCTIONS........................14
Control Panel ...................................................14
Control Panel Operation...................................14
Filtration...........................................................15
Program Modes................................................15
FEATURE OPERATIONS ...............................15
Air Control Valves ............................................15
WATER BALANCE .........................................16
Water Chemistry ..............................................16
Start-Up Procedures ........................................16
Water Quality ...................................................16
pH Control........................................................16
Total Alkalinity..................................................16

2
LETTER OF INTRODUCTION
Dear Valued Customer:
Congratulations. On behalf of the entire L.A. Spas family, thank you for your decision to purchase one
of our products.
Every effort has been made to ensure the accuracy of this owner’s manual, however, L.A. Spas
reserves the right to modify and improve the product without notice. This may create minor variations
between this manual and your spa. If you have any questions regarding your spa, or the owner’s
manual, please contact your authorized L.A. Spas dealer.
The following pages contain valuable and helpful information for the care and safe operation of your new
spa. Every effort has been made to insure optimum therapy and relaxation at minimal cost of operation,
delivering maximum value for you, your family, and your home.
Please take the time to read these instructions carefully. When the spa is properly installed and
maintained, your spa will provide years of enjoyable, trouble free operation.
We are confident that once you become familiar with the various options, maintenance features, and the
general operation of your new spa, you will be completely satisfied that you made the right decision in
purchasing an L.A. Spas product.
Sincerely yours,
L.A. Spas, Inc.

3
SPA RECORD KEEPING INFORMATION
Serial Number Location
The serial number is located in the lower right corner of the equipment access panel on the front of the
spa.
PLEASE FILL IN THE INFORMATION BELOW
Spa Information:
Model _______________ Color _______________ Serial #___________________
Owner Information:
Name _____________________________________ Date of Purchase ___________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Dealer Information:
Name ________________________________________________________________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Telephone # ___________________________________________________________
SAVE THIS INFORMATION FOR FUTURE REFERENCE
TO OFFICIALLY ACTIVATE YOUR WARRANTY, YOU MUST GO TO WWW.LASPAS.COM AND
REGISTER YOUR SPA BY CLICKING ON THE REGISTER YOUR SPA LINK UNDER THE
CUSTOMER CORNER TAB AND FILL OUT ALL THE INFORMATION

4
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ THE ENTIRE OWNER’S MANUAL & SAFETY INSTRUCTIONS BEFORE OPERATING THE
SPA. When installing the spa, basic safety precautions should always be followed, including the
following:
1. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are
closely supervised by an adult at all times.
2. WARNING: A grounding wire connector is provided on this unit to connect a minimum 8 AWG
(8.4mm2) solid copper conductor between this unit and any metal equipment, metal enclosure of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5 m) of the unit.
3. DANGER – RISK OF ACCIDENTAL DROWNING: Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot use this spa
unless they are closely supervised by an adult at all times.
4. DANGER – RISK OF INJURY: The suction fittings in this spa are sized to match the specific water
flow created by the pump. Should the need arise to replace the suction fittings or the pump, be
sure to replace with same model suction fittings for safety and compatible flow rates. NEVER
OPERATE THE SPA IF THE SUCTION FITTINGS ARE BROKEN OR MISSING. NEVER
REPLACE A SUCTION FITTING WITH ONE RATED LESS THAN THE FLOW RATE MARKED
ON THE ORIGINAL SUCTION FITTING.
5. DANGER – RISK OF INJURY: Do not remove suction grate. Suction through drains and skimmer
is powerful when the jets in the spa are in use. Damaged suction grate can be hazardous to
children and adults with long hair. Should any part of the body or hair be drawn into these fittings
or stuck onto the fittings, turn off the spa immediately. As a precaution, long hair should NOT be
allowed to float freely in the spa.
6. DANGER – RISK OF ELECTRIC SHOCK: Install the spa at least 5 feet (1.5 m) from all metal
surfaces. As an alternative, a spa maybe installed within 5 feet (1.5 m) of metal surfaces if, in
accordance with the National Electrical Code, each metal surface is permanently connected by a
minimum 8 AWG (8.4mm2) solid copper conductor to the wire connector on the terminal box that is
provided for this purpose.
7. DANGER – RISK OF ELECTRIC SHOCK: Do not permit any electric appliances such as light,
hair dryer, telephone, radio, or television with 5 feet (1.5 m) of the spa. Never operate any
electrical appliances from inside the spa or while wet.
8. DANGER: To reduce risk of injury:
a. The water in a spa should never exceed 104°F (40°C). Water temperatures between 100°F
(38°C) and 104°F (40°C) are considered safe for a healthy adult. Lower water temperatures are
recommended for young children and when spa use exceeds 10 minutes.
b. Since excessive water temperatures have a high potential for causing fetal damage during the
early months of pregnancy, pregnant women should limit spa water temperatures to 100°F
(38°C).

5
c. Before entering a spa, the user should check the water temperature with an accurate
thermometer since tolerance of water temperature regulating devices can vary and not reflect
the proper temperature.
d. The use of alcohol, drugs, or medication before or during spa use is prohibited and may lead to
unconsciousness with the possibility of drowning.
e. Obese persons and persons with a history of heart disease, low or high blood pressure,
circulatory system problems, or diabetes should consult a physician before using a spa.
f. Persons using medication should consult a physician before using a spa since some medication
may induce drowsiness while other medications may affect heart rate, blood pressure, and
circulation.
9. Do not use spa immediately after strenuous exercise.
10. Maintain water chemistry as recommended by your authorized dealer.
11. CAUTION – RISK OF ELECTRIC SHOCK: Replace components only with identical components.
12. WARNING – PREVENT ELECTROCUTION: Do not connect any auxiliary components such as
cable or lights to the system.
13. Do not service this product yourself as opening or removing covers may expose you to dangerous
voltage or other risk of injury. Refer all servicing to qualified service personnel from your local L.A.
Spas authorized dealer.
14. For more information on Spa safety you can visit www.APSP.org and go to their Safety section to
download free brochures.

6
HYPERTHERMIA INFORMATION
Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above
normal body temperature of 98.6°F (37°C).
The symptoms of hyperthermia include:
Dizziness
Fainting
Drowsiness
Lethargy
Increase in internal body temperature
The effects of hyperthermia include:
Unawareness of impending hazard
Failure to perceive heat
Failure to recognize the need to exit spa
Physical inability to exit spa
Fetal damage in pregnant women
Unconsciousness resulting in a danger of drowning
SAFETY PRECAUTIONS
a. Always enter and exit a spa slowly.
b. Do not use the spa alone.
c. Before entering the spa, always measure the water temperature with an accurate thermometer.
Tolerance of water temperature regulating devices can vary as much as ±5°F (3°C). Always check
the spa water temperature before entering.
d. Since excessive water temperature has a high potential for causing fetal damage during early
months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to
100°F (38°C). Always consult your doctor prior to using a spa.
e. Children’s body temperature can increase more rapidly than adults in the same water with elevated
temperatures above 99°F (37°C). Children should spend less time in water above body temperature
than adults.
f. The use of alcohol, drugs, and/or medication before or during spa use may lead to unconsciousness,
hypothermia, serious injury or the possibility of drowning.
g. Persons suffering from obesity or with a medical history of heart disease, diabetes, high or lower
blood pressure, or circulatory system problems should consult with their physician before using the
spa.
h. Persons on medication should consult with their physician before entering the spa since some
medication may induce drowsiness while other medication may affect heart rate, blood pressure, and
circulation.
i. People with infections, sores, or skin abrasions should not use the spa. Warm and hot water
temperatures may allow the growth of infectious bacteria if not properly disinfected.
j. Test the GFCI (Ground Fault Circuit Interrupter) unit before each use. (Refer to instructions provided
by GFCI manufacturer.)
k. Do not service or repair any equipment without making sure the circuit breaker and/or all power to
the spa is turned off.
l. Cover must be kept on the spa at all times when not in use and locked, especially if children are
present.

7
SAFETY SIGN
Each spa has been provided with a warning sign that outlines safety precautions. This sign should be
permanently placed in a location that is visible to all spa users. This sign has been mounted
permanently to the front of the spa. Replacement signs can be obtained from:
L.A. Spas, Inc.
1311 N. Blue Gum Street
Anaheim, CA 92806
SPA CAUTIONS
1. Persons suffering from heart disease, diabetes, high or low blood pressure, any condition requiring
medical treatment, pregnant women, the elderly, or infants should consult with a physician before
using a spa.
2. The Consumer Product Safety Commission has stated that the water temperature in a spa or hot
tub should not exceed 104°F (40°C). Immersion in water in excess of 104°F (40°C) can be
hazardous to your health.
3. Observe a reasonable time limit when using the spa. Long exposures at higher temperatures can
cause high body temperature. Symptoms may include dizziness, nausea, fainting, drowsiness, and
reduced awareness. These effects could result in possible drowning.
4. Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use of the spa under
these conditions may lead to serious consequences.
5. Always test the spa water temperature before entering the spa. Enter and exit the spa slowly. Wet
surfaces can be very slippery.
6. Never bring any electrical appliance into or near the spa. Never operate any electrical appliance
from inside the spa or when you are wet.
7. Proper chemical maintenance of spa water is necessary to maintain safe water and prevent
possible damage to spa components.
8. Use the spa straps and clip tie downs to secure the cover when not in use. This will help to
discourage unsupervised children from entering the spa and keep the spa cover secure in high
wind conditions. There is no representation that the cover, clip tie downs, or actual locks will
prevent access to the spa.

8
SPA EQUIPPED SAFETY DEVICES
Your spa is equipped with the following safety features:
1. Overheat Protection – A water temperature sensor circuit in the system will monitor the water
temperature. If the temperature reaches 112°F (44°C), the pump and all accessories will shut off.
The spa will resume normal operation when the water temperature drops to 109°F (42°C).
2. Heater High Limit Protection – If the water temperature reaches 119°F (48°C) as determined by
the water temperature sensor circuit, the pump and all accessories will shut off. The spa will
resume normal operation when the water temperature drops to 109°F (42°C) and a key press to
clear the fault.
3. Heater Dry Run Protection – The system will prevent the heater from turning on if it determines
that there is not enough water flow to operate the heater.
4. Freeze Protection Mode – The freeze protection system will activate at 44°F (6.6°C). The system
will turn on the low speed pump and heat to the set temperature. The spa will resume normal
operation upon reaching a temperature of 45°F (7.2°C).
5. Timeouts – The pump will turn off automatically after 30 minutes of continuous operation. The
light will turn off automatically after 4 hours of continuous operation.

9
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA
CSA SAFETY INFORMATION
READ AND FOLLOW ALL INSTRUCTIONS
When using this electrical equipment, basic safety precautions should always be followed, including the
following:
1. A colored terminal or a terminal marked G, GR, Ground, Grounding, or the grounding symbol is
located inside the supply terminal box/compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the electric supply service panel
with a continuous copper wire equivalent in size to the circuit conductors supplying this equipment.
2. A strip of lugs marked “BONDING LUGS” are provided on the external surface or on the inside of
the supply terminal box/compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the hot tub or spa to these terminals with an insulated or bare
copper conductor not smaller than 6 AWG.
3. All field installed metal components such as rails, ladders, drains, or other similar hardware within 3
meters of the spa or hot tub shall be bonded to the equipment grounding bus with copper
conductors not smaller than 6 AWG.
WARNING: Children should not use spas or hot tubs without adult supervision.
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION
SANS SURVEILLANCE.
WARNING: Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair
entrapment.
AVERTISSEMENT: POUR EVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS PUISSENT
ETRES ASPIRES, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DE PRISE
D’ASPIRATION NE SONT PAS TOUTES EN PLACE.
WARNING: People using medications and/or having adverse medical history should consult a
physician before using a spa or hot tub.
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MEDICAMENTS OU ONT DES
PROBLEMES DE SANTE DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE
DE RELAXATION.
WARNING: People with infectious diseases should not use a spa or hot tub.
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE DEVRAIENT
PAS UTILISER UNE CUVE DE RELAXATION.
WARNING: To avoid injury, exercise care when entering and exiting the spa or hot tub.
AVERTISSEMENT: POUR EVITER DES BLESSURES, USER DE PRUDENCE EN ENTRANT DANS
UNE CUVE DE RELAXATION ET EN SORTANT.
WARNING: Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid
unconsciousness and possible drowning.

10
AVERTISSEMENT: POUR EVITER L’EVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE
PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND
ON S’Y TROUVE.
WARNING: Pregnant or possibly pregnant women should consult a physician before using a spa or hot
tub.
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMEE OU
NON, DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE DE RELAXATION.
WARNING: Water temperature in excess of 100°F (38°C) maybe injurious to your health.
AVERTISSEMENT: IL PEUT ETRE DANGEREUX POUR LA SANTE DE LE PLONGER DANS DE
L’EAU A PLUS DE 38°C.
WARNING: Before entering the spa or hot tub, measure the water temperature with an accurate
thermometer.
AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE RELAXATION MESURER LA
TEMPERATURE DE L’EAU A L’AIDE D’UN THERMOMETRE PRECIS.
WARNING: Do not use a spa or hot tub immediately following strenuous exercise.
AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION IMMEDIATEMENT APRES UN
EXERCICE FATIGANT.
WARNING: Prolonged immersion in a spa or hot tub may be injurious to your health.
AVERTISSEMENT: L’UTILISATION PROLONGEE D’UNE CUVE DE RELAXATION PEUT ETRE
DANGEREUSE POUR LA SANTE.
WARNING: Do not permit electric appliances (light, telephone, radio, television, etc.) within 1.5m of this
spa or hot tub.
AVERTISSEMENT: NE PAS PLACER D’APPAREIL ELECTRIQUE (LUMINAIRE, TELEPHONE,
RADIO, TELEVISEUR, ETC.) A MOINS DE 1.5M DE CETTE CUVE DE RELAXATION.
CAUTION: Maintain water chemistry in accordance with manufacturer’s instructions.
ATTENTION: LA TENEUR DE L’EAU EN MATIERES DISSOUTES DOIT ETRE CONFORME AUX
DIRECTIVES DU FABRICANT.
WARNING: The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in spas or
hot tubs.
AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE
CONSIDERABLERMENT LES RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE
RELAXATION.

11
INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Read all instructions in this manual prior to having your spa installed at the selected location, whether
indoors or outdoors. IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID
THE WARRANTY.
SURFACE AND PAD REQUIREMENTS
1. We recommend that your new spa be placed on a 4” (10 cm) thick reinforced concrete pad or level
foundation capable of supporting the total filled weight of your specific spa model. The foundation
should support the entire base of the spa and must offer structural integrity for the life of the spa. A
typical spa, filled with water, could weigh as much as 3 tons, and if the concrete is not fully cured, it
could easily crack. AN UNEVEN OR UNSTABLE FOUNDATION OR THE USE OF SHIMS OF
ANY KIND MAY CAUSE THE SPA TO BUCKLE, DISTORT, AND/OR CRACK, AND WILL VOID
THE WARRANTY ON YOUR SPA.
2. If your spa is located near water sprinklers, adjust or cap them so the water will not hit the wood
cabinet of the spa.
3. Balconies and decks must be constructed to current state and local codes to safely support the
maximum load of your water filled spa and the number of people using the spa. Check with your
construction contractor for these safety specifications.
4. Access gates “fencing/wall” must be self-closing and self-locking. Check your local codes for
regulations regarding fences and gates.
5. Ensure that the spa installation and location allows a clear and unobstructed access to the spa. It
is the responsibility of the owner to provide clear access on all sides of the spa for service. Failure
to do so may result in additional charges or assessments to service and/or repair the spa.
6. Ensure that water drains away from the spa in order to keep water out of the equipment
compartment and away from all electrical components.
7. Assure accessibility is maintained to your spa should the need arise. Your spa is an appliance and
may require occasional service requirements. Assure the installation allows access to the
equipment area, side panels, and removal of the spa if possible. Construction or reconstruction
costs associated with spa removal or reinstallation are not covered by the warranty.
ELECTRICAL INSTALLATION REQUIREMENTS
IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID THE WARRANTY.
NOTE: Do not turn on electrical power to your spa until you are told to do so later in the Owner’s
Manual.
1. We strongly recommend that only a licensed and bonded electrician perform the electrical
installation. Improper electrical connections may damage the equipment, cause injury, cause a
fire, and void your spa warranty.

12
2. It is the responsibility of the spa owner to ensure that a qualified electrician performs the electrical
installation. This installation must be in accordance with the National Electrical Code; local and
state electrical codes; and the manufacturer’s instructions.
3. This equipment has been designed to operate on 240V/120V 60Hz alternating current.
4. This spa must be connected to a dedicated branch circuit.
5. The electrical supply for this spa must include a suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with Section 422-20 of the National Electric Code (NEC).
A disconnect switch must be located where visible, not less than 5 feet (1.5 m) from the spa and
not to exceed 50 (15 m) feet from the spa. This requirement maybe filled with the GFCI circuit
breaker and sub-panel.
6. The electrical circuit to the spa must include a Class A type Ground Fault Circuit Interrupter (GFCI)
as required by the NEC.
7. All supply wires must be copper and rated at a minimum of 167°F (75°C).
8. Input power wiring and circuit breaker selection:
IMPORTANT INFORMATION REGARDING ELECTRICAL INSTALLATION
Equipment Type Electrical Rating Branch Circuit Circuit Breaker
1
Wire Size
2
1 pump 120V
3
16A 2 wires + ground 20A 14 AWG
1 pump 240V 32A 3 wires + ground 40A 8 AWG
1. Circuit breaker amperages may vary according to the area of installation. Please check local electrical codes to verify
requirements and assure compliance.
2. The minimum wire size does not account for the distance of wire run to the spa from the service input.
3. Includes a 20A GFCI cord.
4. Only a licensed electrician should size and install the electrical connections to the spa.
ELECTRICAL CONNECTIONS
For 240V installation only: To hook up your spa, follow these instructions:
1. Remove the front center cabinet panel.
2. Loosen the 2 screws on the top front of the equipment control enclosure.
3. Use ¾” flexible conduit for 8 AWG copper wire. Run the conduit from the power source to the spa,
through the hole in the left or right front corner of the spa and into the equipment control pack.
4. After pulling all four wires through the conduit and into the equipment control box, connect them to
the proper terminals as indicated by the wiring diagram on the lid of the equipment control box.
Please note that the ground wire returns through a hole in the controller to the outside ground buss.
5. Close the lid on the equipment control box and tighten the screws.
6. Electrical hook up is now complete. Do not re-attach the front center cabinet panel yet.

13
INITIAL START-UP INSTRUCTIONS
DO NOT TURN ON THE POWER TO THE SPA WHEN THE SPA IS EMPTY OR PARTIALLY FILLED.
1. Ensure the circuit breaker to the spa is off.
2. Rotate all the jets in the spa to a counterclockwise position (fully open position).
3. Ensure the gate valve is fully open. Pull the “T” handle on the gate valve (located near the jet
pump) all the way up. When opened, there will be approximately 2” (5 cm) of metal rod visible.
4. Check the heater unions, pump unions, and pump plugs to assure that they are tight to prevent the
possibility of leakage in the equipment bay.
5. Close and cap the hose bib located in the equipment compartment. This is used for draining the
spa.
6. Fill the spa with water to a level of approximately 4” (10 cm) above the top of the filter. To prevent
the pumps being air locked, it is recommended to fill the water at the filter bucket area.
7. Turn on the circuit breaker. The control panel will go through some numbers, then Pr will be
displayed for about 4 minutes. Pr depicts priming mode. Press the Jets key twice to turn the
pump on high speed. Observe to ensure adequate water flow. Once the water is flowing smoothly,
press the Temp key to exit the priming mode. If there is no water flow through the jets, the pump
needs to be primed to eliminate air lock.
Pump Priming
•Turn off the power to the spa.
•Remove the handle from the jet selector valve supplied by the pump you are priming.
•Loosen the pump union on the suction side of the pump until some water starts gushing out of
the pump union.
•Tighten the pump union.
8. After the priming mode, the control panel will display two dashes --. The system will take about 2
minutes to register the water temperature. Set the desired temperature by pressing the Temp key.
Refer to the Control Panel Operation section for instructions on how to adjust the set temperature.
9. Re-attach the front center cabinet panel.
10. Depending upon the size of the spa and the size of the electrical circuit, heating will occur at a rate
of approximately 5°F (2°C) per hour.
11. After completing the above steps, it is necessary to ensure proper water chemistry. See the Water
Balance section in the manual.
12. Place the thermal cover on the spa to conserve energy and to keep it ready for use.

14
OPERATING INSTRUCTIONS
CONTROL PANEL
This easy to use control has been pre-programmed to be “plug and play”. Turn the power on, adjust the
desired temperature and the system is ready to go. If there are situations that require additional filtering
time, the filter settings can be customized to any special requirements. Simple to use and easy to read,
the Control System makes using the spa effortless.
CONTROL PANEL OPERATION
Please note: The pump has an automatic timeout (shut-off) programmed 30 minutes after the pump is
activated. The low speed pump will remain running if there is a call for heat, and will continue to do so
until the set temperature is reached.
1. Jets key:
When the Jets key is pressed the first time, the low speed of the jet pump is turned on. When the
Jets key is pressed the second time, the high speed of the jet pump is turned on. Pressing the
Jets key the third time will turn the pump off.
2. Light key:
Press the Light key once to turn the light on. Press the Light key a second time to turn off the
light.
3. Temp key:
Press the Temp key once to display the set temperature. To change the set temperature, press
the Temp key a second time before the display stops flashing. Each press of the Temp key will
continue to either increase or decrease the set temperature. If the opposite direction is desired,
allow the display to revert to the water temperature. Press the Temp key to display the set
temperature, and again to make the temperature change in the desired direction. After three
seconds, the display will stop flashing and begin to display the current water temperature. The
default temperature is programmed at 100°F (38°C).

15
FILTRATION
The spa is factory programmed to filter two times a day for 1 hour. In most cases, this is sufficient
filtration. However, the cycle duration can be modified between 1 and 8 hours in increments of 1 hour.
The first cycle begins 6 minutes after the initial start-up of the spa, and the second cycle is 12 hours
later. To change the filtration cycle duration, press the Temp key, then the Jets key. The display will
show the default setting, F1. Press the Temp key to adjust the duration. The sequence will repeat after
cycling through 1 to 8. Once the desired filtration cycle duration is displayed, press the Jets key to
accept the selection and exit the program.
PROGRAM MODES
Mode is changed by pressing the Temp key, then the Light key. The default setting is in Standard
mode. The spa is factory equipped with three program modes: Standard, Economy, and Sleep modes.
Standard mode maintains the set temperature. The equipment control pack checks the water
temperature twice per hour and heats accordingly. It will not allow the water temperature to reach below
20°F (10°C). St will be displayed momentarily when switched into Standard mode.
Economy mode heats the spa to the set temperature only during the filter cycles. Ec will be displayed
momentarily when switched into Economy mode. Ec will also be displayed when the water temperature
is not current, and will alternate with water temperature when the pump is running.
Sleep mode heats the spa to within 20°F (10°C) of the set temperature only during filter cycles. SL will
be displayed momentarily when switched into Sleep mode. SL will also be displayed when the water
temperature is not current, and will alternate with water temperature when the pump is running.
FEATURE OPERATIONS
AIR CONTROL VALVES
Your spa may be equipped with air controls. The air control is an on/off valve that allows air to be
introduced into a specific jet configuration resulting in a more vigorous jet action. Turn the valve handle
clockwise to turn the air on, and counterclockwise to turn the air off. Opening the valve increases jet
pressure and closing the valve decreases the jet pressure.

16
WATER BALANCE
WATER CHEMISTRY
Maintaining proper water chemistry is imperative to maintaining safe water and preventing possible
damage to your spa and spa components.
START-UP PROCEDURES
1. Fill spa to correct level (approximately 4” above the top of the filter cartridge).
2. With your cartridge filter, you may add stain and scale control, or a similar sequestering agent,
such as Metal Gone.
3. Test and adjust total alkalinity – run pump for ½ hour.
4. Test and adjust pH – run pump for ½ hour.
5. If sanitizing with bromine, add sodium bromide with jets running (see Bromine in this section).
a. Fill and set bromine floater or adjustable bromine feeder and place in the spa water.
b. Shock water with potassium peroxymonosulfate (such as “Renew”) with jets running.
6. If sanitizing with chlorine, use only a granular “Dichlor” compound (see Chlorine in this section).
a. Fill and set chlorine floater or chlorine feeder and place in the spa water.
b. Shock water with potassium peroxymonosulfate (such as “Renew”) with jets running.
7. Run pump for ½ hour.
WATER QUALITY
Your spa is equipped with a specially designed cartridge filter system. Filtering the water helps maintain
water cleanliness and clarity. While the filter traps most solid materials, it is still necessary to add a
sanitizer such as bromine or chlorine to the water in order to control bacteria, algae, and to oxidize any
organic materials in the water.
We recommend that you purchase your chemicals from your spa dealer. The dealer can also advise
you on alternative methods for water sanitation. Use of the wrong chemicals can be dangerous and
may void the warranty on your spa.
pH CONTROL
All water has a pH value determined by a scale of 0-14, which is a measure of the acid to alkaline
relationship. While a pH reading of 7.0 is considered neutral, a lower reading is considered acidic and a
higher reading is alkaline. The proper pH for spa water is between 7.2-7.6. High pH (above 7.8) can
reduce sanitizer efficiency, cloud the water, promote scale formation on spa surface and equipment and
interfere with filter operations. When pH is too high, add a pH down solution. Low pH (below 7.2) is
equally damaging and can cause equipment corrosion, water that is irritating, and rapid sanitizer
dissipation. Add pH increaser to adjust the level. Follow the chemical manufacturer’s directions and
procedures when adding chemicals to spa water.
NOTE: Always add pH adjuster with jets operating and circulate all chemicals for at least 30 minutes.
Remember that good pH control and sanitation are absolutely essential for proper spa water treatment.
TOTAL ALKALINITY
Total alkalinity is the amount of carbonate, bicarbonate, and hydroxyl ions in the water. Total alkalinity
affects and buffers the pH of the water. With high total alkalinity (above 160), pH resists adjustment.
With low total alkalinity (below 130), pH is unstable and difficult to keep in the ideal range. Proper total
alkalinity levels allow other spa chemicals to work effectively.

17
WATER TREATMENT
SANITIZERS
The importance of maintaining an adequate levels of sanitizer in your spa cannot be overemphasized.
Warm water presents a fertile environment for the growth of bacteria and viruses. This growth is
prevented when adequate sanitizer levels are continuously maintained.
WARNING – Sanitizers such as tri-chlor (tablets or sticks), calcium hypochlorite, sodium hypochlorite,
and any chemical that dissolves on or remains un-dissolved in contact with the spa surface will damage
your spa surface and will void the warranty completely.
BROMINE
Bromine is the most common sanitizer used in spas. Maintain a proper total bromine level of 3.0-5.0
ppm. If the reading is below the minimum, raise the level before using the spa. If the reading is above
5.0 ppm, allow ppm to drop to the proper range before using the spa. Brominating tablets are a
convenient and effective source of bromine for your spa. Do not drop bromine tablets directly into the
water as this may damage the spa surface. A chemical “floater” safely and properly dispenses the
tablets into the spa water. When used properly, brominating tablets will keep you water clean, clear,
and odor-free. To ensure maximum effectiveness, add ½ oz. of sodium bromide per 100 gallons of
water every time you fill your spa. This will establish a bromide reserve.
CHLORINE
Chlorine is a water sanitizer also; however it is more sensitive to pH than bromine. To be effective, you
must have a pH range of 7.2-7.6. Any reading outside this range will greatly reduce chlorine
effectiveness.
Use a chlorine test kit or test strip to maintain a reading of 2.0-3.0 ppm of free chlorine. If the reading is
below the minimum, raise the level before using the spa. If the reading is above 5.0 ppm, allow ppm to
drop to the proper range before using the spa. Read the instructions on your chlorine container
carefully, or consult your spa dealer if you are having difficulty adjusting your chlorine level.
The best chlorine for your spa is a granular “Dichlor” compound. It dissolves quickly in moving water
and has a nearly neutral pH. Add chlorine while jets are running and let the jets run for ½ hour.
Generally, heavily contaminated water can be disinfected using large chlorine doses, in the range of 8-
10 ppm, but a more practical method is to drain the spa and refill it with fresh water.
The effectiveness of chlorine is decreased when the cover is left off the water for two reasons: (1)
sunlight decays chlorine rapidly, and (2) organic debris is blown into the spa and taxes the effectiveness
of the chlorine. In addition, the higher the water temperature, the faster chlorine will decay.
NOTE: Two or more individuals in a spa may reduce the level of sanitizer rapidly.
SUPER CHLORINATION
Super chlorination quickly oxidizes the spa water to burn out wastes such as perspiration, hairspray,
lotions, etc. that cannot be removed by the spa filter. This waste build-up reduces the power of the
sanitizer, making the water dull and irritating to the eyes and skin. It may also produce an odor. When
this occurs, the free chlorines have become chloramines which are much less effective as a sanitizer.
This can be eliminated by super chlorination as needed. An application of 5 times the normal chlorine
dosage will act as an adequate treatment.

18
SHOCK TREATMENTS (POTASSIUM PEROXYMONOSULFATE)
Even with regular sanitization, shock treatment may be necessary on occasion. Shock is recommended
over super chlorination because it does not add additional sanitizer to the water. It is also effective in
oxidizing wastes and will reduce chloramines or bromamines. Follow the manufacturer’s instructions
listed on the label.
WATER TESTING
It is recommended that you test your spa water regularly with an accurate test kit or test strip. These are
available from your local authorized L.A. Spas dealer. Be sure to follow the chemical manufacturer’s
instructions for chemical use.
STAIN AND SCALE INHIBITOR
Staining and scaling may be a common problem in spas. Because the water is hot, scale may be
deposited more quickly. The circulation of water can cause the erosion of metals from spa equipment,
which can stain interior surfaces. A weekly dose of a stain and scale fighter will help control these
problems.
A sequestering agent, such as Metal Gone, can be added to the spa water when filling a spa (for the first
time or when draining and refilling). This will help eliminate metals in your water and increases the life of
your spa equipment.
FOAM INHIBITOR
Soap residue from a user’s body, hair, and swimsuit combined with rapid circulation of spa water may
cause foaming in your spa. Foam inhibitors will suppress foam, but cannot remove soap from the water.
When foaming occurs, a shock treatment can oxidize the soap in your water and help prevent this
condition. If foam remains a problem, change the water. Consult the directions on the foam inhibitor
container for usage amount. When adding chemicals to your spa water, add to the center of the spa
with the pump and air blower (if equipped) operating simultaneously. Never add chemicals directly into
the skimmer. Make sure the water is heated. Never add chemicals to cold water, as this will affect the
chemical reaction.
Store all chemicals in a cool dry location and in such a manner to prevent contact by children or pets.
You should consult your local authorized L.A. Spas dealer prior to any chemical use.
KEEPING YOUR WATER CLEAN AND SAFE
Monday Friday
Test: Bromine/Chlorine
pH
Total Alkalinity
Test: Bromine/Chlorine
pH
Total Alkalinity
Adjust: Follow steps 1-4 Adjust: Follow steps 1-3
Add: Stain & Scale control
Step 1: Adjust total alkalinity – ideal range is 130-160. Test water, follow directions on manufacturer’s
label, and add the required amount of spa chemicals with the jets on. Wait 30 minutes before
performing additional tests.
