L.A. Spas IN-FIT User manual

2011 North American
L.A. Spas
IN-FIT Swim Spa
Owner’s Manual

TABLE OF CONTENTS
WATER BALANCE.........................................20
Water Chemistry..............................................20
Start-Up Procedures........................................20
Water Quality...................................................20
pH Control........................................................20
Total Alkalinity..................................................20
WATER TREATMENT.....................................21
Sanitizers.........................................................21
Bromine ...........................................................21
Chlorine ...........................................................21
Super Chlorination...........................................21
Shock Treatments (Potassium
Peroxymonosulfate).........................................22
Water Testing ..................................................22
Stain and Scale Inhibitor..................................22
Foam Inhibitor..................................................22
Keeping Your Water Clean and Safe...............22
SPA CARE......................................................23
Filter Cleaning..................................................23
Care for Spa Surface.......................................23
Care for Spa Pillows ........................................23
Care of Spa Cabinet (ThermoPlus Cabinet) ....23
Care for Therm-Rite
TM
Spa Cover....................23
Draining the Spa..............................................24
Special Cold Weather Instructions
(Winterizing).....................................................24
Warranty Service Information ..........................24
TROUBLESHOOTING ....................................25
LETTER OF INTRODUCTION...........................2
SPA RECORD KEEPING INFORMATION........3
IMPORTANT SAFETY INSTRUCTIONS...........4
HYPERTHERMIA INFORMATION....................6
SAFETY PRECAUTIONS..................................6
SAFETY SIGN...................................................7
SPA CAUTIONS................................................7
SPA EQUIPPED SAFETY DEVICES ................8
IMPORTANT SAFETY INSTRUCTIONS FOR
CANADA ...........................................................9
INSTALLATION INSTRUCTIONS...................11
Surface and Pad Requirements.......................11
Electrical Installation Requirements.................11
Electrical Connection .......................................12
INITIAL START-UP INSTRUCTIONS..............13
OPERATING INSTRUCTIONS........................14
Control Panel ...................................................14
Control Panel Operation...................................14
Standard Mode.................................................15
Economy Mode................................................15
Sleep Mode......................................................15
Filtration System ..............................................15
Programming the Control System....................15
Standby Mode..................................................17
Control Panel Lock...........................................17
Temperature Lock............................................17
FEATURE OPERATIONS ...............................17
Jet Selector Valve (Diverter Valve) ..................17
Air Control Valves ............................................17
Water Features and Water Feature Control
Valve................................................................18
Stereo System..................................................18
1 rev. 2011-5-26

2 rev. 2011-5-26
LETTER OF INTRODUCTION
Dear Valued Customer:
Congratulations. On behalf of the entire L.A. Spas family, thank you for your decision to purchase one
of our products.
Every effort has been made to ensure the accuracy of this owner’s manual, however, L.A. Spas
reserves the right to modify and improve the product without notice. This may create minor variations
between this manual and your spa. If you have any questions regarding your spa, or the owner’s
manual, please contact your authorized L.A. Spas dealer.
The following pages contain valuable and helpful information for the care and safe operation of your new
spa. Every effort has been made to insure optimum therapy and relaxation at minimal cost of operation,
delivering maximum value for you, your family, and your home.
Please take the time to read these instructions carefully. When the spa is properly installed and
maintained, your spa will provide years of enjoyable, trouble free operation.
We are confident that once you become familiar with the various options, maintenance features, and the
general operation of your new spa, you will be completely satisfied that you made the right decision in
purchasing an L.A. Spas product.
Sincerely yours,
L.A. Spas, Inc.

3 rev. 2011-5-26
SPA RECORD KEEPING INFORMATION
Serial Number Location
The serial number is located in the lower right corner of the equipment access panel on the front of the
spa.
PLEASE FILL IN THE INFORMATION BELOW
Spa Information:
Model _______________ Color _______________ Serial #___________________
Owner Information:
Name _____________________________________ Date of Purchase ___________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Dealer Information:
Name ________________________________________________________________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Telephone # ___________________________________________________________
SAVE THIS INFORMATION FOR FUTURE REFERENCE
TO OFFICIALLY ACTIVATE YOUR WARRANTY, YOU MUST GO TO WWW.LASPAS.COM AND
REGISTER YOUR SPA BY CLICKING ON THE REGISTER YOUR SPA LINK UNDER THE
CUSTOMER CORNER TAB AND FILL OUT ALL THE INFORMATION

4 rev. 2011-5-26
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
READ THE ENTIRE OWNER’S MANUAL & SAFETY INSTRUCTIONS BEFORE OPERATING THE
SPA. When installing the spa, basic safety precautions should always be followed, including the
following:
1. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are
closely supervised by an adult at all times.
2. WARNING: A grounding wire connector is provided on this unit to connect a minimum 8 AWG
(8.4mm2) solid copper conductor between this unit and any metal equipment, metal enclosure of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5 m) of the unit.
3. DANGER – RISK OF ACCIDENTAL DROWNING: Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot use this spa
unless they are closely supervised by an adult at all times.
4. DANGER – RISK OF INJURY: The suction fittings in this spa are sized to match the specific water
flow created by the pump. Should the need arise to replace the suction fittings or the pump, be
sure to replace with same model suction fittings for safety and compatible flow rates. NEVER
OPERATE THE SPA IF THE SUCTION FITTINGS ARE BROKEN OR MISSING. NEVER
REPLACE A SUCTION FITTING WITH ONE RATED LESS THAN THE FLOW RATE MARKED
ON THE ORIGINAL SUCTION FITTING.
5. DANGER – RISK OF INJURY: Do not remove suction grate. Suction through drains and skimmer
is powerful when the jets in the spa are in use. Damaged suction grate can be hazardous to
children and adults with long hair. Should any part of the body or hair be drawn into these fittings
or stuck onto the fittings, turn off the spa immediately. As a precaution, long hair should NOT be
allowed to float freely in the spa.
6. DANGER – RISK OF ELECTRIC SHOCK: Install the spa at least 5 feet (1.5 m) from all metal
surfaces. As an alternative, a spa maybe installed within 5 feet (1.5 m) of metal surfaces if, in
accordance with the National Electrical Code, each metal surface is permanently connected by a
minimum 8 AWG (8.4mm2) solid copper conductor to the wire connector on the terminal box that is
provided for this purpose.
7. DANGER – RISK OF ELECTRIC SHOCK: Do not permit any electric appliances such as light,
hair dryer, telephone, radio, or television with 5 feet (1.5 m) of the spa. Never operate any
electrical appliances from inside the spa or while wet.
8. DANGER: To reduce risk of injury:
a. The water in a spa should never exceed 104°F (40°C). Water temperatures between 100°F
(38°C) and 104°F (40°C) are considered safe for a healthy adult. Lower water temperatures are
recommended for young children and when spa use exceeds 10 minutes.
b. Since excessive water temperatures have a high potential for causing fetal damage during the
early months of pregnancy, pregnant women should limit spa water temperatures to 100°F
(38°C).

5 rev. 2011-5-26
c. Before entering a spa, the user should check the water temperature with an accurate
thermometer since tolerance of water temperature regulating devices can vary and not reflect
the proper temperature.
d. The use of alcohol, drugs, or medication before or during spa use is prohibited and may lead to
unconsciousness with the possibility of drowning.
e. Obese persons and persons with a history of heart disease, low or high blood pressure,
circulatory system problems, or diabetes should consult a physician before using a spa.
f. Persons using medication should consult a physician before using a spa since some medication
may induce drowsiness while other medications may affect heart rate, blood pressure, and
circulation.
9. Do not use spa immediately after strenuous exercise.
10. Maintain water chemistry as recommended by your authorized dealer.
-For models equipped with audio/video system-
11. CAUTION – RISK OF ELECTRIC SHOCK: Do not leave stereo compartment door open.
12. CAUTION – RISK OF ELECTRIC SHOCK: Replace components only with identical components.
13. Do not operate the audio/video controls while inside the spa.
14. WARNING – PREVENT ELECTROCUTION: Do not connect any auxiliary components such as
cable, additional speakers, headphones, additional audio/video components, etc. to the system.
15. These units are not provided with an outdoor antenna. If provided, it should be installed in
accordance with Article 810 of the National Electrical Code.
16. Do not service this product yourself as opening or removing covers may expose you to dangerous
voltage or other risk of injury. Refer all servicing to qualified service personnel from your local L.A.
Spas authorized dealer.
17. When the power supply connections or power supply cord(s) are damaged; if water is entering the
audio/video compartment or any electrical equipment compartment area; if the protective shields or
barriers are showing signs of deterioration; or if there are signs of other potential damage to the
unit, turn off the unit and refer servicing to a qualified service person from your local L.A. Spas
authorized dealer.
18. The system should be subjected to periodic routine maintenance (for example, once every 3
months) to make sure that the system is operating properly.
19. For more information on spa safety you can visit www.APSP.org and go to their Safety section to
download free brochures.
SAVE THESE INSTRUCTIONS

6 rev. 2011-5-26
HYPERTHERMIA INFORMATION
Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above
normal body temperature of 98.6°F (37°C).
The symptoms of hyperthermia include:
Dizziness
Fainting
Drowsiness
Lethargy
Increase in internal body temperature
The effects of hyperthermia include:
Unawareness of impending hazard
Failure to perceive heat
Failure to recognize the need to exit spa
Physical inability to exit spa
Fetal damage in pregnant women
Unconsciousness resulting in a danger of drowning
WARNING – The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in hot tubs
and spas.
SAFETY PRECAUTIONS
a. Always enter and exit a spa slowly.
b. Do not use the spa alone.
c. Before entering the spa, always measure the water temperature with an accurate thermometer.
Tolerance of water temperature regulating devices can vary as much as ±5°F (3°C). Always check
the spa water temperature before entering.
d. Since excessive water temperature has a high potential for causing fetal damage during early
months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to
100°F (38°C). Always consult your doctor prior to using a spa.
e. Children’s body temperature can increase more rapidly than adults in the same water with elevated
temperatures above 99°F (37°C). Children should spend less time in water above body temperature
than adults.
f. The use of alcohol, drugs, and/or medication before or during spa use may lead to unconsciousness,
hypothermia, serious injury or the possibility of drowning.
g. Persons suffering from obesity or with a medical history of heart disease, diabetes, high or lower
blood pressure, or circulatory system problems should consult with their physician before using the
spa.
h. Persons on medication should consult with their physician before entering the spa since some
medication may induce drowsiness while other medication may affect heart rate, blood pressure, and
circulation.
i. People with infections, sores, or skin abrasions should not use the spa. Warm and hot water
temperatures may allow the growth of infectious bacteria if not properly disinfected.
j. Test the GFCI (Ground Fault Circuit Interrupter) unit before each use. (Refer to instructions provided
by GFCI manufacturer.)
k. Do not service or repair any equipment without making sure the circuit breaker and/or all power to
the spa is turned off.
l. Cover must be kept on the spa at all times when not in use and locked, especially if children are
present.

7 rev. 2011-5-26
SAFETY SIGN
Each spa has been provided with a warning sign that outlines safety precautions. This sign should be
permanently placed in a location that is visible to all spa users. This sign has been mounted
permanently to the front of the spa. Replacement signs can be obtained from:
L.A. Spas, Inc.
1311 N. Blue Gum Street
Anaheim, CA 92806
SPA CAUTIONS
1. Persons suffering from heart disease, diabetes, high or low blood pressure, any condition requiring
medical treatment, pregnant women, the elderly, or infants should consult with a physician before
using a spa.
2. The Consumer Product Safety Commission has stated that the water temperature in a spa or hot
tub should not exceed 104°F (40°C). Immersion in water in excess of 104°F (40°C) can be
hazardous to your health.
3. Observe a reasonable time limit when using the spa. Long exposures at higher temperatures can
cause high body temperature. Symptoms may include dizziness, nausea, fainting, drowsiness, and
reduced awareness. These effects could result in possible drowning.
4. Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use of the spa under
these conditions may lead to serious consequences.
5. Always test the spa water temperature before entering the spa. Enter and exit the spa slowly. Wet
surfaces can be very slippery.
6. Never bring any electrical appliance into or near the spa. Never operate any electrical appliance
from inside the spa or when you are wet.
7. Proper chemical maintenance of spa water is necessary to maintain safe water and prevent
possible damage to spa components.
8. Use the spa straps and clip tie downs to secure the cover when not in use. This will help to
discourage unsupervised children from entering the spa and keep the spa cover secure in high
wind conditions. There is no representation that the cover, clip tie downs, or actual locks will
prevent access to the spa.

8 rev. 2011-5-26
SPA EQUIPPED SAFETY DEVICES
Your spa is equipped with the following safety features:
1. Overheat Protection – A water temperature sensor circuit in the system will monitor the water
temperature. If the temperature reaches 112°F (44°C), the pump and all accessories will shut off.
The spa will resume normal operation when the water temperature drops to 109°F (42°C).
2. Heater High Limit Protection – If the water temperature reaches 119°F (48°C) as determined by
the water temperature sensor circuit, the pump and all accessories will shut off. The spa will
resume normal operation when the water temperature drops to 109°F (42°C) and a key press to
clear the fault.
3. Heater Dry Run Protection – The system will prevent the heater from turning on if it determines
that there is not enough water flow to operate the heater.
4. Freeze Protection Mode – The freeze protection system will activate at 44°F (6.6°C). The system
will turn on the low speed pump and heat to the set temperature. The spa will resume normal
operation upon reaching a temperature of 45°F (7.2°C).
5. Timeouts – The pump will turn off automatically after 40 minutes of continuous operation. The
lights will turn off automatically after 1 hour of continuous operation.

9 rev. 2011-5-26
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA
SAFETY INFORMATION
READ AND FOLLOW ALL INSTRUCTIONS
When using this electrical equipment, basic safety precautions should always be followed, including the
following:
1. A colored terminal or a terminal marked G, GR, Ground, Grounding, or the grounding symbol is
located inside the supply terminal box/compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the electric supply service panel
with a continuous copper wire equivalent in size to the circuit conductors supplying this equipment.
2. A strip of lugs marked “BONDING LUGS” are provided on the external surface or on the inside of
the supply terminal box/compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the hot tub or spa to these terminals with an insulated or bare
copper conductor not smaller than 6 AWG.
3. All field installed metal components such as rails, ladders, drains, or other similar hardware within 3
meters of the spa or hot tub shall be bonded to the equipment grounding bus with copper
conductors not smaller than 6 AWG.
WARNING: Children should not use spas or hot tubs without adult supervision.
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION
SANS SURVEILLANCE.
WARNING: Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair
entrapment.
AVERTISSEMENT: POUR EVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS PUISSENT
ETRES ASPIRES, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DE PRISE
D’ASPIRATION NE SONT PAS TOUTES EN PLACE.
WARNING: People using medications and/or having adverse medical history should consult a
physician before using a spa or hot tub.
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MEDICAMENTS OU ONT DES
PROBLEMES DE SANTE DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE
DE RELAXATION.
WARNING: People with infectious diseases should not use a spa or hot tub.
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE DEVRAIENT
PAS UTILISER UNE CUVE DE RELAXATION.
WARNING: To avoid injury, exercise care when entering and exiting the spa or hot tub.
AVERTISSEMENT: POUR EVITER DES BLESSURES, USER DE PRUDENCE EN ENTRANT DANS
UNE CUVE DE RELAXATION ET EN SORTANT.

10 rev. 2011-5-26
WARNING: Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid
unconsciousness and possible drowning.
AVERTISSEMENT: POUR EVITER L’EVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE
PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND
ON S’Y TROUVE.
WARNING: Pregnant or possibly pregnant women should consult a physician before using a spa or hot
tub.
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMEE OU
NON, DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE DE RELAXATION.
WARNING: Water temperature in excess of 100°F (38°C) maybe injurious to your health.
AVERTISSEMENT: IL PEUT ETRE DANGEREUX POUR LA SANTE DE LE PLONGER DANS DE
L’EAU A PLUS DE 38°C.
WARNING: Before entering the spa or hot tub, measure the water temperature with an accurate
thermometer.
AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE RELAXATION MESURER LA
TEMPERATURE DE L’EAU A L’AIDE D’UN THERMOMETRE PRECIS.
WARNING: Do not use a spa or hot tub immediately following strenuous exercise.
AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION IMMEDIATEMENT APRES UN
EXERCICE FATIGANT.
WARNING: Prolonged immersion in a spa or hot tub may be injurious to your health.
AVERTISSEMENT: L’UTILISATION PROLONGEE D’UNE CUVE DE RELAXATION PEUT ETRE
DANGEREUSE POUR LA SANTE.
WARNING: Do not permit electric appliances (light, telephone, radio, television, etc.) within 1.5m of this
spa or hot tub.
AVERTISSEMENT: NE PAS PLACER D’APPAREIL ELECTRIQUE (LUMINAIRE, TELEPHONE,
RADIO, TELEVISEUR, ETC.) A MOINS DE 1.5M DE CETTE CUVE DE RELAXATION.
CAUTION: Maintain water chemistry in accordance with manufacturer’s instructions.
ATTENTION: LA TENEUR DE L’EAU EN MATIERES DISSOUTES DOIT ETRE CONFORME AUX
DIRECTIVES DU FABRICANT.
WARNING: The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in spas or
hot tubs.
AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE
CONSIDERABLERMENT LES RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE
RELAXATION.
SAVE THESE INSTRUCTIONS

11 rev. 2011-5-26
INSTALLATION INSTRUCTIONS
Read all instructions in this manual prior to having your spa installed at the selected location, whether
indoors or outdoors. IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID
THE WARRANTY.
SURFACE AND PAD REQUIREMENTS
1. We recommend that your new spa be placed on a 6” (15 cm) thick reinforced concrete pad or level
foundation capable of supporting the total filled weight of your specific spa model. The foundation
should support the entire base of the spa and must offer structural integrity for the life of the spa. A
typical swim spa, filled with water, could weigh as much as 8 tons, and if the concrete is not fully
cured, it could easily crack. AN UNEVEN OR UNSTABLE FOUNDATION OR THE USE OF
SHIMS OF ANY KIND MAY CAUSE THE SPA TO BUCKLE, DISTORT, AND/OR CRACK, AND
WILL VOID THE WARRANTY ON YOUR SPA.
2. If your spa is located near water sprinklers, adjust or cap them so the water will not hit the wood
cabinet of the spa.
3. Access gates “fencing/wall” must be self-closing and self-locking. Check your local codes for
regulations regarding fences and gates.
4. Ensure that the spa installation and location allows a clear and unobstructed access to the spa. It
is the responsibility of the owner to provide clear access on all sides of the spa for service. Failure
to do so may result in additional charges or assessments to service and/or repair the spa.
5. Ensure that water drains away from the spa in order to keep water out of the equipment
compartment and away from all electrical components.
6. Assure accessibility is maintained to your spa should the need arise. Your spa is an appliance and
may require occasional service requirements. Assure the installation allows access to the
equipment area, side panels, and removal of the spa if possible. Construction or reconstruction
costs associated with spa removal or reinstallation are not covered by the warranty.
ELECTRICAL INSTALLATION REQUIREMENTS
IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID THE WARRANTY.
NOTE: Do not turn on electrical power to your spa until you are told to do so later in the Owner’s
Manual.
1. We strongly recommend that only a licensed and bonded electrician perform the electrical
installation. Improper electrical connections may damage the equipment, cause injury, cause a
fire, and void your spa warranty.
2. It is the responsibility of the spa owner to ensure that a qualified electrician performs the electrical
installation. This installation must be in accordance with the National Electrical Code; local and
state electrical codes; and the manufacturer’s instructions.
3. This equipment has been designed to operate on 240V 60Hz alternating current.

12 rev. 2011-5-26
4. This spa must be connected to a dedicated branch circuit.
5. The electrical supply for this spa must include a suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with Section 422-20 of the National Electric Code (NEC).
A disconnect switch must be located where visible, not less than 5 feet (1.5 m) from the spa and
not to exceed 50 (15 m) feet from the spa. This requirement maybe filled with the GFCI circuit
breaker and sub-panel.
6. For spa use in other than single-family dwellings, a clearly labeled emergency switch shall be
provided as part of the installation. The switch shall be readily accessible to the occupants and
shall be installed at least 5 feet (1.5m) away, adjacent to, and within sight of the spa.
7. The electrical circuit to the spa must include a Class A type Ground Fault Circuit Interrupter (GFCI)
as required by the NEC.
8. All supply wires must be copper and rated at a minimum of 167°F (75°C).
9. Input power wiring and circuit breaker selection:
IMPORTANT INFORMATION REGARDING ELECTRICAL INSTALLATION
Equipment Type Electrical Rating Branch Circuit Circuit Breaker
1
Wire Size
2
5 pumps 240V 48A 3 wires + ground 60A 6 AWG
5 pumps with
optional heater 240V 48A + 240V 24A33 wires + ground 3 wires + ground360A + 30A36 AWG + 10 AWG3
1. Circuit breaker amperages may vary according to the area of installation. Please check local electrical codes to verify
requirements and assure compliance.
2. The minimum wire size does not account for the distance of wire run to the spa from the service input.
3. Additional 240V 30A electrical service is required for spas with the optional heater.
4. Only a licensed electrician should size and install the electrical connections to the spa.
ELECTRICAL CONNECTIONS
To hook up your spa, follow these instructions:
1. Remove the front cabinet panel.
2. Loosen the 2 screws on the top front of the equipment control enclosure.
3. Use ¾” flexible non-metallic conduit for 10 AWG copper wire and 1” flexible non-metallic conduit
for 6 AWG copper wire. Run the conduit from the power source to the spa, through the hole in the
left or right front corner of the spa and into the equipment control pack.
4. After pulling all four wires through the conduit and into the equipment control box, connect them to
the proper terminals as indicated by the wiring diagram on the lid of the equipment control box.
Please note that the ground wire returns through a hole in the controller to the outside ground buss.
5. Close the lid on the equipment control box and tighten the screws.
6. Electrical hook up is now complete. Do not re-attach the front cabinet panel yet.

13 rev. 2011-5-26
INITIAL START-UP INSTRUCTIONS
DO NOT TURN ON THE POWER TO THE SPA WHEN THE SPA IS EMPTY OR PARTIALLY FILLED.
1. Ensure the circuit breaker to the spa is off.
2. Rotate all the jets in the spa to a counterclockwise position (fully open position).
3. Ensure the gate valve is open fully. Pull the “T” handle on the gate valve (located near the jet
pump) all the way up. When opened, there will be approximately 2” (5 cm) of metal rod visible.
4. Check the heater unions, pump unions, and pump plugs to assure that they are tight to prevent the
possibility of leakage in the equipment bay.
5. Close and cap the hose bib located in the equipment compartment. This is used for draining the
spa.
6. Fill the spa with water to a level of approximately 6” (15 cm) below the top of the spa. To prevent
the pumps being air locked, it is recommended to fill the water at the filter bucket area.
7. Turn on the circuit breaker. The control panel will go through some numbers, then Pr will be
displayed for about 4 minutes. Pr depicts priming mode. Turn on the pumps one at a time to
ensure adequate water flow. Once the water is flowing smoothly, press the Warm or Cool key to
exit the priming mode. If there is no water flow through the jets, the pumps need to be primed to
eliminate air lock.
Pump Priming
•Turn off the power to the spa.
•Remove the handle from the jet selector valve supplied by the pump you are priming.
•Loosen the pump union on the suction side of the pump until some water starts gushing out of
the pump union.
•Tighten the pump union.
8. After the priming mode, the control panel will display two dashes --. The system will take about 2
minutes to register the water temperature. Set the desired temperature by pressing the Warm or
Cool key.
9. Re-attach the front cabinet panel.
10. Due to the size of the swim spa, heating will occur at a rate of approximately 0.5°F (0.3°C) per
hour. For spas equipped with an additional optional heater, heating will occur at a rate of
approximately 1°F (0.6°C) per hour.
11. After completing the above steps, it is necessary to ensure proper water chemistry. See the Water
Balance section in the manual.
12. Place the thermal cover on the spa to conserve energy and to keep it ready for use.

OPERATING INSTRUCTIONS
CONTROL PANEL
ML900 Main Control Panel
ML400 Auxiliary Control Panel
These easy to use controls have been pre-programmed to be “plug and play”. Turn the power on, adjust
the desired temperature and the system is ready to go. If there are situations that require additional
filtering time, the filter settings can be customized to any special requirements. Simple to use and easy
to read, the Control System makes using the spa effortless.
CONTROL PANEL OPERATION
Please note: The pumps have an automatic timeout (shut-off) programmed 40 minutes after the pump
is activated. The low speed spa pump will remain running if there is a call for heat, and will continue to
do so until the set temperature is reached.
1. Swim 1 key:
Swim 1 key is associated with the lower swim jet. Press the Swim 1 key once to turn on the swim
pump #1. Press the Swim 1 key again to turn off the pump.
2. Swim 2 key:
Swim 2 key is associated with the upper right swim jet. Press the Swim 2 key once to turn the
swim pump #2 on low speed. Press the Swim 2 key a second time to turn the swim pump #2 on
high speed. Press the Swim 3 key the third time to turn off the pump.
3. Swim 3 key:
Swim 3 key is associated with the upper left swim jet. Press the Swim 3 key once to turn the swim
pump #3 on low speed. Press the Swim 3 key a second time to turn the swim pump #3 on high
speed. Press the Swim 3 key the third time to turn off the pump.
14 rev. 2011-5-26
4. Leveler key:

15 rev. 2011-5-26
Leveler key is associated with the leveler swim jet. Press the Leveler key once to turn on the
leveler swim pump. Press the Leveler key again to turn off the pump.
5. Spa Jets key:
Spa Jets key is associated with the therapy jets. Press the Spa Jets key once to turn the spa
pump on low speed. Press the Spa Jets key a second time to turn the spa pump on high speed.
Press the Spa Jets key the third time to turn off the pump.
6. Main Light key:
Press the Main Light key once to turn on the LED lights. Press the Main Light key a second time
to turn off the LED lights. To select a specific color, after the LED lights have been turned off,
press the Main Light key within 10 seconds to change to the next color selection. Continue until
the desired color is reached. The color setting will store in the memory when the LED lights are
turned off for more than 30 seconds. This feature allows the user to retain a favorite color setting.
A total of 10 color settings are available:
-Ice
-Blue
-Red
-Green
-Sunburst (yellow and orange glow)
-Magenta (blue and red glow)
-Tidal (fade between blue and green)
-Afterburner (fade between red and yellow)
-Color Burst Fast (entire color spectrum)
-Color Burst Slow (entire color spectrum)
7. Swim Light key:
Press the Swim Light key once to turn on the swim LED light. Press the Swim Light key a
second time to turn off the swim LED light. To select a specific color, after the LED lights have
been turned off, press the Swim Light key within 10 seconds to change to the next color selection.
Continue until the desired color is reached. The color setting will store in the memory when the
swim LED light is turned off for more than 30 seconds. This feature allows the user to retain a
favorite color setting. See above for the 10 color settings.
8. Invert key:
The Invert key is used to invert the display on the control panel.
9. Warm and Cool keys:
Press the Warm key to increase the set temperature. Press the Cool key to decrease the set
temperature. The current spa water temperature will remain in the control panel display until a
temperature key is pressed. Once the desired water temperature has been set, the spa will begin
to heat. The default set temperature is 90°F (32°C).
Note: When selecting the spa operating temperature, it is important to factor in the outside ambient
temperature. A spa cannot operate at temperatures lower than that of the surrounding conditions,
or the operating environment of the spa. For the hot summer months, if cooler water is desired, the
Economy mode can be utilized.
10. Time key:
Press the Time key to display the time on the control panel.
11. Mode/Prog key:

16 rev. 2011-5-26
The Mode/Prog key is used to switch between program modes. The spa is factory equipped with
three program modes: Standard, Economy, and Sleep modes. Press the Mode/Prog key to enter
mode programming, press the Cool key to cycle through to desired mode. The control panel
display flashes until confirmed. Press Mode/Prog to confirm selection.
STANDARD MODE
In Standard mode, the system maintains the desired temperature. Note that the last measured spa
temperature displayed is current only when the spa pump has been running for at least 1 minute. The
“STANDARD” icon will display when the Standard mode is engaged.
ECONOMY MODE
Economy mode heats the spa water to set temperature only during filter cycles. The “ECONOMY” icon
will display when the Economy mode is engaged.
SLEEP MODE
Sleep mode heats the spa water to within 20°F (11°C) of the set temperature only during filter cycles.
The “SLEEP” icon will display when the Sleep mode is engaged.
FILTRATION SYSTEM
The spa is factory programmed to filter two times a day for 2 hours. In most cases, this is sufficient
filtration. However, the cycle duration can be adjusted. Refer to the Programming the Control System
section for instructions on how to adjust the filtration cycles. The first cycle begins at 12PM, and the
second cycle begins at midnight. The F1 indicator light will come on when the first filter cycle is on. The
F2 indicator light will come on when the second filter cycle begins.
PROGRAMMING THE CONTROL SYSTEM
1. Clock:
Press the Time key then the Mode/Prog key to engage the programming mode. Then press the
Warm or Cool key to change the hour setting. Once the desired hour is displayed, press the
Mode/Prog key again to accept the selection, and move to programming the minute setting. Use
the Warm or Cool key to change the minute setting. Once the desired minute is displayed, press
the Mode/Prog key again to accept the selection and proceed to programming the filter 1 start
time, or press the Time key to exit the programming mode.
2. Filter 1 Start Time:
To set the start time of the first filter cycle, press the Time key then the Mode/Prog key 3 times to
access the filter 1 start time programming. The control panel will display SET FILTER 1 and a
flashing “START TIME” icon. Press the Warm or Cool key to adjust the hour setting. Program
default setting is 12PM. Press the Mode/Prog key to accept the hour setting and proceed to
program the minute setting. Press the Warm or Cool key to adjust the minute setting in
increments of 5 minutes. Press the Mode/Prog key to accept the minute setting and proceed to
programming the filter 1 end time.
3. Filter 1 End Time:
After setting the start time of the first filter cycle, the control panel will display SET FILTER 1 and a
flashing “END TIME” icon. Press the Warm or Cool key to adjust the hour setting. Program
default setting is 2PM. Press the Mode/Prog key to accept the hour setting and proceed to
program the minute setting. Press the Warm or Cool key to adjust the minute setting in

17 rev. 2011-5-26
increments of 5 minutes. Press the Mode/Prog key to accept the minute setting and proceed to
programming the filter 2 start time.
4. Filter 2 Start Time:
After setting the end time of the first filter cycle, the control panel will display SET FILTER 2 and a
flashing “START TIME” icon. Press the Warm or Cool key to adjust the hour setting. Program
default setting is 12AM. Press the Mode/Prog key to accept the hour setting and proceed to
program the minute setting. Press the Warm or Cool key to adjust the minute setting in
increments of 5 minutes. Press the Mode/Prog key to accept the minute setting and proceed to
programming the filter 2 end time.
5. Filter 2 End Time:
After setting the start time of the second filter cycle, the control panel will display SET FILTER 2 and
a flashing “END TIME” icon. Press the Warm or Cool key to adjust the hour setting. Program
default setting is 2AM. Press the Mode/Prog key to accept the hour setting and proceed to
program the minute setting. Press the Warm or Cool key to adjust the minute setting in
increments of 5 minutes. Press the Mode/Prog key to accept the minute setting and exit the
programming mode.
STANDBY MODE
Standby mode is helpful when changing a filter. Press Warm or Cool key, then Swim 2 key will turn off
all spa functions temporarily. Press any key to reset the spa.
CONTROL PANEL LOCK
Press the Time, Spa Jets, then Warm keys within 3 seconds. When locked, the PL indicator light will
come on. All keys on the control panel will be disabled except for the Time key. To unlock the control
panel, press the Time, Spa Jets, then Cool keys.
TEMPERATURE LOCK
Press the Warm or Cool key, then the Time, Spa Jets, and Warm keys within 3 seconds to activate the
set temperature lock. The TL indicator light will come on. To unlock the set temperature, press the
Warm or Cool key, then the Time, Spa Jets, and Cool keys.
FEATURE OPERATIONS
JET SELECTOR VALVE (DIVERTER VALVE)
Your spa may be equipped with a jet selector valve (diverter valve). This valve can be used to divert jet
power from one area in the spa to another area. This valve is fully adjustable and can be used to suit
the user’s desired effect. The valve may be slightly harder to turn when the jet pump is on high speed.
This is normal due to high rate of water flow and pressure present in the valve.
AIR CONTROL VALVES
Your spa may be equipped with air controls. The air control is an on/off valve that allows air to be
introduced into a specific jet configuration resulting in a more vigorous jet action. Turn the valve handle
clockwise to turn the air on, and counterclockwise to turn the air off. Opening the valve increases jet
pressure and closing the valve decreases the jet pressure.

WATER FEATURES AND WATER FEATURE CONTROL VAVLE
Your spa may be equipped with water features. They are turned on/off by the water feature control
valve. Turn the valve handle clockwise to turn the water features on, and counterclockwise to turn the
water features off. Water features are always supplied by the spa pump.
STEREO SYSTEM
Your spa may be equipped with a stereo system and a spa side stereo control panel. The stereo
manufacturer’s owner’s manual is provided within the spa owner’s manual. In addition to the following
instructions, please refer to the stereo manufacturer’s owner’s manual for the operation of the stereo
system.
Note: It is imperative that you keep your stereo system clean and dry. The spa is equipped with a self-
closing stereo door to protect the unit from moisture intrusion. Stereo equipped spas should be
protected from direct contact with water streams from irrigation systems. During use, the stereo door
should remain closed. Audio CD should be dry before inserting into the stereo unit.
Spa Side Wired Stereo Control
Power – Press the Power/Fader key to turn the system on or off.
Source – Press the Source (SRC) key to select a source between the following (in order): Tuner, CD,
Aux.
Band – (Radio mode only) Press the Band key to select between FM1, FM2, FM3, AM1, AM2, and WB
(weather band).
Fader – Press and hold the Power/Fader key to select the following (in order): FAD-FRONT (front
speakers only), FAD-REAR (rear speakers only), and FAD-ALL (front and rear speakers).
Mute – Press and hold the Track Down/Mute key to attenuate the volume. A second press and hold
will put the volume back to its previous level.
Volume Up/Down – Press the Volume Up key to increase the volume. Press the Volume Down key to
decrease the volume.
18 rev. 2011-5-26

19 rev. 2011-5-26
Track Up/Down – Press the Track Up/Down to function the followings.
•Radio mode: To select the next or previous preset station. Press and hold the Track Up/Down key
to seek up or down to the next station. Scan mode stops as soon as a strong station is found.
•Weather Band mode: To select the next or previous memorized station.
•CD mode: To change tracks. Press and hold the Track Up/Down key to fast forward or rewind.
•MP3 mode: To select a file up or down.
