L.A. Spas 2012 North American User manual

2012 North American
Owner’s Manual
Premium

1 rev. 2012v1
TABLE OF CONTENTS
LETTER OF INTRODUCTION..................................................................................................................3
SPA RECORD KEEPING INFORMATION...............................................................................................4
IMPORTANT SAFETY INSTRUCTIONS..................................................................................................5
HYPERTHERMIA INFORMATION...........................................................................................................7
SAFETY PRECAUTIONS.........................................................................................................................7
SAFETY SIGN..........................................................................................................................................8
SPA CAUTIONS.......................................................................................................................................8
SPA EQUIPPED SAFETY DEVICES .......................................................................................................9
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA.......................................................................10
INSTALLATION INSTRUCTIONS..........................................................................................................12
SURFACE AND PAD REQUIREMENTS .............................................................................................12
ELECTRICAL INSTALLATION REQUIREMENTS...............................................................................12
ELECTRICAL CONNECTIONS...........................................................................................................13
INITIAL START-UP INSTRUCTIONS.....................................................................................................14
OPERATING INSTRUCTIONS...............................................................................................................16
CONTROL PANEL TYPES AND MODELS..........................................................................................16
CONTROL PANEL OPERATION.........................................................................................................16
STANDBY MODE................................................................................................................................17
ECONOMY MODE ..............................................................................................................................18
FILTRATION SYSTEM........................................................................................................................18
PROGRAMMING THE CONTROL SYSTEM.......................................................................................18
FEATURE OPERATIONS ......................................................................................................................19
JET SELECTOR VALVES (DIVERTER VALVES) ...............................................................................19
AIR CONTROL VALVES .....................................................................................................................20
WATER FEATURE CONTROL VAVLE ...............................................................................................20
STEREO SYSTEM..............................................................................................................................20
WATER BALANCE ................................................................................................................................20
WATER CHEMISTRY..........................................................................................................................20
START-UP PROCEDURES.................................................................................................................20
WATER QUALITY ...............................................................................................................................20
PHCONTROL......................................................................................................................................21
TOTAL ALKALINITY............................................................................................................................21
WATER TREATMENT............................................................................................................................21
SANITIZERS .......................................................................................................................................21
BROMINE............................................................................................................................................21
CHLORINE..........................................................................................................................................22
SUPER CHLORINATION ....................................................................................................................22
SHOCK TREATMENTS (POTASSIUM PEROXYMONOSULFATE)....................................................22
OZONE................................................................................................................................................22
WATER TESTING...............................................................................................................................22
STAIN AND SCALE INHIBITOR..........................................................................................................23

2 rev. 2012v1
FOAM INHIBITOR...............................................................................................................................23
KEEPING YOUR WATER CLEAN AND SAFE.....................................................................................23
SPA CARE .............................................................................................................................................24
FILTER CLEANING.............................................................................................................................24
CARE FOR SPA SURFACE ................................................................................................................24
CARE FOR SPA PILLOWS..................................................................................................................24
CARE OF SPA CABINET (THERMOPLUS CABINET) ........................................................................24
CARE FOR THERM-RITETM SPA COVER ..........................................................................................24
DRAINING THE SPA...........................................................................................................................25
SPECIAL COLD WEATHER INSTRUCTIONS (WINTERIZING)..........................................................25
WARRANTY SERVICE INFORMATION..............................................................................................25
TROUBLESHOOTING............................................................................................................................26

3 rev. 2012v1
LETTER OF INTRODUCTION
Dear Valued Customer:
Congratulations! On behalf of the entire L.A. Spas family, thank you for your decision to purchase one
of our products.
The following pages contain valuable and helpful information for the care and safe operation of your new
spa. Every effort has been made to insure optimum therapy and relaxation at minimal cost of operation,
delivering maximum value for you, your family, and your home.
Please take the time to read these instructions carefully. When the spa is properly installed and
maintained, your spa will provide years of enjoyable, trouble free operation.
Every effort has been made to ensure the accuracy of this owner’s manual, however, L.A. Spas
reserves the right to modify and improve the product without notice. This may create minor variations
between this manual and your spa. If you have any questions regarding your spa, or the owner’s
manual, please contact your authorized L.A. Spas dealer.
We are confident that once you become familiar with the various options, maintenance features, and the
general operation of your new spa, you will be completely satisfied that you made the right decision in
purchasing an L.A. Spas product.
Sincerely yours,
L.A. Spas, Inc.

4 rev. 2012v1
SPA RECORD KEEPING INFORMATION
Serial Number Location
The serial number is located in the lower right corner of the equipment access panel on the front of the
spa.
PLEASE FILL IN THE INFORMATION BELOW
Spa Information:
Model _______________ Color _______________ Serial No. _________________
Owner Information:
Name _____________________________________ Date of Purchase ___________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Dealer Information:
Name ________________________________________________________________
Address_______________________________________________________________
City ____________________________ State__________ Zip Code ____________
Telephone No. _________________________________________________________
SAVE THIS INFORMATION FOR FUTURE REFERENCE
TO OFFICIALLY ACTIVATE YOUR WARRANTY, YOU MUST GO TO
www.LAspas.com AND REGISTER YOUR SPA BY CLICKING ON THE REGISTER
YOUR SPA LINK UNDER THE CUSTOMER CORNER TAB AND FILL OUT ALL THE
INFORMATION

5 rev. 2012v1
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
READ THE ENTIRE OWNER’S MANUAL & SAFETY INSTRUCTIONS BEFORE OPERATING THE
SPA. When installing the spa, basic safety precautions should always be followed, including the
following:
1. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are
closely supervised by an adult at all times.
2. WARNING: A grounding wire connector is provided on this unit to connect a minimum 8 AWG
(8.4mm2) solid copper conductor between this unit and any metal equipment, metal enclosure of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5 m) of the unit.
3. DANGER – RISK OF ACCIDENTAL DROWNING: Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot use this spa
unless they are closely supervised by an adult at all times.
4. DANGER – RISK OF INJURY: The suction fittings in this spa are sized to match the specific water
flow created by the pump. Should the need arise to replace the suction fittings or the pump, be
sure to replace with same model suction fittings for safety and compatible flow rates. NEVER
OPERATE THE SPA IF THE SUCTION FITTINGS ARE BROKEN OR MISSING. NEVER
REPLACE A SUCTION FITTING WITH ONE RATED LESS THAN THE FLOW RATE MARKED
ON THE ORIGINAL SUCTION FITTING.
5. DANGER – RISK OF INJURY: Do not remove suction grate. Suction through drains and
skimmers is powerful when the jets in the spa are in use. Damaged suction grate can be
hazardous to children and adults with long hair. Should any part of the body or hair be drawn into
these fittings or stuck onto the fittings, turn off the spa immediately. As a precaution, long hair
should NOT be allowed to float freely in the spa.
6. DANGER – RISK OF ELECTRIC SHOCK: Install the spa at least 5 feet (1.5 m) from all metal
surfaces. As an alternative, a spa maybe installed within 5 feet (1.5 m) of metal surfaces if, in
accordance with the National Electrical Code, each metal surface is permanently connected by a
minimum 8 AWG (8.4mm2) solid copper conductor to the wire connector on the terminal box that is
provided for this purpose.
7. DANGER – RISK OF ELECTRIC SHOCK: Do not permit any electric appliances such as light,
hair dryer, telephone, radio, or television within 5 feet (1.5 m) of the spa. Never operate any
electrical appliances from inside the spa or while wet.
8. DANGER: To reduce risk of injury:
a. The water in a spa should never exceed 104°F (40°C). Water temperatures between 100°F
(38°C) and 104°F (40°C) are considered safe for a healthy adult. Lower water temperatures are
recommended for young children and when spa use exceeds 10 minutes.
b. Since excessive water temperatures have a high potential for causing fetal damage during the
early months of pregnancy, pregnant women should limit spa water temperatures to 100°F
(38°C).

6 rev. 2012v1
c. Before entering a spa, the user should check the water temperature with an accurate
thermometer since tolerance of water temperature regulating devices can vary and not reflect
the proper temperature.
d. The use of alcohol, drugs, or medication before or during spa use is prohibited and may lead to
unconsciousness with the possibility of drowning.
e. Obese persons and persons with a history of heart disease, low or high blood pressure,
circulatory system problems, or diabetes should consult a physician before using a spa.
f. Persons using medication should consult a physician before using a spa since some medication
may induce drowsiness while other medications may affect heart rate, blood pressure, and
circulation.
9. Do not use spa immediately after strenuous exercise.
10. Maintain water chemistry as recommended by your local L.A. Spas authorized dealer.
-For models equipped with audio system-
11. CAUTION – RISK OF ELECTRIC SHOCK: Do not leave stereo compartment door open.
12. CAUTION – RISK OF ELECTRIC SHOCK: Replace components only with identical components.
13. Do not operate the audio controls while inside the spa.
14. WARNING – PREVENT ELECTROCUTION: Do not connect any auxiliary components such as
cable, additional speakers, headphones, additional audio components, etc. to the system.
15. These units are not provided with an outdoor antenna. If provided, if should be installed in
accordance with Article 810 of the National Electrical Code.
16. Do not service this product yourself as opening or removing covers may expose you to dangerous
voltage or other risk of injury. Refer all servicing to qualified service personnel from your local L.A.
Spas authorized dealer.
17. When the power supply connections or power supply cord(s) are damaged; if water is entering the
audio compartment or any electrical equipment compartment area; if the protective shields or
barriers are showing signs of deterioration; or if there are signs of other potential damage to the
unit, turn off the unit and refer servicing to a qualified service person from your local L.A. Spas
authorized dealer.
18. The system should be subjected to periodic routine maintenance (for example, once every 3
months) to make sure that the system is operating properly.
19. For more information on spa safety you can visit www.APSP.org and go to their Safety section to
download free brochures.
SAVE THESE INSTRUCTIONS

7 rev. 2012v1
HYPERTHERMIA INFORMATION
Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above
normal body temperature of 98.6°F (37°C).
The symptoms of hyperthermia include:
Dizziness
Fainting
Drowsiness
Lethargy
Increase in internal body temperature
The effects of hyperthermia include:
Unawareness of impending hazard
Failure to perceive heat
Failure to recognize the need to exit spa
Physical inability to exit spa
Fetal damage in pregnant women
Unconsciousness resulting in a danger of drowning
WARNING – The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in hot tubs
and spas.
SAFETY PRECAUTIONS
a. Always enter and exit a spa slowly.
b. Do not use the spa alone.
c. Before entering the spa, always measure the water temperature with an accurate thermometer.
Tolerance of water temperature regulating devices can vary as much as ±5°F (3°C). Always check
the spa water temperature before entering.
d. Since excessive water temperature has a high potential for causing fetal damage during early
months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to
100°F (38°C). Always consult your doctor prior to using a spa.
e. Children’s body temperature can increase more rapidly than adults in the same water with elevated
temperatures above 99°F (37°C). Children should spend less time in water above body temperature
than adults.
f. The use of alcohol, drugs, and/or medication before or during spa use may lead to unconsciousness,
hypothermia, serious injury, or the possibility of drowning.
g. Persons suffering from obesity or with a medical history of heart disease, diabetes, high or lower
blood pressure, or circulatory system problems should consult with their physician before using the
spa.
h. Persons on medication should consult with their physician before entering the spa since some
medication may induce drowsiness while other medication may affect heart rate, blood pressure, and
circulation.
i. People with infections, sores, or skin abrasions should not use the spa. Warm and hot water
temperatures may allow the growth of infectious bacteria if not properly disinfected.
j. Test the GFCI (Ground Fault Circuit Interrupter) unit before each use. (Refer to instructions provided
by GFCI manufacturer.)
k. Do not service or repair any equipment without making sure the circuit breaker and/or all power to
the spa is turned off.
l. Cover must be kept on the spa and locked at all times when not in use, especially if children are
present.

8 rev. 2012v1
SAFETY SIGN
Each spa has been provided with a warning sign that outlines safety precautions. This sign should be
permanently placed in a location that is visible to all spa users. This sign has been mounted
permanently to the front of the spa. Replacement signs can be obtained from:
L.A. Spas, Inc.
1311 N. Blue Gum Street
Anaheim, CA 92806
SPA CAUTIONS
1. Persons suffering from heart disease, diabetes, high or low blood pressure, any condition requiring
medical treatment, pregnant women, the elderly, or infants should consult with a physician before
using a spa.
2. The Consumer Product Safety Commission has stated that the water temperature in a spa or hot
tub should not exceed 104°F (40°C). Immersion in water in excess of 104°F (40°C) can be
hazardous to your health.
3. Observe a reasonable time limit when using the spa. Long exposures at higher temperatures can
cause high body temperature. Symptoms may include dizziness, nausea, fainting, drowsiness, and
reduced awareness. These effects could result in possible drowning.
4. Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use of the spa under
these conditions may lead to serious consequences.
5. Always test the spa water temperature before entering the spa. Enter and exit the spa slowly. Wet
surfaces can be very slippery.
6. Never bring any electrical appliance into or near the spa. Never operate any electrical appliance
from inside the spa or when you are wet.
7. Proper chemical maintenance of spa water is necessary to maintain safe water and prevent
possible damage to spa components.
8. Use the spa straps and clip tie downs to secure the cover when not in use. This will help to
discourage unsupervised children from entering the spa and keep the spa cover secure in high
wind conditions. There is no representation that the cover, clip tie downs, or actual locks will
prevent access to the spa.

9 rev. 2012v1
SPA EQUIPPED SAFETY DEVICES
Your spa is equipped with the following safety features:
1. Overheat Protection – All pumps and heater are shut off when the water temperature reaches
112.5°F (44.7°C). This protection is turned off when the water temperature drops below 112°F
(44.4°C).
2. High Limit Protection – When the water temperature reaches 119°F (48°C), the high limit circuit
has tripped. All pumps and heater are shut off. This protection requires the power to be reset at
the circuit breaker.
3. Ambient Overheat Protection – The light output is disabled when an on-board temperature
sensor reaches 194°F (90°C). This protection automatically turns off when the on-board
temperature sensor drops back down to 192°F (89°C). If the internal temperature continues to rise
and reaches 212°F (100°C), all outputs are turned off. This protection automatically turns off if the
temperature at the on-board sensor cools back down to 210°F (99°C).
4. Heater Dry Run Protection – This protection is a water flow detection algorithm of the heater that
prevents the heater from turning on until there is sufficient water flow.
5. Smart Winter Mode – The Smart Winter Mode is used to prevent water from freezing in the
plumbing. When SWM is enabled, the system periodically starts a purge of all pumps and the
blower (if equipped) to ensure there is always warm water in the plumbing. This function is
achieved by measuring the temperature of an on-board sensor to estimate the temperature in the
equipment area. This protection starts as soon as there is a risk of freezing. The SWM protection
will turn back off only after 24 hours without a risk of freezing. The delay between each SWM
purge cycle depends on the pumps’ idle time (see table below).
Freeze Risk Temperature Range at
On-Board Sensor Temperature Range in Equipment Area Max. Idle Time
None > 62°F (16.7°C) > 42°F (5.6°C) 120 minutes
Low 62 – 53°F
(16.7 – 11.7°C) 42 – 33°F (5.6 – 0.6°C)
Medium 53 – 48°F
(11.7 – 8.9°C) 33 – 28°F (0.6 – -2.2°C) 60 minutes
High 48 – 44°F
(8.9 – 6.7°C) 28 – 24°F (-2.2 – -4.4°C) 30 minutes
Severe < 44°F (6.7°C) < 24°F (-4.4°C) 15 minutes
6. Timeouts – The pumps and light turn off automatically after 30 minutes of continuous operation.

10 rev. 2012v1
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA
SAFETY INFORMATION
READ AND FOLLOW ALL INSTRUCTIONS
When using this electrical equipment, basic safety precautions should always be followed, including the
following:
1. A colored terminal or a terminal marked G, GR, Ground, Grounding, or the grounding symbol is
located inside the supply terminal box/compartment. To reduce the risk of electric shock, this
terminal must be connected to the grounding means provided in the electric supply service panel
with a continuous copper wire equivalent in size to the circuit conductors supplying this equipment.
2. At least two lugs marked “BONDING LUGS” are provided on the external surface or on the inside
of the supply terminal box/compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the hot tub or spa to these terminals with an insulated or bare
copper conductor not smaller than 6 AWG.
3. All field installed metal components such as rails, ladders, drains, or other similar hardware within 3
meters of the spa or hot tub shall be bonded to the equipment grounding bus with copper
conductors not smaller than 6 AWG.
WARNING: Children should not use spas or hot tubs without adult supervision.
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER UNE CUVE DE RELAXATION
SANS SURVEILLANCE.
WARNING: Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair
entrapment.
AVERTISSEMENT: POUR EVITER QUE LES CHEVEUX OU UNE PARTIE DU CORPS PUISSENT
ETRES ASPIRES, NE PAS UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DE PRISE
D’ASPIRATION NE SONT PAS TOUTES EN PLACE.
WARNING: People using medications and/or having adverse medical history should consult a
physician before using a spa or hot tub.
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES MEDICAMENTS OU ONT DES
PROBLEMES DE SANTE DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE
DE RELAXATION.
WARNING: People with infectious diseases should not use a spa or hot tub.
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES INFECTIEUSES NE DEVRAIENT
PAS UTILISER UNE CUVE DE RELAXATION.
WARNING: To avoid injury, exercise care when entering and exiting the spa or hot tub.
AVERTISSEMENT: POUR EVITER DES BLESSURES, USER DE PRUDENCE EN ENTRANT DANS
UNE CUVE DE RELAXATION ET EN SORTANT.
WARNING: Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid
unconsciousness and possible drowning.

11 rev. 2012v1
AVERTISSEMENT: POUR EVITER L’EVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE
PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND
ON S’Y TROUVE.
WARNING: Pregnant or possibly pregnant women should consult a physician before using a spa or hot
tub.
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR GROSSESSE SOIT CONFIRMEE OU
NON, DEVRAIENT CONSULTER UN MEDECIN AVANT D’UTILISER UNE CUVE DE RELAXATION.
WARNING: Water temperature in excess of 100°F (38°C) maybe injurious to your health.
AVERTISSEMENT: IL PEUT ETRE DANGEREUX POUR LA SANTE DE LE PLONGER DANS DE
L’EAU A PLUS DE 38°C.
WARNING: Before entering the spa or hot tub, measure the water temperature with an accurate
thermometer.
AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE RELAXATION MESURER LA
TEMPERATURE DE L’EAU A L’AIDE D’UN THERMOMETRE PRECIS.
WARNING: Do not use a spa or hot tub immediately following strenuous exercise.
AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION IMMEDIATEMENT APRES UN
EXERCICE FATIGANT.
WARNING: Prolonged immersion in a spa or hot tub may be injurious to your health.
AVERTISSEMENT: L’UTILISATION PROLONGEE D’UNE CUVE DE RELAXATION PEUT ETRE
DANGEREUSE POUR LA SANTE.
WARNING: Do not permit electric appliances (light, telephone, radio, television, etc.) within 1.5m of this
spa or hot tub.
AVERTISSEMENT: NE PAS PLACER D’APPAREIL ELECTRIQUE (LUMINAIRE, TELEPHONE,
RADIO, TELEVISEUR, ETC.) A MOINS DE 1.5M DE CETTE CUVE DE RELAXATION.
CAUTION: Maintain water chemistry in accordance with manufacturer’s instructions.
ATTENTION: LA TENEUR DE L’EAU EN MATIERES DISSOUTES DOIT ETRE CONFORME AUX
DIRECTIVES DU FABRICANT.
WARNING: The use of alcohol or drugs can greatly increase the risk of fatal hyperthermia in spas or
hot tubs.
AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE DROGUE AUGMENTE
CONSIDERABLERMENT LES RISQUES D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE
RELAXATION.
SAVE THESE INSTRUCTIONS

12 rev. 2012v1
INSTALLATION INSTRUCTIONS
Read all instructions in this manual prior to having your spa installed at the selected location, whether
indoors or outdoors. IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID
THE WARRANTY.
SURFACE AND PAD REQUIREMENTS
1. L.A. Spas recommends your new spa be placed on a 4” (10 cm) thick reinforced concrete pad or
level foundation capable of supporting the total filled weight of your specific spa model. The
foundation should support the entire base of the spa and must offer structural integrity for the life of
the spa. A typical spa, filled with water, could weigh as much as 3 tons, and if the concrete is not
fully cured, it could easily crack. AN UNEVEN OR UNSTABLE FOUNDATION OR THE USE OF
SHIMS OF ANY KIND MAY CAUSE THE SPA TO BUCKLE, DISTORT, AND/OR CRACK, AND
WILL VOID THE WARRANTY ON YOUR SPA.
2. If your spa is located near water sprinklers, adjust or cap them so the water will not hit the wood
cabinet of the spa.
3. Balconies and decks must be constructed to current state and local codes to safely support the
maximum load of your water filled spa and the number of people using the spa. Check with your
construction contractor for these safety specifications.
4. Access gates “fencing/wall” must be self-closing and self-locking. Check your local codes for
regulations regarding fences and gates.
5. Ensure that the spa installation and location allows a clear and unobstructed access to the spa. It
is the responsibility of the owner to provide clear access on all sides of the spa for service. Failure
to do so may result in additional charges or assessments to service and/or repair the spa.
6. Ensure that water drains away from the spa in order to keep water out of the equipment
compartment and away from all electrical components.
7. Assure accessibility is maintained to your spa should the need arise. Your spa is an appliance and
may require occasional service requirements. Assure the installation allows access to the
equipment area, side panels, and removal of the spa if possible. Construction or reconstruction
costs associated with spa removal or reinstallation are not covered by the warranty.
ELECTRICAL INSTALLATION REQUIREMENTS
IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID THE WARRANTY.
NOTE: Do not turn on electrical power to your spa until you are told to do so later in the Owner’s
Manual.
1. We strongly recommend that only a licensed and bonded electrician perform the electrical
installation. Improper electrical connections may damage the equipment, cause injury, cause a
fire, and void your spa warranty.

13 rev. 2012v1
2. It is the responsibility of the spa owner to ensure that a qualified electrician performs the electrical
installation. This installation must be in accordance with the National Electrical Code; local and
state electrical codes; and the manufacturer’s instructions.
3. This equipment has been designed to operate on 240V 60Hz alternating current.
4. This spa must be connected to a dedicated branch circuit.
5. The electrical supply for this spa must include a suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with Section 422-20 of the National Electric Code (NEC).
A disconnect switch must be located where visible, not less than 5 feet (1.5 m) from the spa and
not to exceed 50 feet (15 m) from the spa. This requirement maybe filled with the GFCI circuit
breaker and sub-panel.
6. For spa use in other than single-family dwellings, a clearly labeled emergency switch shall be
provided as part of the installation. The switch shall be readily accessible to the occupants and
shall be installed at least 5 feet (1.5m) away, adjacent to, and within sight of the spa.
7. The electrical circuit to the spa must include a Class A type Ground Fault Circuit Interrupter (GFCI)
as required by the NEC.
8. Wire size must be appropriate for your spa and per NEC and/or local codes. Refer to the table
below for the electrical ratings. All supply wires must be copper and rated at a minimum of 167°F
(75°C). Do not use aluminum wires.
9. Input power wiring and circuit breaker selection:
IMPORTANT INFORMATION REGARDING ELECTRICAL INSTALLATION
Equipment Type Electrical Rating Branch Circuit Circuit Breaker
1
1 pump 240V 32A 3 wires + ground 40A
1 pump with blower 240V 32A 3 wires + ground 40A
2 pumps 240V 40A 3 wires + ground 50A
2 pumps with blower 240V 40A 3 wires + ground 50A
3 pumps 240V 48A 3 wires + ground 60A
3 pumps with blower 240V 48A 3 wires + ground 60A
1. Circuit breaker amperages may vary according to the area of installation. Please check local electrical codes to verify
requirements and assure compliance. Spas purchased not fully equipped may operate at a reduced total amp rating thus
allowing installation of a lower rate GFCI circuit breaker and service installation.
2. Only a licensed electrician should size and install the electrical connections to the spa.
ELECTRICAL CONNECTIONS
To hook up your spa, follow these instructions:
1. Remove the front center cabinet panel.
2. Loosen the 2 screws of the equipment control pack door and open it.
3. Use ¾” flexible non-metallic conduit for a spa requiring 10 AWG or 8 AWG wire. Use 1” flexible
non-metallic conduit for a spa requiring 6 AWG wire. Run the conduit from the power source to the
spa, through the hole in the left or right front corner of the spa and into the equipment control pack.

14 rev. 2012v1
4. Pull the wires/cable through the conduit and through the cutout of the equipment control pack.
Secure the wires/cable with a 1” strain relief. Make sure only the uncut sheathing is clamped at
this opening.
5. Connect the wires to the proper terminals as indicated on the sticker.
6. Secure the wire connections. Push the wires into the equipment control pack.
7. Close the equipment control pack door and tighten the 2 screws.
8. Electrical hook up is now complete. Do not re-attach the front center cabinet panel yet.
INITIAL START-UP INSTRUCTIONS
DO NOT TURN ON THE POWER TO THE SPA WHEN THE SPA IS EMPTY OR PARTIALLY FILLED.
1. Ensure the circuit breaker to the spa is off.
2. Rotate all the jets in the spa to a counterclockwise position (fully open position).
3. Ensure the gate valves are fully open. Pull the “T” handle on the gate valve (located near the jet
pump) all the way up. When opened, there will be approximately 2” (5 cm) of metal rod visible.
Each pump is supplied with one valve.
4. Check the heater unions, pump unions, and pump plugs to assure that they are tight to prevent the
possibility of leakage in the equipment bay.
5. Close and cap the hose bib located in the center of the equipment compartment. This is used for
draining the spa.
6. Fill the spa with water to a level of approximately 5” (13 cm) below the top of spa. To prevent the
pumps being air locked, it is recommended to fill the water at the filter bucket area.
7. Turn on the circuit breaker. The upper control panel display will alternate between the clock and
three dashes ---. The system takes up to 3 minutes to register the water temperature. The
display will then alternate between the clock and the water temperature. Set the desired
temperature by using the Up or Down arrow key.
8. Press the Pump1 key twice to turn pump #1 on high speed. Observe to ensure adequate water
flow. Press the Pump2 key to turn on pump #2 (if equipped). Observe to ensure adequate water
flow. Press the Pump3 key to turn on pump #3 (if equipped). Observe to ensure adequate water
flow. DO NOT ALLOW THE PUMPS TO RUN FOR MORE THAN 1 MINUTE WITHOUT WATER
FLOWING OUT OF THE JETS. PUMPS WITH DRY RUN PROBLEMS WILL NOT BE COVERED
UNDER WARRANTY. If there is no water flow through the jets, the pumps need to be primed to
eliminate air lock.
Pump Priming
•Turn off the power to the spa.
•Remove the handle from the jet selector valve supplied by the pump you are priming.
•Loosen the pump union on the suction side of the pump until some water starts gushing out of
the pump union.

15 rev. 2012v1
•Tighten the pump union.
9. Check to ensure that water is flowing through the Ultimate Water Management System. Observing
the footwell for bubbles will determine if there is water flow. If there are no bubbles, turn off the
spa, disconnect the hose above the circulation pump and allow any trapped air to escape.
10. Re-attach the front center cabinet panel.
11. Depending upon the size of the spa and the size of the electrical circuit, heating will occur at a rate
of approximately 5°F (2°C) per hour.
12. After completing the above steps, it is necessary to ensure proper water chemistry. See the Water
Balance section in the manual.
13. Because the Aqua Klean®Filtration System is so efficient and there is no by-pass for proper filter
maintenance, the filters should be cleaned every other day for the first two weeks of operation.
14. Place the spa cover on to conserve energy and to keep it ready for use.

OPERATING INSTRUCTIONS
CONTROL PANEL TYPES AND MODELS
in.k600 Control Panel
This easy to use control has been pre-programmed to be “plug and play”. Turn the power on, adjust the
desired temperature and the system is ready to go. If there are situations that require additional filtering
time, the filter settings can be customized to any special requirements. Simple to use and easy to read,
the Command Control System makes controlling the spa effortless.
CONTROL PANEL OPERATION
Please note: All pumps, blower (if equipped), and light have an automatic timeout (shut-off)
programmed 30 minutes after the pump or light is activated.
1. ON/Off key
Press and release the On/Off key to shut the system down for 30 minutes. The display will toggle
between Sby and water temperature. Press the On/Off key to restart the system before the
expiration of the 30 minutes delay.
2. Pump1 key
Press the Pump1 key to turn on the low speed of jet pump #1. Press the Pump1 key a second
time to turn on the high speed of jet pump #1. A third press of the key to turn the pump off.
3. Pump2 key
Press the Pump2 key once to turn on jet pump #2. Press the Pump2 key a second time to turn the
pump off.
Note: This key may be non-operational in some models.
4. Pump3 key
Press the Pump3 key once to turn on jet pump #3. Press the Pump3 key a second time to turn the
pump off.
16 rev. 2012v1

Note: This key may be non-operational in some models.
5. Blower key
Press the Blower key once to turn on the air blower. Press the Blower key a second time to turn
the air blower off.
Note: This key may be non-operational in some models.
6. Program key
Use the Program key to display the time or enter Programming menu by press and hold the key for
3 seconds. In Programming mode, the following parameters can be set: time, filter cycle start time,
filter cycle duration, filter cycle frequency, and temperature unit. Refer to the Programming the
Control System section for the programming instructions.
7. Light key
Press the Light key once to turn on the LED light. Press the Light key a second time to turn off
the LED light. To select a specific color, after the LED light has been turned off, press the Light
key within 10 seconds to change to the next color selection. Continue until the desired color is
reached. The color setting will store in the memory when the LED light is turned off for more than
30 seconds. This feature allows the user to retain a favorite color setting. A total of 10 color
settings are available:
-Ice
-Blue
-Red
-Green
-Sunburst (yellow and orange glow)
-Magenta (blue and red glow)
-Tidal (fade between blue and green)
-Afterburner (fade between red and yellow)
-Color Burst Fast (entire color spectrum)
-Color Burst Slow (entire color spectrum)
8. Up/Down keys +/-
Press the Up key to increase the set temperature. Press the Down key to decrease the set
temperature. Press the respective key one time for each degree of temperature change. Press
and hold the key to adjust the temperature rapidly. The current spa water temperature will remain
in the control panel display until a temperature key is pressed. Once the desired water
temperature has been set, the spa will begin to heat.
Note: When selecting the spa operating temperature, it is important to factor in the outside ambient
temperature. A spa cannot operate at temperatures lower than that of the surrounding conditions,
or the operating environment of the spa. For the hot summer months, if cooler water is desired, the
Economy mode can be utilized.
STANDBY MODE
A quick press and release of the On/Off key will shut the system down (i.e. to set it to Standby mode) for
30 minutes. The display will toggle between Sby and the water temperature. All keys are disabled.
Press the On/Off key again to reactivate the system before the expiration of the 30 minutes delay.
17 rev. 2012v1

18 rev. 2012v1
In order to warn the user, the spa light will flash for a few seconds before the exit of the Standby mode.
ECONOMY MODE
The economy mode is used to reduce power consumption when the spa is not in use. In economy
mode, the heater will only engage when the water reaches a temperature equal to 20°F (11°C) below
the set temperature during a certain period of the day. The factory default period is from midnight to
6AM. If a different period is desired, please refer to the Programming the Control System section for
programming instructions.
While the Economy mode is engaged, the display will toggle between Eco and the water temperature.
The Economy mode can be cancelled by pressing and holding the On/Off key for 5 seconds.
The Economy mode can be manually enabled immediately outside the pre-programmed period. It will
stop at its next programmed stop time. Press and hold the On/Off key for 5 seconds to manually enable
the Economy mode.
FILTRATION SYSTEM
The spa is factory programmed to filter two times a day for 1 hour. In most cases, this is sufficient
filtration. However, the number of cycles can be modified between 1-4 cycles per day, and the cycle
duration can be modified between 0-6 hours per cycle in increments of 1 hour. Refer to the
Programming the Control System section for programming instructions.
Filter cycles occur in two steps: a purge and a clean step. During the purge step, typically, all pumps
are turned on for one minute to purge the spa plumbing. For the remainder of the filter cycle, pump #1
low speed will operate to perform the clean step.
The filtration cycle can be suspended by pressing any of the jet keys. The filtration icon will blink on the
control panel display. The filtration cycle will resume after 40 minutes from the last key press.
PROGRAMMING THE CONTROL SYSTEM
1. Clock:
Press and hold the Program key for 5 seconds to engage the programming mode. Then press the
Up or Down arrow key to change the hour setting. Once the desired hour is displayed, press the
Program or OK key to accept the selection, and move to programming the minute setting. Use the
Up or Down arrow key to change the minute setting. Once the desired minute is displayed, press
the Program or OK key to accept the selection and move to programming the filter cycle start time.
2. Filter Cycle Start Time:
To set the start time of the filter cycle, press and hold the Program key to initiate the programming
mode. Then press the Program key twice to access the filter cycle start time programming. Press
the Up or Down arrow key to cycle through the hour between 0 and 23 in increments of 1 hour.
Program default setting is 12, which depicts 12PM start time. For a midnight start time, select 0.
Once the desired start time is displayed, press the Program or OK key to accept the selection and
move to programming the filter cycle duration.
3. Filter Cycle Duration:
To set the duration of each filter cycle, press and hold the Program key to initiate the programming
mode. Then press the Program key three times to access the filter cycle duration programming.
Press the Up or Down arrow key to cycle through 0-24 hours in increments of 1 hour. Program
default is 1 hour. Once the desired duration is displayed, press the Program or OK key to accept

19 rev. 2012v1
the selection and move to programming the filter cycle frequency. It is not recommended to set the
filter cycle duration to 0.
4. Filter Cycle Frequency:
To adjust the number of filter cycles per day, press and hold the Program key to initiate the
programming mode. Then press the Program key four times to access the filter cycle frequency
programming. Press the Up or Down arrow key to cycle through the number of filter cycles, 1-4
cycles. The default setting is 2 cycles per day. Once the desired number of filter cycles is
displayed, press the Program or OK key to accept the selection and move to programming the
economy mode.
5. Economy Mode:
Press and hold the Program key to initiate the programming mode. Then press the Program key
five times to access the economy mode programming. Press the Up or Down arrow key to enable
or disable the economy mode. The display will show EP1 when the economy mode is enabled.
When the economy mode is disabled, the display will show EP0. Program default is EP1. Once the
desired setting is displayed, press the Program or OK key to accept the selection and move to
programming the economy start time.
6. Economy Start Time:
To adjust the start time of the economy mode, press and hold the Program key to initiate the
programming mode. Then press the Program key six times to access the economy start time
programming. Press the Up or Down arrow key to cycle through the hour between 0 and 23 in
increments of 1 hour. Program default setting is 0, which depicts a midnight start time. Once the
desired start time is displayed, press the Program or OK key to accept the selection and move to
programming the economy duration.
7. Economy End Time:
To set the end time of the economy mode, press and hold the Program key to initiate the
programming mode. Then press the Program key seven times to access the economy end time
programming. Press the Up or Down arrow key to cycle through 0-24 hours in increments of 1
hour. Program default is 6 hours. Once the desired duration is displayed, press the Program or
OK key to accept the selection and move to programming the temperature unit. It is not
recommended to set the economy duration to 0 hour.
8. Temperature Unit:
To adjust the temperature unit, press and hold the Program key to initiate the programming mode.
Then press the Program key eight times to access the temperature unit programming. Press the
Up or Down arrow key to toggle between Fahrenheit (°F) and Celsius (°C). Program default is °F.
Once the desired temperature unit is displayed, press the Program or OK key to accept the
selection and exit the programming sequence.
FEATURE OPERATIONS
JET SELECTOR VALVES (DIVERTER VALVES)
Your spa may be equipped with a jet selector valve (diverter valve). This valve can be used to divert jet
power from one area in the spa to another area. This valve is fully adjustable and can be used to suit
the user’s desired effect. The valve may be slightly harder to turn when the jet pump is on high speed.
This is normal due to high rate of water flow and pressure present in the valve.
