L-Acoustics kudo multi-mode wst Quick start guide

KUDO®Multi-Mode WST®System
KUDO®Système Multi-Mode WST®
VERSION 1.0
www.l-acoustics.com
EN
F
R
RIGGING PROCEDURES
PROCÉDURES D’ACCROCHAGE

www.l-acoustics.com

KUDO_RM_ML_1.0 www.l-acoustics.com 1en
EN
1SAFETY WARNINGS
All information hereafter detailed applies for the rigging structure L-ACOUSTICS®KBUMP or for one of the rigging
accessories L-ACOUSTICS®KLIFT or KJACK, hereafter designated as ‘‘the product’’.
1.1 Symbol description
Throughout this manual the potential risks are indicated by the following symbols:
The WARNING symbol indicates a potential risk of physical harm to the user or people within close
proximity to the product.
In addition, the product may also be damaged.
The CAUTION symbol notifies the user about information to prevent possible product damage.
The IMPORTANT symbol is a notification of an important recommendation of use.
1.2 Important safety instructions
1. Read this manual
2. Heed all safety warnings
3. Follow all instructions
4. The user should never incorporate equipment or accessories not approved by L-ACOUSTICS®
5. Personnel qualification
Installation and set-up should only be carried out by qualified personnel that are familiar with the
rigging techniques and safety recommendations outlined in this manual. It is recommended to attend
the training courses offered by L-ACOUSTICS®before proceeding with the installation of the
system.
6. Personnel health and safety
During installation and set-up personnel should wear protective headgear and footwear at all times.
Under no circumstances personnel should climb on the loudspeaker assembly.
!
IMP
O
RTANT
!
CAUTION
!
WARNING
!
WARNING
!
WARNING

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 2en
7. System parts and rigging inspection
All system components must be inspected before use, in order to detect any possible defects.
Please refer to the “Care and maintenance” section of this manual as well as any other manuals
pertaining to the system for a detailed description of the inspection procedure.
Any part showing any sign of defect must immediately be put aside and withdrawn from use to be
inspected by qualified service personnel.
8. Additional rigging equipment
L-ACOUSTICS®is not responsible for any rigging equipment and accessories that are not
manufactured by L-ACOUSTICS®.
It is the user’s responsibility to ensure that the Working Load Limit (WLL) of all additional
hardware rigging accessories is greater than the total weight of the loudspeaker assembly in use.
9. Suspension points
It is the user’s responsibility to ensure that the Working Load Limit (WLL) of the suspension
points and/or chain hoists is greater than the total weight of the loudspeaker assembly in use.
10. System load capacity and setup safety limits
Load capacity and setup safety limits when flying or stacking a loudspeaker assembly should be
strictly followed according to the instructions outlined in this manual.
Always refer to the mechanical data and warning indications provided in SOUNDVISION to
verify that safe system setup safety limits apply.
11. Local regulations
Some countries require higher Ultimate Strength Safety Factors and specific rigging approvals. It
is the user responsibility to ensure that any overhead suspension of L-ACOUSTICS®systems
has been made in accordance with all applicable local regulations.
As a general rule, L-ACOUSTICS®recommends the use of safety steel at all times.
12. Flying a loudspeaker assembly
Always ensure that nobody is standing underneath the loudspeaker assembly when it is being
raised. As the system is being raised check each individual component to make sure that it is
securely fastened to the component above. Never leave the system unattended during the
installation process.
13. Ground stacking a loudspeaker assembly
Do not ground stack the system on uneven ground or platform.
If the system is ground stacked on a structure, platform, or stage always check that it can
support the total weight of the system.
Secure the system to the structure, platform, or stage using ratchet straps or any other
applicable devices.
14. Dynamic load
When a loudspeaker assembly is deployed in an open air environment wind effect should be
taken into account. Wind can produce dynamic stress to the rigging components and suspension
points. If the wind force exceeds 6 bft. (Beaufort scale) it is highly recommended to lower down
and/or secure the loudspeaker assembly.
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING

KUDO_RM_ML_1.0 www.l-acoustics.com 3en
EN
15. Manual
Keep this manual in a safe place during the product lifetime. This manual forms an integral part of the
product. Reselling of the product is only possible if the user manual is available. Any changes made to
the product have to be documented in writing and passed on to the buyer in the event of resale.
1.3 EC declaration of conformity
L-ACOUSTICS®
13 rue Levacher Cintrat
Parc de la Fontaine de Jouvence
91462 Marcoussis Cedex
France
States that the following products:
Rigging structure, KBUMP
Rigging accessory, KLIFT
Rigging accessories, KJACK
Are in conformity with the provisions of:
Machinery Directive 98/37/EC
Applied rules and standards:
EN ISO 12100-1: 2004
Established at Marcoussis, France, the 12/20/2004
Jacques Spillmann
!
IMPORTANT

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 4en
2CONTENTS
1SAFETY WARNINGS 1
1.1 Symbol description ............................................................................................................................................... 1
1.2 Important safety instructions ................................................................................................................................ 1
1.3 EC declaration of conformity................................................................................................................................ 3
2CONTENTS 4
3INTRODUCTION 5
3.1 Welcome to L-ACOUSTICS®............................................................................................................................... 5
3.2 Unpacking............................................................................................................................................................. 5
4KUDO®SYSTEM 6
5KUDO®RIGGING COMPONENTS 7
5.1 KBUMP rigging structure and KJACK rigging accessories..................................................................................... 7
5.2 KLIFT rigging accessory ........................................................................................................................................ 9
6INSTALLATION 10
6.1 Flying a vertical line source array (using KBUMP) .............................................................................................. 10
6.1.1 Assembling the KUDO®enclosures and the KBUMP structure............................................................ 10
6.1.2 Flying the KUDO®array in the vertical position.................................................................................... 13
6.1.3 Taking down the array........................................................................................................................... 15
6.2 Ground stacking a vertical line source array (using KBUMP and KJACKx2)....................................................... 17
6.2.1 Stacking the KUDO®array in the vertical position................................................................................ 17
6.2.2 Disassembling the ground stacked array................................................................................................ 23
6.3 Flying a horizontal line source array (using KLIFT)............................................................................................. 25
6.3.1 Rigging and flying.................................................................................................................................... 25
6.3.2 Disassembling......................................................................................................................................... 26
7CARE AND MAINTENANCE 27
8SPECIFICATIONS 28
9APPENDIX 29
9.1 KBUMP rigging points......................................................................................................................................... 29
9.2 KLIFT site angle setting....................................................................................................................................... 30

KUDO_RM_ML_1.0 www.l-acoustics.com 5en
EN
3INTRODUCTION
3.1 Welcome to L-ACOUSTICS®
Thank you for purchasing the L-ACOUSTICS®KUDO®Multi-Mode WST®Enclosure.
This manual contains essential information on the L-ACOUSTICS®KUDO®rigging procedures. Read this manual
carefully in order to make familiar with these procedures.
As part of a continuous evolution of techniques and standards, L-ACOUSTICS®reserves the right to
change the specifications of the product and the content of this manual without prior notice. Please check
the L-ACOUSTICS®internet website @ www.l-acoustics.com on a regular basis for latest update.
If the product requires repair or if information about the warranty is needed, please contact an approved
L-ACOUSTICS®distributor. In order to obtain the address of the nearest distributor go to the internet website
@ www.l-acoustics.com.
3.2 Unpacking
Carefully open the shipping carton and check the product for any noticeable damage. Each L-ACOUSTICS®product is
tested and inspected before leaving the factory and should arrive in perfect condition.
If found to be damaged, notify the shipping company or the distributor immediately. Only the consignee may initiate a
claim with the carrier for damage incurred during shipping. Be sure to save the carton and packing materials for the
carrier's inspection.
The KBUMP package comprises the following elements:
•One L-ACOUSTICS®KBUMP rigging structure with 4 ball locking pins hereafter designated as ‘‘BLP’’.
•Two shackles fitted with 22 mm/0.87 in. screw pin, hereafter designated as ‘‘22-shackles’’.
The KLIFT package comprises the following elements:
•One L-ACOUSTICS®KLIFT rigging bar.
•One shackle fitted with 18 mm/0.71 in. screw pin, hereafter designated as ‘‘18-shackle’’.
The KJACK package comprises the following elements:
•Two wheel-handled threaded rods.
•Two U-brackets attached to support base.
KBUMP
KLIFT
KJACK
Figure 1: KUDO®rigging components

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 6en
4KUDO®SYSTEM
The L-ACOUSTICS®KBUMP structure and the KLIFT and KJACK accessories are dedicated to fly and stack the
KUDO®system.
The system approach developed by L-ACOUSTICS®for KUDO®comprises the elements needed to fully take
advantage of the possible configurations and optimize the system. The main components of the system are:
KUDO® Full range active 3-way loudspeaker enclosure
KBUMP  Rigging structure to fly or stack a KUDO®array in the vertical orientation
KJACK  Rigging accessories (x2) used in conjunction with KBUMP to stack KUDO®
KLIFT  Rigging accessory to fly a KUDO®array in the horizontal orientation
KPLA-2, KCOV  Removable front dolly board and protective cover to ship the KUDO®
SB118, SB28  Subwoofer enclosures for extended low frequency response
LA8  Dedicated amplified controller
SOUNDVISION  Acoustical and mechanical modeling software
LA NETWORK MANAGER  Remote control software
Figure 2: KUDO®system components
Each system configuration should first be modeled using the L-ACOUSTICS®SOUNDVISION software to verify
that safe system setup safety limits apply. A detailed description on the use of the SOUNDVISION software is beyond
the scope of this manual. Please refer to the appropriate documentation, also available on the L-ACOUSTICS®internet
website @ www.l-acoustics.com.
KUDO®
KBUMP
KLIFT
SOUNDVISION
LA8 LA NETWORK MANAGER
KJACKx2
KPLA-2 KCO
V
SB118 SB28

KUDO_RM_ML_1.0 www.l-acoustics.com 7en
EN
5KUDO®RIGGING COMPONENTS
5.1 KBUMP rigging structure and KJACK rigging accessories
The L-ACOUSTICS®KBUMP rigging structure has been exclusively designed to fly or stack the L-ACOUSTICS®
KUDO®enclosures as a variable-curvature, vertical line source array.
Figure 3: KBUMP with two shackles
The KBUMP is supplied with two 22-shackles (Figure 3) that can support up to 2000 kg / 4409 lb. each with an Ultimate
Strength Safety Factor of 5:1. Thirteen pick up points are available on the central spreader bar section and side bars
allowing for a wide variety of hoist set up. Please refer to appendix 9.1 for a detailed description of the KBUMP rigging
options examples.
KBUMP can fly a maximum amount of weight of 1830 kg / 4034 lb.
Therefore, a maximum of 21 KUDO®enclosures can be flown underneath the KBUMP rigging
structure without any additional load.
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
that safe system setup safety limits apply (see section ‘‘Mechanical Data’’ in the SOUNDVISION
software).
!
WARNING

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 8en
Figure 4: KBUMP and KJACK elements for stacking a KUDO®array
KBUMP can also be used as a horizontal or tilted ground stacking platform using two complimentary KJACK accessories
(Figure 4).
A maximum of 6 KUDO®can be stacked onto a horizontally configured KBUMP (site angle set at 0°).
When KBUMP is used with the complimentary KJACK accessories so as to form a tilted platform, the
following limitations apply:
K-BUMP
site angle [-10°,-9°[ [-9°,-7°[ [-7°,-6°[ [-6°,-1.5°] [1.5°,2°[ [2°,9°[ [9°,10°]
Maximum
number
of
KUDO®
3 4 5 6 6 5 4
And as a general guideline, always refer to the mechanical data and warning indications provided in
SOUNDVISION to verify that safe system setup safety limits apply (see section ‘‘Mechanical Data’’ in
the SOUNDVISION software).
Ensure that KBUMP is physically secured to the stacking platform or subwoofer stack using ratchet
straps or any applicable materials.
!
WARNING

KUDO_RM_ML_1.0 www.l-acoustics.com 9en
EN
5.2 KLIFT rigging accessory
The L-ACOUSTICS®KLIFT rigging accessory has been exclusively designed to fly the L-ACOUSTICS®KUDO®
enclosures as a 10°-constant curvature, horizontal line source array.
The KLIFT is supplied with one 18-shackle (Figure 5) that can support up to 1250 kg / 2756 lb. with an Ultimate
Strength Safety Factor of 5:1. Twelve pick up points are available on the KLIFT to set the site angle. Please refer to
appendix 9.2 for a detailed description of the KLIFT available configurations.
Figure 5: KLIFT rigging accessory with shackle
One or more KLIFT accessories can fly horizontal arrays composed of a minimum of 2 KUDO®enclosures. Figure 6
shows six examples of single or dual suspension point arrays: it can be seen that only symmetrical configurations are
available in order to properly balance the array’s center of gravity.
A single KLIFT can support a maximum amount of weight of 522 kg / 1150 lb. and can therefore
support up to 6 KUDO®enclosures without any additional load.
Any configuration containing one or more KLIFT accessories should be prior modeled using
SOUNDVISION software.
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
that safe system setup safety limits apply (see section ‘‘Mechanical Data’’ in the SOUNDVISION
software).
Figure 6: Two to seven-KUDO®horizontal arrays with KLIFT accessories
!
WARNING

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 10 en
6INSTALLATION
6.1 Flying a vertical line source array (using KBUMP)
Before installation, in order to position and correctly place the array the user should use L-ACOUSTICS®
SOUNDVISION software to determine:
•Correct hole position of the shackles on the KBUMP
•Number of KUDO®enclosures
•Inter-angles between KUDO®enclosures
•Check of the system’s mechanical conformity
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
that safe system setup safety limits apply (see section ‘‘Mechanical Data’’ in the SOUNDVISION
software).
The rigging method to fly the KUDO®system comprises the elements KBUMP and KUDO®. Attaching one element to
the next is done by using fully integrated components unique to each KUDO®. There is no need for any other external
fastening accessory. Each KUDO®enclosure incorporates two rotating arms that lock into the device above, and four
rigging points that lock into the device below, using ball locking pins (BLP).
The following procedures describe how to fly a vertical KUDO®line source array, and how to disassemble it.
6.1.1 Assembling the KUDO®enclosures and the KBUMP structure
All along the following procedure systematically ensure that each BLP is correctly secured by pulling
on it, and that screw pin is correctly secured on each shackle anchor.
1. Line up the KBUMP structure and all KUDO®enclosures at the rigging location.
Figure 7: Lining up the KUDO®enclosures and the KBUMP structure
!
WARNING
!
WARNING

KUDO_RM_ML_1.0 www.l-acoustics.com 11 en
EN
2. On each KUDO®enclosure, adjust the K-LOUVER®panels (see the ‘‘KUDO ®’’ user manual).
3. On each KUDO®enclosure, remove the 8 BLP.
4. On both sides of each KUDO®enclosure, push forward the rotating arm tab (accessible in the handle pocket) and
secure the front rigging point using the corresponding BLP.
Figure 8: Securing the front rigging points
5. Align all KUDO®enclosure front rigging points (do not attach).
6. On both sides of each KUDO®enclosure, push out the rotating arm and attach the rear inter-enclosure BLP (do not
pre-select angle).
Figure 9: Attaching the rear inter-enclosure BLP (angle selection and front rigging points are not secured)

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 12 en
7. On both sides of the first KUDO®enclosure, select the 5° angle (the top enclosure will be parallel to the KBUMP).
Figure 10: First enclosure 5° angle setting
8. On the KBUMP structure, ensure that the 4 BLP are located in their inner storage holes.
9. a. Place the KBUMP in position by aligning both stop tabs with the top KUDO®enclosure’s front rigging points.
The KBUMP should be installed with the serial number tag oriented towards the
rear of the array.
Support the KBUMP in order to prevent it from falling.
b. Attach the 4 BLP in the outer storage holes so as to secure the KBUMP to the top KUDO®enclosure.
10. Attach the 22-shackles according to the specifications detailed in appendix 9.1.
Figure 11: Securing the KBUMP to the first KUDO®enclosure, positioning the shackles
Inner storage hole
Outer storage hole
Stop tab
!
WARNING

KUDO_RM_ML_1.0 www.l-acoustics.com 13 en
EN
11. For each KUDO®enclosure, remove both dolly board BLP by pulling on both lanyards.
Figure 12: Pulling on the dolly board BLP lanyards
12. On each KUDO®enclosure, connect the loudspeaker cables (refer to the ‘‘KUDO®’’ user manual).
Secure the loudspeaker cables to the KBUMP.
For clarity purposes the loudspeaker cables will not be represented on the following figures.
6.1.2 Flying the KUDO®array in the vertical position
All along the following procedure, systematically ensure that each BLP is correctly secured by
pulling on it.
Ensure that no one is standing under or in close proximity to the system when it is being
raised in the air.
1. Attach the motor hooks to the KBUMP shackles. Lift the KBUMP/first KUDO
®
assembly in the horizontal position.
Figure 13: Raising the KBUMP/first KUDO®assembly
!
IMPORTANT
!
WARNING

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 14 en
2. Select the desired angle between KUDO®#1 and #2 (the rotating arms slide freely between the enclosures).
Figure 14: Selecting the angle between KUDO®#1 and #2
3. Raise the system to lift KUDO®#2 into position.
Figure 15: Raising KUDO®#2 into position

KUDO_RM_ML_1.0 www.l-acoustics.com 15 en
EN
4. Secure KUDO®#2 to KUDO®#1 by attaching both BLP to both front rigging points.
Figure 16: Securing KUDO®#2 to KUDO®#1
5. Repeat steps 2 through 4 for all KUDO®enclosures.
6. Arrange / stack the dolly boards.
6.1.3 Taking down the array
1. Remove both lower front BLP from the next to bottom KUDO®enclosure.
Figure 17: Detaching the next to bottom enclosure’s front rigging points

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 16 en
2. Lower the system so as to land the bottom enclosure on its dolly board, attach both BLP.
3. Remove both rear angle selection BLP on the bottom enclosure (both rear inter-enclosure BLP remain attached).
Figure 18: Removing both rear angle selection BLP
4. Repeat steps 1 through 3 until the entire system is landed.
5. Detach the motor hooks.
6. Take down the KBUMP by removing its 4 BLP and placing them into the 4 inner storage holes.
When removing the BLP support KBUMP in order to prevent it from falling.
7. For each KUDO®enclosure, remove all remaining BLP.
8. On both sides of each KUDO®enclosure:
a. Push the rotating arm into the captive
position.
b. Arrange the front rigging point by
pushing the rigging tab inwards so that it
is flush with the enclosure.
c. Place the 2 BLP in their storage
locations (the rotating arm will be
locked).
Figure 19: Preparing a KUDO®enclosure for transportation
a.
b.
c.
!
WARNING

KUDO_RM_ML_1.0 www.l-acoustics.com 17 en
EN
6.2 Ground stacking a vertical line source array (using KBUMP and KJACKx2)
Before installation, in order to position and correctly place the array the user should use L-ACOUSTICS®
SOUNDVISION software to determine:
•Number of KUDO®enclosures
•Angle between KBUMP and ground
•Inter-angle between KUDO®enclosures
•Check of the system’s mechanical conformity
Always refer to the mechanical data and warning indications provided in SOUNDVISION to verify
that safe system setup safety limits apply (see section ‘‘Mechanical Data’’ in the SOUNDVISION
software).
Ensure that KBUMP is physically secured to the stacking platform or subwoofer stack using ratchet
straps or any applicable materials.
The rigging method to stack the KUDO®system comprises the KBUMP and KUDO®elements as well as the KJACK
accessories. Attaching one element to the next is done by using fully integrated components unique to each KUDO®.
There is no need for any additional fastening accessory. Each KUDO®enclosure incorporates two rotating arms that
lock into the device above, and four rigging points that lock into the device below, using ball locking pins (BLP).
The following procedures describe how to stack a vertical KUDO®line source array, and how to disassemble it.
6.2.1 Stacking the KUDO®array in the vertical position
All along the following procedure systematically ensure that each BLP is correctly secured by pulling
on it.
1. Line up the KUDO®enclosures and the KBUMP structure at the stacking location.
Figure 20: KUDO®and KBUMP at the stacking location
!
WARNING
!
WARNING

KUDO®MULTI-MODE WST®SYSTEM
Rigging Procedures
VERSION 1.0
KUDO_RM_ML_1.0 www.l-acoustics.com 18 en
2. On each KUDO
®
enclosure, adjust the K-LOUVER
®
panels to the desired settings (see the ‘‘KUDO
®
’’ user manual ).
3. On each KUDO®enclosure, remove the 8 BLP.
4. On both sides of each KUDO®enclosure, push forward the rotating arm tab (accessible in the handle pocket)
and secure the front rigging point using the dedicated BLP.
Figure 21: Securing the front rigging points
5. For each rotating arm on each KUDO®enclosure:
a. Manipulate the rotating arm to approx 10° to free the front rigging point.
b. Align the front rigging point and attach to next KUDO®enclosure.
Figure 22: Securing the front rigging points to the next KUDO®
b.
a.
