Lütze TLM-10 User manual

Transportation Solutions
TLM-10 Configuration tool
Operating instructions
Version 01

TLM-10 Configuration tool
2
Lütze Transportation GmbH reserves the right to make changes to its products in the interest of
further technical development. These changes are not necessarily documented in each individual
case.
These operating instructions are an integral part of the device and contain important information
on safety and operation. Read the operating instructions before use to exclude possible dangers
and to ensure proper use.
These operating instructions and the information contained therein have been compiled with due
care. However, Lütze accepts no liability for printing or other errors or for any damage resulting
therefrom.
The brands and product names mentioned in this book are trademarks or registered trademarks
of the respective titleholders.
©Copyright 2023 by Lütze Transportation GmbH. All rights reserved.
Contact:
Lütze Transportation GmbH
Bruckwiesenstraße 17-19
D-71384 Weinstadt - Großheppach
Germany
Phone: [phone]
Fax: [phone]
E-Mail: Sales.Transportat[email protected]
Internet: www.luetze-transportation.com

TLM-10 Configuration tool
3
Content
1Introduction..................................................................................5
1.1 About this operating manual .............................................................................5
2General Information.....................................................................6
2.1 Symbol Description...........................................................................................6
2.1.1 Safety Messages ................................................................................................................6
2.1.2 Handling Notes ...................................................................................................................6
2.2 Copyright...........................................................................................................6
2.3 Disclaimer.........................................................................................................7
2.4 Standards and norms........................................................................................7
2.4.1 Observe other applicable documents.................................................................................7
3Safety............................................................................................8
3.1 Applicable documents.......................................................................................8
3.2 Safety information.............................................................................................8
3.2.1 Contents of the operating instructions................................................................................8
3.2.2 Appropriate use...................................................................................................................8
3.2.3 Addressees.........................................................................................................................8
3.2.3.1 Operating Personnel..................................................................................................8
3.2.4 Responsibility of the operator.............................................................................................9
4Product Overview.......................................................................10
4.1 TLM-10 Configuration tool...............................................................................10
4.1.1 The TLM-10 device –short description ........................................................................... 10
5Comissioning .............................................................................11
5.1 Installation Npcap ...........................................................................................11
6User interface.............................................................................12
6.1 Log-in..............................................................................................................12
6.2 Settings...........................................................................................................14
6.2.1 Language......................................................................................................................... 14
6.2.2 Changing Account Password........................................................................................... 15
6.2.3 Log out - Safe exit............................................................................................................ 16
6.3 Overview and information on the nodes (NODES)..........................................16
6.3.1 Background to the Origin of the NODE List..................................................................... 16
6.3.2 Special Role Locally Connected Device (NODE) ID 01 .................................................. 17
6.3.3 Network Structure............................................................................................................ 18
6.3.4 Reachable devices .......................................................................................................... 18
6.3.5 Display of the nodes ........................................................................................................ 20
6.4 Overview Quick Menu Bar ..............................................................................21
6.4.1 Device-specific menu bar ................................................................................................ 22
6.4.1.1 UPGRADE NODE................................................................................................... 22
6.4.1.2 Restart Node........................................................................................................... 23
6.4.1.3 SAVE CONFIGURATION ....................................................................................... 23
6.4.1.4 LOAD CONFIGURATION....................................................................................... 24

TLM-10 Configuration tool
4
6.4.1.5 REFRESH NODE.................................................................................................... 26
6.4.1.6 OPTIONS................................................................................................................ 26
6.4.1.7 FACTORY RESET NODE ...................................................................................... 27
6.4.2 Selective menu bar.......................................................................................................... 28
6.4.2.1 Upgrade nodes........................................................................................................ 29
6.4.2.2 Restart Nodes ......................................................................................................... 29
6.4.2.3 Change Domain...................................................................................................... 30
6.4.2.4 Refresh Nodes ........................................................................................................ 32
6.4.2.5 Options Dropdown .................................................................................................. 32
6.5 Status query nodes.........................................................................................33
6.5.1.1 Status OK –Device’s screen .................................................................................. 34
7Configurations............................................................................35
7.1 Configuration of a Node..................................................................................35
7.1.1 TL-Domain....................................................................................................................... 36
7.1.2 Extended Seed ................................................................................................................ 37
7.1.3 Network settings .............................................................................................................. 38
7.1.4 Heartbeat Details............................................................................................................. 39
7.2 Configuration of multiple devices (nodes).......................................................40
7.2.1 Marking individual nodes ................................................................................................. 41
7.2.2 Marking several nodes..................................................................................................... 42
7.2.3 Upgrade Nodes................................................................................................................ 43
7.2.4 Restarting of selected nodes........................................................................................... 43
7.2.5 Change Domain Password.............................................................................................. 44
7.2.6 Updating the data of all nodes......................................................................................... 45
8Overview of parameter limitations............................................45
8.1 General...........................................................................................................45
8.2 TL DOMAIN ....................................................................................................45
8.3 EXTENDED SEED..........................................................................................45
8.4 HEARTBEAT DETAILS...................................................................................45
9Troubleshooting / FAQs ............................................................46
9.1 The tool starts and finds no nodes despite correct connection / the window
remains white..........................................................................................................46
9.2 I have changed a parameter, but the behavior of the device has not changed
accordingly..............................................................................................................46
9.3 After changing the parameters of a device, one or more devices no longer
appear in the node list.............................................................................................46
9.4 One or more nodes display N/A instead of the parameters.............................46
10 More information........................................................................47
10.1 EULA TLM-10 Configuration Framework........................................................47
11 Service........................................................................................48
12 Revision history.........................................................................49

TLM-10 Configuration tool
5
1 Introduction
This operating manual is a part of the TLM-10 Configuration tool. It contains important
information about the safety and operation of the devices.
This manual must be read and understood before installing, operating,
maintaining, or disposing of the device. Keep this document for later use.
Risk of injury and damage to property due to non-observance of the
operating instructions.
Always read these operating instructions before planning the system in order
to avoid or reduce risks and damage.
These operating instructions contain important information on safety,
commissioning, operation, maintenance, and disposal of the device.
Always keep the document at hand. This applies until the device is disposed
of. Pass on the operating instructions if the device is sold, distributed, or
loaned.
You can also find these operating instructions at
www.luetze-transportation.de.
Enter either the product name or the product number in the search field.
Select the product in the displayed search result. At the bottom of the
respective product page, you will find the documents belonging to the
product.
1.1 About this operating manual
This instruction provides information on how to handle the products throughout its entire product
life cycle, from delivery to disposal.
Further documents apply in addition to this operating manual.
If you have suggestions for improving this document, please contact Lütze Transportation GmbH.
The contact details can be found in chapter 11. Service.

TLM-10 Configuration tool
6
2 General Information
2.1 Symbol Description
2.1.1 Safety Messages
This document contains several safety messages. Each safety message contains a defined
signal word and a color. The color and the word are referring to an alert level. There are 4 levels.
The safety messages point out hazardous situations and give information on how to avoid these.
Indicates a hazardous situation, which if not avoided will result in death
or serious injury.
Indicates a hazardous situation, which if not avoided can result in death
or serious injury.
Indicates a hazardous situation, which if not avoided can result in minor
or moderate injury.
Indicates a situation which could damage the product or the
environment. This notice does not apply to personal injury.
2.1.2 Handling Notes
Additionally, the following symbols can be found. These refer to important technical information
and instructions:
Refers to important technical information. This indicates to the user a
specific action that must be performed to operate the device safely.
2.2 Copyright
These instructions are only intended for the operator and his personnel. The contents may not be
passed on, reproduced, utilized or otherwise communicated to third parties, either in whole or in
part, unless this has been expressly permitted in writing by Lütze Transportation GmbH.
General data, text, images and drawings are copyrighted and are liable to the industrial property
right. Contravention can be prosecuted. The named brands and product names in this document
are trademarks or registered trademarks by titleholder.

TLM-10 Configuration tool
7
2.3 Disclaimer
The document was written under consideration of the applied standards, regulations and the
current state of technology.
The content is verified of accuracy. Discrepancies are not excluded. For those discrepancies we
disclaim liability. Applicable changes and additional information will be in the next version of the
document.
The Lütze Transportation GmbH does not assume liability for any damages and accidents of
following reasons:
•Nonobservance of the document
•Untrained and unqualified personnel
•Non conventional use
•Non approved reconstructions and functional modifications of the product
•Using non original or non-admitted parts or equipment
2.4 Standards and norms
The product is state of the art and follows the specified safety regulations and European
standards (DIN EN50657:2017 according to basic integrity).
The latest versions of the standards and further information about the
product can be found in the corresponding data sheets that are valid
with this document.
2.4.1 Observe other applicable documents
When operating the device, please also observe all operating instructions enclosed with other
components of your system.
These operating instructions contain important information on safety,
commissioning, operation, maintenance and disposal of the unit.
Always keep the document handy. This applies until the appliance is
disposed of. Pass on the operating instructions if the unit is sold, distributed
or lent out.
For reasons of clarity, we would like to point out that these operating instructions cannot describe
all conceivable problems in connection with the use of this device.
Should you require further information or encounter special problems that are not dealt with in
sufficient detail in the operating instructions, you can request the necessary information about
service from Lütze Transportation GmbH.
(See also chapter 11. Service)

TLM-10 Configuration tool
8
3 Safety
3.1 Applicable documents
-
3.2 Safety information
3.2.1 Contents of the operating instructions
These instructions must be read and understood before installing,
operating or maintaining the device.
These operating instructions must be read and observed before any work is carried out on or with
the units. This applies to all persons who come into contact with the devices. Trained personnel
and specialists, especially electricians (see also chapter „Electrically qualified persons“) who
have already worked with similar equipment should also have read and understood the manual.
3.2.2 Appropriate use
The devices are designed exclusively for railway use. The intended use includes the procedure
according to the manual. Proper and safe operation of the product requires proper transport,
storage, installation, and assembly as well as careful operation and maintenance.
3.2.3 Addressees
This operating instruction is directed towards planers, project managers and programmers, as
well as to staff authorized to commission, operate, and maintain the devices and systems.
A distinction is made between various qualification levels of the staff.
3.2.3.1 Operating Personnel
Only qualified personnel may carry out the following work on the modules:
Working range
Competency
Transport and storage
Trained Employee
Installation, commissioning,
decommissioning
Experts
Operation
Trained Employee
Servicing and maintenance
Experts
Troubleshooting
Experts
Risk of injury by usage through insufficient qualified operating
personnel! Misusage through performed insufficient or qualified
personnel can cause property damage and personal injuries.
•Tasks which apply special procedures should be done by trained and
qualified employees or experts, especially electricians.
(according to EN 60204-1)

TLM-10 Configuration tool
9
Trained Employee
The employee was trained by the employer on the task and possible hazardous situations.
The employee does not have any technical knowledge.
Experts
The employee has a technical education, knowledge and/or experience in the required field.
The employee is capable to perform specific operations on and with the product.
Electrically qualified persons
The employee has a technical education in the required field. The employee is capable to
perform special operations on and with the product. The different sections of the document refer
to the qualification level of the operating personnel.
According to European Standard EN 50110-1:2008-09-01 Section 3.2.3.
The individual sections refer to the qualification level of the personnel.
3.2.4 Responsibility of the operator
The customer is subject to an obligation to report back when safety-related
errors are discovered.
Since the device is used in a commercial area, the operator of the device is subject to the legal
obligations for occupational safety:
•The operator of the device is obliged to instruct the operating personnel and to inform
himself about the industrial safety regulations.
•The operator must ensure that safety, accident prevention and environmental protection
regulations are observed.
•The operator must make an appropriate risk assessment on the Workplace/location to
detect and warn of special hazards.
•The manual must be kept in the immediate vicinity of the device.
•The information in the operating instructions must be followed.
•The device may only be operated in technically perfect condition.

TLM-10 Configuration tool
10
4 Product Overview
4.1 TLM-10 Configuration tool
The configuration tool for the TLM-10 units is designed to enable powerline communication in rail
vehicles.
The TLM-10 configuration tool allows the user to configure his TLM-10
devices according to his wishes and to update the firmware and
configuration.
The TLM-10 configuration tool is available from our support at:
[e-mail]
4.1.1 The TLM-10 device –short description
The Train Line Modem 10 (TLM-10) is a device for transmitting Ethernet data in rail vehicles via
existing and occupied power lines.
The device uses the existing NF cabling for data transmission. A tap-proof data transfer is
guaranteed by a 128-bit AES encryption. The bandwidth of the transmission line is constantly
determined via a DSP, which ensures an optimal data throughput.
Since the line length changes when vehicles are coupled, this means that the best possible data
throughput can always be achieved.
The following types of TLM-10 are currently available:
1. Part no. 806601, type TLM-10 10TE DC 24V-110V PI PB, rack mounting
2. Part no. 806610, type TLM-10 10TE DC 24V-110V FM, flange mounting*
3. Part no. 806611, type TLM-10 10TE DC 24V-110V FM PB, flange mounting
4. Part no. 806710, type TLM-10 10TE FM POE, flange mounting
*Former PICASO item number: 501010100110

TLM-10 Configuration tool
11
5 Comissioning
5.1 Installation Npcap
Before using the TLM10 tool, the program Npcap must be installed in
version 1.55 or higher.
The tool can be found here:
Npcap: Windows Packet Capture Library & Driver (nmap.org).
Npcap: Windows Packet Capture Library & Driver
Npcap is the package capture library for modern Windows versions.
The fast, secure and compatible successor of WinPcap. Npcap is free to use.
The default settings can be kept during installation.

TLM-10 Configuration tool
12
6 User interface
6.1 Log-in
1. Open the configuration tool by double-clicking on the program icon.
Installation of the program is not required.
The login password is available from our support at:
[e-mail]
2. The program starts in the language set in Windows, if this language is English, French, or
German. English is the default language if your system is set to another language.
Select the language here.
3. Enter your username and password.

TLM-10 Configuration tool
13
4. After entering the username and password
the application starts within a maximum of 15 seconds.
5. The user interface appears. By clicking the Refresh Nodes button , all devices on the
network are detected and displayed in the list shown on the left.
The user interface adapts to the respective screen size of your device. (Responsive Design).
If no nodes are displayed or the program starts but is displayed as a
white window, please consult Chapter 9 Troubleshooting / FAQs.

TLM-10 Configuration tool
14
6.2 Settings
The Settings symbol is located at the top right.
Basic settings can be made here.
6.2.1 Language
The language can still be set after login.
1. To change the language, click on the Settings icon in the upper right corner and then
on Settings.
2. A new window will open. By clicking on Language, you can set the language.
3. By selecting a language from the drop-down menu Set application language, the
language of the program is changed immediately.
The setting does not need to be confirmed as it is automatically applied.

TLM-10 Configuration tool
15
6.2.2 Changing Account Password
The account password can be changed.
To change the password, click on the Settings icon at the top right and then on Settings:
A new window opens. You can set a new password by clicking on Account Password.
1. To do this, first enter your old password in the Previous password line.
2. Then think of a new password and enter the new password at New password.
3. Confirm your new password by entering it again in the Confirm Password line.
4. Confirm your entry by pressing CHANGE PASSWORD.
5. Now you have set a new password.
If the user forgets his password, he must download the configuration
tool again and log in with the original password.

TLM-10 Configuration tool
16
6.2.3 Log out - Safe exit
Click on Log out to exit the application.
If you want to exit the application completely, you must click on
Settings / Log out.
You must log in again when you open the application again. This
ensures that no unauthorized person can make changes.
6.3 Overview and information on the nodes (NODES)
6.3.1 Background to the Origin of the NODE List
A NODE (node) refers to a device on the network. (For example, a NODE is the TLM-10 device).
The list of NODES (nodes) is created automatically by the tool as soon as it searches for
devices on the network. The list of nodes is regenerated each time the program is started, each
time all nodes are updated, and each time the firmware of one or more nodes is updated.
Depending on which network is identified first, the arrangement of the nodes may vary.

TLM-10 Configuration tool
17
6.3.2 Special Role Locally Connected Device (NODE) ID 01
Each unit is displayed with a human-readable ID, e.g., "01, 02, 03". This is to make it easier for
the user to identify the units.
The numbering is done in the order in which the devices are identified
in the network.
The device with ID 01 is one of the nodes that is directly connected to the configuration computer
or to a local switch. This is to help the user to identify the local device at any time. All local nodes
are marked with the local node symbol: .
If several nodes are connected via a switch, for example, all nodes that can be reached via
Ethernet are marked with the symbol . All nodes that can be reached indirectly (via another
node) do not have this symbol.
If the computer is disconnected from the device with ID 1 and
connected to another device, the directly connected device is marked
with ID 1.
The locally connected device is always marked with 01. If several devices are
connected to one switch, the devices directly connected to the switch are
marked with the local node symbol:

TLM-10 Configuration tool
18
6.3.3 Network Structure
Since there can be multiple TLM10 (TL) networks on an Ethernet network, the UI provides a
visual representation of the connected networks. For example, if the computer is connected to a
switch, there may be multiple local nodes. Local nodes are marked with the icon. If multiple
local nodes exist, all nodes belonging to a domain are displayed under the respective local node.
The network section in which two or more nodes communicate is described as a domain.
In the example shown here, nodes 01 - 03 belong to network 1 (domain 1) and nodes 04 - 05
belong to network 2 (domain 2).
6.3.4 Reachable devices
The following example is intended to illustrate which nodes in a given network are identifiable
and configurable.
In the image above, the configuration tool is executed on the laptop shown. All nodes connected
directly via Ethernet are identified by the tool as Local Nodes and marked with the corresponding
symbol " ". All devices directly connected to these Local Nodes can be identified and
configured by means of the tool. All devices that can be configured by the laptop shown are
enclosed by the large green rectangle in the graphic above.

TLM-10 Configuration tool
19
In the above figures the devices (in the case of updating all nodes) are not necessarily assigned
the same NODE ID.
This behavior always occurs when the entire network is re-identified. This behavior is triggered by
pressing the "Update nodes" button of the selective menu bar (see chapter 6.4.2 Selective menu
bar).
Furthermore, this behavior can occur after firmware upgrade of several local nodes. If the
currently selected node (green bar to the left of the node tile) is identified again after all nodes
have been updated, the selection is retained even if the order of the nodes is changed.

TLM-10 Configuration tool
20
6.3.5 Display of the nodes
On the left side below the menu bar, you will see an overview of the created nodes with further
information:
1. Node [number].
All nodes in the same network are recognized at the start of the program and uniquely identified
by their MAC address.
2. Firmware [version number]
The firmware version of the selected node is displayed.
Example of a firmware version: VXX.XX.XXXX with X element [0,9]
3. Configuration [version number]
The identification of the TLM's configuration is displayed here.
Example of a configuration version: CXX.XX.XXXX with X element [0,9]
4. The green tick indicates the correct operation of the device.
NOTE: See also the following chapter "6.5 Status query nodes".
5. Local node icon
This icon is displayed if the given node is a local node and is connected to the TLM configuration
tool directly or via a switch.
