L2A CS408 Manual

Nottingham ENGLAN
D
Full Compact PA Systems
CS408 with 2 x10” PA Speakers
CS415 with 2 x 12” PA Speakers
Owners Manual & Instruction Guide

Nottingham ENGLAN
D
Thank you for choosing the L2A CS range of complete compact PA systems. We’re confident that
your purchase will give you years of service and the high quality of sound reproduction that our
customers have come to expect. We pride ourselves in designing the right product for the right
application. We have listened to our customers and have designed what we consider to be the
best product in both performance and value for money that is available on the market today.
Please take some time to read this manual and then keep it somewhere safe for future reference.
Also, here at L2A, we welcome your feedback and information. We like to know what you’re
using your L2A product for!
Please take a few minutes to register your purchase online at www.l2audio.co.uk/warranty
within 14 days of purchase. Failure to do so could affect your warranty. This information is for
our information only and will not be passed on to any third party. Complete customer
satisfaction is our goal at L2A. If you have any questions, technical or otherwise please drop us an
email at [email protected].
Once again, many thanks for your purchase.........
The L2A team.

INTRODUCTION
This manual is designed to help you get the most out of your L2A CS complete compact PA
system. The CS range is a range of powered mixer heads complete with speakers, leads and a
microphone.
The speakers have 10” and a horn in the CS408 system and 12” and a horn in the CS415. Both
have ‘top hats’ on the underside to enable you to place them on speaker stands (available from
www.musicgeardirect.co.uk).
It is the ideal system for any application from education use to rehearsal rooms. There are 4
separate channels to each of the mixer heads for multiple inputs. The mixer also has built in vocal
effects. This is the ultimate in cost affective ‘plug in and go’ PA systems. Please take time to read
through this manual to familiarise yourself with all the functions that are at your fingertips.
Front Panels of CS408 & CS415.
1. Bass. This is used to boost or cut the amount of bass or low frequencies to the channel. The
12 0 clock position is ‘0’. This is the optimum setting for the channel and indicates that bass
has not been either increased or decreased. Be careful not to wind in too much bass as this
could result in a low rumble type sound called feedback occurring and could potentially
damage your speakers.

2. Treble. This is used to boost or cut the amount of treble or high frequencies to the channel.
The 12 0’ clock position is ‘0’. This is the optimum setting for the channel and indicates that
treble has not been either increased or decreased. Be careful not to wind in too much
treble as this could result in a high whistling type sound called feedback occurring and
could potentially damage your speakers.
3. Level. This is to adjust the amount of volume to the channel.
4. EFX. This is to adjust the amount of reverb to the channel.
5. Mic. This is a low impedance input for connecting a microphone. Often referred to as an
XLR input.
6. Line. This is a high impedance input for connecting instruments, etc, or anything that
requires a ¼” jack. Please make sure that you are using a screened instrument lead and not
a speaker lead when using this input. They look very similar.
7. Master bass. This is to adjust the overall bass. As with the individual channel, the zero
position is at 12 0’ clock so bass can be reduced as well as increased.
8. Master treble. This is to adjust the overall treble. As with the individual channel, the zero
position is at 12 0’ clock so treble can be reduced as well as increased.
9. Reverb/Depth (on CS415). This is to adjust the overall reverb or DSP effect.
10. Footswitch. This is to plug in a footswitch to enable the effects to be turned on and off
(sold separately). This is useful for speaking in between singing.
11. Power. This is the power light that indicates that the mixer is switched on when
illuminated.
12. Master volume. This adjusts the overall volume to all channels simultaneously.
13. Music volume. This adjusts the amount of music volume coming into the mixer when a CD/
MP3/tape player, etc, is plugged into the Music in inputs.
14. Music in. This is used to plug a music source into. The inputs are via phono (sometimes
referred to as RCA) inputs. This cable is available separately from
www.musicgeardirect.co.uk.
15. Rec out. This is to plug any recording device into to allow you to record anything that is
plugged into the inputs of the mixer.
16. Graphic Equalizer (CS415 only). This allows you to cut or boost certain frequencies to help
enhance the mix. The middle of each graphic is your 0dB starting point. Frequencies tend to
be cut or ‘notched out’ more than boosted. Ideal if you are in a room which does not have
particularly good acoustics. You can use the graphic to cut certain frequencies that
sometimes tend to feedback.

17. DSP (CS415 only). This is a rotary knob that allows you to choose one of the 16 DSP effects
that are built into the mixer. A list of all effects is listed below
Rear Panel Of The CS Mixer Range
19
18
20
21
18. Power. This is to switch the mixer on and off.
19. AC Power connector. This is where the mains IEC plugs in. It also houses the internal AC
power fuse.
20. Speaker. These are outputs that connect to the speakers supplied. Please use the leads
provided. If longer leads are required they can be purchased from
www.musicgeardirect.co.uk.
21. Line out. This is used to connect the mixer to another mixer input source. This is useful if
you need to amplify more speakers for a larger application.

WARRANTY TERMS AND CONDITIONS
1. L2A is exclusively distributed by the MGD group limited (hereinafter referred to as
‘MGD’)
2. MGD or any MGD authorised agent warrant that the products supplied are free from
defective material or workmanship. This warranty is for a period of one year from date of
purchase. (Exceptions are listed in points 6 & 7)
3. The product should be registered within 14 days of purchase. There is a dedicated on line
form at www.l2audio.co.uk/warranty. If you are not able to register online, please
contact MGD at the address below within 14 days of purchase.
4. Your warranty is a RTB (return to base) warranty. In the unlikely event that your product
needs to be returned, please initially contact your place of purchase to obtain a returns
advice number. We will however always try first to establish if the fault can be rectified
without returning the product.
5. Every effort must be made to retain the original packaging. Any return not in original
packaging is more susceptible to transit damage. Any subsequent claim may be invalidated
due to insufficient packaging. MGD is not liable for any goods sent back that are received
damaged.
6. The warranty does not apply to any misuse, modifications, accidental damage, wear and
tear, neglect or loss occurred during transit.
7. Mains leads and batteries (rechargeable or other) are not covered under this warranty.
Please refer to ‘Battery care’ section of this manual for further information.
8. Your statutory rights are not affected.
