Nexo GEOM1210-I User manual

DP2818-01-DI
GEO M12 Series
GEOM1210-I – GEOM1220-I
User manual

CONTENU
Page 2 / 20 GEOM1210-I - GEOM1220-I
CONTENU
CONTENU _____________________________________________________________________________ 2
WARNINGS ____________________________________________________________________________ 3
DESCRIPTION__________________________________________________________________________ 4
PRESET GEOM12_______________________________________________________________________ 5
GEOM12 RIGGING ______________________________________________________________________ 9
GEOM12 –ACCESSORIES ______________________________________________________________ 10
ARRAY EQ____________________________________________________________________________ 12
MAINTENANCE________________________________________________________________________ 13
TECHNICAL SPECIFICATIONS ___________________________________________________________ 15
USER NOTES _________________________________________________________________________ 16
EU Conformity declaration
We,
NEXO SA
ZA DU PRE DE LA DAME JEANNE
60128 PLAILLY –France
Declare under our sole responsibility that the product
Type
Serial number
Loudspeaker
GEOM12
On the product
Is in conformity with the provisions of the following directive
including all applicable amendments:
2014/35/UE (Low Voltage Directive)
Applied rules and standards:
Plailly, January, 2019
EN 13155, EN 62368
Joseph CARCOPINO, R&D Director

WARNINGS
GEOM1210-I - GEOM1220-I Page 3 / 20
WARNINGS
PRECAUTIONS
Do not open the speaker, do not try to disassemble it neither to modify it in any way. The system doesn’t include any user-
repairable part.
If the system seems to be malfunctioning or damaged, stop using it at once and have it repaired by a NEXO qualified technician.
Do not expose the system directly to the sun or to the rain, do not immerse it into fluids, do not place objects filled with liquid on the
system. If a liquid gets into the system, please have it inspected by a NEXO qualified technician.
The connection should be performed by qualified technician, by ensuring that power is off.
Operating temperature with temperate climate: 0°C to +40°C (+32°F to +104); -20°C à +60°C (-4°F to +140°F) for storage.
SAFETY INFORMATIONS
Read this manual before using the speaker.
Keep this manual available for further reference.
Observe all warnings and cautions.
Please check the NEXO Web site nexo-sa.com to get the most up-to-date version of this manual.
Ensure you are aware of the safety rules applying to rigging, stacking or installing on tripod or speaker stand. Failure to observe
these rules may expose persons to potential wounds or even death.
Only use the system with accessories specified by NEXO.
Please always consult a NEXO-accredited technician if the installation needs architectural works and observe following precautions:
Mounting Precautions:
- Please select screws and mounting location supporting 4 times the system weight.
- Do not expose the system to excessive dust, vibrations, to extreme cold or hot temperatures, to reduce the risk of
damaging components.
- Do not place the system in an unstable position: it could fall accidentally.
- If the system is used on a tripod, please ensure the tripod’s specifications are adapted and that it’s height does not exceed
1.40m/55”. Do not move the tripod with the system in position.
Connection and Powering Precautions:
- Unplug connected cables before moving the system.
- Power off the system before connecting the system.
- When switching on the installation, the amplifier must be powered last; when switching the installation off, shut off the
amplifier first.
- If you work by cold temperatures, progressively raise the level to nominal value during the first minutes of use, to allow the
system components to stabilize.
Please check regularly the system condition.
HIGH SOUND PRESSURE LEVELS
Exposure to very high sound pressure levels may cause permanent hearing losses. Degrees of hearing losses may be different
from one person to another, but almost everybody will be affected if exposed to high sound pressure levels during a long period of
time. The OSHA (Occupational Safety and Health Administration) American Agency specified the following maximal exposures:
Number of Hours
Sound Pressure Level (dBA),
Slow Response
8
90
6
92
4
95
3
97
2
100
1 ½
102
1
105
½
110
¼ or less
115
WASTE OF ELECTRIC OR ELECTRONIC EQUIPMENT
This symbol on the product or its packaging indicates that this product must not be treated as household waste.
Instead, it is your responsibility to hand it over to a designated collection point for the recycling of waste
electrical and electronic equipment. By ensuring your waste equipment is recycled, you will help prevent
potential negative consequences for the environment and human health, which could appear if this product was
not recycled. Recycling helps spare natural resources. For more information about the recycling of this product,
please contact your local city office, your household waste disposal service or your reseller.

DESCRIPTION
Page 4 / 20 GEOM1210-I - GEOM1220-I
DESCRIPTION
GEOM1210-I and GEOM1220-I are a mid-size line array, 2 ways active/passive, with a 12’’ LF and a 1.4’’ HF.
You can change the HF horizontal directivity from 80° to 120° by adding a pair of magnetic flanges.
The GEOM12 can be stacked of flown with the HF waveguide exit on the left or the right side of the front panel, allowing
to broaden or narrow the stereo image depending on your need and the characteristics of the venue. We recommend to
build system with the HF waveguide on the outside of each assembly (larger stereo image).
GEOM1210-I: 10° vertical dispersion
GEOM1220-I: 20° vertical dispersion
Versions:
•GEOM1210-I: fix installations; Black
•GEOM1210-IPW: fix installations; White
•GEOM1220-I: fix installations; Black
•GEOM1220--PW: fix installations; White
Connectors:
•GEOM1210-I/1220-I: two cable-glands (clamping range, Ø 10 to 17mm), four fast connectors behind the plate.
- Remove the connecting plate.
- Pass the cables through the cable-gland.
- Connect to the fast connectors:
•ACTIVE
oLF (+) Red / (-) Black.
oHF (+) Orange / (-) Grey
•PASSIVE: (+) Orange / (-) Grey
- Tight the cable-gland and remount the connecting plate.
Amplification:
•The GEOM12 cabinets MUST be used with a NEXO processor to handle EQ, phase alignment, crossover and
excursion/thermal protection for the system loudspeakers.
•The following table shows the number of GEOM12 usable with each solution.
NXAMP4x1(bridged)
NXAMP4x2
NXAMP4x4
GEOM12
Up to 2 per channel
1 per channels
Up to 3 per channel
Recommended

PRESET GEOM12
GEOM1210-I - GEOM1220-I Page 5 / 20
PRESET GEOM12
Please consult nexo-sa.com for NEXO TD Controllers firmware information.
For the GEOM1210 or GEOM1220, with or without directivity flanges, the following setups are available:
Passive Mode
oSetup for one stand-alone box, with high-pass at 50, 60, 75, 85, 95 or 120 Hz.
oSetup for arrays from 2 to 3 boxes, with high-pass at 50, 60, 75, 85, 95 or 120 Hz.
oSetup for arrays from 4 to 6 boxes, with high-pass at 50, 60, 75, 85, 95 or 120 Hz.
oSetup for arrays from 7 to 12 boxes, with high-pass at 50, 60, 75, 85, 95 or 120Hz.
oSetup for Stack Monitor, with high-pass at 50, 60 or 75 Hz.
Active Mode
oSetup HF for arrays from 2 to 3 boxes, 1 kHz–20 kHz
oSetup HF for arrays from 4 to 6 boxes, 1 kHz–20 kHz
oSetup HF for arrays from 7 to 12 boxes, 1 kHz–20 kHz
oSetup LF for arrays from 2 to 3 boxes, 50, 60, 75, 85, 95 or 120 Hz to 1kHz.
oSetup LF for arrays from 4 to 6 boxes, 50, 60, 75, 85, 95 or 120 Hz to 1kHz.
oSetup LF for arrays from 7 to 12 boxes, 50, 60, 75, 85, 95 or 120 Hz to 1kHz.
•1Box
ox
Default Cross over on one box 50 Hz Front Fill, multi-diff, sound reinforcement all short throw application;
High SPL Small system using 2x GEOM12 and 2x MSUB18 in 85 Hz;

PRESET GEOM12
Page 6 / 20 GEOM1210-I - GEOM1220-I
•2Boxes
For small flying or stacking configuration, mid throw application used at 60 Hz without MSUB18 and
default 85 Hz with MSUB18 at 85 Hz too.
Possibilities to use 2-3Box setup in stack configuration using MSUB18 in OMNI or CARDIO mode with 1
Back and 2 Front and 3 GEOM12 on top of them, application venue up to 25 meters, default cross over
85 Hz but small overlap could have impact if needed, for example (MSUB18 120Hz and GEOM12 75 Hz).

PRESET GEOM12
GEOM1210-I - GEOM1220-I Page 7 / 20
4-6Boxes
For long throw flying application used in GEOM12 at 60 Hz without sub and GEOM12 at 85 Hz with flying
MSUB18 in omni mode at 95 Hz.
For long throw stacking application on floor or on MSUB18, up to 6 boxes used at 60 Hz without Sub and
85 Hz with MSUB18 at 85 Hz.

PRESET GEOM12
Page 8 / 20 GEOM1210-I - GEOM1220-I
7-12Boxes
For very long throw stacking application used with Sub either ground stack or flying, recommended
MSUB18 cardioid mode, cross over MSUB18 95 Hz and 12 GEOM12 cross over 75 Hz for maximum
impact. Don’t forget to put HF Waveguide either to the exterior or the interior of the venue.
Ground Stack Sub design

GEOM12 RIGGING
GEOM1210-I - GEOM1220-I Page 9 / 20
GEOM12 RIGGING
Assembly
Front
Positioning 2x GEOM12-I.
Connect both cabinets by inserting the axis through front holes
and secure axis with brake nuts.
Back
Adjust the appropriate inter-angle value with the Linkbar and secure with the provided screws.
Screws: 1 shoulder screw (D10x20), 2 washers (M10), 1 brake nut (M8).

GEOM12 –ACCESSORIES
Page 10 / 20 GEOM1210-I - GEOM1220-I
GEOM12 –ACCESSORIES
WARNINGS
All GEOM12 accessories are specifically rated in agreement with structural computations.
Never use other accessories –including push-pins –when assembling GEOM12 cabinets than the ones provided by NEXO:
NEXO will decline responsibility over the entire GEOM12 accessory range if any component is purchased from different
supplier.
All GEOM12 accessories have been designed so that cabinet are arrayed vertically.
GEOM12 horizontal assemblies as shown in figure below are UNSAFE and STRICTLY PROHIBITED
VNI-BUMPM12 / VNT-BUMPM12
Rated for a maximum of 12 GEOM12 or 8 MSUB18, or a
combination with a maximum of 4 MSUB18 and 6 GEOM12.
Flown on 2 rigging points with retractable rings.
Usable with VNT-EXBARM12 for extra tilt angle and flown on
one or two rigging points.
Ground stack assembly alone, or with VNT-GSTKM10M12S /
VNT-GSTKM10M12L for adding stability.
2 locations for laser/clinometer (VNT-BUMPM12 only).
VNT-EXBARM12

GEOM12 –ACCESSORIES
GEOM1210-I - GEOM1220-I Page 11 / 20
VNT-GSTKM10M12S –VNT-GSTKM10M12L
VNT-MNSTKM12
Rated for a maximum of 3 GEOM12 on the top of MSUB18.
GMT-LBUMPM12
Rated for a maximum of 12 GEOM12.
Usable with GMT-EXBARM12L for a one rigging point.
GMT-EXBARM12L
GMT-FLGM12
Pair of flanges for 120°horizontal directivity.
No tools, magnetic clamp.

ARRAY EQ
Page 12 / 20 GEOM1210-I - GEOM1220-I
ARRAY EQ
The ArrayEQ allows to adjust the system frequency response in its lower range
(see curves below, with different ArrayEq values):

MAINTENANCE
GEOM1210-I - GEOM1220-I Page 13 / 20
MAINTENANCE
Front panel disassembly
1
Remove the 4 screws (Tx25) to remove the grille.
2
Remove the front panel (10 screws Tx25)
3
To remove the HF Driver, unscrew the 4 nuts, and
remove it from the wave guide.
4
To remove the 12’’ driver, remove the 8 screws (Tx25).
Pay attention to the 4 spacers below the PMP.
Tightening torque for the 12’’: 3.5 Nm

MAINTENANCE
Page 14 / 20 GEOM1210-I - GEOM1220-I
Spare parts
MARK
QUANTITY
REFERENCE
DESIGNATION
1
2
05LEXM1210
Lexan GEOM1210 black
2
05LEXM1210-PW
Lexan GEOM1210 white
2
05LEXM1220
Lexan GEOM1220 black
2
05LEXM1220-PW
Lexan GEOM1220 white
2
1
05LEXWAR1
Lexan Warning
1
05LEXWAR1-PW
Lexan Warning White
3
1
05LEXRIG-ANGL1
Lexan Rigging Angles
1
05LEXRIG-ANGL1-PW
Lexan Rigging Angles White
4
1
05LEXCNX-M1210-I
Lexan CNX GEOM1210-I
1
05LEXCNX-M1210-IPW
Lexan CNX GEOM1210-I White
1
05LEXCNX-M1220-I
Lexan CNX GEOM1220-I
1
05LEXCNX-M1220-IPW
Lexan CNX GEOM1220-I White
5
1
05GEOM12UA-I
Complete grille Installation Black
1
05GEOM12UA-IPW
Complete grille Installation White
6
1
05NH78TN-16
HF Driver complete (with screws)
1
05NH78TN-16-RK
HF Diaphragm
7
1
05HPB12PN-8
12’’ Driver
1
05HPB12PN-8-RK
Recone kit HPB12PN-8

TECHNICAL SPECIFICATIONS
GEOM1210-I - GEOM1220-I Page 15 / 20
TECHNICAL SPECIFICATIONS
GEOM12 WITH NEXO ELECTRONICS
Model
GEOM12
Frequency range (±6dB)
50Hz –20kHz
Sensibility (1W / 1m)
105dB SPL Nominal
Peak SPL Level (1m)
140dB
Operating voltage
50 Vrms (180 Vpeak)
Vertical Dispersion
10° for GEOM1210
20° for GEOM1220
Horizontal Dispersion
80° or 120° (with magnetic flanges GMT-FLGM12)
Crossover Frequency
LF-HF : 1.1kHz Passive
Nominal Impedance
Active mode: (8Ω LF - 16Ω HF) –Passive mode: 8 Ω
Recommended Amplification
Active mode: (1250W LF + 650W HF) –Passive mode: 1250 W per cabinet
CARACTÉRISTIQUES
Model
GEOM12
Components
LF: 1x 12’’ - 8Ω - Long excursion –Neodymium driver with PDDTM
HF: 1x3” voice coil 1.4’’ throat driver on a BEA/FEA optimized HRWTM
Material
Lightweight polyurethane composite
Finish
Black or white structural paint
Front finish
Black or white acoustic fabric fitted front steel grille
Fittings
2 Side handles horizontal
Back grip
Connectors
2 x cable gland with 4 cores cables
Weight
34 kg –75 lb
Dimensions

USER NOTES
Page 16 / 20 GEOM1210-I - GEOM1220-I
USER NOTES

USER NOTES
GEOM1210-I - GEOM1220-I Page 17 / 20

USER NOTES
Page 18 / 20 GEOM1210-I - GEOM1220-I

USER NOTES
GEOM1210-I - GEOM1220-I Page 19 / 20

USER NOTES
Page 20 / 20 GEOM1210-I - GEOM1220-I
NEXO S.A.
Parc d’activité de la Dame Jeanne
F-60128 PLAILLY
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
nexo-sa.com
