La Crosse WS-9037U-IT User manual

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 1
Model: WS-9037U-IT
Quick Setup Guide
DC: 082516
Wireless Forecast Station
with Pressure History
Get Started
Removable
Stand
Indoor Temp,
Humidity +
Comfort Icon
Outdoor
Temperature
ºF/ºC + Channel
Indicator
Time +
WWVB Icon
Forecast Icon +
Tendency
Date, Alarm
Time, Moon
Phase
Barometric
Pressure +
24 hour
Pressure
History Graph
Battery
Compartment
3 “AA”
batteries
Battery
Compartment
2 “AA” batteries
FRONT
VIEW
TX29UDTH-IT
Remote Sensor
BACK
VIEW
IN button
OUT/+ button
ALM/DATE button
SET button
SNOOZE/CH button

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 2
Step 1: Insert the 2 new AA batteries (not included) into the
TX29UDTH-IT remote sensor. Observe the correct polarity.
Step 2: Insert the 3 new AA” Alkaline batteries (not included) into the
weather station. Observe the correct polarity
Restart: If there is no remote temperature data after 3 minutes, unplug the AC
adapter and remove batteries from the weather station & remote sensor for 15
minutes. Return to Step 1 above.
Set Time, Date, Temperature Unit
1. Hold the SET button to enter SET mode.
2. Press the OUT/+ button to adjust the values.
3. Press the SET button to confirm adjustments and move to the next
item.
Time setting order:
1. Contrast 1-7
2. Time Zone - 7 time zones
3. DST (Daylight Saving Time On/Off)
4. RCC ON/OFF (WWVB signal)
5. 12/24 hour time format
6. Hour
7. Minutes
8. Year
9. Month
10. Date
11. Fahrenheit/Celsius
12. InHg or hPa (Pressure unit of measure)
13. Relative pressure
14. Forecast Sensitivity (low for ocean, high for desert)
Press the SET button to exit, or wait 20 seconds without pressing
buttons to return to the normal time display.
Set Time Alarm
1. Hold the ALM/DATE button to enter alarm
SET mode. Hours and minutes will flash
together.
2. Press the IN button to set the hour and the OUT/+ button to adjust
the minutes.
3. Press the SNOOZE/CH button to confirm & exit.
Activate/Deactivate Time Alarm
This clock has time zones
from GMT 0 to +/-12h
North American time zones:
-4 h - Atlantic
-5 h- Eastern (default)
-6 h- Central
-7 h- Mountain
-8 h- Pacific
-9 h– Alaska
-10 h-Hawaiian

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 3
•ACTIVATE: Press and release the ALM/DATE button to toggle
between the alarm and day/date. When the alarm time
and alarm icon are showing to the right of the moon
phase, the alarm is activated.
•DEACTIVATE ALARM: Press and release the ALM/DATE
button and alarm icon will disappear. When the day and
date are showing, the alarm is deactivated.
Snooze (Silences Alarm Temporarily)
•When the time alarm sounds, press and release the
SNOOZE/CH button. The snooze will be activated for
10 minutes.
•Press and release any button, other than the SNOOZE/CH button to
silence the alarm.
Note: The alarm is crescendo sound. The alarm sounds for 2 minutes
and then shut off completely.
Moon Phase
The moon phase is based on the year, month and date, set manually or
set by the WWVB signal.
Forecast Icons
The forecast station uses changing atmospheric pressure to predict
weather conditions for the next 12-hours with 70-75% accuracy.
Forecast Trend Arrows
The up or down arrow indicate current trends in air pressure.
Alarm
Icon
Sunny Partly Sunny Rainy

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 4
Up Arrow: Air pressure is increasing; weather will improve.
Down Arrow: Air pressure is decreasing; weather will degrade.
No Arrow: Air pressure is stable
Indoor Comfort Level Icon
The comfort level indicator appears in between the indoor
temperature and humidity.
Happy Face will display when the temperature is between 68 and 79
degrees Fahrenheit (20 and 25.9 degrees Celsius) and the humidity is
between 45% and 64% Rh.
Sad Face will be displayed when the temperature and humidity are
outside the above mentioned ranges.
View/Reset MIN/MAX Values
The forecast station shows MIN/MAX temperatures
with time and date of occurrence.
Note: To view a 24-hour min/max reading, reset the
min/max temperatures at the same time each day.
View Indoor MIN/MAX: Press the IN button to display Indoor Max, Min
and Current records with time and date stamp.
Reset Indoor Records: Press the IN button to select the record you
wish to reset. Hold the SET button for five seconds. The record is now
reset to the Current Date, Temperature and Humidity.
Note: Each Min or Max value will need to be reset separately.
View Outdoor MIN/MAX:Press the OUT/+ button to display the
Outdoor Max, Min and Current records with time and date stamp.
Reset Outdoor Records: Press the OUT/+ button to select the record
you wish to reset. Hold the SET button for five seconds. The record is
now reset to the Current Date, Temperature and Humidity.
Note: Each Min or Max value will need to be reset separately.
Note: Press the SNOOZE/CH to view outdoor minimum/maximum
reading when using multiple transmitters.
Outdoor Temperature Reception Icon/Channel Indicator
•The outdoor temperature reception icon will flash every
second when searching for the sensor.
Indoor
Comfort
Icon
Outdoor
Reception
Icon

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 5
•Once connected, the icon will show for 3 seconds when outdoor
temperature update is received.
•The channel indicator will show below the reception icon.
•Press the SNOOZE/CH button to view sensors on other
channels.
Note: Channel 1 will not show if only one sensor is
connected.
Setup with Multiple Sensors
1. Insert batteries into sensor 1
2. Insert batteries into the forecast station
3. When outdoor temperature appears, insert batteries into sensor 2
4. When channel 2 appears insert batteries into sensor 3
5. Keep the forecast station and all sensors together for 15 minutes.
24 Hour Pressure History Graph
•The bar chart indicates the air pressure history
trend over the last 24 hours.
•The columns represent the pressure change
(”InHg” or “hPa”) readings at specific times.
•The “0” is equal to the current pressure and
each bar represents how past pressure was
compared to the current pressure.
•Read the graph from left to right. If the bars are rising, it means that
the weather is getting better due to the increase of air pressure.
•If the bars go down, it means the air pressure has dropped and the
weather is expected to get worse from the present time.
•The numeric barometric air pressure reading is displayed directly
under the weather forecast icon. You can set this to your local
reporting station through the program menu.
Manual WWVB Atomic Time Signal Search
For information about WWVB visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
ATOMIC SIGNAL SEARCH:
The forecast station will search for 1 hour between midnight and 6am
until the WWVB time signal is received. After reception, the forecast
station will only search for the atomic signal after midnight.
Low Battery Icon
•The low battery icon will show when the forecast station
needs fresh batteries.
Outdoor
Channel
Icon
2
WWVB
ATOMIC
ICON
Low Battery
Icon

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 6
Specifications
Indoor
Temperature Range:
+14.2°F to +139.8°F (-9.9°C to 59.9°C)
Humidity Range:
20%-95% (RH)
Outdoor
Temperature Range:
-39.8°F to 139.8°F (-39.9°C to 59.9°C)
Humidity Range:
1%-99% (RH)
Distance: Over 330 ft. (100 meters)
RF 915MHz (open air)
Power
Weather Station 2 “C” IEC LR14Alkaline Batteries
(not included)
TX29UDTH-IT Remote Sensor: 2-AA, IEC, LR6 batteries
(not included)
Battery Life
Weather Station
Battery life is over 24 when using
reputable battery brands
TX29UDTH-IT Remote Sensor: Battery life is over 24 months when
using reputable battery brands
Dimensions
Weather Station: 6.88” x 4.72” x 1.22”
(175 x 120 x 31 mm
TX29UDTH-IT Remote Sensor:
1.50” x 0.83” x 5.05”
(38.2mm x 21.2mm x 128.3mm)
Remote Sensor Use and Positioning
•Mount the Remote Sensor on a north-facing wall or in any well
shaded area. Under an eave or deck rail is preferred.
•The maximum wireless transmission range to the weather station is
over 330 feet (100 meters) in open air, not including walls or floors.
•Be sure the remote sensor is mounted vertically.
Weather Station Care & Maintenance
•Do not mix old and new batteries
•Do not mix Alkaline, Standard, Lithium or Rechargeable
Batteries

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 7
•Always purchase the correct size and grade of battery most suitable
for the intended use.
•Replace all batteries of a set at the same time.
•Clean the battery contacts and also those of the device prior to
battery installation.
•Ensure the batteries are installed correctly with regard to polarity
(+and -).
•Remove batteries from equipment with is not to be used for an
extended period of time.
•Remove used batteries promptly.
•Do not expose to extreme temperature, vibration or shock.
•Clean with a soft damp cloth. Do not use solvents or scouring
agents.
•The product is not a toy. Keep it out of reach of children.
•The product is not to be used for medical purpose or for public
information. It is intended for home use only.
•The specs of this product may change without prior notice.
•Improper use or unauthorized opening of housing voids warranty.
•If the product is not working properly, change the batteries.
Warranty and Support Information
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of
purchase) on this product relating to manufacturing defects in materials &
workmanship.
Before returning a product, please contact our friendly customer support
with questions or visit our online help (manuals and FAQS):
Phone: [phone]
Online Product Support: www.lacrossetechnology.com/support
Warranty Address:
La Crosse Technology, Ltd
2830 S. 26th St.
La Crosse, WI 54601
Protected under U.S. Patents:
5,978,738 | 6,076,044 |RE43903
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio

Model: WS-9037U-IT www.lacrossetechnology.com/support Page | 8
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other antenna or
transmitter. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user
authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or
duplicated or processed using electronic, mechanical or chemical process without the
written permission of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly
checked and corrections are included in subsequent editions. We disclaim any
responsibility for any technical error or printing error, or their consequences.
All trademarks and patents are recognized.

WS-9080U-IT www.lacrossetechnology.com/support Page | 1
Model: WS-9080U-IT
Instruction Manual
DC: 051616
Wireless Temperature Station
Get Started
1. Insert 2 NEW AA batteries (not included) into the TX29U-IT
outdoor sensor. Observe the correct polarity.
2. Insert 2 NEW AAAAlkaline batteries (not included) into the
temperature station. Observe the correct polarity.
3. After 5 minutes, place the sensor outside in a shaded
location. Maximum range is 330 feet (100 meters)
open air.
Out Temp
+ Daily
MIN/MAX
In Temp
+ Daily
MIN/MAX
Foldout
Stand
Battery
Compartment
2 AAA Batteries
Time,
Calendar, +
WWVB Icon
Wall
Hanging
Hole
Buttons
+SET
MIN/MAX CH/-
TX29U-IT
Sensor

WS-9080U-IT www.lacrossetechnology.com/support Page | 2
Time Set (Time, Date & F/C)
1. Hold the SET button to enter time set mode.
2. Press the +or CH/-buttons to adjust values.
3. Press the SET button to confirm adjustments and move to the
next item.
Settings order:
1. LCD contrast
2. Time Zone (GMT +/- 12)
3. Daylight Saving Time Indicator ON/OFF
4. Atomic Time Reception (RCC) ON/OFF
5. 12/24 Hour Time Format
6. Hour
7. Minutes
8. Year
9. Month
10. Date
11. Fahrenheit/Celsius
Press the SET button to exit, or wait 20 seconds without pressing
buttons to return to the normal time display.
MIN/MAX Readings (Daily MIN/MAX & Time/Date Stamped)
The temperature station offers indoor/outdoor MIN/MAX readings as a
daily update and as a time/date stamped historical record.
Daily MIN/MAX
•The daily MIN/MAX records are always shown on the
temperature station under the indoor and outdoor temperature.
•Daily minimum resets automatically at 8pm each day.
•Daily maximum resets automatically at 8am each day.
•These values cannot be reset manually
Time/Date Stamped MIN/MAX
•Press and release the MIN/MAX button to view: Indoor minimum,
indoor maximum, outdoor minimum and outdoor maximum
temperatures.
•Each minimum and maximum temperature will show the time and
date of occurrence.
-4h
Atlantic
-5h
Eastern
-6h
Central
-7h
Mountain
-8h
Pacific
-9h
Alaska
-10h
Hawaii
Time Zones - GMT +/- 12
North American
Time Zones:

WS-9080U-IT www.lacrossetechnology.com/support Page | 3
•Hold the MIN/MAX button to reset all time/date stamped
MIN/MAX readings.
•This reset will not change the daily MIN/MAX readings.
Display Modes (Weekday/day, Month/date, Seconds)
Press the +button to change what is displayed next to the time:
•Weekday & Day
•Month and Date
•Seconds
Setup with Multiple Outdoor Sensors
The temperature station can receive up to 3 outdoor transmitters.
Extra TX29U-IT transmitters may be found online or at your retailer.
Additional transmitters allow you to monitor remote temperatures of
up to 3 locations within a 330 Ft wireless range of the temperature
station.
1. Remove batteries from the temperature station and all outdoor
sensors for 15 minutes.
2. Insert batteries into the first TX29U-IT outdoor sensor. Observe
the correct polarity.
3. Insert batteries into the temperature station. Observe the correct
polarity.
4. When outdoor temperature shows on the temperature station,
insert batteries into the second TX29U-IT outdoor sensor.
Observe the correct polarity.
5. When channel 2 shows on the temperature station, insert
batteries into the third TX29U-IT outdoor sensor. Observe the
correct polarity.
6. Let all sensors sit next to the temperature station for 15 minutes
before positioning outside in a shaded location.
Channel Indicator (When multiple outdoors sensors are in use)
•Press and release the CH/-button to view a different channel. A
shift from one number to the next should be observed in the
OUTDOOR LCD.
Note: When only one transmitter is connected, you cannot see other
channels and the channel indicator will not show.

WS-9080U-IT www.lacrossetechnology.com/support Page | 4
Outdoor Sensor Reception Icon
•When the signal is successfully received from the outdoor
transmitter, the icon will flash every 4 seconds when it
updates.
•The icon will flash every second when searching for the outdoor
transmitter signal.
•If reception is not successful, the icon will not be shown in LCD.
WWVB Radio-Controlled Time
For info visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
Position Temperature Station on Wall or Tabletop
•Hang on wall with wall hang hole on back of temperature station.
•Use the fold out stand to set on desk or table.
Position Outdoor Transmitter
•Mount the outdoor transmitter on a North-facing wall or in any
well shaded area. Under an eave or deck rail is preferred.
•The maximum transmitting range to the temperature station is
over 330-feet (100 meters) in open air, not including walls.
Low Battery Icon – Warns to Replace Batteries
Temperature Station: Icon displays in Indoor LCD section
Transmitter: Icon displays in Outdoor LCD section
Care and Maintenance
•Do not mix old and new batteries
•Do not mix Alkaline, Standard, Lithium, or Rechargeable Batteries
•Always purchase the correct size and grade of battery suitable for
the intended use.
•Replace all batteries of a set at the same time.
•Clean the battery contacts and also those of the device prior to
battery installation.
•Ensure the batteries are installed correctly in regard to polarity
(+/-).
WWVB
icon

WS-9080U-IT www.lacrossetechnology.com/support Page | 5
•Remove batteries from equipment when it is not to be used for an
extended period.
•Promptly remove expired batteries.
Specifications
Indoor Temperature Range: 32°F to 139.8°F (0°C to 59.9°C)
Outdoor Temperature Range: -39.8°F to 157.8°F (-39.9°C to 69.9°C)
Distance: Over 330 ft. (100 meters)
RF 433MHz (open air)
Update interval: about every 4 seconds
Power Requirements:
Temperature Station: 2-AAA, IEC, LR3 batteries
(not included)
TX29U-IT sensor: 2-AA, IEC, LR6 batteries
(not included).
Battery Life TX29U-IT Battery life is over 24 months when
using reputable battery brands
Temperature Station
Battery Life: Battery life is over 12 months when
using reputable battery brands
Dimensions:
Temperature Station: 3.74” L x .074” W x 5.35” H
(95 x 18.8 x 136mm)
TX29U-IT: 1.5” L x 0.83” W x 5.05” H
(38.2 x 21.2 x 128.3mm)
Warranty and Support Information
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date
of purchase) on this product relating to manufacturing defects in materials &
workmanship.
For warranty work, technical support or other information contact our
friendly support staff:
La Crosse Technology, Ltd
2830 26th Street S.
La Crosse, WI 54601
View full warranty details online at:
www.lacrossetechnology.com/warranty_info.pdf

WS-9080U-IT www.lacrossetechnology.com/support Page | 6
Contact Support: 1-608-782-1610
Online Product Support:
www.lacrossetechnology.com/support
Product Registration:
www.lacrossetechnology.com/support/register
Protected under U.S. Patents:
5,978,738 | 6,076,044 | RE43903
FCC Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device must not be co-located or operating in conjunction with any other
antenna or transmitter.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modifications to this equipment. Such modifications could
void the user authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in
part, or duplicated or processed using electronic, mechanical or chemical
process without the written permission of the publisher. This booklet may
contain errors or misprints. The information it contains is regularly checked
and corrections are included in subsequent editions. We disclaim any
responsibility for any technical error or printing error, or their consequences.
All trademarks and patents are recognized.
