Labconco Protector 34000 Series User manual

ProtectorEvidence Drying
Cabinets
Models
34000 Series 3'
34040 Series 4'
34050 Series 5'

Copyright © 2018 Labconco Corporation. The information contained in this manual and the accompanying
products are copyrighted and all rights reserved by Labconco Corporation. Labconco Corporation reserves
the right to make periodic design changes without obligation to notify any person or entity of such change.
Returned or Damaged Goods
Do not return goods without the prior authorization from Labconco. Unauthorized returns will not be
accepted. If your shipment was damaged in transit, you must file a claim directly with the freight carrier.
Labconco Corporation and its dealers are not responsible for shipping damages.
The United States Interstate Commerce Commission rules require that claims be filed with the delivery
carrier within fifteen (15) days of delivery.
Limitation of Liability
The disposal and/or emission of substances used in connection with this equipment may be governed by
various federal, state, or local regulations. All users of this equipment are required to become familiar with
any regulations that apply in the user’s area concerning the dumping of waste materials in or upon water,
land, or air and to comply with such regulations. Labconco Corporation is held harmless with respect to
user’s compliance with such regulations.
Contacting Labconco Corporation
If you have questions that are not addressed in this manual, or if you need technical assistance, contact
Labconco’s Customer Service Department or Labconco’s Product Service Department at 1-800-821-5525
or 1-816-333-8811, between the hours of 7:30 a.m. and 5:30 p.m., Central Standard Time.
Part #3898400, Rev. G
ECO L479
Warranty
Labconco Corporation provides a warranty to the original buyer for the repair or replacement of parts and
reasonable labor as a result of normal and proper use of the equipment with compatible chemicals. Broken
glassware and maintenance items, such as filters, gaskets, light bulbs, finishes and lubrication are not
warranted. Excluded from warranty are products with improper installation, erratic electrical or utility
supply, unauthorized repair and products used with incompatible chemicals.
The warranty for Protector®Evidence Drying Cabinets will expire one year from date of installation or two
years from date of shipment from Labconco, whichever is sooner. Warranty is non-transferable and only
applies to the owner (organization) of record.
Buyer is exclusively responsible for the set-up, installation, verification, decontamination or calibration of
equipment. This limited warranty covers parts and labor, but not transportation and insurance charges. If the
failure is determined to be covered under this warranty, the dealer or Labconco Corporation will authorize
repair or replacement of all defective parts to restore the unit to operation. Repairs may be completed by 3rd
party service agents approved by Labconco Corporation. Labconco Corporation reserves the rights to limit
this warranty based on a service agent’s travel, working hours, the site’s entry restrictions and unobstructed
access to serviceable components of the product.
Under no circumstances shall Labconco Corporation be liable for indirect, consequential, or special damages
of any kind. This warranty is exclusive and in lieu of all other warranties whether oral, or implied.

T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S
CHAPTER 1: INTRODUCTION 1
CHAPTER 2: PREREQUISITES 2
Space Requirements 2
Clearance 2
Location Requirements 3
Exhaust Requirements 3
Electrical Requirements 3
Drain Requirements 3
Water Requirements (Models 34000-10 thru -14, 34040-10 thru -14,
34050-10 thru -14 only) 4
CHAPTER 3: GETTING STARTED 5
Unpacking the Cabinet 5
Moving the Cabinet 6
Attaching the Cabinet to the Wall 7
Drain Options-UV Lamp Models (Models 34000-00 thru -04,
34040-00 thru -04, 34050-00 thru -04 only) 9
Drain Options-Wash Down Models (Models 34000-10 thru -14,
34040-10 thru -14, 34050-10 thru -14 only) 10
Water Supply Connection-Wash Down Models (Models 34000-10
thru -14, 34040-10 thru -14, 34050-10 thru -14 only) 10
Preparing the Evidence Drying Cabinet for Operation 11
Initial Operation 12
CHAPTER 4: PERFORMANCE FEATURES AND SAFETY
PRECAUTIONS 13
Directional Airflow 14
Optional Evidence Prefilters 15
Prefilters 15
HEPA Filters 15
Blower 16
Cabinet Air Intake and Exhaust 16
Ultraviolet (UV) Lamp (Models 34000 -00 thru -04 only) 16
Safety Precautions 17

CHAPTER 5: USING THE CABINET 19
UV Lamp Models (Models 34000-00 thru -04, 34040-00 thru -04,
34050-00 thru -04 only) 19
Fan/UV Light Switch 19
UV Security Lock 19
Filter System Light 19
Shelf Operation 20
Drying in the Cabinet 20
Wash Down Models (Models 34000-10 thru -14, 34040-10 thru -14,
34050-10 thru -14 only) 22
Fan/Drain Pump Switch 22
Filter System Light 22
Shelf Operation 23
Drying in the Cabinet 23
CHAPTER 6: MAINTAINING THE CABINET 26
Routine Maintenance Schedule 26
Service Operations 27
Door Evidence Prefilter Replacement 27
Door Prefilter Replacement 27
Cabinet Evidence Prefilter Replacement 28
Cabinet Prefilter Replacement 28
Granular Activated Carbon and HEPA Filter Replacement 29
Changing the UV Lamp (Models 34000-00 thru -04, 34040-00
thru -04, 34050-00 thru -04) 30
Resetting a Circuit Breaker 31
Setting the Speed Control 31
CHAPTER 7: TROUBLESHOOTING 32
APPENDIX A: COMPONENTS 34
APPENDIX B: DIMENSIONS 35
APPENDIX C: SPECIFICATIONS 36
APPENDIX D: ACCESSORIES 37

Product Service 1-800-522-7658
1
C
Ch ha ap pt te er r 1 1: :
I
In nt tr ro od du uc ct ti io on n
Congratulations on the purchase of a Labconco Protector Evidence Drying
Cabinet. The cabinet is designed to protect you, and the room environment from
biohazardous aerosols and offensive odors while drying evidence. The Protector
Series cabinet is the result of years of experience in manufacturing laboratory
equipment, and users like you suggested many of its features to us.
The Evidence Drying cabinet models offer many unique features to enhance
performance and flexibility. To take full advantage of them, please acquaint
yourself with this manual and keep it handy for future reference. If you are
unfamiliar with how evidence drying cabinets operate, please review Chapter 4:
Performance Features and Safety Precautions before you begin using the cabinet.
Even if you are an experienced cabinet user, please review Chapter 5: Using the
Cabinet; it describes the cabinet’s features so that you can use it efficiently.
This manual and other technical information is available in PDF format at
our website: www.labconco.com.

Product Service 1-800-522-7658
2
C
Ch ha ap pt te er r 2 2: :
P
Pr re er re eq qu ui is si it te es s
Before you install the evidence drying cabinet, you need to plan the site for
installation. Examine the location where you intend to install the cabinet. You
must be certain that the area is level and of solid construction. In addition, a
source of electrical power must be located near the installation site.
Carefully read this chapter to learn:
Location requirements.
Electrical power requirements.
Exhaust requirements.
Service utility requirements.
Space requirements.
Drain requirements.
Water Supply Requirements (Models #3400010 thru -14, 3404010 thru -14,
and 3405010 thru -14 Only)
Refer to Appendix C: Specifications, for complete cabinet electrical and
environmental conditions, specifications and requirements.
Space Requirements
The dimensions for the Evidence Drying Cabinet are shown in Appendix B:
Dimensions.
Clearance
A minimum clearance of at least 6 inches (150 mm) is suggested on the top of the
cabinet for service. There should be 36 inches (914 mm) clearance at the front of
the cabinet to allow the door to swing open without hitting any obstructions.

Chapter 2: Prerequisites
Product Service 1-800-522-7658
3
Location Requirements
Note: The 3' Cabinet is equipped with locking casters to ease installation and
maintenance. It should be located on a flat floor for proper cabinet alignment and
door operation.
Exhaust Requirements
If you intend to connect the cabinet to the optional Exhaust Connection Kit, first
examine the location to ensure that it accommodates the cabinet’s exhaust duct.
The area directly above the cabinet’s exhaust port should be clear of structural
elements, water and utility lines, or other fixed obstructions. There should be
enough clearance to accommodate a 5-inch diameter duct. For further information
about the cabinet’s exhaust system requirements, please refer to Appendix D:
Accessories.
Electrical Requirements
The Evidence Drying Cabinet models have the following electrical requirements:
Model #
Requirements
34000-00 & -10
34040-00 & -10
34050-00 & -10
115 VAC, 60 Hz, 6 Amps
34000-01 thru -04 & -11 thru -14
34040-01 thru -04 & -11 thru -14
34050-01 thru -04 & -11 thru -14
230 VAC, 50/60 Hz, 3 Amps
Note: An outlet with a circuit breaker rated at 10 amps for 115 volt models (5 amps
for 230 volt models) should be located as close as possible to the right rear side of
the cabinet. Power cords supplied with the Evidence Drying cabinet are 3 meters
(10 feet) long.
Drain Requirements
If you intend to connect the optional drain kit, or if you have
Model # 34000-10 thru -14, 34040-10 thru -14, or 34050-10 thru -14 you will need
to have the Evidence Drying Cabinet within 6 feet (1.8m) of a suitable floor drain.
Note: The floor drain must be located below the level of the drain hose exiting
the cabinet for all models, even the drain pump-equipped models ending -10
thru -14. This will allow complete drainage of the system during wash down
operations. The cabinet and floor drain should be located in an area not
subject to freezing temperatures.
Table 2-1

Chapter 2: Prerequisites
Product Service 1-800-522-7658
4
Water Requirements (Model # 34000-10 thru -14, 34040-10
thru -14 & 34050-10 thru -14 Only)
If you intend to connect the water supply to wash down the cabinet, locate the
cabinet within 6 feet (1.8 m) of a domestic water line, equipped with a water shut
off valve ending in a 3/4" male garden hose connector. Water system pressure
should be 10-40 PSIG (0.7-2.8 Bar).

Product Service 1-800-522-7658
5
C
Ch ha ap pt te er r 3 3: :
G
Ge et tt ti in ng g S St ta ar rt te ed d
Now that the installation site is properly planned, you are ready to inspect and
install the Protector Evidence Drying Cabinet. This chapter covers how to:
Unpack and move the cabinet.
Install the cabinet.
Connect the electrical supply source.
Tools required for installation of the cabinet include two 1/2" wrenches, a flat-
blade screwdriver, a #2 Phillips screwdriver, scissors, or a box knife.
Note: The 3' cabinet weighs approximately 300 lbs. (136 kg), 4' cabinet 400 lbs.
(182 kg), and 5' cabinet 510 lbs. (232 kg). The shipping pallet allows for lifting
with a mechanical lift truck or floor jack. If you must lift the product manually,
use at least six (6) persons and follow safe-lifting guidelines. All of the cabinets
are very heavy, use a mechanical lift and safe moving practices at all times.
Unpacking the Cabinet
Carefully remove the outer carton and inspect the cabinet for damage that may
have occurred in transit. If the cabinet is damaged, notify the delivery carrier
immediately and retain the entire shipment intact for inspection by the carrier.
Note: United States Interstate Commerce Commission rules require that claims be
filed with the delivery carrier within fifteen (15) days of delivery.
Do not return goods without the prior authorization of Labconco. Unauthorized
returns will not be accepted.
If the cabinet was damaged in transit, you must file a claim directly with the
freight carrier. Labconco Corporation and its dealers are not responsible for
shipping damages.
Do not discard the carton or packing material for the cabinet until all of the
components have been checked, installed and tested.

Chapter 3: Getting Started
Product Service 1-800-522-7658
6
3' Cabinet Sizes
The 3' Cabinet is secured to the pallet using four transport brackets, two on each
side. To remove the brackets, do the following:
1. Using the 1/2" wrenches, loosen and remove the bolts and locknuts that
secure the brackets to the pallet.
2. Using a 1/2" wrench, loosen and remove the nuts and bolts securing the
transport brackets to the bottom of the cabinet.
3. Discard the brackets, shipping nuts and bolts.
The cabinet is now ready to be removed from the pallet.
NOTE: A ramp has been provided attached to the wood pallet. Follow the
instructions on the face of the cabinet for safe removal.
After removing the cabinet from the pallet, carefully remove plastic wrapping
around the cabinet, and open the cabinet door. Locate the two transport brackets
attached to the face of the cabinet liner. Using a #2 Phillips screwdriver, remove
the screws securing the brackets, discard the brackets, and reinstall the screws.
4' & 5' Cabinet Sizes
The 4' & 5' Cabinets are secured to the pallet using four transport bolts securing
the cabinet to the pallet. To remove the bolts, do the following:
1. Using the 1/2" wrench, loosen and remove the bolts that secure the cabinet
to the pallet.
2. Discard the bolts and washers.
The cabinet is now ready to be removed from the pallet.
After removing the cabinet from the pallet, install the four Leveling Legs into the
bottom of the cabinet. Leveling Legs are located in the lower cabinet compartment.
Then, carefully remove the plastic wrapping around the cabinet, and open the
cabinet doors. Locate the two transport brackets attached to the face of the cabinet
liner. Using a #2 Phillips screwdriver, remove the screws securing the brackets,
discard the brackets, and reinstall the screws.
Moving the Cabinet
When moving the cabinet, DO NOT PUSH ON THE FRONT OR BACK OF
THE UNIT. Move the cabinet by pushing or pulling it sideways. This will
minimize the possibility of the unit overturning when in motion.

Chapter 3: Getting Started
Product Service 1-800-522-7658
7
Attaching the Cabinet to the Wall
WARNING: The evidence drying cabinet must be secured to a wall stud, or
other suitable wall structure, using the included strap(s) and bracket(s). This
will minimize the possibility of the unit overturning when in use.
1. Remove the wall bracket secured to the strap, located on the back of the
unit on top (or located in the lower cabinet compartment).
2. Locate a stud inside the wall directly behind the cabinet’s installation
location.
NOTE: The screws provided with the wall bracket are intended to be used
when attaching the bracket to a wooden wall stud. If your wall is made of
different materials (cinder block, concrete, etc.), you will need to attach the
wall bracket to the wall using an anchor or fastener approved for that type of
construction.
3. Position the bracket, centered on the stud, with the top of the strap slot 79
inches above the floor. Mark the top of each screw hole, as shown in
Figure 3-1.
4. Using a 1/8" (3 mm) drill, drill pilot holes at both marked locations to a
depth of at least 1-½ inches (38 mm).
5. Using a #3 Phillips screwdriver, tighten both bracket screws until the
bracket is secured to the wall.
6. Thread the strap through both bracket slots (one strap per slot on 4' & 5'
cabinets), and then through both slots located at the top corners on the rear
of the cabinet (each strap goes through only one slot on cabinet on 4' & 5'
cabinets).
7. Push the cabinet back into its final location, and then tighten the strap until
there is minimal slack in the strap. Do NOT overtighten strap(s).

Chapter 3: Getting Started
Product Service 1-800-522-7658
8
Figure 3-1
79.0" (2400 cm)
from the floor to
the top of the
strap slot
Secure bracket
to wall stud

Chapter 3: Getting Started
Product Service 1-800-522-7658
9
Drain Options - UV Lamp Models (Model # 34000-00 thru -04,
34040-00 thru -04 & 34050-00 thru -04 only)
NOTE: These models can either drain to a bucket, already located in the
lower storage area, or the bucket can be removed, and an optional Drain Kit
(#3928200) can be installed. The optional drain kit allows the cabinet to drain
to a nearby floor drain.
On units equipped with the drain bucket:
NOTE: The drain bucket had a working capacity of approximately 1.5
gallons. Periodically monitor the liquid level in the bucket during
decontamination or washdown operations.
1. Access the bucket by opening the bottom storage area door on the front of
the cabinet.
2. Before using, ensure the bucket is in its correct position under the drain.
To install the Drain Kit (#3928200):
NOTE: The drain line should be routed to a floor drain with an air gap
only. NEVER directly connect the drain line to a sewer or drain system, or
use a stand pipe, to prevent backflow into the cabinet.
1. Remove the bucket from the lower storage area and save for possible reuse.
2. Connect the drain hose assembly to the tail pipe of the drain (on the bottom
of the drain assembly). Push the drain assembly up onto the stand pipe until
it is fully seated.
3. Hand-tighten the compression ring of the drain assembly to the tail pipe
until it is secure.
4. Route the drain hose through the appropriate hole in the bottom rear panel
of the cabinet.
5. Route the drain hose to the floor drain and secure the end of the hose to
prevent it from moving.
6. Pour water into the cabinet drain, and inspect the entire drain system for
leaks. Tighten any leaking fittings.

Chapter 3: Getting Started
Product Service 1-800-522-7658
10
Drain Options - Wash Down Models (Model # 34000-10
thru -14, 34040-10 thru -14 & 34050-10 thru -14 only)
NOTE: This model is designed to have its drain hose routed to a nearby floor
drain.
To install the drain hose assembly:
NOTE: The drain line should be routed to a floor drain with an air gap
only. NEVER directly connect the drain line to a sewer or drain system, or
use a stand pipe, to prevent backflow into the cabinet.
1. Remove the packing materials securing the hose to the back of the cabinet.
2. Route the drain hose to the floor drain and secure the end of the hose to
prevent it from moving.
Water Supply Connection - Wash Down Models
(Model # 34000-10 thru -14, 34040-10 thru -14 & 34050-10 thru -14
only)
NOTE: This model has a cabinet water shut off valve located behind the
lower front door. The valve should be in the “off” position whenever the unit
is not being washed down.
1. Connect the water supply hose (the stainless steel braided hose) to a
domestic water line, equipped with a shut off valve, and ending in a 3/4"
male garden hose connector.
2. Ensure the water supply valve is in the “off” position.
3. Slowly open the water line shut off valve.
4. Check the cabinet’s water supply hose for leaks.
5. Slowly open the cabinet shut off valve, and check again for leaks.
6. Set the spray gun nozzle to “shower” and slowly pull the trigger.
7. When water flows steadily from the gun, the cabinet shut off valve can then
be turned to the “off” position.

Chapter 3: Getting Started
Product Service 1-800-522-7658
11
Preparing the Evidence Drying Cabinet for
Operation
After the evidence drying cabinet has been removed from its pallet and positioned
in its final location, you must:
1. Remove the tie and/or tape securing the door, the lower storage area door,
and the filters on top of the unit.
2. Ensure that the transport brackets have been removed from the front of the
cabinet liner.
Note: The following are located in a box in the lower storage space:
User’s Manual
Power Cord
Product Registration Card
UV Security Lock Key(s) (model #s 34000-00 thru -04,
34040-00 thru -04 & 34050-00 thru -04 only)
Drain Strainer Cup & Grid
Rubber Drain Stopper
If you did not receive one or more of the components listed for the cabinet, or
if any of the components are damaged, contact Labconco Corporation
immediately for further instructions.
3. Using a step ladder, remove the tape and/or packaging material around the
top of the unit.
4. Plug the power cord into the back of the cabinet, and then into an
appropriate outlet. Install the Key into the UV Security lock on the upper
panel on those models equipped with a UV light.

Chapter 3: Getting Started
Product Service 1-800-522-7658
12
Initial Operation
Prior to use with evidence, you should perform the following operational tests to
ensure the cabinet is operating properly:
Airflow Smoke Pattern Test
With the cabinet fan ON, introduce smoke (from a cigarette,
chemical smoke stick, etc.) into the prefilter at the bottom of the
door. The smoke should flow directly into the cabinet, and then into
the upper prefilter located at the top of the cabinet liner. The smoke
should move from the door to the intake prefilter in approximately 5
seconds or less. If the smoke does not flow as described, see the
“Adjusting the Fan Speed” section of Chapter 6.
UV Light and Interlock Tests
With the door closed, turn the “Fan/UV Light” switch to “UV” and
the “UV Security Keylock to “ON”. The UV light will then turn on.
Open the door, and the UV light will turn off. Close the door, and
the UV light should relight. Turn the UV Security Keylock to the
“OFF” position, and the UV light will turn off. If the UV light does
not work as described, call Labconco’s Product Service Department
at 1-800-522-7658 or 816-333-8811.
Spray Gun and Drain Pump and Tests (Model # 34000-10 thru -14,
34040-10 thru 34040-14 & 34050-10 thru -14 only)
Open the cabinet door, and ensure that the drain strainer is in place.
Open the lower door, and turn the cabinet water supply valve on.
Use the spray gun in the “Shower” setting, ensuring proper
operation. Turn the gun and cabinet supply valve off. Push the
control switch to the “Drain Pump” position. The majority of water
should be pumped out of the cabinet and to the floor drain. Some
water may remain in the bottom of the cabinet due to surface
tension or the floor not being level. In this case, use a small
squeegee or sponge to direct the remaining water to the drain. Shut
off the drain pump when finished.

Product Service 1-800-522-7658
13
C
Ch ha ap pt te er r 4 4: :
P
Pe er rf fo or rm ma an nc ce e F Fe ea at tu ur re es s a an nd d S Sa af fe et ty y
P
Pr re ec ca au ut ti io on ns s
The Protector Evidence Drying Cabinet operates using the following principles:
Directional airflow.
Prefiltration of large particulates by an inlet prefilter (in the door) and an
exhaust prefilter (in the top of the liner).
Filtration and retention of particulates by a High Efficiency Particulate Air
(HEPA) filter.
Adsorption of organic (odorous) chemicals by a granular activated carbon
filter.
The major components in the cabinet are:
The prefilters
The blower to force air through the cabinet
The HEPA filter
The granular activated carbon filter

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
14
Directional Airflow
Directional airflow plays a critical role in evidence drying cabinet performance.
Air is drawn into the inlet prefilter, located on the bottom of the door. The filtered
air then flows upward through the liner, passing over the evidence to be dried.
Before leaving the liner, the air then passes through the exhaust prefilter, that is
designed to protect the HEPA filter from large particulates, and may be removed to
examine it for the collection of evidence. The air is pressurized by the blower, and
then forced through the HEPA and carbon filters, to remove biohazardous
particulates and odorous chemicals, respectively. This is illustrated in Figure 4-1.
Figure 4-1
Room Air HEPA-filtered Air Contaminated Air

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
15
Optional Evidence Prefilters
Optional Evidence Prefilters can be fitted on the inside (cabinet side) of the door
prefilter (located on the front of the door) and cabinet prefilter (located on the
inside top of the liner). These thin prefilters are designed for single-use, to be
removed after the evidence has dried. After removal, the Evidence Prefilters can be
examined for trace evidence, or stored with the evidence in a sealed bag for future
reference. See Appendix A for reorder part numbers.
Prefilters
Both the door prefilter (located on the front of the door) and cabinet prefilter
(located on the inside top of the liner) are disposable, polyester particulate filters.
Both filters have a Minimum Efficiency Reporting Value (MERV) of 11, meaning
they remove 65-79% of particles 1.0-3.0 microns in size, and more than 85% of
particles 3.0-10 microns in size. See Appendix A for reorder part numbers.
HEPA Filters
HEPA filters are disposable, dry-type particulate filters. The filter material or
media is typically made of borosilicate microfibers formed into a thin sheet, in a
process similar to the production of paper. This sheet is folded, or pleated to
increase its surface area. The pleats are held in place by aluminum diffusers or by
beads of glue that add rigidity to the media pack. The pack is then set into a frame,
and sealed as shown in Figure 4-2.
The HEPA filter manufacturer establishes the efficiency of the filter by challenging
it with an aerosol of known particle size. The number of particles that penetrate the
filter are quantified, and this establishes the efficiency of the filter. The filters used
in the evidence drying cabinets are at least 99.99% efficient in removing particles
0.3 micron.
Note: The HEPA filter media is very fragile. DO NOT touch the media. If
you think the media of a HEPA filter is damaged, DO NOT USE THE
CABINET. Call Labconco’s Product Service Department at 1-800-522-7658 or
816-333-8811.
Note: HEPA Filters are only effective against particulate material. Gases will pass
through the filter.
Figure 4-2
Polyurethane seal
Between media pack
and filter frame
Filter frame
Filter media pack –
A continuous sheet
of filter media

Chapter 4: Performance Features and Safety Precautions
Product Service 1-800-522-7658
16
Blower
The blower assembly pulls room air into the intake prefilter on the front of the
door, through the liner and exhaust prefilter, and then forces it through the HEPA
and granular activated carbon filter. The evidence drying cabinet uses a motorized,
backward curved fan for quiet, energy efficient operation.
Cabinet Air Intake and Exhaust
In order to operate properly, the air intake at the bottom of the door, the exhaust
prefilter area in the top of the liner, and the top surface of the activated carbon
filter must be unobstructed. Blocking or restricting any of these areas, or allowing
the prefilters to become excessively loaded with dust can adversely affect the
performance of the cabinet.
Ultraviolet (UV) Lamp (Model # 34000-00 thru -04, 34040-00 thru -04
& 34050-00 thru -04 only)
The optional UV lamp generates a primary wavelength of light of 254nm. A
secondary emission is in the visible (blue) wavelength, resulting in the
characteristic blue color while operating. UV light with a wavelength of 254 nm is
biocidal, primarily by creating thymine dimers in DNA. These dimers prevent the
correct transcription of the DNA into RNA, resulting in cellular death or viral
inactivation. In order to be effective, the UV light must directly strike the nucleic
acid, and its effectiveness can be diminished or negated by dissolved proteins or
metals, or by other UV-opaque substances protecting the target nucleic acid.
Because of its limitations, UV light should be used as an adjunct to good surface
disinfection practices. In order to get optimum performance from the UV light, it
should be replaced after 6,000 hours of operation or less, and the exterior surface
of the lamp should be kept clean and free of dust.
Note: UV irradiation is absorbed by the tempered safety glass of the door.
Independent research has shown that the level of UV irradiation on the outside of
the cabinet’s door is equal to background radiation levels.
Note: The UV sensitivity of a target organism varies, depending on the UV output
of the lamp, the genus and species of the organism, the medium the agent is
suspended in, etc. Contact the Health and Safety Officer at your facility for UV
light use and recommendations.
