LabRepCo LABH?30RX User manual
















REFRIGERATORANDFREEZERUNITSFORHAZARDOUSLOCATIONS–MODEL:
LABH‐30RX,30FX,30DTX,20RX,20FX,17RX,17FX,14RX,14FX
OWNER’SINSTRUCTIONS
Thismanualdescribeshowtooperateandcareforyourappliancetogetthebest,mostefficient,performance.
READTHISBOOK!
NotetoCustomer:
Thismerchandisewascarefullypackedandthoroughlyinspectedbeforeleavingourplant.Responsibilityforits
safedeliverywasassumedbythecarrieruponacceptanceoftheshipment.Asdirectedonthesideofyour
packingcarton,claimsforlossordamagesustainedintransitmustbemadeonthecarrierasfollows:

A.) VisibleLoss,Damage,ShortageExternalEvidenceofLossorDamage:Thistypeofdamagemustbenotedon
thefreightbillandacknowledgedbythecarrier’sagent(driver)attimeofdelivery.Makesureyougetasigned
copy.Sendawrittenrequestforaninspectiontothecarrier.
B.) ConcealedDamage:Thistypeofdamagemaynotbediscovereduntiltheunitisbeingunpacked.When
concealeddamageisdiscovered,stopunpackingimmediatelyandcontactthecarrierimmediatelytoreport
theclaimandrequestaninspection.Thisshouldbedoneassoonaspossibleand,inanycase,mustbedone
within15daysorreceivingthemerchandise.Ifatallpossible,donotmovetheitemandsaveallpackaging
materialforcarrier’sinspection.
C.) FAILURETOFOLLOWTHESEINSTRUCTIONSMAYRESULTINTHECARRIERREFUSINGTOHONORYOUR
COMPANY’SCLAIM.UNDERNOCIRCUMSTANCESSHOULDTHEMERCHANDISEBERETURNEDTOTHE
MANUFACTURER.NORETURNSWILLBEACCEPTEDWITHOUTPRIORAUTHORIZATION.


Horizon Scientific
125 Varnfield Drive
Summerville, SC 29483
Phone: [phone]
Fax: [phone]
Warranty:
Two-Year Parts and Labor
5 Years Compressor Parts
Revision Date
12/29/11



2



TableofContents
RECEIVING................................................................................................4
INSTALLATION..........................................................................................5
REFRIGERATORANDFREEZEROPERATION..............................................7
QUICKTROUBLESHOOTINGGUIDE..........................................................8
MAINTENANCEANDCLEANING...............................................................9
PRODUCTWARRANTYINFORMATION...................................................12




BEFORECALLINGTHEMANUFACTURER’STECHNICALSUPPORTDEPARTMENT,pleasehavetheunit’s
modelandserialnumberreadyaswellastheproblemdescription.Themodelandserialnumberis
locatedontheserialtagwhichcanbefoundontheinteriorleftupperwalloftheunit.
Forconvenience,youmaywanttorecordthefollowinginformationhereforeasyaccessinthefuture.
Modelnumber:__________________________________
Serialnumber:__________________________________
Dateofdelivery:_________________________________



3

ATTENTION!!

PLEASEBESURETOCAREFULLYREADANDFOLLOWTHESE
IMPORTANTSAFETYINSTRUCTIONS!!

THISEQUIPMENTISINTENDEDFORSTORAGEOFFLAMMABLELIQUIDS
ANDMATERIALSCAPABLEOFPRODUCINGFLAMMABLEVAPORSIN
HAZARDOUSLOCATIONS,CLASSI,DIVISIONII,GROUPC&D.KEEP
AWAYFROMSPARKSANDOPENFLAMES.

STORINGUNSEALEDCONTAINERSOFCORROSIVEMATERIALSCAN
CAUSEPERMANENTDAMAGETOTHISREFRIGERATIONUNITANDWILL
VOIDTHEWARRANTY.

ALWAYSWEARSAFETYGLASSESWHENWORKINGWITHTHIS
EQUIPMENT.

ANYUNAUTHORIZEDMODIFICATIONORSERVICEONTHISEQUIPMENT
WILLVOIDTHEFACTORYWARRANTY.FORANYSERVICEISSUEOR
CONCERNONTHISEQUIPMENT,PLEASECONTACTUS.

PERNFPA(NationalFireProtectionAssociation),THEPOWERSOURCE
TOTHISEQUIPMENTMUSTBEHARD‐WIRED.UNDERNO
CIRCUMSTANCESSHOULDANOTHERUNITBEWIREDINTOTHISSAME
CIRCUIT.



4

RECEIVING

Yourunitwasbuilt,packaged,andinspectedwithextremecare.Weshippedittoyouusing
carrierswetrustwithaproventrackrecordofcarefulhandling,goodcustomerservice,andon
timedelivery.Unfortunately,regardlessofalloftheseeffortssometimesaccidentshappenand
occasionallythoseaccidentsresultinshippingdamage.Whenthecarrierpickedupthe
merchandisefromus,theyassumedresponsibilityforitsconditionenroutetoyou.Thus,any
claimsforshippingdamagemustbefiledwiththecarrier.Likeanybodyelse,carriersdon’tlike
topayoutoninsuranceclaims,sotheirclaimsproceduresandrequirementsarevery
restrictive.Youshouldconsultthecarrier’swebsitefortheirspecificclaimsprocedures.You
shouldalsoknowthattimeisoftheessence.
Therearetwogeneraltypesofshippingdamage.Thefirstisvisibledamage.Thistypeof
damageincludesvisibleloss,damage,shortageoranyexternalevidenceoflossordamagethat
isvisibleattimeofdelivery.Thistypeofdamagemustbenotedindetailonyourdelivery
receipt.Makesurethedriversignsanddatesthedeliveryreceipt,acknowledgingthe
damage.Thishastohappenatthetimeofdeliveryoritwon’thappenatall.Keepacopyfor
yourrecordsandsendanothertothecarrier’sdamageclaimsdepartmentalongwithaformal
requestforaninspectionreport.Followupwithaphonecall.Theircontactinformationcanbe
foundonthecarrier’swebsite.
Thesecondtypeofshippingdamageisconcealeddamage.Thistypeofdamagewillprobably
notbeapparentattimeofdeliveryandmaynotbediscovereduntilunpackingandinspecting
theunit.Remember,timeisoftheessencehere.Youshouldunpackandinspecttheunitas
soonaspossible.Eachdaythatpassesreducesthelikelihoodthatthecarrierwillpaytheclaim.
Assoonastheconcealeddamageisdiscovered,stopunpackingandretainallpacking
materials.Contactthecarrierbyphonetoreporttheclaim.Notethedateandtimeand
personyouspokewith.Getaclaimnumber.Followupwithawrittenletterreferencingthe
claimnumberandincludingaformalrequestforaninspection.Again,consultthecarrier’s
websiteforspecificclaiminstructionsandfollowthemprecisely.
ASSTATEDABOVE,THECARRIERISYOURSOLESOURCEFORSATISFACTIONOFADAMAGE
CLAIM.UNDERNOCIRCUMSTANCESSHOULDTHEMERCHANDISEBERETURNEDTOTHE
MANUFACTURER.NORETURNSWILLBEACCEPTEDWITHOUTPRIORAUTHORIZATION.


5

INSTALLATION

UNCRATING–Moveyourrefrigeratorasclosetothefinallocation
aspossiblebeforeunpacking.Removethewoodenplanksor
skid.Thelocationshouldbeascloseaspossibletothepower
outletsoanextensioncordisnotneeded.Thisunitrequiresa
minimumof4inchesofairflowspaceinbackand3incheson
thesidesandtop.Donotstorematerialonthetopofthis
unit.


PLEASENOTE!Yourrefrigeratororfreezerisdesigned
forINDOORUSEandshouldbeoperatedinanairconditioned
spacewithtemperaturebetween65°Fto85°F.


LEVELINGYoucanlevelyourunitwiththescrew‐typeadjustablelevelinglegsonthefront
cornersoftheunit.Turncounterclockwisetoraisethecorner;turnclockwisetolowerit.
Levelinglegsarerequiredinfrontonly.Unitmayhaveaslighttiltfromfronttobackafter
legsareinstalled.Thisisacceptableandisrecommendedonthisunit.

POWERSOURCE–Thisunitisequippedwith18INFACTORYSEALEDWIRING.THESEWIRES
MUSTBEHARDWIREDTHROUGHSEALEDCONDUITTOTHEPOWERSOURCEPERNFPAAND
NEC.VOLTAGESHOULDNOTVARYMORETHAN5%FROMSERIALPLATERATINGS.
PROTECTTHECIRCUITWITHA20AMPDELAY‐TYPEFUSEORCIRCUITBREAKER.

STARTING–Therearenocompressorshippingboltstoloosenorvalvestoopen.Allthatis
necessaryaftertheunithasbeenproperlyconnectedandleveledistoenergizethecircuit.
Whenstartingthisnewappliance,allowthecabinettooperateaminimumofeighthours,
oruntilithasstartedcyclingnormally,beforeplacingproductinthecabinet.Themotor
compressormaystartandstopseveraltimeswhentheunitisfirststartedorafter
defrosting,especiallyiftheweatherisveryhot.Thisisnormaloperationofthemotor
overloadprotector.Themotorcompressorwillcyclenormallyassoonastheexcessheat
hasbeenremoved.



6

ShelfInstallation(FORREFRIGERATORSONLY)

Hookshelfclipsontopilasterstrips(seeIllustration).Positionallfourshelfclipsequalin
distancefromthefloorforflatshelves.Wireshelvesareorientedsothatcrosssupportbarsare
facingdown.

Placeshelvesonshelfclipsmakingsureallcornersareseatedproperly.




Temperaturecontrol
NOTE:Allofthesecontrolsarepresetatthefactorytoprovidethedesiredairandproduct
temperaturesinsideoftheunitsandrequirenofurtheradjustment.Pleasecontactthe
manufacturersTechnicalSupportDepartmentbeforemakinganyadjustmentstodetermineif
adjustmentisnecessaryand,ifso,tomakesureitisperformedproperly.
Bothrefrigeratorsandfreezershaveamanualthermostatlocatedinsidethemetallicsealedbox
nearthetoprearcorneroftheunit.Thisthermostatcontrolsthecompressor.Turningthe
thermostattowardsthehighernumberswillmaketheunitcolder.Lowernumberswillmakeit
warmer.Turningthethermostattotheoffor0positionwillturntheunitoff.Forcombounits
(refrigeratorandfreezer),thisthermostatcontrolsthecompressorbasedonfreezer
temperature.Temperatureintherefrigerationcompartmentiscontrolledbyventingairfrom
thefreezercompartment

7

RefrigeratorandFreezerOperation
Aftertheunitisproperlyinstalledandpowerisapplied,itwilltakesometimebeforethe
systemiscooleddowntotemperatureandcyclingnormally.Youshouldwait8hoursonthe
firststartupbeforebeginningtoaddproducttotheunit.Thisensuresthattheunitisinstalled
andoperatingproperlybeforebeingputintoservice.Onsubsequentstartups(aftercleanings,
forexample),thiswaittimecanbereducedtoabout3hours.Afterthiswaittime,theunit
shouldbecyclinginthedesigntemperaturerange.Theunitsarecalibratedbeforeleavingthe
factory,sonoadjustmentshouldbenecessary.
Loadingtheunitswillagaincausetemperaturetoriseasthewarmerproductisintroducedinto
thecompartment.Ifalargeamountofproductistobeintroduced,itisagoodideatodoitin
stages,allowingseveralhoursbetweenstagestoallowtemperaturetostabilizeagainbefore
introducingadditionalwarmproduct.Thiswillminimizethetemperaturetransientwhile
loading.Othertipsforsuccessfulloadinginclude:
‐Leaveabout2‐3inchesoffreespacealongthebackandsidesoftheunittoallowforproper
airflowand,therefore,moreevencoolingoftheproduct.
‐Whenloadingthetopshelf,avoidblockingtheevaporatorfan(s)(ifinstalled).Thereshould
beatleast4inchesofclearancebelowthefan(s)toallowproperairflow.
‐Donotoverloadtheunit.Afullloadisabout70to75%full.Additionally,theloadshouldbe
distributedevenlyfromtoptobottomandsidetosideforbestresults.
‐Minimizethetimethedoorisopen.Ontopoflettingthecoldairout,youarealsoletting
warm,moistairinwhichcanresultinmorecondensationand/orfrostintheunit.
Rememberthattheunitsarecalibratedtothedesigntemperaturerangebeforeleavingthe
factory.Wealsodoextensivetestingtoensurethatthesetemperatureswillresultinproduct
temperaturesinthedesiredband.Thereshouldbenoneedtoadjustthetemperaturecontrol
ontheseunits,butifitisnecessary,theycanbeadjustedusingthemanualthermostatonthe
backoftheunit.

ItisSTRONGLYRECOMMENDEDthatyoucontactthemanufacturer’sTechnicalSupport
Departmentpriortoperforminganytemperatureadjustmentstoensuretheadjustmentis
necessaryand,ifso,itisperformedcorrectly.


8

QuickTroubleshootingGuide

Checktheseitemsbeforecallingforservice
PROBLEM:POSSIBLECAUSE/SOULTIONS:
Unitdoesnotrun
Electricalcircuitisnot110‐120V60Hz.
Thepowercordisnotpluggedin.
Nopoweratelectricaloutlet.Checktomakesurebreakeris
nottrippedorfuseisnotblown.Additionally,makesureunit
isnotpluggedintoaGroundFaultCircuitInterrupter(GFCI)
typeofoutlet.
Unitdoesnotmaintainatthe
propertemperature
Checktheroomtemperature.Werecommendthe
refrigeratororfreezershouldbeplacedintheairconditioned
roombetween65°Fto85°F.Iftheroomtempistoowarm,
therefrigeratororfreezermaynotbeabletomaintainthe
interiortempatproperrange.
Doorisnotclosedproperly.
Amountofstoredproductisoverloaded.
Productreplacementsarepushedagainstrearwallor
interruptedtheproperrefrigeratoraircirculation.Forthe
properaircirculation,placetheproductsevenlyoneach
shelf.Donotpushagainsttherefrigerator’srearorside
walls.
Evaporatorisblockedbyfrostorice.Removetheproducts,
unplugtherefrigeratororfreezerpower,andallowtheunit
todefrost.Iftheproblemstillexists,callforservice.
3rdpartythermometerisplacedincorrectly.Forproper
temperaturemonitoring,thethermometershouldbeplacein
themiddleofrefrigerator.

PLEASENOTE!Priortoshipment,eachrefrigeratorandfreezerhas
beencalibratedandtestedatpropertemperaturerange.
Appliancerunstoolong
Prolongdooropenings.
Controlsettoocold.
Roomtemperatureishighwhichwillmaketheunitwork
hardertokeepcool.
Temperatureofexternalwall
surfaceiswarm
Theexteriorwallscanbeasmuchas30degreeswarmerthan
roomtemperatureduetotheembeddedcondensercoils.
Thisisnormalwhentheunitisoperating.



9

PROBLEM: POSSIBLECAUSE/SOULTIONS:
Compressornoises

Compressormaybeoverheated.Pleasechecktheroom
tempandensuretherangeiswithin65°Fto85°F.Ifthe
problemstillexists,callforservice.
Moisturecollectsinside

Doorgasketisnotsealingproperly.Checkfordebris,
cracks,anditemspassingthroughdooratthegasket.
Therefrigeratororfreezerisfacingadoorwayoris
underneathofairconditioningvent.Relocatetheunitor
redirectairvent.
Toomanydooropenings.Minimizetimedoorisopen.
Hot,humidweatherincreasescondensation.
Makesurethereisawatertrap(U‐shapedloop)inthe
draintubenearthecompressor.Thiswill“trap”asmall
amountofwaterintheloopandpreventairfrom
enteringthechamberthroughthetube.
Moisturecollectsonoutside
surface
Hot,humidweatherincreasescondensation.
Ashumiditydecreases,moisturewilldisappear.
Odorinsidetheunit

Interiorneedstobecleaned.Seesectionon
maintenanceandcleaninginthismanual.
Makesureproductcontainersaretightlysealedto
preventleakage
Doorwillnotclose

Theunitisnotlevel.RefertotheLevelingsectionatthe
beginningofthismanual
Checkfordirtanddebrisoritemspassingthroughthe
doorseal.
MoistureduringtheSummermonths
Theamountofmoisture,condensation,orhighhumidityrelatedissuesincreaseduringthesummer
and,inmostcases,willself‐resolvewhentheweathercoolsdown.Pleasenotearefrigeration
systemwillNOTgeneratemoistureorwaterbutsimplycondensesthemoisturethatisalreadyin
thechamber.Keepingtheunitinanairconditioned,lowhumidityspacewillresolvemanyissues.
Otherthingsyoushouldcheck:
1. Locationoftherefrigerator(SeeQuickTroubleshootingGuideabove)
2. Doorsealingandfrequencyofdooropeningevent(SeeQuickTroubleshootingGuideabove)
3. Makesurethereisawatertrap(U‐shapedloop)inthedraintubeneartheend.Thiswill
“trap”asmallamountofwaterintheloopandpreventairfromenteringthechamber
throughthetube.

BEFORECALLINGTHEMANUFACTURER’STECHNICALSUPPORTDEPARTMENT,pleasehavethe
unit’smodelandserialnumberreadyaswellastheproblemdescription.Themodelandserial
numberislocatedontheserialtagwhichcanbefoundontheinteriorleftupperwallofthe
unit.

10

MaintenanceandCleaning
Freezersshouldbedefrostedwhenever¼to½inchoffrosthasaccumulated.Usetheproceduresinthe
defrostingsectionstartingatthebottomofthispageforbestresults.
Refrigeratorsrequirelittlemaintenancebutshouldbecleanedperiodicallytokeepthemrunning
efficiently.Usethecleaningagentsandsuggestionsinthistableforbestresults.
CLEANING
PARTCLEANINGAGENTSTIPSANDPRECAUTIONS
InteriorandDoor
Liners
Soapandwater
Bakingsodaandwater
Use2tablespoonsofbakingsodain1quartof
warmwater
Besuretowringexcesswateroutofspongeor
clothbeforecleaningaroundcontrols,lightbulb
oranyelectricalparts.
DoorGasketsSoapandwaterWipegasketsandtheirseatingsurfaceswitha
cleansoftcloth
ShelvesSoapandwaterDonotwashremovableshelvesindishwasher
Exteriorand
Handles
Soapandwater
NonAbrasiveGlass
Cleaner
Donotusecommercialhouseholdcleaners,
ammonia,oralcoholtocleanhandles
Useasoftclothtocleansmoothhandles
Donotuseadryclothtocleansmoothhandles


DEFROSTING(FREEZERSANDCOMBOUNITSONLY)

Itisimportanttodefrostandcleanthefreezerwhen¼to½inchoffrosthasaccumulated.Frost
maytendtoaccumulatefasteronupperpartofthefreezerduetowarm,moistairenteringthe
freezerwhenthedoorisopened.Betweendefrostevolutions;youcanminimizefrostbuild‐up
byusingaplasticscrapertoremovefrost.Scrapewithapullingmotion.Neveruseametal
instrumenttoremovefrost.Neveruseadampclothorwethandsastheywillsticktotheinside
surfaceswhencold.Whendefrostingbecomesnecessary,disconnectfreezerfrompower
sourcebyunpluggingtoavoidelectricalhazard.DONOTADJUSTTHETHERMOSTAT.Remove
theproductandleavethedooropenwhiledefrostingthefreezer.
