OPERATION MANUAL
STEREO ZOOM
MICROSCOPE
MSC41-060ST

Contents
1. ……………………………………………...............………3Before use
2. ………………………………………………...................4
Nomenclature
3. ………………………………………………….................6Assemblage
4. Operation
4-1 ………………………………………...............…8Use the glass stage
4-2 ….………8Adjust the degree of tightness of the focusing arm
4-3 …………………………………….............….8Set the specimen side
4-4 …………………………............…….……8
Adjust diopter and focus
4-5 ……………...........……….…….9Adjust the interpupillary distance
4-6 ………………………………...............….…….9Use Eyepiece shields
4-8 ………………...........……….……. .9Install the illumination device
4-9 ………………………………...........….10Choose the optical system
4-10 - ……10ount the photo eyepiece and the PK mount adapter
4-11 ………………...….10
Adjust the brightness of the bottom light
4-12 ………………………………………..............…10Replace the lamps
4-13 …………………………………...............………..10Replace the fuse
5. ……………………………………………...............……11Configuration
6. ……………………………….….............………13Technical parameter
7. …………………………….……..…...............………15Troubleshooting
www.labstac.com
2
STEREO ZOOM MICROSCOPE

1
Before use
Notice
1) .
icroscope ought to be place in a dry and clean place Do not expose the
. .
microscope in the sun directly Avoid high temperature and violent vibration
2) , ,
icroscope is a precision instrument so handle with care avoiding impact or abrupt
.
movement during transportation
3) ,
To keep the image clear do not leave fingerprints or stains on the surfaces of the
.
lens
4)
Never turn the left and right focusing knob in the adverse direction at the same
, .
time otherwise the microscope will be damaged
1-2 aintenance
1) .
All lenses must be kept clean Fine dust on the surface of the lens should be blown
;
off with hand blower or wiped off gently with a soft lens tissue Fingerprints or oil
marked on it should be wiped off with a tissue moistened with a small amount of a
3:7 .
mixture of alcohol and ether
2) (
Never use the organic solution to clean the other surface especially the plastic
). , .
surfaces If necessary please choose the neutral detergent
3) .
Do not take the microscope apart for fearing that it is damaged
4) , -
After using cover the microscope with the dust cover provided and store it in a dry
.
and clean place free from moisture to prevent rust
5) , .
To keep the performance of the microscope please check it periodically
3
STEREO ZOOM MICROSCOPE
www.labstac.com

2 Nomenclature
www.labstac.com
4
STEREO ZOOM MICROSCOPE
Head
Eyepiece shield
Eyepiece
Diopter adjust ring
Lock-screw
Glass
stage
Clip
Bracket
Focusing
knob
Illu ination device
Base
Fuse
Botto variable light
control
Botto variable light
control

5
STEREO ZOOM MICROSCOPE
www.labstac.com
Base
Bracket
Photocube
Illu ination
device
Focusing knob
device
Eyepiece shield
Eyepiece
Diopter adjust
ring
Glass
stage
Head
Lock-screw
Clip
Top variable light
control
Botto variable light
control
Fuse
Switch

3. Assemblage
www.labstac.com
6
STEREO ZOOM MICROSCOPE

PK- ount adapter
Photo eyepiece
Eyepiece shield
C- ount
Eyepiece
Illu ination device
Head
Clip
Glass stage
Base
7
STEREO ZOOM MICROSCOPE
www.labstac.com

4 Operation
4-1 Use the glass stage
1)
Press the glass stage on the sunken place then
.( .1)
the other side of the glass stage will be lifted Fig
. 1
Fig
4-4-2 Adjust the degree of tightness of the
focusing arm
1)
If you want to adjust the degree of tightness of the tightness
,
of the focusing arm you can hold one of the focusing knob
.
and turn another one to attain a suitable position The degree
of tightness relies on the direction
.2 . , ,
Fig to be turned The clockwise direction is tight otherwise is
.
loose
2)
The suitable position of the tightness can make the adjustment
more comfortable and prevent the focusing bracket from
.
slipping down by its weight during the observation （. 2 Fig ）
4-3 4-3 Set the s ecimen slide
①
1) .
Set the specimen in the center of stage plate
, .
If necessary clamp the slide with the clips
2) .
Turn on the light
.3
Fig
4-4 4-4 Adjust dio ter and focus
1) Turn the focusing knob and observe the specimen through
.
the right eyepiece till the image of the specimen is clear
2)
Observe the specimen through the left eyepiece and adjust
① .( . 3)
the diopter adjustment ring till the image is clear Fig
Fig. 4
www.labstac.com
8
STEREO ZOOM MICROSCOPE

44-5-5 Adjust the inter u illary distance
Adjust the prism housing along the direction of arrow of the
.4 .
Fig till the observation is comfortable
. 5
Fig
44-6-6 Use eye iece shields
1) , -
For user who does not wear glasses hold the diopter
adjusting ring to prevent them from rotating and turn the
.
eyepiece till the eyepiece shield fit the observer well
2) ,
For user who wears glasses take the eyepiece shields off
.
before observation
. 6
Fig
4-77 Install and remove the o tional eye iece micrometer
1) ② .
Turn and remove the mounting ring from the eyepiece
( .5)
Fig
2) ①,
Clean the eyepiece micrometer and mount it to the
.
mounting ring with the inscription side downward
3)
Gently twist the mounting ring with the eyepiece
② .
micrometer into the eyepiece till tightening securely
4) ,
To remove the eyepiece micrometer take down the
,
mounting ring by twisting and take out of the micrometer
.
and the wrap it in clean soft paper for storage
. 7
Fig
4-8 4-8 Install the illumination device
1) ①
Insert the illumination device in the bracket with the
- ② -
protrudent side toward the lock screw and tighten the lock
.( .6)
screw Fig
2)
Put the plug into the socket of the pillar stand
. 8
Fig
9
STEREO ZOOM MICROSCOPE
www.labstac.com

4-9 4-9 Choose the o tical system
1) You can alternate the binocular and video capture by pushing
“ ”.
or pulling the pole You can attain binocular observation by
“ ” ,
pushing the pole inside or attain video capture by pulling it
.( .7)
outside Fig
. 9
Fig
4-10 Mount the hoto eye iece and the PK-mount
ada ter
1) -
Put the photo eyepiece into the eyepiece socket of the tri
.
ocular
2) - ,
Connect the PK mount adapter with the photo eyepiece and
- .( .8)
then tighten the lock screw Fig
. 10
Fig
4-11 4-11 Adjust the brightness of the bottom light
1) ① Turn the adjustable light knob according to the sign
,
marked on the base along the clockwise the brightness will
, . ( .9)
be added otherwise it will be weakened Fig
4-12
Fig. 11 4-12 Re lace the lam s
1)
Press the stage on the sunken place then the other side will
. ( .10)
be lifted Fig
2) .
Take the lamp out of the jack
3) .
Put a new lamp into the jack thoroughly
4) .( .11)
Recover the stage plate Fig
Note: ① , . Before replacing the lamps turn off the power first
② .
Avoid violence while the lamp is plugged into the jack
4-13 Re lace the fuse
1)
Screw the fuse tube out with a screwdriver and the pull the
①.
fuse out of the tube
2) .( . 12)
Remove the fuse and mount it in an adverse way Fig
①
. 12
Fig
www.labstac.com
10
STEREO ZOOM MICROSCOPE

5
Configuration chart
5-1 ST60 Series Configuration
Configuration odel
Parts Specification
SC
41-
060S
T
12 1
B
SC
41-
060S
T
12 2
B
4
SC
1-
060ST
T
12 3
B
4
SC
1-
060ST
T
12 1
T
SC
41-
060S
T
12 2
T
SC
41-
060S
T
12 3
T
Eyepieces
10*20
SZ EWh О О О О О О
15*15
SZ EWh
20*10
SZ EWh
Objectives
1 /100
X mm О О О О
2 /100
X mm О О О О
3 /100
X mm О О
4 /100
X mm О О
Binocular 60 ST О О О
-
Tri ocular 60 ST TR О О О
Big
conversion
lens
0.5/165
SZ AO
mm 1.5/45
SZ AO m
m2/30
SZ AO m
m
Focusing arm 1 SZ A О О О О О О
Stand
1
SZ ST О О
2
SZ ST О О
3
SZ ST О О
1
SZSTL
2
SZSTL
Transformer 1 SZT
-
Epi
illuminator 1
SZ L О О О О
Hold for
illuminator
1
SZFH
1
SZPD
device SZ PH
Gem clamp / - S ST GC
Ring
fluorescence
Light
SZRL О О
Box
Inside foam
Outside carton О О О О О О
Note: “ ” . The items marked О included and others for option
11
STEREO ZOOM MICROSCOPE
www.labstac.com

www.labstac.com
12
STEREO ZOOM MICROSCOPE

6 Technical parameter
6-1 ST60 series o tical arameter
Objective
.
ag
Workin
g
Distanc
(
e mm
)
Eyepiece ( ) Eyepieces option
10 20
SZ EWh X 15
SZ EWh X
15 20 10
SZ EWh X
ag
.Objective
field
ag
.Objective
field
ag
.Objective
field
1X
100
10X20 15X15 20X11
2X20X10 30X7.5 40X5
3X30X6.7 45X560
ST
X3.3
4X40X560
ST
X3.75 80X2.5
6-2 Auxiliary objective for ST60 series
Auxiliary objectives agnification Working distance （mm ）
0.5
SZ AO 0.5X165
1.5
SZ AO 1.5X45
2
SZ AO 2X30
.
Working distance is fixed regardless of the magnification factor
.= . . .
Total mag Objective mag X Auxiliary mag X Auxiliary mag
Eyepiece field
Diameter of field of view （mm ）
= . .
Objective mag X Auxiliary objective mag
.= .( .)
Photo adaptor mag Objective mag X Auxiliary objective mag X Photo eyepiece
.
mag
6-3 The base electrical s ecification of ST60 series
odel
Parts
SZ ST
12
SZ ST 3 SZ ST
Power supply No 220 -50
V Hz
110 -50/ 60
V ST Hz
220 -50
V Hz
110 -50/ 60
V ST Hz
Transformer No :220/110
Input VAC
:12 /45
Output VDC W
:220/110
Input VAC
:12 /45
Output VDC W
Illumina
te
Top
light
No
12 /15
V W halogen
lamp
12 /15
V W halogen
lamp
Botto
m
light
12 /15
V W halogen
lamp
220 /110
V V 、
7W
fluorescence lamp
13
STEREO ZOOM MICROSCOPE
www.labstac.com

6-4 Configuration arameter of ST60 series
odel
Parts 6012/
ST
60 12
ST TR
6013/
ST
60 13
ST TR
6024/
ST
60 24
ST TR
Head
Objective
magnification 1X、
2X1X、 3X2X、 4X
Working
distance 100mm
Observation
angle 45°
Interpupillary
distance
adjustment
Linkage between left and right eyepiece tube
:54-75
Range of single adjustment mm
Diopier
adjustment
Range of single adjustment ：±5D
ount with
auxiliary
objectives
Screw hole ：48*0.75
Objecti
ve
Field of view φ20mm
ain
body
ount the
head
ount the head in the bracket hole whose
φ76
diameter is mm
Focusing device
The degree of adjustable by rotating the
.
focusing knob
:49
Range of single adjustable mm
Glass stage Diameter ：φ95mm
Clips Put it on the base from top
www.labstac.com
14
STEREO ZOOM MICROSCOPE

7 Trouble shooting
’ .
The performance of the microscope can t be made fully because of unfamiliar using
.
This table will give some advices
Trouble Cause Remedy
1.
Double images
Interpipillary distance is
not correct
Readjust it
Diopter djustment is not
correct
Readjust it
agnification of each
eyepiece is not the
same size
ount the same size
eyepiece
2.
Dirt appears in the
field of view
Dirt on the specimen Clean the specimen
Dirt on the surface of
eyepiece
Clean the surface
3.
Image is not clear
Dirt on the surface of
the objective
Clean the objectives
4.
Image is not clear
while the focus
changing
Diopter adjustment is
not correct
Readjust the diopter
Focus is not correct Readjust the focus
5.
The focusing knob is
not smooth
The focusing knob is
too tight
Loosen it to a
suitable position
6.
The image is obscure
because of the head
slipping down by itself
during observation
The focusing knob is
too loose
Tighten it to a
suitable position
7.
Incision image
appears in the field of
view or of the video
view
The pole is not in
correct position
Pull or push it to
the correct position
8.
Eyes fell tired easily
Diopter adjustment is
not correct
Adjust the diopter
Brightness of light is not
correct
Adjust the brightness
9.
Bulb does not work
when the switch is on
No power in
Check the
connection with the
power supply
The bulb was not insert
correct
Insert it correctly
Bulb is wrong
Replace with a new
one
10.
Bulb is burned out
suddenly
Use the wrong bulb
Replace with a
correct one
The voltage is too high
Control the voltage
:
Eg use voltage
regulator
11.
Brightness is not
enough
Use the wrong bulb
Replace with a
correct one
The voltage is too low
Increase the input
voltage
15
STEREO ZOOM MICROSCOPE
www.labstac.com

12.
The bulb flickers or
the brightness is
unstable
The bulb will burn out
soon
Replace with a new
one
The bulb was not
inserted correctly
Insert it correctly
www.labstac.com
16
STEREO ZOOM MICROSCOPE

Email: [e-mail]
Website: www.labstac.com
17
STEREO ZOOM MICROSCOPE
www.labstac.com
