Laguna Designs ZEPHYR User manual

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
1
Zephyr Consoles Copyright 2015
Zephyr Product Guide
Zephyr: “the west wind” is a furniture based console system that supports a number of technical
applications with a variety of modular options. We have totally re-designed and refined this product line
for 2015 from the bottom up. Zephyr consoles start as stand-alone desks in four standard sizes. Of
course we can customize the surface shapes and apply your choice of finishes.
Figure 1. Z-3 Console configured with (3) 4U turrets
Zephyr is a simple and elegant solution for a variety of tasks. The optional, Electric Lift Base is whisper
quiet and programmable. Recall your favorite “sit-stand” settings with just the touch of a button. The
robust lift capacity is 275 lbs.
All Zephyr desks offer ample cable management, an accessory track for mounting ergonomic monitor
arms and perfect speaker placement. Computers can be easily mounted to either leg extrusions or
under the desk surface.
Zephyr desks are available on our “10 Day Quick Turn” program.
We can ship your desk in any finish selection within two weeks of receipt of order.

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
2
Zephyr Consoles Copyright 2015
Standard Sizing
There are four standard widths available. All feature an accessory rail, cable and power management.
Optional turret placement can be pre-ordered left, center, right or we can provide the turret opening
and filler panels to enable you to easily configure or move the turrets to your desired location.
Figure 2a. Zephyr standard top sizes Figure 2b. Zephyr section view
Custom Sizes:
We can do a variety of shapes with custom widths and depths. For lengths greater than 100”, we need
to add a center, intermediate leg with a shorter foot. Longer tables with the additional intermediate
legs can also include the electric lift option (up to 12’)

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
3
Zephyr Consoles Copyright 2015
Finish Options
Surface Options include High Pressure Laminate (standard) or (optional) Corian or Linoleum.
Standard laminate and linoleum tops have a black, vinyl, “tear drop” edge molding. Corian Tops have a
monolithic, full edge profile.
Base Options:
Zephyr bases provide rigid stability. Bases are available as “standard” and “electric lift”.
Either base can also be configured with wheels.
Figure 3. Zephyr base options
The bases include a chassis with three inch side grommets for running data and power into and out of
the console. The chassis assembly also has an integrated, steel cable trough to manage and hide cables
while providing easy access.

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
4
Zephyr Consoles Copyright 2015
Figure 4. Zephyr base details (Exploded view)
Turret Options:
6 U (Requires larger opening) 4 U Flat top 4 U 3 U
Figure 5. Zephyr turret options
Turret depths are equal. They are interchangeable! (6 unit turrets require additional depth.)

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
5
Zephyr Consoles Copyright 2015
New Turret Feature!
Now with a Brush Grommet cable pass-thru for easy cable routing!
Figure 6. Desk and turret detail
Equipment turrets are easily removable for replacement and upgrades.
Accessories:
Laguna Designs offers many accessories to increase the versatility and usefulness in our consoles and
desks.
We have available:
Monitor Stands, Speaker Mounts, Monitor Arms, Rack Enclosures, CPU holders, Keyboard Trays and
more…

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
6
Zephyr Consoles Copyright 2015
Figure 7. Zephyr (Typical Installation)

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
7
Zephyr Consoles Copyright 2015
Figure 8. Zephyr line drawing--exploded
Accessories shown: Rolling Monitor Stand
Under Counter 12 Unit Rolling Rack
Slide-out Keyboard Tray
Under Desk CPU Holder
Pole Mounted Articulating Speaker Supports
Interchangeable Equipment Turrets
Radial Monitor Arms
See our Accessories Page for more options and details.

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
8
Zephyr Consoles Copyright 2015
ZEPHYR CONNECT
Zephyr components can be connected
together with a continuous work surface
to create multi position consoles. This is
a great solution where cable
management, power distribution and an
accessory rail are required, but there is
no need for integrated rack space below
the console surface.
Console surfaces and edge profiles are
uninterrupted.
Figure 9 a & b. Zephyr Connect line drawings
Connected Zephyr’s can have electric lift bases (with three lifting columns up to 12’). Several
configurations are available. Angled configurations are also available.
FINISH SELECTION: http://www.lagunadesigns.com/finishes-guide

Laguna Designs Inc. Technical Millwork for Broadcast and Post 2014
9
Zephyr Consoles Copyright 2015
For more information please visit our website: www.lagunadesigns.com
Z-3 with 2 turrets, mixer and switcher Z-3 Bare (no turrets)
Zephyr Connect with desk top turrets
Custom Zephyr with cut-outs for a mixer, small switcher and 6U desk top turret.
