laguna 37 x 2 User manual

Owner's Manual
Laguna Tools
744 Refuge Way Grande Prairie, TX
Service: [phone]
Email: [e-mail]
Updated February 2022
Double Drum Sander 37 x 2
Height: 49" Width: 51" Depth: 38"
Copyright Laguna Tools 2021

Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of
Laguna Tools, Inc. All rights reserved. 04/01/2019
LAGUNA AMERICAN HEADQUARTERS
Texas: 744 Refuge Way Suite 200, Grand Prairie, Texas 75050, U.S.A. Phone:
[phone]
Huntington Beach: 7291 Heil Ave Huntington Beach, CA 92647, U.S.A. Phone:
[phone]
South Carolina: 825 Bistline Dr. Ste 101, West Columbia, SC29172, U.S.A. Phone:
[phone]
Minnesota: 5250 West 74th St, Edina, MN 55439, U.S.A Phone: [phone]
lagunatools.com
supermaxtools.com
lagunacleanair.com
lagunalathe.com
LAGUNA EUROPE
Walker Rd, Bardon Hill, Coalville LE67 1TU, United Kingdom. Phone: [phone]
lagunatools.uk
DAKECORPORATION
724 Robbins Road, Grand Haven, MI 49417, United States [phone]
dakecorp.com
Call: [phone]
or
Email: [e-mail]
For immediate service on any Laguna Tools products:

All rights reserved. No parts of this work maybe reproduced in anyform or by any means - graphic, electronic, or
mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the
written permission of Laguna Tools.
Products that are referred to in this document are either trademarks and/or registered trademarks of Laguna Tools,
Inc. The publisher and the author make no claim to these trademarks.
While every precaution has been taken in the preparation of this document, the publisher and the author assume no
responsibilityfor errors or omissions, or for damages resulting from the use of information contained in this
document or from the use of programs and source code that mayaccompany it. In no event shall the publisher and
the author be liable for anyloss of profit or anyother commercial damage caused or alleged to have been caused
directly or indirectly by this document.
Published: February 2022

5Contents
5
Contents
Letter to Woodworker 7
General Information 8
Safety Rules ...................................................................................................................... 10
Machine Overview ............................................................................................................ 14
Unboxing ........................................................................................................................... 16
Supermax Specifications .................................................................................................. 18
Supermax Accessory & Supply Check List ........................................................................ 19
Machine Set-Up 20
Electrical Connections ....................................................................................................... 21
Connecting Dust Collectors ............................................................................................... 23
Checking Drum Alignment ................................................................................................ 24
Wrapping Abrasive Strips .................................................................................................. 29
Machine Operation 32
Setting Cut Depth .............................................................................................................. 33
Disengaging the Drums ..................................................................................................... 36
Selecting Intellisand Feed Rates ....................................................................................... 37
Selecting Drum Abrasives ................................................................................................. 40
Supermax Infeed/Outfeed Assembly ................................................................................. 41
Mainteance 42
Tips for Maximum Performance ........................................................................................ 43
Troubleshooting ................................................................................................................ 46
Servicing the Supermax ................................................................................................... 48
Readjustment Procedures ................................................................................................................................. 49
Adjusting Table Support Casting ..................................................................................................................... 51
Adjusting Sanding Drums ................................................................................................................................ 52
Adjusting Tension Rollers ................................................................................................................................ 55
Drumhead Assembly Exploded View 56
Drumhead Parts List 57
Conveyor Exploded View 59
Conveyor Parts List 60
Exploded Diagrams 62

Double Drum Sander 37 x 26
Laguna Tools 2021
Parts Lists 63
Electrical Diagrams 64
Rotating/Replacing Drum Bearings 65
Replacing Conyeor Belts 71
Reassembly Procedure 74
Disassembly Procedure 75
Replacing the Sanding Drums 78
Warranties 79
Modifications & RMA Policy ............................................................................................... 80

Letter to Woodworker 7
Letter to Woodworker
Thank you for investing in a Double Drum Sander Model 37 x 2 by Laguna Tools. This planer is one of a family of
unique machines proudly offered by Laguna Tools. Every Laguna machine is engineered for years of dependable
service. Please feel free to contact Laguna Tools if you have a question or suggestion. We appreciate working with
you and your choice of a Laguna Tools machine for your shop.
Regards, Torben Helshoj
President & Founder Laguna Tools

Double Drum Sander 37 x 28
General Information
IMPORTANT: BEFORE OPERATING YOUR SUPERMAX, READ THE INSTRUCTIONS IN THIS MANUAL FOR
UNPACKING AND SETTING UP YOUR MACHINE.
SUPERMAX OWNER’S MANUAL
CAUTION, SAFETY FIRST:
When maintaining and operating this machine, always put safety first. For your own safety, read and understand
this owner’s manual before operating this machine. Always heed and follow all nor- mal safety precautions,
including the following:
• Always wear eye protection while operating the sander.
• Always feed stock against the drum rotation.
• Never place hands or fingers under the drum or dust cover.
• Keep hands and clothing away from operating drums.
• Never operate the sander without its dust cover or drum and belt guarding in place.
• Always maintain control of boards to avoid kickback; know how to prevent it.
• Always disconnect electrical power before doing any servicing or adjusting of the machine.
MODEL IDENTIFICATION:
Your SUPERMAX Drum Sander is one of a family of machines from Supermax Tools designed to help you
achieve results comparable to industrial-size sanders at a fraction of the cost.
The SUPERMAX is available in 25" or 37" Dual Drum Models.
For future reference, attach the Model/Serial # Bar Code label below or find the model and serial numbers on the
front table mount (#20, page 39) and write them in below:
Model:_____________ Serial Number:__________________
Date Purchased:____________ Dealer: _______________
CAUTION, IMPORTANT SAFETY INFORMATION:
FOR SAFE SANDING OPERATION, FOLLOW THESE GUIDELINES:
• BECOME FAMILIAR WITH THE PROPER OPERATIONAL PROCEDURES FOR USING THIS MACHINE.
• ALWAYS BE SAFETY CONSCIOUS WHEN OPERATING THE MACHINE.
• ALWAYS WEAR EYE PROTECTION WHILE OPERATING THE SANDER.
• ALWAYS FEED STOCK AGAINST THE ROTATION OF THE DRUM(S).
• NEVER PLACE HANDS UNDER THE DRUM(S) OR DUST COVER.
• NEVER OPERATE SANDER WITHOUT ITS DUST COVER OR DRUM AND BELT GUARDING IN PLACE.
• KEEP HANDS AND CLOTHING AWAY FROM OPERATING DRUM(S), BELT AND PULLEYS.
• ALWAYS MAINTAIN CONTROL OF STOCK TO AVOID KICKBACK; KNOW HOW TO PREVENT IT.
• ALWAYS DISCONNECT ELECTRICAL POWER BEFORE PERFORMING ANY SERVICING OR ADJUSTMENT

General Information 9
OF THE MACHINE.
Additional Safety Information:
1.) KEEP GUARDS IN PLACE and in working order.
2.) REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to see that keys and adjusting
wrenches are removed from tool before turning it on.
3.) KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
4.) DON'T USE IN DANGEROUS ENVIRONMENT. Do not use power tools in damp or wet locations or expose
them to rain. Keep work area well lighted.
5.) KEEP CHILDREN AWAY. All visitors should be kept safe distance from work area.
6.) MAKE WORKSHOP KID PROOF with padlocks, master switches, or by removing starter keys.
7.) DON'T FORCE TOOL. It will do the job better and safer at the rate for which it was designed.
8.) USE RIGHT TOOL. Do not force tool or attachment to do a job for which it was not designed.
9.) USE PROPER EXTENSION CORD. Make sure your Extension cord is in good condition. When using an
extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord
will cause a drop in line voltage resulting in loss of power and overheating. Table A shows the correct size to use
depending on cord length and nameplate ampere rating. If in doubt, use the next heavier gage. e smaller the gage
number, the heavier the cord.
10.) WEAR PROPER APPAREL Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry
which may get caught in moving parts. Nonslip footwear is recommended. Wear protective hair covering to contain
long hair.
11.) ALWAYS USE SAFETY GLASSES. Also use face or dust mask if cutting operation is dusty. Everyday
eyeglasses only have impact resistant lenses, they are NOT safety glasses.
12.) SECURE WORK. Use clamps or a vise to hold work when practical. It is safer than using your hand and it
frees both hands to operate tool.
13.) DON'T OVERREACH. Always keep proper footing and balance.
14.) MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
15.) DISCONNECT TOOLS before servicing; when changing accessories, such as blades, bits, cutters, and the
like.
16.) REDUCE THE RISK OF UNINTENTIONAL STATING. Make sure switch is in o position before plugging in.
17.) USE RECOMMENDED ACCESSORIES. Consult the owner's manual for recommended accessories. The use
of improper accessories may cause risk of injury to persons.
18.) NEVER STAND ON TOOL Serious injury could occur if the tool is tipped or if the cutting tool is unintentionally
contacted.
19.) CHECK DAMAGED PARTS. Before further use of the too., a guard or other part that is damaged should be
carefully checked to determine that it will operate properly and perform its intended function - check for alignment of
moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions that may act its
operation. A guard or other part that is damaged should be properly repaired or replaced.
20.) DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rotation of the blade or cutter
only.
21.) NEVER LEAVE TOOL RUNNING UNATTENDED. TURN POWER OFF. Do not leave tool until it comes to a
complete stop.
For three phase models: "The installer shall follow local regulation s and National Electrical Code,
ANSI/NFPA 7 0 installation requirements".

Double Drum Sander 37 x 210
Safety Rules
PLEASE READ AND UNDERSTAND ALL SAFETY WARNINGS AND
OPERATING INSTRUCTIONS BEFORE USING THIS MACHINE
FAILURE to follow all instructions listed below, may result in electric shock, fire, and/or serious personal injury
or property damage.Woodworking can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using the machine with
respect and caution will considerably lessen the possibility of personal injury. However, if normal safety precautions
are overlooked or ignored, improper operation or assembly of this machine could result in personal injury to the
operator. Safety equipment such as guards, push sticks, hold downs,feather boards, goggles, dust masks and
hearing protection can reduce your potential for injury. But even the best guard won’t make up for poor judgment,
carelessness or inattention.
ALWAYS use common sense and exercise caution in the workshop. If a procedure feels dangerous, don’t try
it.Consult a professional to find an an alternative procedure which is safer and more efficient.
NOTICE! Your personal safety is YOUR responsibility.
This machine was designed for certain applications only. We strongly recommend that this
machine not be modified and/or used for any application other than that for which it was designed. If you have any
questions relative to a particular application, DO NOT use the machine until you have first contacted the
manufacturer to determine if it can or should be performed on the product.
If you have any questions relative to its application DO NOT use the product until you have
contacted the manufacturer and we have advised you. When using an electrical machine, basic precautions should
always be followed, including the following:
Read and understand all warnings and operation instructions before using any tool or equipment. Always follow
basic safety precautions to reduce the risk of personal injury. Improper operation,
maintenance or modification of tools or equipment could result in serious injury and property damage. There are
certain applications for which tools and equipment are designed. This product should NOT be modified and/or used
for any application other than for which it was designed. It is important for you to read and understand this manual.
The information it contains relates to
protecting your safety and preventing problems.
Machine & Workshop Safety Instructions
READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS
EQUIPMENT. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW, MAY RESULT IN ELECTRIC
SHOCK, FIRE, AND/OR SERIOUS PERSONAL INJURY OR PROPERTY DAMAGE.
MACHINERY CAN BE DANGEROUS IF SAFE AND PROPER OPERATING PROCEDURES ARE NOT
FOLLOWED. AS WITH ALL
MACHINERY, THERE ARE CERTAIN HAZARDS INVOLVED WITH THE OPERATION OF THE PRODUCT. USING
THE MACHINE WITH
RESPECT AND CAUTION WILL CONSIDERABLY LESSEN THE POSSIBILITY OF PERSONAL INJURY.
HOWEVER, IF NORMAL

General Information 11
SAFETY PRECAUTIONS ARE OVERLOOKED OR IGNORED, PERSONAL INJURY TO THE OPERATOR MAY
RESULT. SAFETY
EQUIPMENT SUCH AS GUARDS, PUSH STICKS, HOLD-DOWNS, FEATHER BOARDS, GOGGLES, DUST
MASKS AND HEARING
PROTECTION CAN REDUCE YOUR POTENTIAL FOR INJURY. BUT EVEN THE BEST GUARD WON’T MAKE UP
FOR POOR
JUDGMENT, CARELESSNESS OR INATTENTION. ALWAYS USE COMMON SENSE AND EXERCISE CAUTION
IN THE WORKSHOP.
IF A PROCEDURE FEELS DANGEROUS, DON’T TRY IT. FIGURE OUT AN ALTERNATIVE PROCEDURE THAT
FEELS SAFER.
REMEMBER: YOUR PERSONAL SAFETY IS YOUR RESPONSIBILITY.
OWNER’S MANUAL. READ AND UNDERSTAND THIS OWNER’S MANUAL BEFORE USING MACHINE.
TRAINED OPERATORS ONLY. UNTRAINED OPERATORS HAVE A HIGHER RISK OF BEING HURT OR KILLED.
ONLY ALLOW TRAINED/SUPERVISED PEOPLE TO USE THIS MACHINE. WHEN MACHINE IS NOT BEING
USED, DIS-CONNECT POWER, REMOVE SWITCH KEYS, OR LOCK-OUT MACHINE TO PREVENT
UNAUTHORIZED USE—ESPECIALLY AROUND CHILDREN. MAKE
YOUR WORKSHOP KID PROOF!
DANGEROUS ENVIRONMENTS. DO NOT USE MACHINERY IN AREAS THAT ARE WET, CLUTTERED, OR
HAVE POOR LIGHTING.
OPERATING MACHINERY IN THESE AREAS GREATLY INCREASES THE RISK OF ACCIDENTS AND INJURY.
MENTAL ALERTNESS REQUIRED. FULL MENTAL ALERTNESS IS REQUIRED FOR SAFE OPERATION OF
MACHINERY. NEVER
OPERATE UNDER THE INFLUENCE OF DRUGS OR ALCOHOL, WHEN TIRED, OR WHEN DISTRACTED.
ELECTRICAL EQUIPMENT INJURY RISKS. YOU CAN BE SHOCKED, BURNED, OR KILLED BY TOUCHING
LIVE ELECTRICAL
COMPONENTS OR IMPROPERLY GROUNDED MACHINERY. TO REDUCE THIS RISK, ONLY ALLOW
QUALIFIED SERVICE
PERSONNEL TO DO ELECTRICAL INSTALLATION OR REPAIR WORK, AND ALWAYS DISCONNECT POWER
BEFORE ACCESSING
OR EXPOSING ELECTRICAL EQUIPMENT.
DISCONNECT POWER FIRST. ALWAYS DISCONNECT MACHINE FROM POWER SUPPLY BEFORE MAKING
ADJUSTMENTS,
CHANGING TOOLING, OR SERVICING MACHINE. THIS PREVENTS AN INJURY RISK FROM UNINTENDED
START-UP OR
CONTACT WITH LIVE ELECTRICAL COMPONENTS.
EYE PROTECTION. ALWAYS WEAR ANSI-APPROVED SAFETY GLASSES OR A FACE SHIELD WHEN
OPERATING OR OBSERVING
MACHINERY TO REDUCE THE RISK OF EYE INJURY OR BLINDNESS FROM FLYING PARTICLES.
EVERYDAY EYEGLASSES ARE
NOT APPROVED SAFETY GLASSES.
WEARING PROPER APPAREL. DO NOT WEAR CLOTHING, APPAREL OR JEWELRY THAT CAN BECOME
ENTANGLED IN MOVING

Double Drum Sander 37 x 212
PARTS. ALWAYS TIE BACK OR COVER LONG HAIR. WEAR NON-SLIP FOOTWEAR TO REDUCE RISK OF
SLIPPING AND LOSING
CONTROL OR ACCIDENTALLY CONTACTING CUTTING TOOL OR MOVING PARTS.
HAZARDOUS DUST. DUST CREATED BY MACHINERY OPERATIONS MAY CAUSE CANCER, BIRTH
DEFECTS, OR LONG-TERM
RESPIRATORY DAMAGE. BE AWARE OF DUST HAZARDS ASSOCIATED WITH EACH WORKPIECE MATE-
RIAL. ALWAYS WEAR A
NIOSH-APPROVED RESPIRATOR TO REDUCE YOUR RISK.
HEARING PROTECTION. ALWAYS WEAR HEARING PROTECTION WHEN OPERATING OR OBSERVING
LOUD MACHINERY.
EXTENDED EXPOSURE TO THIS NOISE WITHOUT HEARING PROTECTION CAN CAUSE PERMANENT
HEARING LOSS.
REMOVE ADJUSTING TOOLS. TOOLS LEFT ON MACHINERY CAN BECOME DANGEROUS PROJECTILES
UPON STARTUP. NEVER
LEAVE CHUCK KEYS, WRENCHES, OR ANY OTHER TOOLS ON MACHINE. ALWAYS VERIFY REMOVAL
BEFORE STARTING!
USE CORRECT TOOL FOR THE JOB. ONLY USE THIS TOOL FOR ITS INTENDED PURPOSE—DO NOT
FORCE IT OR AN
ATTACHMENT TO DO A JOB FOR WHICH IT WAS NOT DESIGNED. NEVER MAKE UNAPPROVED
MODIFICATIONS, MODIFYING
TOOL OR USING IT DIFFERENTLY THAN INTENDED MAY RESULT IN MALFUNCTION OR MECHANICAL
FAILURE THAT CAN
LEAD TO PERSONAL INJURY OR DEATH!
AWKWARD POSITIONS. KEEP PROPER FOOTING AND BALANCE AT ALL TIMES WHEN OPERATING
MACHINE. DO NOT
OVERREACH! AVOID AWKWARD HAND POSITIONS THAT MAKE WORKPIECE CONTROL DIFFICULT OR
INCREASE THE RISK OF
ACCIDENTAL INJURY.
CHILDREN & BYSTANDERS. KEEP CHILDREN AND BYSTANDERS AT A SAFE DISTANCE FROM THE WORK
AREA.STOP USING
MACHINE IF THEY BECOME A DISTRACTION.
GUARDS & COVERS. GUARDS AND COVERS REDUCE ACCIDENTAL CONTACT WITH MOVING PARTS OR
FLYING DEBRIS. MAKE
SURE THEY ARE PROPERLY INSTALLED, UNDAMAGED, AND WORKING CORRECTLY BEFORE OPERATING
MACHINE.
FORCING MACHINERY. DO NOT FORCE MACHINE. IT WILL DO THE JOB SAFER AND BETTER AT THE RATE
FOR WHICH IT WAS
DESIGNED.
NEVER STAND ON THE MACHINE. SERIOUS INJURY MAY OCCUR IF MACHINE IS TIPPED OR IF THE
CUTTING TOOL IS
UNINTENTIONALLY CONTACTED.

General Information 13
STABLE MACHINE. UNEXPECTED MOVEMENT DURING OPERATION GREATLY INCREASES RISK OF
INJURY OR LOSS OF
CONTROL. BEFORE STARTING, VERIFY MACHINE IS STABLE AND MOBILE BASE (IF USED) IS LOCKED.
USE RECOMMENDED ACCESSORIES. CONSULT THIS OWNER’S MANUAL OR THE MANUFACTURER FOR
RECOMMENDED
ACCESSORIES. USING IMPROPER ACCESSORIES WILL INCREASE THE RISK OF SERIOUS INJURY.
UNATTENDED OPERATION. TO REDUCE THE RISK OF ACCIDENTAL INJURY, TURN MACHINE OFF AND
ENSURE ALL MOVING
PARTS COMPLETELY STOP BEFORE WALKING AWAY. NEVER LEAVE MACHINE RUNNING WHILE
UNATTENDED.
MAINTAIN WITH CARE. FOLLOW ALL MAINTENANCE INSTRUCTIONS AND LUBRICATION SCHEDULES TO
KEEP MACHINE IN
GOOD WORKING CONDITION. A MACHINE THAT IS IMPROPERLY MAINTAINED COULD MALFUNCTION,
LEADING TO SERIOUS
PERSONAL INJURY OR DEATH.
DAMAGED PARTS. REGULARLY INSPECT MACHINE FOR DAMAGED, LOOSE, OR WRONGLY ADJUSTED
PARTS—OR ANY
CONDITION THAT COULD AFFECT SAFE OPERATION. IMMEDIATELY REPAIR/REPLACE BEFORE
OPERATING MACHINE. FOR
YOUR OWN SAFETY, DO NOT OPERATE MACHINE WITH DAMAGED PARTS!
MAINTAIN POWER CORDS. WHEN DISCONNECTING CORD-CONNECTED MACHINES FROM POWER, GRAB
AND PULL THE
PLUG—NOT THE CORD. PULLING THE CORD MAY DAMAGE THE WIRES INSIDE. DO NOT HANDLE
CORD/PLUG WITH WET
HANDS. AVOID CORD DAMAGE BY KEEPING IT AWAY FROM HEATED SURFACES, HIGH TRAFFIC AREAS,
HARSH CHEMICALS,
AND WET/DAMP LOCATIONS.

Double Drum Sander 37 x 214
Machine Overview
ABOUT THE SUPERMAX SYSTEM:
The SUPERMAX System is basically made up of the following 5-five major components:
1) Machined Drums wrapped with Abrasive Strips.
2) Take-Up Mechanism to Process Stock Feed.
3) No-Give Conveyor Table.
4) Variable Power Feed Motor.
5) Height Adjustment Mechanism.
Sand Two Grits in a Single Pass with a 37×2 Double Drum Sander. Featuring INTELLISAND Technology and a
5 HP 220 Volt 1 phase motor, you can significantly reduce the amount of time you spend sanding.
The 37×2 Double Drum Sander features INTELLISAND Technology that auto-regulates the conveyor based on
load, preventing burning, gouging, and damaging stock. The machine comes standard on an open column base and
features a 5 HP motor. Available in Single phase only.
25×2 Double Drum Sander Also Available
Features:
INTELLISAND Technology: Automatically adjusts conveyor speed based on load.
Prevents gouging, damaging, or burning stock.
Provides consistent finish even with varying grain pattern and density.
Greatly increases abrasive planning and dimensioning speed.
SKU: SUPMX-937003
Features of the 37×2 Double Drum Sander include:
37x2 Double Drum Sander-Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel
cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010" across the width of the sander.
Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much
shorter or thinner.
Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and
overlap.
Easiest access to abrasive fastening system of any drum sander! Machine design includes additional space around
abrasive, eliminating the need for special tools.
Self-colling drum prevents overheating and extends abrasive life.

General Information 15
Additional Details:
Sanding Capacity
•Maximum Width (in): 37"
•Minimum Length (in): 3-½"
•Maximum Thickness (in): 12"
•Minimum Thickness (in): 1/32"
Dimensions (H x W x D) : 49" x 58" x 31".
Drum (Extruded Aluminum): 5" x 37".
Drum Speed: 1740 RPM.
Dust Hood (Plastic Hood, Hinged at Back): (3) – 4" Vacuum ports, Min. CFM: 1200 recommended.
Ball Bearings (1"): 4, sealed and permanently lubricated.
Conveyor Motor: 254 in.-lb. torque, direct drive D.C. motor, ranged variable, 0-15 FPM.
Drive Motor (TEFC): 5 HP.
Power Requirements: 208-230V, 60Hz, 1 Phase 30 Amp Service; 3 Phase 20 Amp Service.
Shipping Dimensions (L x W x H): 62" x 52" x 45".

Double Drum Sander 37 x 216
Unboxing
UNPACKING YOUR SUPERMAX:
If any damage has occurred because of shipment, notify the transportation company as soon as possible and ask
them to make an immediate inspection. Ask for a damage or loss report.
Important: To avoid problems and potential damage to the machine, please read the unpacking instructions below
before proceeding to set up the machine in your shop.
1.) Unbolt the machine legs from the shipping pallet. Install the rubber-based leveling feet or casters on legs
(Figure 2-See Below). The feet and mounting hardware are in the STOP bag packed with your machine.
2.) Loosen the hex nut and set screws on the table support castings (Figure 3-See Below).
The set screws on the table support castings have been tightened at the factory to eliminate free play between the
table support casting and the column tube during shipment. There are two table support castings on the
SUPERMAX, one each for the right and left column tubes.
Important: These set screws are tightened for shipping, must be loosened, and readjusted before operating either
the height adjustment mechanism or the conveyor drive.
To properly adjust for operation, loosen each set screw by first loosening its hex nut with an open-end wrench and
then the set screw with an Allen wrench. Then re-tighten each set screw with your fingers not touching the column
tube.
Hold each set screw in position with an Allen wrench and retighten the hex nut. Failure to follow these procedures
may result in misalignment of the drum(s) and/or the conveyor table.
Caution: On the SUPERMAX MODELS: Do Not Loosen the Set Screws on the Upper Drum Support

General Information 17
Castings.

Double Drum Sander 37 x 218
Supermax Specifications

General Information 19
Supermax Accessory & Supply Check List

Double Drum Sander 37 x 220
Machine Set-Up
SETTING UP YOUR SUPERMAX:
This section covers the pre-operational checks you should make after unpacking and final assembly. Unnecessary
problems can be avoided if these essential checks are performed before operating the sander. Likewise, performing
the recommended monthly maintenance procedures listed at the end of this section will help assure trouble-free
service.
MAKING ELECTRICAL CONNECTIONS:
The Neutral Wire (White Wire) in the power cord to the sander is not used and does not need to be
connected on 4-four wire 220V, Single Phase (Angle Connector).
(2) Phases are present:
Single Phase: The drums of all SUPERMAX single phase sanders are powered by a 5 HP, 208- 230-volt, 1-
Single Phase Motor.
