Lakos TWISTIICLEAN User manual

Maximum Flow Ranges:

• T2C-075¾"Inlet/Outlet
0to25USgpm
(0to5.7m³/hr)
• T2C-1001"Inlet/Outlet
0to39USgpm
(0to8.9m³/hr)
• T2C-1501½"Inlet/Outlet
0to78USgpm
(0to17.7m³/hr)
Maximum Pressure:
• 100psiat73˚F
(6.9barat38˚C)
Temperature Range:
• 32˚F-120˚F
(0˚C-49˚C)
Mesh Sizes:
• 30Mesh(600Micron)
Element(Brown)
• 60Mesh(250Micron)
Element(White)
• 100Mesh(150Micron)
Element(Gray)
• 140Mesh(105Micron)
Element(Black)
Pre-Installation Checklist
A.Selectagoodlterlocation:
  Installonthepressure(outlet)sideofanypumps
  InaverticalpositionwithPurgeExitpointingdown 
  Awayfromextremeweatherconditionstoprotectfromfreezing
  Atleast12inchesawayfromwalls,etc.sotophandlecanbetwisted
  Allowenoughclearancebeneaththeunitto:
  (a) attachapurgedrainhosetothePurgeExit(recommended)
  (b) removetheclearbowlassembly,toallowreplacementofelementasneeded
B.Asasunnyoutdoorinstallationmightleadtoalgaegrowthinsidetheclearbowland
 affecttheoperationofyourTWISTIICLEAN.AnoptionalSunShieldisavailable.
Safety Notes:
DespitetheeaseofinstallationandoperationoftheLAKOSTWISTIICLEANproduct,certain
precautionsshouldbetaken.
1. Lubricate“O”ringswithNSFapprovedsilicongreaseonly-Dow111isrecommended.
2. Donotovertightenthethreadedconnections.Donottightenmorethana1/4turnpastnger
tight.Handtightenthebowl,donotusetools.
3. Donotusewrenchesonplasticlterparts.Useoftoolsonlterwillvoidwarranty.
4. Forthreadedconnections,usetheTeon™tapesealantprovidedwithproduct.
5. Filtercomponentsthathave“O”ringsdonotrequirethreadsealant.
6. Removeclearbowlifthelteristobeinstalledusinganysolventwelding.Thiswillprevent
solventdamagetotheclearbowl.
7. Thislterisdesignedforusewithwateronly.Otherchemicalsorcomponentscandamagethe
ltercomponents.Evaluateallchemicalsforproperusagewiththelter.
8. Protectunitfromfreezing,asyouwouldwithanyotherwatersupplylines.
9. Followalllocalandstatecodes,laws,andregulationswheninstallinganylter.
TopHandle
RedSafetyLatch
Inlet
Outlet
FlowDirectionArrow
Mounting
Eyelets
ClearBowl
FilterElement
PurgeExit
IfforanyreasonthefilterelementdoesnotcleancompletelyduringthenormalTwisttoClean
operation,manualcleaningmaybeneeded.Inthiscase,removethebowlandcleantheelementwith
asoftbrush,brushingandrunningwateracrosselement.
Caution: If the lter bowl is to be removed, all water ow must be shut off going to the lter.
Maintenance and Troubleshooting
Limited Warranty
TheLAKOSTWISTIICLEANiswarrantedtobefreeofmaterialorworkmanshipdefectsforatleastoneyear
fromdeliverydate.
Ifafaultdevelops,notifyus,givingacompletedescriptionoftheallegedmalfunction.Includethemodel
number(s),dateofdeliveryandoperatingconditionsofsubjectproduct(s).Wewillsubsequentlyreviewthis
informationand,atouroption,supplyyouwitheitherservicingdataorshippinginstructionandreturnedmateri-
alsauthorization.Uponprepaidreceiptofsubjectproduct(s)attheinstructeddestination,wewilltheneither
repairorreplacesuchproduct(s),atouroption,andifdeterminedtobeawarranteddefect,wewillperform
anyproducts,damagesorinjuriesresultingfrommisuse,neglect,normalexpectedwear,chemically-caused
corrosion,improperinstallationoroperationcontrarytofactoryrecommendation.Nordoesitcoverequipment
thathasbeenmodifed,tamperedwithoralteredwithoutauthorization.Nootherextendedliabilitiesarestated
orimpliedandthiswarrantyinnoeventcoversincidentalorconsequentialdamages,injuriesorcostsresulting
fromanysuchdefectiveproduct(s). LS-866(Rev.3/11)
Inlet/OutlettoPurgePort
TotalLength
TWISTIICLEAN
Installation Instructions for
3/4-inch Model T2C-075
1-inch Model T2C-100
1 1/2-inch Model T2C-150
Quick-Start Guide
Width
Dimensions
Total
Flow Rate (US gpm)
Flow Rate (m3/hr)
Clean Conditions
Head Loss (Bar) Head Loss (psi)
=Recommendedowrange
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0
0 10 20 30 40 50 60 70 80
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
www.TWISTIICLEAN.com
0
1
2
3
4
5
6
7
8
9
10
T2C-075 T2C-100 T2C-150
Max Flow=
25gpm 39gpm 78gpm

www.TWISTIICLEAN.com
Fig A
Fig B
Fig C
Installation In 7 Easy Steps
Optional Accessories
Sun Shield For Outdoor
Installations
Blackneoprenewovencover,slipsover
bowltopreventgrowthofalgaeandother
organics.
Purge Exit
Hose
Model Size
T2C-075(¾")
T2C-100(1")
T2C-150(1-½")

SUN SHIELD
1. RemovetheTWISTIICLEANfromitsbox.Checktomakesure
theboxalsocontainsasmalldispenserofTeontapeandtwo
slip/threadedadaptersforuseifneeded.
2. Besuretheclearbowlissecurelytightened(handtightenonly).
Theunitisshippedwiththebowlloose.Lifttheredsafetylatch
androtatethetophandleafewtimestomakesureitwillrotate
¼clockwiseturn.
3. PreparethepipingmanifoldtoinstallTWISTIICLEAN.Select
thebestfittingsforyourinstallation,usingsliporthreaded
ttingsasdesired.Noticethedirectionofwaterowthroughthe
unit--aowdirectionarrowismoldedintothesideoftheunit.
(FigA).
4. UseproperPVCsolventsandfollowgluinginstructionson
solventcontainer.Donotspillsolventonanypartofthe
TWISTIICLEANunit.
5. Mountingeyeletsprovideforamorestableinstallation(FigB).
Stabilizerboltsarerecommendedforlongtermstabilityofyour
TWISTIICLEAN.Use⅜"HexLagScrewspluswashersand
PVCpipetoconnecttoasecuresurface.ThesepartsareNOT
suppliedwithyourTWISTIICLEAN.
6. Onceinstalled,testbyturningwatersupplyonslowly,allowing
watertofeedthroughtheunit.Checkforleaks.Afterlifting
thesafetylatch,twistthetophandlewitha¼clockwiseturnto
re-directtheowforcleaning.Thisshouldliftthescreenelement
insidethebowlandreleaseushwaterthroughthepurgeexitat
thebottomoftheunit.Twistthehandlebacktoits“run”position,
lowerthesafetylatchandcheckforleaks.
7. Attachaushdrainhose(ifnecessary)todirectthepurged
particlematterandexcesswatertoadrainorotherdesiredarea
fordischarge(FigC).
J
u
s
t
T
W
I
S
T
t
o
C
L
E
A
N
TWISTIICLEANremovessandandorganicsasthewaterpassesthroughthefilterelement.
Periodiccleaningisnecessarytooptimizefilterperformance,reducethepressurelossand
prolongtheproductlife.Whenthelterelement
lookslikeitislledwithdebris,itshouldbecleaned.
Justagentle1/4clockwiseTWISTofthetop
handlebeginsthepatentedreverseushingaction.
Injustafewseconds,alldebrisarebackwashed
offthefilterelementandflushedoutthebottom
ofthePurgeExitport.Besuretoraisethesafety
latchbeforetwistingthehandleandloweritafter
ushing.
Using Your TWISTIICLEAN
Normal Mode Flush Cleaning
Mode
Water Flow Direction TWISTIICLEAN Exploded View
and Spare Parts
SafetyLatch
StabilizerBolts
(notprovidedbyLAKOS)
Gasket/Housing
O-RingKit
131729(T2C-075and100)
132237(T2C-150)
FilterElementKit
131730(30Mesh)
131731(60Mesh)
131732(100Mesh)
131733(140Mesh)
132232(30Mesh)
132233(60Mesh)
132234(100Mesh)
132235(140Mesh)
Pin&O-RingKit
132093(T2C-075-100)
Bowl&O-RingKit
131728(T2C-075-100)
132236(T2C-150)
O-RingKit
132346(T2C-150)
T2C-
075-100
T2C-150
Sun Shield
Part Number
131355
132240
