LAMAX BEAT SENTINEL SE-1 How to use

Quick starting guide
Sentinel SE-1 by

Functions:
Bluetooth 2.1
Micro SD card
Micro USB
FM radio
Handsfree
Audio imput
LED ashlight
Buttons:
a) top side
Front overview
b) back c) bottom
Sentinel SE-1 by
d) front logo
Pantone 7467C - Color of frame, all other parts originally in orange as well as the font on the rear side Pantone Cool Gray 2C - Color of front side logo Black - Indicates all inner embosssments
Back side Front side
The new graphics has to be lined up with the original buttons. There should be enough space for the LED indicator above the buttons. Please center the rear side graphics horizon- taly.
Bottom overview
Rear overview
Top overview
Back side Front side
All graphics bellow use the real size measurements.
LED light
Next / Volume +
Previous / Volume -
Play / Pause / Handsfree
Mode

Button
name
Bluetooth
mode
FM radio
mode
Audio
mode
Power
ON / OFF Switch On/O to turn on/o the device
Previous /
Volume -
Press – Go to
previous track
Press – Go to
the previous
station
Press – Go
to previous
track
Hold – Decrease volume
Play /
Pause
Press – Stop /
Start playback
Incoming call:
Press – An-
swer call
Hold – Reject
call
Press – Turn
radio On / O
Hold – Search
for stations
Press – Stop /
Start playback
Next /
Volume +
Press – Go to
the next track
Press – Go to
next station
Press – Go to
the next track
Hold – Increase volume
Mode Press – Go to next mode
Light Press to turn LED light On/O

Overview of voice alerts:
„Power on“ - the device was turned on.
„Bluetooth mode. Pair the device.“ - The unit is in Blue-
tooth mode and is ready for pairing.
„Paired“ - it has been successful paired with a Bluetooth
device.
„Radio“ - the device is in FM radio mode.
„Audio imput“ - The unit is in playback mode, ready to
play audio recordings from device connected via the
3.5mm jack.
„SD card“ - the device is ready to play tracks from a micro
SD card.
Pairing with a Bluetooth device:
Press„M“ to go to Bluetooth mode. Speaker can be paired
with a device which supports Bluetooth 2.1 or higher.
In the list of active devices the Sentinel SE-1 is displayed
as„SE-1 by LAMAX Beat“.
Once paired, you will hear the notication„Paired“.
If the device is disconnected or the connection is lost you
will hear„Bluetooth mode. Pair the device”.
FM radio mode:
Go to mode by pressing„M“.
Connect the micro USB cable, which acts as an antenna.

To nd all available stations hold down the „Play / Pause
/ Handsfree“ button. The device will then scan FM
frequencies and store all stations found.
You can then navigate between the stations using the
„Previous“ and„Next“.
Playback audio les from the micro SD card:
Enter mode by pressing „M“. Speaker announces „SD
card“.
Sentinel SE-1 then plays the MP3s stored on the micro
SD card.
Audio imput:
After connecting the audio cable to the AUX jack, it plays
music from any connected device.
Using handsfree:
To use this feature, you must have the Sentinel SE-1
paired via Bluetooth with a smartphone.
Calls can be accepted / rejected in the standard way
on the phone or accepted by pressing the „Handsfree“
button and rejected by holding the„Handsfree“ button.
LED light:
Pressing the„Light“ button turns the LED light on / o.

Charging:
The speaker can be charged using the included micro
USB cable from any charger with a USB output or from
any computer equipped with a USB output. Charge the
device only under supervision.

Full English manual can be downloaded from here:
Die Bedienungsanleitung in Deutsch können Sie von hier runterladen:
Mode d‘emploi en français à télécharger ici:
Český manuál ke stažení zde:
Slovenský manuál na stiahnutie tu:
Instrukcja obsługi w języku polskim do pobrania tutaj:
Használati útmutató:
Srpski priručnik možete preuzeti ovde:
http://beat.lamax-electronics.com/SE1/manuals
