Lander BAE HAWK Quick start guide

BAE HAWK
OPERATIONAL MANUAL

- 2 -
Please read before operating this system!
W
e would like thank you for purchasing our new product –Bae Hawk
designed for the hobby enthusiast. Base on its full - scale counterpart,
this Great British Jet can finish loops, inverted flight and rolls and
other aerobatics easily. It is also made as a highly maneuverable
model for the intermediate to expert pilot. With the Bae Hawk model
which includes EDF set*, speed controller, electric servos, retractable
landing gear with front steering and full scale functional lighting
system. You will have joyful time in model flying.
Remarks:*
We have several different metal EDF sets for your selection.
1) Rclander 64mm metal EDF is a higher grade EDF set which is an
aluminum alloy material EDF more powerful output, efficient and
durability.
2) Please be noticed that all servo have been pre-set the center point
before out of factory. It maybe appeared some difference due to
difference brand mark radio control. Kindly make sure to do the
adjustment (special to pre-set the travel throw of gear servo up
to 110-115 %. ) with your own radio equipment before installation
this jet model.
4) From main wing edge to center around 72mm±2mm is the CG
point.
5) Please make sure to use a little piece of attached velco to secure
your LiPo battery for fixing on the battery bay before flying.
Specifications:
Wing Span :
750mm
Length:
860mm
Flying weight:
1.1kg
Servo:
9g×7pcs
Power system:
Brushless electrical metal ducted fan(3900kv/4300kv)
Thrust:
Up to 1.2kg
Function:
1) Retractable landing gear
2)Lighting system
ESC:
50A or above
Radio:
5CH or above
Battery:
Li-po 14.8V/4S-2200mAH or above

- 3 -
Main Accessories
Main Fuselage
Main Wing Set
Horizontal Stabilizer
Vertical Stabilizer
Both Side Intake Set
EDF Cover Set
Rocker Tube
Canopy Set
Horizontal Stabilizer Mechanical Set
Lighting System Set
Full Set Retractable Landing Gear
Remarks: 1) Operational Manual (included)
2) 5 Min. epoxy set (included)
3) Y Cord X 3 pcs (included except ARF version)
4) Push rods for Elevator, Rudder, Aileron, and Retract Gear & Steering (included)
5) One plastic bag included Screws, Control Horns, Linkage Stoppers & ply wood of Battery compartment
And Receiver compartment

- 4 -
Assembling the aircraft
01
1) Nose retract gear has been assembled by
factory.
02
1) Using epoxy to glue up the nose gear ply
wood on the related compartment and install
both of retract gear & steering servos on the
specific position then link up the push rob as
shown.
03
1) Using some double clear tape to fix the
nose gear plastic cover on the lower main
fuselage.

- 5 -
04
1) Find out the horizontal stabilizer set and
mechanical set.
2) Using some epoxy to glue up both side
horizontal stabilizer on the mechanical set
first
05
1) Install both side horizontal stabilizer
on the main fuselage and using the
provided screws to lock up the
stopper as shown
06
1) Install the vertical stabilizer.

- 6 -
07
1) Using some epoxy to glue on the
vertical stabilizer on the main fuselage.
08
1) Install the main retracts landing gear
on the main wing.
09
1) Using the attached screws to tight up the
main retract landing gear on the gear
bay square hard wood.
2) Using some double tape to fix the plastic
wheel cover set on the main wing.
3) Link up the push rob with the retract gear
servo (remind to adjust the TX gear
travel throw up to 110-115%)

- 7 -
10
1)Install the aileron servos.
11
1) Using a Y cord to link up both servos cord
as shown.
12
1) Install both side of intake set

- 8 -
13
1) Using epoxy to glue up both side intakes
set on the main fuselage.
14
1) Install the Rclander 64mm metal EDF set
with ESC.
15
1）Using the attached two pieces strong
double foam tape (pls cut out from two to
four pieces) to put on the EDF set bay first.

- 9 -
16
1) Take some force to install the EDF set on
the bay as shown then use some hot melt
glue on the gap in order to strengthen the
tighten of the EDF on the bay of main
fuselage.
17
1) Using the attached clear pvc sheet and
two screws to tight up the ESC on the bay
of the main fuselage as shown.
18
1) Install those push robs of elevator and
rudder.

- 10 -
19
1) Two 1.2mm wire push robs are the
elevator then 1.4mm wire push rob is for
rudder and link up the related control horn
as shown.
20
1) Connect both 1.2mm push robs with two
elevator servos (remind to take one
reverse operation direction servo for
elevator)
2) Connect the 1.4mm push rob with the
steering servo as shown.
21
1) Install the EDF cover set.
