L&W Compressors LW 200 B MC User manual

C H A P T E R O V E R V I E W
Operating Instructions
..............................................................................................................
ECC - Electronic Compressor Control (if equipped
.........................................................
Spare Parts Lists
..........................................................................................................................
Options (if equipped
.................................................................................................................
Attachment
....................................................................................................................................
A
B
C
D
E
Manufacturer in terms of 97/23/EC
The full name and address of the manufacturer is:
Lenhardt & Wagner GmbH
An der Tuchbleiche 39
686 3 Hüttenfeld / Germany
Phone: +49 (0) 6 56 - 85 88 0 - 0
Fax: +49 (0) 6 56 - 85 88 0 - 14
E-Mail: [e-mail]
Internet: www.lw-compressors.com

S E R V I C E I N F O R M A T I O N / W A R R A N T Y
Compressor information
Type designation
Serial number
Date of construction
Purchase information
Purchase date
First commissioned on
Warranty period
Dealer's stamp
Warranty
L&W will uphold warranty claims made during a period of 1 months from the invoice date.
If the compressor was purchased from an official L&W dealer, the date on the dealer's invoice is
valid. Warranty claims can only be made on presentation of the original invoice.
Should verifiably defective parts have been delivered, we will decide to either replace the parts or
repair them. The resulting transport and assembly costs will be invoiced.
No reduction of the purchase price or changes to the contract can be made. The parts for which a
claim is being made should be kept safe by the purchaser and, when requested, sent to us at their
cost. Replaced parts become the property of L&W. If maintenance work is carried out without our
knowledge or permission by the purchaser or a third party, we are absolved from any liability for
warranty claims. As a matter of principle, warranty claims can only be made by the initial purchaser.

A
Operating Instructions
Breathing Air Compressor
LW 200 B MC / LW 250 B MC
Version: 01.05.2020

Page A - 2
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
T A B L E O F C O N T E N T S
General Information and Technical Data
General Information / Description of Marks and Warning Signs ....................................................... 4
Scope of Delivery .............................................................................................................................. 5
Technical Data .................................................................................................................................. 6
Unit Assembly .................................................................................................................................. 7
Drive Engine ...................................................................................................................................... 8
Flow Chart ........................................................................................................................................ 9
Safety Precautions
Intended Use / Operators ................................................................................................................ 11
Safety Instructions on the Unit ....................................................................................................... 12
General Safety Precautions ............................................................................................................. 13
Unit customised Safety Notices ....................................................................................................... 14
Maintenance Instructions ............................................................................................................... 15
Transportation Instructions / Safety Regulations ............................................................................. 16
Installation
Outdoor Installation ........................................................................................................................ 18
Dimensions ...................................................................................................................................... 19
Minimum Distances ........................................................................................................................ 20
Operation
Important Operation Instructions ................................................................................................... 22
First Commissioning ................................................................................................................ 23 - 24
Daily Commissioning ...................................................................................................................... 25
Filling Procedure ............................................................................................................................. 26
Switch off the Compressor ............................................................................................................. 27
Remedying Faults ............................................................................................................. 29 - 32

Page A - 3
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
T A B L E O F C O N T E N T S
Maintenance and Service
Service, Repair and Maintenance .................................................................................................... 34
Maintenance Lists / Maintenance Intervals ............................................................................... 35 - 37
Service Kits ..................................................................................................................................... 38
Check V-Belt Tension / Tension V-Belt / Settings ............................................................................... 39
Compressor Lubrication / Check Oil Level ........................................................................................ 40
Oil Change ...................................................................................................................................... 41
Manual Condensation Dump System .............................................................................................. 42
Maintenance - Oil / Water Separators 2nd Stage ............................................................................. 43
Filter Housing / Filter Cartridge ........................................................................................................ 44
Filter Cartridge Change .................................................................................................................... 45
Maintenance - Filter Housing ........................................................................................................... 46
Inlet Filter ....................................................................................................................................... 47
Maintenance - Inlet Filter Housing ................................................................................................... 48
Valve Heads and Valves ................................................................................................................... 49
Replace Inlet- / Outlet Valve 1st Stage ...................................................................................... 50 - 51
Replace Inlet- / Outlet Valves 2nd / 3rd Stage ........................................................................... 52 - 53
Safety Valves ................................................................................................................................... 54
Pressure Maintaining / Non Return Valve ......................................................................................... 55
Adjust Pressure Maintaining Valve .................................................................................................. 56
O-rings - Filling Valve and Filling Hose ............................................................................................ 57
Test of Pressure Equipment ............................................................................................................. 58
Maintenance Records .............................................................................................................. 60 - 64
Storage
Conservation / Storage of the Compressor ....................................................................................... 65
De-conservation, Commissioning .................................................................................................... 66
Transportation Instructions / Disposal / Electric and Electronic Components ................................... 67

Page A - 4
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Warning
Indicates a potentially hazardous situation which, if not avoided, could result in physical
injury or damage to the product or environment.
Caution
Indicates an imminently hazardous situation which, if not avoided, could result in serious
injury, physical injury or death.
General Information
We strongly recommend reading this manual thoroughly prior to operation and follow all the safety
precautions precisely. Damage resulting from any deviation from these instructions is excluded from
warranty and liability for this product. Carry out other commissioning steps only if you have fully
understood the following contents.
Before commissioning and using the unit, carry out all the essential preliminary work and measures
concerning legal regulations and safety. These are described on the following pages of this operati-
on manual.
G E N E R A L I N F O R M A T I O N
!
!
Note
Indicates additional information on how to use the unit.
i
Description of Marks and Warning Signs
The following warning signs are used in this document to identify the corresponding warning notes
which require particular attention by the user. The warning signs are defined as follows:

Page A - 5
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Scope of Delivery LW 200 B MC / 250 B MC
The MC Serie is the perfect solution for dive centers, ships, boats and places with limited space and
convince with a brand new and powerful compressor block.
An innovative characteristic based on the new Motion Link design allows a very slim design.
Customers can choose between two different models with a delivery rates of 200 l/min or 250 l/min.
These compressors are designed for a long lifetime and continuously operations, the ideal machine
for smaller stationary applications. Long maintenance intervals guarantee extremely low
maintenance costs.
With a small and handy frame these compressors are highly predestined for mobile breathing air
applications.
Versions
Filling pressure versions:
• PN 225 bar
• PN 330 bar
• PN 225 / 330 bar
Specifications
Options
• Automatic stop at final pressure
• Additional filling hose c/w filling valve
• Oil pump
• Oil pressure gauge
• Intermediate pressure gauges
• Switch over device 200 / 300 bar
• Hour counter
• Additional high pressure outlet
• Wheelset
• Honda drive engine
• 4 stroke drive engine
• Manual condensate drain
• 1 x Filling hose c/w filling valve and
pressure gauge
• Pressure maintaining and non return valve
• All pistons c/w steel piston rings
• Oil- / Water separators after 2nd and 3rd stage
• Safety valves after each stage
• 3 x concentric inlet / outlet valves
• Filling pressure to your choice
(200 or 300 bar)
• Connections to your choice
(DIN 200 bar or 300 bar, CGA 200 bar or 300
bar and INT)
• Breathing air purification in accordance to
EN 12021
D E S C R I P T I O N

Page A - 6
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Technical Data
D E S C R I P T I O N
Technical Data LW 200 B MC LW 250 B MC
Capacity [l/min]: 200 250
Max. Operating Pressure [bar]: 350 350
RPM [min-1]: 1425 1825
Number of Pressure Stages: 3 3
Cylinder Bore 1st Stage [mm]: Ø 75.5 Ø 80
Cylinder Bore 2nd Stage [mm]: Ø 32 Ø 32
Cylinder Bore 3rd Stage [mm]: Ø 14 Ø 14
Medium: Compressed Air / Breathing Air
Intake Pressure: atmospheric
Oil Capacity [l]: 0,8 0,8
Intake Temperature [°C]: 0 < +45 0 < +45
Ambient Temperature [°C]: +5 < +45 +5 < +45
Engine:
Drive Power [kW / HP] : 6.7 / 9.0 6.7 / 9.0
RPM Motor [min-1]: 3600 3600
Start: Starter Cord Handle
Noise level [dB(A)]: 89 90
Dimensions L x W x H [mm]: 1060 x 500 x 590 1060 x 500 x 590
Dimensions with telescope intake pipe
B x T x H [mm]: 1060 x 500 x 1300 1060 x 500 x 1300
Weight [kg]: 110 110
Content Volume Filter housing [l]: 0.44 0.44
Briggs & Stratton

Page A - 7
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Unit Assembly
D E S C R I P T I O N
No. Designation
1 Drive Engine
2 Final Filter Housing with Safety Valve
3 Condensate Drain Hoses
4 Filling Hose with Filling Valve and Filling Pressure Gauge
5 Compressor Block
6 Telescope Intake Pipe
3
1
2
6
5
4

Page A - 8
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
D E S C R I P T I O N
Drive Engine
No. Designation
1 Throttle Control
2 Choke
3 Fuel Shut-off
4 Starter Cord handle
5 Stop Switch
5
1
2
3
4

Page A - 9
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
1. Air Intake Filter
2. 1st Pressure Stage
3. Safety Valve 1st Stage
4. Cooling Pipe 1st Stage
5. 2nd Pressure Stage
6. Cooling Pipe 2nd Stage
7. Oil-/Water Separator
8. Safety Valve 2nd Stage
9. Condensate Release Valve
10. Condensate Release Hose
11. 3rd Pressure Stage
12. Cooling Pipe Final Stage
13. Oil-/Water Separator
14. Final Pressure-Safety Valve
15. Condensate Release Valve
16. Condensate Release Hose
17. Pressure Maintaining Valve
18. Non-Return Valve
19. Filling Hose
20. Filling Connector
21. Filling Valve
22. Pressure Gauge (Filling Pressure)
23. Vent Valve
24. Unit Filling Valve "Cross Design"
D E S C R I P T I O N
Flow Chart

A
S A F E T Y P R E C A U T I O N S

Page A - 11
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Intended Use
Only use the unit in perfect condition for its intended purpose, safety and intended use and observe
the operating instructions! In particular disorders that may affect safety have to be eliminated im-
mediately!
Use the unit exclusively for the determined medium (see "Technical Data"). Any other use that is not
specified is not authorized. The manufacturer/supplier shall not be liable for any damages resulting
from such use. Such risk lies entirely with the user. Authorization for use is also under the condition
that the instruction manual is complied with and inspection and maintenance requirements are en-
forced.
No change and modification to the unit can be made without the written agreement of the manu-
facturer. The manufacturer is not liable for damage to persons or property resulting from unauthori-
sed modifications.
Operators
Target groups in these instructions;
Operators
Operators are persons who are authorized and briefed for the use of the compressor.
Qualified personnel
Qualified personnel are persons who are entitled to repair, service, modify and maintain the system.
S A F E T Y P R E C A U T I O N S
Warning
Only trained personnel are permitted to work on the unit!
!
Warning
Work on the electrical equipment on / with the machine / unit may only be carried out by
qualified electricians.
!

Page A - 12
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
Safety Instructions on the Unit
Importance of notes and warning signs that are affixed to the compressor according to the applica-
tion or its equipment.
S A F E T Y P R E C A U T I O N S
Warning
High voltage!
Note
Ensure correct direction of
rotation!
Warning
Hot surfaces!

Page A - 13
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
S A F E T Y P R E C A U T I O N S
General Safety Precautions
• Read the Operating Instructions of this product carefully prior to use.
• Strictly follow the instructions. The user must fully understand and strictly observe the instruc-
tions. Use the product only for the purposes specified in the intended use section of this
document.
• Do not dispose the operating instructions. Ensure that they are retained and appropriately used
by the product user.
• Only trained and competent personnel are permitted to use this product.
• Comply with all local and national rules and regulations associated with this product.
• Only trained and competent personnel are permitted to inspect, repair and service the product.
• Only authentic L&W parts and accessories may be used for maintenance work. Otherwise, the
proper functioning of the product may be impaired.
• Do not use faulty or incomplete products. Do not modify the product.
• Inform L&W in the event of any product or component fault or failure.
• The quality of the air supply must meet EN 12021 specifications for breathing air.
• Do not use the product in areas prone to explosion or in the presence of flammable gases. The
product is not designed for these applications. An explosion might be the result if certain conditi-
ons apply.

Page A - 14
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
S A F E T Y P R E C A U T I O N S
Unit customised Safety Notices
Organisational measures
• In addition to the instruction manual, observe and comply with universally valid legal and other
obligatory regulations regarding accident prevention and environment protection.
• In addition to the instruction manual, provide supplementary instructions for supervision and
monitoring duties taking into consideration exceptional factors e.g. with regard to organisation
of work, production, personnel employed.
• Supervise personnel’s work in accordance with the instruction manual, taking into account safety
and danger factors.
• Observe all safety and danger notices on the compressor and check readability and completen-
ess.
Safety Instructions Operation
• Take measures to ensure that the machine is only taken into operation under safe and functional
conditions. Only operate the compressor if all protective and safety equipment, e.g. detachable
protective equipment, are provided and in good working order.
• Check the compressor at least once per day for obvious damage and defects. Inform the respon-
sible department / person immediately if anything is not as is should be (including operation per-
formance). Shut down the machine immediately if necessary and lock it.
• In case of malfunction, stop the compressor immediately and lock it. Repair malfunctions imme-
diately.
• If there is a failure in the electric energy supply, shut the machine / unit down immediately.
• Ensure safe and environmentally friendly disposal of consumables and old parts.
• The stipulated hearing protectors must be worn.
• Soundproofing equipment on the compressor has to be activated in safety function during ope-
ration.
• When handling with fats, oils and other chemical agents, observe the note for the product-
related safety.

Page A - 15
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
S A F E T Y P R E C A U T I O N S
Maintenance Instructions
• Hoses have to be checked by the operator (pressure and visual inspection) at reasonable inter-
vals, even if no safety-related defects have been detected.
• Immediately repair any damage. Escaping compressed air can cause injury.
• Depressurise system and pressure lines before beginning repair work.
• Pressurised air lines must be laid and mounted by qualified personnel. Connections must not be
mixed up. Fittings, length and quality of the piping must correspond to requirements.
• Adjustment, maintenance and inspection activities and keep appointments, including informati-
on on replacement parts / equipment, prescribed in the operating instructions have to be respec-
ted.
• If the machine / equipment is completely off during maintenance and repair work, it must be
protected against unexpected restart. Turn off main control device and remove the key and/or
display a warning sign on the main switch.
• The machine and especially the connections and fittings should be cleaned from oil, fuel and
maintenance products at the beginning of the maintenance / repair. Do not use aggressive
cleaning agents. Use fibre-free cleaning cloths.
• Switch off compressor and clean with a slightly damp cloth. Remove dirt from cooling pipes by
using a brush.
• After cleaning, examine all pipes for leaks, loose connections, chafing and damage. Immediately
eliminate any faults.
• Always retighten any screw connections loosened for maintenance or repair work.
• If it is necessary to remove safety devices for maintenance and repair work, these must be re-
placed and checked immediately after completion of the maintenance or repair work.
• The electrical equipment of the compressor must be regularly checked. Defects, such as loose
screw connections or burnt wires, must be immediately rectified by electrically skilled personnel.
• Only personnel with particular knowledge and experience with pneumatics may carry out work
on pneumatic equipment.
• Only personnel with particular knowledge and experience in gas equipment may carry out work
on gas equipment.

Page A - 16
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
S A F E T Y P R E C A U T I O N S
Transportation Instructions
• Parts which need to be dismantled for transport purposes must be carefully replaced and secured
before taking into operation.
• The transport may only be carried out by trained personnel.
• For transportation, only use lifting devices and equipment with sufficient lifting power.
• Do not stand or work under suspended loads.
• Also separate from minor relocation machinery / system of any external energy supply. Before
recommissioning, reconnect the machine to the mains according to regulations.
• When recommissioning, proceed according to the operating instructions..
Safety Regulations
• Inspections according to legal and local obligatory regulations regarding accident prevention are
carried out by the manufacturer or by authorised expert personnel. No guarantees whatsoever
are valid for damage caused or favoured by the non-consideration of these directions for use.

A
I N S T A L L A T I O N

Page A - 18
A
LW 200 B MC / 250 B MC
Version: 01.05.2020
I N S T A L L A T I O N
Danger
Compressors with petrol or diesel motors must only be located outdoors, never indoors,
not even in partially closed rooms however large they may be.
No operation in explosion-hazard areas.
The unit is not approved for operation in areas prone to explosion.
!
Outdoor Installation
For outside installation observe the following:
• Install the unit horizontally and level. The floor must be vibration-free and capable of taking the
load of the system weight.
• On units employing petrol or diesel motors, it is most important that only clean air is used.
Position compressor in direction of wind so that exhaust fumes are blown away from the unit.
• Intake air must be free from noxious gas e.g. smoke, solvent vapours, exhaust fumes etc.
• Observe the specified operating temperature (see "Technical Data")!
