Landworks LBB02 User manual

REV 08/12/19
Instruction Manual
24V Power Barrow
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules
and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required. Keep
these instructions to assist in future servicing.

SPECIFICATIONS
POWER BARROW SAFETY USE WARNINGS
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres,such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or fumes.
3. Keep children and by standers away while operating a power tool.Distractions can cause you to lose control.
4. When operating the machine, stand behind the machine and hold the handles firmly.
5. Do not allow anyone stand in the barrow.
6. When operating the machine in reverse and walking backward, watch behind you and be careful not to slip or
trip.
7. Do not use the machine when visibility is poor, because there is a risk of striking obstacles.
8. When operating the machine on rough ground, decrease speed and exercise caution.
9. When using the machine, avoid soft ground to prevent overturn due to the shoulder of the road collapsing.
10. Do not operate the machine on upward slopes greater than 12°.
11. If you find an abnormality, stop the machine on flat ground.
12. The machine, make sure that the lock lever is fully pulled down and completely locked. If the lock is incomplete,
there is a risk of accident or injury as the carrier or bucket may be tilted and the objects fall when going down-
hill.
OPERATION ON SLOPE WARNINGS
1. Do not cross on slopes.Be sure to decrease speed and exercise caution.
2. Exercise caution when starting or stopping the machine on slopes.
3. As the loads become less stable on slopes, firmly secure the loads with ropes
4. As the view is obscured on slopes, keep the height of the load to a minimum
5. Never park the machine on steep slopes. Park the machine on flat ground, and turn off the power.
6. Do not change the direction or speed mode on steep slopes.
7. Do not release the switch trigger on upward slopes. The machine may go in reverse and cause an accident.
8. Make sure that the remaining battery capacityis enough before operating on slopes. If theremaining battery
capacity is not enough, charge the battery or replace it with a charged one.
LOADING OBJECTIVE WARNINGS
1. Do not overload objects. When loading objects, be sure to follow the instructions and load limits in the manual.
2. Firmly secure the objects with ropes.
3. Load the objects within the bucket. If the objects protrude from the bucket, there is a risk of accidents due to the
objects falling or contact obstacles such as walls.
4. Be sure that loaded objects are below eye level. If the load is too high, it is dangerous because the view is
obscured. Also, there is a risk of overturning and injury because the load is likely to be unbalanced.
5. Load the objects on the carrier or bucket evenly. If the objects are loaded unevenly, there is a risk of overturning
and injury because the load is likely to be unbalanced.
6. When lifting and tilting the carrier or bucket, hold the handles and frame firmly, and work in a stable posture.
Item No.
Rating
Loading Capacity
Battery Specification
Speed
Max. Cubage
LBB02
DC 24V/0.25HP/180W
330lbs/150kgs
12V,7Ah*2
Forward: 0-5km/h(0-3MPH) Variable, Reverse: 0-3.5km/h(0-2.2MPH) Variable
Max 4 Cubic Feet
1

BATTERY POWER TOOL USE AND CARE WARNINGS
1. Ensure the switch is in the off position before inserting battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
2. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery pack.
3. Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk
of injury and fire.
4. When battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or fire.
5. Under abusive conditions, liquid may be ejected from the battery; avoid contact. if contact accidentally occurs,
flush with plenty of soap and water. If liquid contacts eyes, immediately seek medical help. Liquid ejected from
the battery may cause irritation or burns.
6. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or grounded.
7. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric
shock.
8. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
9. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
PERSONAL SAFETY WARNINGS
1. This is not a toy. Children under 14 years of age are not allowed to operate it.
2. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs, alcohol or medication.
3. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal
injuries.
4. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or
BATTERY pack, picking up or carrying the tool.
5. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
6. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in
unexpected situations.
7. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving
parts.
8. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected
and properly used. Use of dust collection can reduce dust-related hazards.
9. Does not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a fraction of a second.
10. Always wear protective goggles to protect your eyes from injury when using power tools.
11. It is an employer's responsibility to enforce the use of appropriate safety protective equipment’s by the tool
operators and by other per- sons in the immediate working area.
2

3
ASSEMBLY
Step 2：
Install bucket bracket (number 1)
and supporting leg (number 18)
with bolts. (See Figure 2)
Step 1：
Install bucket bracket (number 1)
and drive axles (number 8) with
bolts. (See Figure 1)
Step 3：
Fixed assembly of installation nuts with wheels
(number 4) and drive axles (number 8).
(See Figure 3)
Step 4：
Fix the bucket bracket (number 1) and the right handle-
bar (number 3) the left handlebar (number 5) and the
handlebar connecting plate (number 12) with bolts,
respectively. (See Figure 4)
Step 5：
Fixed the bucket bracket (number 1) and the bucket
(number 2) with bolt separately. (See Figure 5)
Figure 1 Figure 2
Figure 3 Figure 4
Figure 5

4
TROUBLESHOOTING
WARRANTY
All new machinery is supplied with limited 12 months Warranty.
1. The manufacturer warrantees this electric power barrow against defects in material and craftsmanship, for a
period of 12 months from date of original purchase;
2. Items considered as consumable parts are not normally covered by the warranty, including but not limited to:
Batteries, Electric cables; Filters;
3. This warranty excludes parts that are worn or damaged due to normal wear, routine tune up or adjustment,
abuse/misuse or neglect, overheating lack of maintenance, fittings/fasteners becoming loose/detached through
lackof maintenance.
4. The warranty does not cover damage caused by accident, misuse or faulty installation, improper handling,
routine maintenance items such as O-rings, seals, and lubricants, accessory parts.
5. The electric power barrow must be installed and maintained in compliance with the instructions.
Problem(s)
The power barrow
does not run.
The power barrow
runs sluggishly
Possible Cause
Battery is not charged
The wire is loose
The controller is damaged
Battery volume is low
The battery is old and does not accept full
charge
The conditions are too stressful for your
power barrow
Corrective Action
Charge the battery pack according to the
instructions included with you model.
Check all the connectors and to see if any part
is loose or not.
Replace the damaged one with specific controller
See the battery indicator to check the volume.
Charge the battery pack according to the
instructions included with you model.
Replace the battery with a new one
The barrow is intended for residential use.
If slopes are too steep or the terrain too bumpy,
your barrow might experience a noticeable
decrease in performance
