Lang Makro-Grip 48409-77 User manual
LANG Technik GmbH •Albstraße 1-6 •D-73271 Holzmaden •www.lang-technik.de •Version 2021/010
Makro•Grip
®
Contour Jaws
Item number
48409-77
48409-125
48419-77
48419-125
48410
48420
Original Instructions
Operating Instructions
3Imprint
Copyright:
LANG Technik GmbH
Albstraße 1–6
D-73271 Holzmaden
Phone: +49 7023 9585-0
Fax: +49 7023 9585-100 Internet: www.lang-technik.de
This documentation contains instructions and information that may not be reproduced,
distributed or transmitted using data technology, or utilized without permission for competitive
purposes, either in whole or in part. This documentation is subject to errors and omissions.
LANG Technik GmbH reserves all rights to this documentation.
Product modifications: Modifications to the product by the customer void the warranty. No
modifications may be made to the product without the manufacturer‘s consent.
Use only original spare parts. There is no guarantee that parts sourced from third parties are
designed and produced to withstand the intended use and safety requirements.
The manufacturer provides full warranty coverage only and exclusively for spare parts ordered
from him.
The manufacturer is continually working to improve his products and reserves the right to make
modifications to them. The manufacturer is therefore under no obligation to make subsequent
modifications to products already delivered.
General Terms and Conditions of Sale and Delivery:
Our General Terms and Conditions of Sale and Delivery generally apply. These terms and
conditions are available to the operator upon the signing of the contract.
Warranty and liability claims for personal injury and property damage are excluded if they are
due to one or more of the following:
– Improper use
– Incorrect installation, commissioning, operation and maintenance
– Operation of the product when it is defective
– Inadequate monitoring of parts that are subject to wear
– Failure to follow the instructions in the documentation
– Catastrophic events caused by external influences or force majeure
1
Chapter 1 Product Description Page
1.1 Unit
1.2 Areas of Application
1.3 Accessories 2
Chapter 2 Technical Data
2.1 General Data
2.2 Material
2.3 Scope of Supply
2.4 Maintenance and Repair 3
Chapter 3 Design and Function
3.1 Assembly
3.2 Disassembly
3.3 Use 4
Chapter 4 Servicing
4.1 Malfunctions/Error 7
Chapter 5 Warnings
5.1 Intended Use
5.2 Personnel Requirements
5.3 Protective Equipment and Safety 7
Chapter 6 Decommissioning
6.1 Disposal 8
Chapter 7 Explanation of Symbols
7.1 Symbols 9
Contents
2
Chapter 1
1 Product Description
1.1 Unit
Our Makro•Grip®Contour Jaws are used to clamp workpieces such as those with
pre-machined contours (see example).
Using the two magnets eliminates the need to screw down the contour jaws.
Information on mounting and use can be found under 3.1.
No special base jaws are required – only the standard Makro•Grip®Jaws.
The illustration below shows two pre-milled contour jaws (in blue), clamped in a
Makro•Grip®5-Axis Vise 48205-125.
1.2 Areas of Application
Using contour jaws, which are adaptable to any workpiece shape, the operator is
able to clamp pre-machined contours with little effort.
1.3 Accessories
Two magnets in each jaw provide additional fixation and stabilization in the
Makro•Grip®5-Axis Vise. These can be removed when disposing of the jaws
and can be reused with new jaws.
3
Chapter 2
2 Technical Data
2.1 General Data
Description Item number Dimensions
Width x Depth x
Height
Weight
(grams)
Contour Jaws for
the inside:
for Makro•Grip®77
48409-77 77 x 30 x 28 mm 155 g
Contour Jaws for
the inside:
for Makro•Grip®125
48409-125 125 x 30 x 33 mm 299 g
Contour Jaws for
the outside:
for Makro•Grip®77
48419-77 77 x 33 x 28 mm 136 g
Contour Jaws for
the outside:
for Makro•Grip®125
48419-125 125 x 43 x 33 mm 307 g
Magnet set 48410 ø 20 x 21 mm 6 g
Mounting tool 48420 77 x 10 x 3 mm 6 g
2.2 Material
Item Material
General components Aluminum and neodymium
2.3 Scope of Supply
The scope of supply includes only the items you ordered. The Makro•Grip®5-Axis Vise as well as
the mounting magnets and the mounting tool must be ordered separately in the correct quantity
and size.
2.4 Maintenance and Repair
Please contact LANG Technik GmbH directly if any item is damaged or malfunctioning.
LANG Technik GmbH •Albstraße 1–6 •D-73271 Holzmaden, Germany •Phone: +49 7023 9585-0
4
3.1 Assembly
PREPARING THE MAKRO•GRIP®CONTOUR JAWS:
1. The magnets (2x) are inserted by hand into
the slots of the top jaw and pushed toward
the outer surfaces.
2. The mounting tool is then positioned with
the pin in the slot facing inward between
the magnet and contour jaw.
3. Next, the magnet is pushed outward using
the mounting tool. The slant helps secure it
in this position.
3.2 Disassembly
1. The mounting tool is also used for removal,
however this is done via the slot facing
outward between the magnet and contour
jaw.
Chapter 3
3 Design and Function
Magnet
Mounting tool, inward
Mounting tool, outward
5
Chapter 3
3 Design and Function
3.3 Use
SETTING UP THE MAKRO•GRIP®CONTOUR JAWS ON THE MAKRO•GRIP®5-AXIS VISE:
1. Place the contour jaws precisely and accurately on the Makro•Grip®Jaws.
The pre-stamped contour must engage and lock into the serration of the
clamping jaws.
2. To ensure that the contour jaws are ideally positioned, they must be tightened to
the maximum torque (M = 70Nm / 100Nm) of the clamping device before they are
used for the first time. This positions them accurately on the Makro•Grip®Jaws with
no clearance.
No precision block
6
3. Before placing the milling contour, a precision block must be clamped between the
contour jaws. This block is tightened with the torque defined and specified for the
future part. Thus the conditions created are the same as those created when
manufacturing the component to be machined.
If there is no precision block, the jaws are clamped against each other. To do this,
the milling contour must be adjusted accordingly.
LANG TECHNIK SAFETY INFORMATION
The minimum clamping depth (E) is limited to 3 mm. In this regard,
applying force above the 3 mm clamping depth is not permitted.
4. The final step is to place the desired workpiece contour into the top jaws. To avoid
future confusion, we recommend engraving/labeling the jaws “left” and ”right” or
with the serial number of the clamping device.
Milled contour
3 Design and Function
Chapter 3
With precision block
No precision block
7
Chapter 4 Chapter 5
4 Servicing
4.1 Malfunctions/Errors
Caution! The component and clamping device can become magnetized.
The inserted magnets, as well as the part, can become magnetized as a result
of using the Makro•Grip®5-Axis Vise several times. Particles from milling can
remain stuck on the device. Regular cleaning of the elements is necessary to
ensure a perfect fit without interference. The magnets can be removed as
necessary for cleaning.
5 Warnings
5.1 Intended Use
The operating company is responsible for using the product as intended, with caution and
under the appropriate conditions. In the event of improper use, no liability shall be assumed
by the manufacturer, nor shall any refund be provided.
5.2 Personnel Requirements
Operating company responsibilities:
Only trained personnel with the relevant background knowledge (specializing in
metal), e.g. CNC operators, are authorized to work with the product.
Personnel responsibilities with regard to installation, commissioning, operation,
maintenance and repair must be clearly defined.
Trainees may work with the product only when supervised by an experienced
professional (specializing in metal) or by a CNC operator.
5.3 Personal Protective Equipment and Safety of Personnel
Personal protective equipment (work clothes and non-slip safety footwear, gloves,
hair net, etc.) must be worn as specified in the guidelines and regulations of the em-
ployer’s liability association and the operating company. Obtain information from your
employer’s safety officer.
8
Chapter 6
6 Decommissioning
6.1 Disposal
as Specified in EU Directive 2018/851
Comply with country-specific disposal regulations when disposing of equipment.
LANG Technik products are not considered household waste.
Failure to comply with disposal requirements is a regulatory offense.
Accessories and packaging are recycled in an environmentally friendly manner.
Product Material Disposal
Housing, screws,
nuts, etc.
Metal Separation of materials
Recycle by melting
down
Protective shield Plastic Recycle
Hoses Rubber, PVC, steel Separation of materials
Recycle
PE lm Plastic Recycle
Packing material Pallet wood Recycle
Hydraulic oil Mineral oil As per local
regulations
9
7 Explanation of Symbols
7.1 Symbols
Please pay attention to the following warning symbols
Read all the operating instructions carefully before commissioning for
the first time and keep it in a safe place for future use
Please read and follow the technical and safety instructions
Direction indicator
Direction indicator, correct rotation
The use of protective gloves made of tough, resistant material is
recommended
A helmet and safety goggles are recommended for personal safety
To reduce the risk of eye injuries, wearing protective goggles as
specified in EN 166 is recommended
Safety footwear are part of the protective equipment
Materials are recycled in an environmentally friendly manner
Do not dispose of the material in household waste
Chapter 7
LANG Technik GmbH
Albstraße 1–6
D-73271 Holzmaden
Phone: +49 7023 9585-0
Fax: +49 7023 9585-100 Internet: www.lang-technik.de
