Lantech MC-116-RPS User manual

INSTALLATION AUXILIARY FIGURES
Accessories Mount ear Mount rack
Pulling cable x 1 Power cord x 1
Slider set x 16
Mount ear x 2
Rubber pedestal x 4
Take screws off to remove mount ear Fasten screws in rack to fix the Chassis
Upper and lower slider of
media converter
Slide in Slide out with pulling
cable
1 2
When installing the media converter to the Chassis,
please attach two sliders to the media converter first.
1. Take off 4 screws from the media converter.
2. Fasten two sliders with screws in top and
bottom locations.
Push the media converter into the Chassis and
fasten screws on the slider of media converter.
Pull out the media converter with the pulling
cable.
Note:
1. For recent media converters, there are 4 reserved screw holes on
laterals or sliders.
2. If your media converters are older versions, please unscrew
first (Refer to Point 1).
3. If your media converters already have reserved lateral holes, please
fasten the sliders directly (Refer to Point 2).
Top view with fan location Fan replacement Power replacement
A C 10 0 - 2 40 V A C 10 0 - 2 40 V
AC 1 00 -2 4 0 V
1AC
1 00 -2 4 0 V
2
Unfasten four screws for fan replacement.
1.Take the fan out from the Chassis, then
pull power jacket off.
2. Replace a new fan, then put power jacket back.
3. Push the new fan back to the Chassis.
4. Fasten four screws.
Remove screws from two sides of power
supply then pull power supply out.

MC-116-RPS
16-Slot
Universal
Medi a Converter
Chassis
User's Guide
Version 2.0
Trademarks
Contents subject to revision without prior notice.
All other trademarks remain the property of their
owners.
Copyright Statement
This publication may not be reproduced as a whole or
in part, in any way whatsoever unless prior consent
has been obtained from the owner.
FCC Warning
The chassis has been tested and certified as with in
Class A digital specifications under Part 15 of FCC
Rules. These standards are designed to provide
reasonable protection from harmful interference when
these units are used in a commercial environment.
These devices can use, generate and radiate radio
frequency energy and may cause harmful interface to
radio communications unless installed in accordance
with the instructions in this User's Guide. Operation of
this device in a residential area is likely to cause
harmful interference which will make the user
responsible for the appropriate remedial action at
his/her expense.
CE Mark Warning
These are Class A products. In some domestic
environments, it may cause radio interface in which
case the user will need to consider adequate
preventative measures.
1. Introduction
The 16 Slots Universal Media Converter Chassis is
designed to accommodate sixteen separate and
independent our media converters within a rack-
mountable rack.
The Chassis is fitted with two hot-swappable power
supplies and three hot-swappable fans for enhanced
reliability. This means that if one power supply fails,
the other is capable of taking over immediately. The
other benefit is that if power supply or fan fails then it
can be replaced with another one without taking back
whole Chassis.
Power status is shown on the LED display for the
user to monitor and respond as necessary. For
optimal performance, please ensure that the Chassis
is placed in a well-ventilated position, enabling air to
circulate above and below the unit.
The Chassis can also be installed in a standard 19-
inch site rack; provision has been made for the
appropriate connecting brackets.
Note: This Chassis has been designed to house only
the proprietary range of media converters. Any other
configuration is at the user´s own risk.
2. Installation(Refer to the back page) 3. Specifications
2.1 Rack Mounting
The Chassis can be mounted in a standard EIA 19-
inch rack. Begin by aligning the mounting brackets
along the sides of the unit with the slit over the
holes. Secure the screws tightly to fit the brackets to
the device before fixing it into the 19-inch rack. Please
ensure that the ventilation holes are not obstructed.
The step-by-step procedure is shown on the next page.
2.2 Media Converter
1. Screw the upper and lower sliders on media
converter.
2. Carefully align the slider with slide way, then
press it with firm and steady pressure.
2.3 Cabling
1. The correct cable specifications and distances will be
listed on the media converter’s documentation.
2. Connect the RJ-45/fiber cable to the front of media
converter.
Slot number
16 slots
LED
Power A Activity
Power B Activity
Redundancy
2 Hot-Swappable Power Modules
Power
AC Power Option (Per Power Supply Unit):
-Input: 100V ~ 240V, 3.0A, 50/60Hz
-Output: 5VDC
DC Power Option (Per Power Supply Unit):
-Input: 48VDC
-Output: 5VDC
Power Consumption: 9.5W (Empty Loading)
Typical Operation & Storage Temperature
Operation: 0 ~ 50°C
To ensure the best performance of standalone
media converters, please keep your environment
temperature under 40 degrees Celsius. Or, install
two power modules for the Chassis.
2.4 Powering
1. Connect the female end of the power cord to the
MCR.
2. Connect the male end of the power cord to an
external AC outlet.
3. LEDs of the power A, B on the Chassis will
illuminate when the installation is done correctly.
4. Similarly, the power indicator LEDs on the media
converter will illuminate when the installation is
complete and correct.
Storage Temperature: -20 ~ 60°C
Humidity: 5% ~ 90% non-condensing
Dimension and Weight
Size: 440 x 385 x 90mm (W x D x H)
Weight:
- 7.65KG (The Chassis Only)
-10.4KG (The Chassis With 2 Power Modules)
Emission/Safety:
EMI: FCC Class A, CE
.
Strongly Recommended:
