Lantronix NM2-GXE-2230 201 Series User manual

NM2-GXE-2230-xx-201 Series
Install Guide
Part Number 33811
Revision E September 2022

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 2
Intellectual Property
© 2022 Lantronix, Inc. All rights reserved. No part of the contents of this publication may be transmitted or
reproduced in any form or by any means without the written permission of Lantronix.
Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries.
Patented: https://www.lantronix.com/legal/patents/; additional patents pending.
Warranty
For details on the Lantronix warranty policy, go to http://www.lantronix.com/support/warranty.
Contacts
Lantronix Corporate Headquarters
48 Discovery, Suite 250
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Tel: [phone], Tel: [phone], or https://www.lantronix.com/technical-support/
Sales Offices
For a current list of our domestic and international sales offices, go to www.lantronix.com/about/contact.
Disclaimer
All information contained herein is provided “AS IS.” Lantronix undertakes no obligation to update the information
in this publication. Lantronix does not make, and specifically disclaims, all warranties of any kind (express, implied
or otherwise) regarding title, non-infringement, fitness, quality, accuracy, completeness, usefulness, suitability or
performance of the information provided herein. Lantronix shall have no liability whatsoever to any user for any
damages, losses and causes of action (whether in contract or in tort or otherwise) in connection with the user’s
access or usage of any of the information or content contained herein. The information and specifications
contained in this document are subject to change without notice.
Revision History
Date
Rev.
Notes
12/16/19
A
Initial release for production.
1/23/20
B
Add NM2-GXE-2230-SFP-201.
9/1/20
C
Update features. Update NM2-GXE-2230-SFP-201 FFC cable drawing on page 5.
3/11/22
D
Update to include OptiPlex 7080 versions.
9/20/22
E
Initial Lantronix rebrand.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 3
Contents
Product Description ........................................................................................................................................ 4
Ordering Information....................................................................................................................................... 4
Supported Fiber Connections......................................................................................................................... 5
Driver Support................................................................................................................................................. 5
Features.......................................................................................................................................................... 5
Specifications.................................................................................................................................................. 6
Regulatory Compliance.................................................................................................................................. 6
Declaration of Conformity ........................................................................................................................... 7
Package Contents .......................................................................................................................................... 7
Reference Views............................................................................................................................................. 8
Product Views............................................................................................................................................. 8
OptiPlex Views............................................................................................................................................ 9
OptiPlex 7060 Micro Ports & Slots ........................................................................................................... 10
Installing the NM2-GXE-2230-xx-201 in the Dell OptiPlex ........................................................................... 11
Installation Overview................................................................................................................................. 11
Removing the Side Cover......................................................................................................................... 12
Replacing the Side Cover ......................................................................................................................... 12
System Board / Layout (7060 Micro) ............................................................................................................ 13
Installing the NM2-GXE-2230-xx-201A in the Dell OptiPlex......................................................................... 14
Installed Views.......................................................................................................................................... 15
NM2-GXE-2230-xx-201 and -201A Views................................................................................................ 16
OptiPlex 7080 Micro Views....................................................................................................................... 18
OptiPlex 7080 Micro Ports & Slots ........................................................................................................... 19
Removing the 7080 Micro Side Cover...................................................................................................... 20
Installing the OptiPlex 7080 Micro Side Cover ......................................................................................... 21
System Board Layout (7080 Micro 35W)...................................................................................................... 22
System Board Layout (7080 Micro 65W)...................................................................................................... 22
OptiPlex 7080 Micro Installed Views ........................................................................................................ 23
Status LED.................................................................................................................................................... 25
Troubleshooting ............................................................................................................................................ 25
For More Information .................................................................................................................................... 25
Record Device and System Information ....................................................................................................... 26

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 4
Product Description
Lantronix NM2-GXE-2230-xx-201 Series M.2 Gigabit Ethernet Fiber Network Interface Cards (NICs) provide a
fixed LC fiber optic interface or a 1000Base-X Open SFP Slot for the Dell OptiPlex™ 3060/5060/7060, 7070 and
7080 Micro PCs. The NM2-GXE-2230-xx-201 Series consists of an M.2 NIC that installs into the OptiPlex PC’s M.2
“A or E keyed” interface, a fiber optic adapter that installs into the OptiPlex Micro PC’s Option port, and a 20-pin
Flat Flex Cable (FFC) that connects the NIC to the fiber adapter. The NICs are electro-mechanically designed to
be compatible (fit, form, function) with these Dell OptiPlex PCs using the M.2 (A or E Key) slot.
M.2 is a specification for internally mounted computer expansion cards and associated connectors. Desktop PCs
are being replaced by smaller computing devices (such as Thin Clients, Micro PCs, Ultrabooks, and Tablets)
which typically have internal M.2 interfaces but do not have PCI or PCIe slots. Many users still need fiber
Ethernet access, and without the external PCIe slot, there is no standard fiber interface on these devices.
See the Dell OptiPlex manual for important notes, cautions, and warnings. Read the section “Before working
inside your computer” before proceeding.
Ordering Information
SKU
Description
For OptiPlex 7080 DGPU Systems: Please refer to our traditional PCIe NICs webpage
For OptiPlex 3060/5060/7060, 7070, and 7080 35W Systems:
NM2-GXE-2230-LC-201
M.2 Gigabit Ethernet Fiber NIC (1000BASE-SX, 850nm, MM, LC) (fixed optic).
1000Base-SX 850nm multimode (LC) [62.5/125 μm fiber: 220 m/722 ft.]
[50/125 μm fiber: 550 m/1804 ft.] Link Budget: 8.0 dB
NM2-GXE-2230-SFP-201
M.2 Gigabit Ethernet Fiber NIC (1000Base-X Open SFP Slot)
For OptiPlex 7080 65W Systems:
NM2-GXE-2230-LC-201A
M.2 Gigabit Ethernet Fiber NIC (1000BASE-SX, 850nm, MM, LC) (fixed optic).
1000Base-SX 850nm multimode (LC) [62.5/125 μm fiber: 220 m/722 ft.]
[50/125 μm fiber: 550 m/1804 ft.] Link Budget: 8.0 dB
NM2-GXE-2230-SFP-201A
M.2 Gigabit Ethernet Fiber NIC (1000Base-X Open SFP Slot)
Accessories (sold separately):
SFP Modules
Please see our SFP Modules products webpage

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 5
Supported Fiber Connections
•1000BASE-SX, 850nm, MM, LC (fixed optic)
•1000BASE-X, SFP Slot
Driver Support
Windows 10, 8.1, 8, and 7 (32 and 64 bit); Linux
Features
•M.2 Gigabit Ethernet Fiber Network Interface Card (NIC)
•Provides a fixed LC fiber optic interface for the Dell OptiPlex™ 3060/5060/7060, 7070 and 7080 Micro PCs
•PCI Express M.2 compliant (3.3V)
•A + E keyed M.2 interface
•IEEE 802.3-2012 compliant
•Full Duplex
•IPv6 Capable
•A + E keyed M.2 interface
•Supports UEFI
•Jumbo frame support 9014 bytes
•PXE Boot support
•Flow control
•Wake on LAN (WOL)
•Smart Load Balancing (SLB)
•TCP Segmentation Offload (TSO)
•Message Signaled Interrupts (MSI)
•Extended Message-Signaled Interrupts (MSI-X)
•LACP support (Teaming)

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 6
Specifications
•Standards: IEEE 802.3-2012
•Bus Slot: M.2 - ‘2230-D4-A-E’
•Data Rate: 1000 Mbps (full duplex only)
•Max Frame Size: 9014 bytes
•Status LEDs: LINK/ACT ON = Link, Flashing = Activity
•Dimensions (M.2 NIC) 2230-D4-A-E
oWidth: 0.87” [22 mm]
oDepth: 1.18” [30 mm]
oHeight: 0.12” [3.08 mm]
•Dimensions (Fiber Interface) Width: 1.65” [42 mm]
oDepth: 2.05” [52 mm]
oHeight: 0.51” [13 mm]
•Dimensions (FFC Cable)
oNM2-GXE-2230-xx-201 version: 5.013" [127.33 mm]
oNM2-GXE-2230-xx-201A version: 4.429" [112.50 mm]
•Power Consumption (LC): 250mA @ 3.3V (0.8 Watts typical)
•Power Consumption (SFP): 120mA @ 3.3V (0.4 Watts typical without SFP module)
•Power Source M.2 interface connector: 3.3V (Refer to table 41 of M.2 Specification)
•Environment:
oOperating Temp: 0°C to +45°C
oStorage Temp: -40°C to 85°C
oHumidity: 5% to 95% (non-condensing)
oAltitude: 0 – 10,000 ft.
•Weight: 0.1 lbs. [0.05 kg]
•Warranty: Lifetime
•FFC Cable Operating temp.:-40⁰C to +105⁰C.
FFC Cable Max current per contact is 0.5 Amps.
•FFC Cable Max voltage is 60V AC.
Regulatory Compliance
Note: Modification of NIC voids regulatory agency compliance.
Compliance: CE Mark; Emissions: EN55032, FCC Part 15 Class B; Immunity: EN55024
Emissions: EN 55032: 2012/AC: 2013; AS/NZS CISPR 32: 2013; VCCI V-3/2015.04; ICES-003, Issue 6: 2016; FCC
Part 15 Subpart B.
Immunity: EN 55024: 2010 (EN 61000-4-2: 2009; EN 61000-4-3: 2006 + A1: 2008 + A2: 2010; EN 61000-4-4: 2004
+ AC: 2006 + A1: 2010; EN 61000-4-5: 2006; EN 61000-4-6: 2009; EN 61000-4-8: 2010; EN 61000-4-11: 2004).

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 7
Declaration of Conformity
Manufacture’s Name: Lantronics, Inc.
Manufacture’s Address: 48 Discovery, Suite 250, Irvine, California 92618 USA
Declares that the products:
NM2-GXE-2230-SFP-201, NM2-FXS-2230-SFP-201 and NM2-GXE-2230-LC-201A, NM2-GXE-2230-SFP-201A
Conform to the following Product Regulations:
EN 55032: 2012/AC: 2013; AS/NZS CISPR 32: 2013; VCCI V-3/2015.04; ICES-003, Issue 6: 2016; FCC Part 15
Class A.
EN 55024: 2010 (EN 61000-4-2: 2009; EN 61000-4-3: 2006 + A1: 2008 + A2: 2010; EN 61000-4-4: 2004 + AC: 2006
+ A1: 2010; EN 61000-4-5: 2006; EN 61000-4-6: 2009; EN 61000-4-8: 2010; EN 61000-4-11: 2004).
With the technical construction on file at the above address, this product carries the CE Mark
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and
Standard(s).
Place: Irvine, California
Date: April 27, 2022
Signature: Fathi Hakam
Full Name: Fathi Hakam
Position: Vice President of Engineering
High Risk Activities Disclaimer: Components, units, or third-party products used in the product described herein
are NOT fault-tolerant and are NOT designed, manufactured, or intended for use as on-line control equipment in
the following hazardous environments requiring fail-safe controls: the operation of Nuclear Facilities, Aircraft
Navigation or Aircraft Communication Systems, Air Traffic Control, Life Support, or Weapons Systems ("High Risk
Activities"). Lantronix and its supplier(s) specifically disclaim any expressed or implied warranty of fitness for
such High Risk Activities.
Package Contents
Verify that you have received the following items. Contact your sales representative if any item is missing.
Please save the packaging for possible future use.
One M.2 NIC PCB attached to FFC Cable and one fiber optic adapter board in
anti-static pouches.
Parts in a 4x6 baggie (1 each): #4 Flat Head Screw, #4 Nylon Washer, #6
Black SEMS Screw.
One NM2-GXE-2230-xx-201 Install Guide (this document).
One Product Support Postcard.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 8
Reference Views
Product Views
These views are shown as example only and not representative of all SKUs. There is variation in the FFC cable
between NM2-GXE-2230-xx-201 and GXE-2230-xx-201A as they are designed to fit the designated OptiPlex
systems.
NM2-GXE-2230-LC-201:
NM2-GXE-2230-SFP-201:

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 9
OptiPlex Views
These views are shown as example only and not representative of all OptiPlex systems. The NM2 NIC part
numbers are designed to fit the specified OptiPlex systems.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 10
OptiPlex 7060 Micro Ports & Slots
These views are shown as example only and not representative of all OptiPlex systems. The NM2 NIC part
numbers are designed to fit the specified OptiPlex systems.
Dell OptiPlex 7060 Micro Front View: 1. Power button and power light. 2. Hard drive activity light.
3. Headset/Universal audio jack port. 4. Line-out port. 5. USB 3.1 Gen 2 Type-C port with PowerShare.
6. USB 3.1 Gen 1 port with PowerShare.
Dell OptiPlex 7060 Micro Back View: 1. External antenna connectors (2) (optional). 2. DisplayPort/VGA/HDMI
2.0b/DP/USB Type-C alt mode (optional). 3. USB 3.1 Gen 1ports (3). 4. Cable holder. 5. Padlock ring. 6. Network
port. 7. USB 3.1 Gen 1 port (supports Smart Power On). 8. Service tag. 9. Kensington security cable slot. 10.
DisplayPorts (2). 11. Power connector port.
Dell Support for OptiPlex 7060: Diagnostics, Support topics & articles, Drivers & downloads, Manuals &
documents, System configuration, and Parts & accessories.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 11
Installing the NM2-GXE-2230-xx-201 in the Dell OptiPlex
The NM2-GXE-2230-xx-201 Series is designed to install in the Dell OptiPlex™ 3060/5060/7060, 7070 and 7080
Micro PCs.
Caution: Only qualified persons should install the NIC. Failure to observe this caution could result in poor
performance or damage to the equipment. Before installing the NIC, review the Pre-Installation Checklist and
Safety Precautions below.
Caution: Wear a grounding device and observe electrostatic discharge precautions when installing the NIC in a
system. Failure to observe this caution could result in damage to the NIC. Before installing the NIC, review the
Pre-Installation Checklist and Safety Precautions below. Before installing the NIC, ensure that system power is
OFF, the power cord is unplugged from the power outlet, and that proper electrical grounding procedure has
been followed.
Warning: High voltage inside the system may present a safety hazard. Make sure that the system power is off
before removing the cover. Unplug and disconnect the PC and then wait for 15-20 seconds before plugging the
NIC into the PC. When removing the NIC, unplug the Ethernet cable before removing the PC cover.
Note: Refer to the Notes, Cautions, and Warnings in the appropriate Dell OptiPlex Service Manual. See Manuals
& documents for details.
Class I Laser Compliance: This product has been tested and found to comply with the limits for FDA Class I laser
for IEC60825, EN60825, and 21CFR1040 specifications. Warning: Visible and invisible laser radiation when open.
DO NOT stare into laser beam or view directly with optical instruments. Failure to observe this warning could
result in damage to your eyes or blindness.
Installation Overview
Before installing your NIC, review the preceding sections, and then do the following:
1. Verify that your system is using the latest BIOS.
2. If you download the driver software, record the path where you saved the downloads.
3. If your system is active, shut it down. Do not install the NIC until system power is completely removed.
When system shutdown is complete, power OFF and unplug your system.
4. Holding the NIC by the edges, remove it from its shipping package and place it on an antistatic surface.
5. Check the NIC for signs of damage, particularly on the PCB edge connector. Caution: Never attempt to install
a damaged NIC card. If the NIC is damaged, report it to Lantronix.
6. Remove the OptiPlex Side Cover. See Removing the Side Cover below.
7. Gently remove the OptiPlex HDD.
8. Remove the OptiPlex 15-Pin DSUB Knockout.
9. Insert the M.2 NIC into the OptiPlex Micro PC’s M.2 “A or E keyed” interface.
10. Insert the fiber optic adapter into the OptiPlex Micro PC’s Option port.
11. Replace the OptiPlex HDD.
12. Replace the OptiPlex Side Cover.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 12
Removing the Side Cover
1. Follow the procedure in “Before working inside your computer”.
2. To remove the cover:
a) Slide the release latch on the back side of the system until it gives a click sound to unlock the side cover [1].
b) Slide and lift the side cover from the system [2].
Replacing the Side Cover
1. Place the cover on the system and slide the cover until it clicks into place [1].
2. The release latch automatically locks the side cover to the system [2].

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 13
System Board / Layout (7060 Micro)
These views are shown as example only and not representative of all OptiPlex systems. The NM2 NIC part
numbers are designed to fit the specified OptiPlex systems.
For OptiPlex 7070 Information
OptiPlex 7070 Documentation: https://www.dell.com/support/home/us/en/04/product-
support/product/optiplex-7070-desktop/docs
Dell OptiPlex 7070 Micro Service Manual: https://topics-cdn.dell.com/pdf/optiplex-7070-desktop_Owners-
Manual5_en-us.pdf
OptiPlex 7080 Micro Service Manual: https://topics-cdn.dell.com/pdf/optiplex-7080-desktop_owners-
manual_en-us.pdf

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 14
Installing the NM2-GXE-2230-xx-201A in the Dell OptiPlex
The NM2-GXE-2230-xx-201 Series consists of a M.2 NIC that installs into the OptiPlex Micro PC’s M.2 “A or E
keyed” interface, and a fiber optic adapter that installs into the OptiPlex Micro PC’s Option port. Review the
“Installation Overview” section on page 11.
1. Remove PC cover.
2. Gently remove the HDD Assembly. See the Dell documentation.
3. Remove the 15-Pin DSUB knockout.
4. Insert the M.2 NIC into the OptiPlex Micro PC’s M.2 “A or E keyed” interface.
5. Secure the M.2 NIC Assembly into place using the Securing Screw.
6. Insert the fiber optic adapter into the OptiPlex Micro PC’s Option port.
7. Attach to PC Case using Black SEMS Screw #6-32x1/4”, and partially tighten to hold in place as shown below.
8. Align #4 Standoff with Top Hole in PC Case.
9. Slip #4 Nylon Washer on top of #4 Standoff and insert #4 Screw to secure.
10. Tighten using Black SEMS Screw #6-32x1/4”.
11. Lift Locking Lever of FFC Connector on fiber optic adapter.
12. Insert end of 20-Position FFC Cable into fiber optic adapter, with Pins facing down.
13. Push Locking Lever Down to Lock. Check that Cable is secure. See figure below for final placement.
14. Gently replace the HDD Assembly.
15. Replace PC cover.
16. Connect the fiber adapter/connector.
17. Power up the PC.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 15
Installed Views
These views are shown as example only and not representative of all OptiPlex systems. The NM2 NIC part
numbers are designed to fit the specified OptiPlex systems.

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 16
NM2-GXE-2230-xx-201 and -201A Views
The specific M.2 Gigabit Ethernet Fiber NIC required is dependent on whether the OptiPlex 7080 is a 35W or
65W system. For OptiPlex 7080 DGPU systems, please refer to our traditional PCIe NICs.
NM2-GXE-2230-LC-201A NM2-GXE-2230-SFP-201A
for 35W
for 65W

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 17
NM2-GXE-2230-SFP-201A Installed View

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 18
OptiPlex 7080 Micro Views
1. Side cover
2. Fan assembly
3. Heatsink
4. Speaker
5. Hard drive caddy
6. System board
7. Chassis
8. Processor
9. M.2 WLAN
10. Memory module
11. SATA Flexible Flat Cable (FFC) bracket
12. M.2 Solid-state drive
13. Hard drive assembly

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 19
OptiPlex 7080 Micro Ports & Slots
1. Power Button 2. Universal Audio Jack 3. Line Out 4. USB 3.2 Gen2 Type-C Port 5. USB 3.2 Gen 2 Type-A Port
(with PowerShare) 6. Wireless Antenna Slots 7. Optional: Serial RS232/PS/2 Ports/DP1.4/HDMI 2.0b/VGA/USB
3.2 Gen 2 Type C with DP Alt Mode 8. RJ-45 9. 2 USB 3.2 Gen 1 Type-A Ports (1 with Smart Power on)
10. 2 USB 3.2 Gen 2 Type-A Ports 11. Cable Clip 12. Thumbscrew 13. Kensington lock slot 14. 2 DisplayPort
1.4 15. Power Connection (DC-in)

Lantronix NM2-GXE-2230-xx-201 Install Guide
33811 Rev. E https://www.lantronix.com/ 20
Removing the 7080 Micro Side Cover
Prerequisites: 1. Follow the procedure in “Before working inside your computer”.
Note: Ensure that you remove the security cable from the security-cable slot (if applicable).
About this task: The following images indicate the location of the side cover and show the removal procedure.
1. Loosen the thumbscrew (6x32) that secures the side cover to the system.
2. Slide the side cover towards the front of the system and lift the cover.
