Lantronix xSenso 2100 User manual

Part Number 900-629-R
Revision A July 2012
xSenso 2100
User Guide

xSenso 2100 User Guide 2
Copyright & Trademark
© 2012 Lantronix, Inc. All rights reserved. No part of the contents of this book may be transmitted
or reproduced in any form or by any means without the written permission of Lantronix.
Lantronix® is a registered trademark and DeviceInstaller™and xSenso™ are trademarks of
Lantronix, Inc.
Windows® and Internet Explorer® are registered trademarks of Microsoft Corporation. Mozilla®
and Firefox® are registered trademarks of the Mozilla Foundation. Chrome™ is a trademark of
Google. Opera™ is a trademark of Opera Software ASA. Tera Term is a registered trademark of
Vector, Inc. All other trademarks and trade names are the property of their respective holders.
Warranty
For details on the Lantronix warranty policy, please go to our web site at
www.lantronix.com/support/warranty.
Contacts
Lantronix Corporate Headquarters
167 Technology Drive
Irvine, CA 92618, USA
Toll Free: 800-526-8766
Phone: [phone]
Fax: [phone]
Technical Support
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix web site at
www.lantronix.com/about/contact.
Disclaimer
The information in this guide may change without notice. The manufacturer assumes no
responsibility for any errors that may appear in this guide.
Revision History
Date Rev. Comments
July 2012 A Initial document for firmware release 7.4.0.0.

xSenso 2100 User Guide 3
Table of Contents
List of Figures _____________________________________________________________9
List of Tables _____________________________________________________________10
1: Using This Guide 12
Purpose and Audience _____________________________________________________12
Summary of Chapters ______________________________________________________12
Additional Documentation ___________________________________________________13
2: Introduction 14
Key Features _____________________________________________________________14
Applications ______________________________________________________________14
Protocol Support _________________________________________________________14
Troubleshooting Capabilities _________________________________________________15
Configuration Methods _____________________________________________________15
Configuration Using the MGMT (USB) Port __________________________________15
Addresses and Port Numbers ________________________________________________16
Hardware Address _____________________________________________________16
IP Address ___________________________________________________________16
Port Numbers _________________________________________________________16
Product Information Label ___________________________________________________17
3: Installation of xSenso 2100 18
Package Contents _________________________________________________________18
User-Supplied Items _______________________________________________________18
Hardware Components _____________________________________________________18
Front/Top Panel _______________________________________________________18
Side Panel ___________________________________________________________21
Back Panel ___________________________________________________________21
Installing the xSenso _______________________________________________________22
4: Using DeviceInstaller 23
Accessing xSenso Using DeviceInstaller _______________________________________23
Device Detail Summary _____________________________________________________23

xSenso 2100 User Guide 4
5: Configuration Using Web Manager 25
Accessing Web Manager ___________________________________________________25
xSenso Home and Device Status Pages ____________________________________28
Live Reading Pages and Configuration Pages ___________________________________29
Web Manager Components _________________________________________________30
Navigating Web Manager ___________________________________________________31
6: Network Settings 33
Network Interface Settings __________________________________________________33
To Configure Network Interface Settings ____________________________________34
To View Network Interface Status _________________________________________34
Network Link Settings ______________________________________________________35
To Configure Network Link Settings ________________________________________35
7: Analog Settings 36
DAQ Format _____________________________________________________________36
To Configure DAQ Settings ______________________________________________36
Analog Input _____________________________________________________________37
To Configure Analog Settings _____________________________________________38
8: Reading 39
Data Reading Configuration _________________________________________________39
To View Data Reading Settings ___________________________________________39
9: Chart 40
Data Chart Configuration ___________________________________________________41
To Configure Data Chart Settings _________________________________________41
10: Logging 42
Data Logging Configuration _________________________________________________42
To Configure Data Logging Settings _______________________________________43
11: Tunnel Settings 44
Tunnel Settings ___________________________________________________________44
Accept Mode __________________________________________________________44
To Configure Tunnel Accept Mode Settings __________________________________45
12: Alarm Settings 46
To Configure Alarm Settings _____________________________________________46

xSenso 2100 User Guide 5
13: Services Settings 48
DNS Settings _____________________________________________________________48
To View or Configure DNS Settings: _______________________________________48
FTP Settings _____________________________________________________________49
To Configure FTP Settings _______________________________________________49
Syslog Settings ___________________________________________________________49
To View or Configure Syslog Settings: ______________________________________50
HTTP Settings ____________________________________________________________50
To Configure HTTP Settings _____________________________________________51
To Configure HTTP Authentication _________________________________________52
RSS Settings _____________________________________________________________52
To Configure RSS Settings ______________________________________________53
14: Security Settings 54
SSH Settings _____________________________________________________________54
SSH Server Host Keys __________________________________________________54
SSH Client Known Hosts ________________________________________________55
SSH Server Authorized Users ____________________________________________55
SSH Client Users ______________________________________________________56
To Configure SSH Settings ______________________________________________57
SSL Settings _____________________________________________________________57
Certificate and Key Generation ___________________________________________58
To Create a New Credential ______________________________________________58
Certificate Upload Settings _______________________________________________59
To Configure an Existing SSL Credential ____________________________________59
Trusted Authorities _____________________________________________________60
To Upload an Authority Certificate _________________________________________60
15: Maintenance and Diagnostics Settings 61
Filesystem Settings ________________________________________________________61
File Display ___________________________________________________________61
To Display Files _______________________________________________________61
File Modification _______________________________________________________62
File Transfer __________________________________________________________62
To Transfer or Modify Filesystem Files ______________________________________63
Protocol Stack Settings _____________________________________________________63
IP Settings ___________________________________________________________63
To Configure IP Network Stack Settings ____________________________________63
ICMP Settings _________________________________________________________64
To Configure ICMP Network Stack Settings __________________________________64
ARP Settings _________________________________________________________64
To Configure ARP Network Stack Settings __________________________________64

xSenso 2100 User Guide 6
SMTP Settings ________________________________________________________65
To Configure SMTP Network Stack Settings _________________________________65
Query Port _______________________________________________________________65
To Configure Query Port Settings _________________________________________65
Diagnostics ______________________________________________________________66
Hardware ____________________________________________________________66
To View Hardware Information ____________________________________________66
IP Sockets ___________________________________________________________66
To View the List of IP Sockets ____________________________________________66
Ping ________________________________________________________________66
To Ping a Remote Host _________________________________________________67
Traceroute ___________________________________________________________67
To Perform a Traceroute ________________________________________________67
Log _________________________________________________________________68
To Configure the Diagnostic Log Output ____________________________________68
Memory ______________________________________________________________68
To View Memory Usage _________________________________________________68
Processes ____________________________________________________________69
To View Process Information _____________________________________________69
Threads _________________________________________________________________69
To View Thread Information ______________________________________________69
System Settings __________________________________________________________70
To Reboot or Restore Factory Defaults _____________________________________70
16: Advanced Settings 71
Email Settings ____________________________________________________________71
To View, Configure and Send Email ________________________________________71
Command Line Interface Settings _____________________________________________72
Basic CLI Settings _____________________________________________________72
To View and Configure Basic CLI Settings ___________________________________72
Telnet Settings ________________________________________________________73
To Configure Telnet Settings _____________________________________________73
SSH Settings _________________________________________________________73
To Configure SSH Settings ______________________________________________74
XML Settings _____________________________________________________________74
XML: Export Configuration _______________________________________________74
To Export Configuration in XML Format _____________________________________75
XML: Export Status _____________________________________________________75
To Export in XML Format ________________________________________________75
XML: Import Configuration _______________________________________________76
Import Configuration from External File _____________________________________76
Import Configuration from the Filesystem ____________________________________76
To Import Configuration in XML Format _____________________________________76

xSenso 2100 User Guide 7
17: Security in Detail 77
Public Key Infrastructure ____________________________________________________77
TLS (SSL) _______________________________________________________________77
Digital Certificates _________________________________________________________77
Trusted Authorities ________________________________________________________77
Obtaining Certificates ______________________________________________________78
Self-Signed Certificates _____________________________________________________78
Certificate Formats ________________________________________________________78
OpenSSL ________________________________________________________________78
Steel Belted RADIUS ______________________________________________________79
Free RADIUS ____________________________________________________________79
18: Updating Firmware 80
Obtaining Firmware ________________________________________________________80
Loading New Firmware through Web Manager __________________________________80
To upload new firmware: _______________________________________________80
Loading New Firmware through FTP __________________________________________81
19: Branding the xSenso 82
Web Manager Customization ________________________________________________82
Short and Long Name Customization __________________________________________83
To Customize Short or Long Names _______________________________________83
Appendix A: Technical Specifications 84
Analog Inputs _________________________________________________________84
Architecture __________________________________________________________84
Network Interface ______________________________________________________84
Management __________________________________________________________84
Security ______________________________________________________________85
Software _____________________________________________________________85
Power* ______________________________________________________________85
Environmental _________________________________________________________85
Physical Characteristics _________________________________________________85
Regulatory Certifications ________________________________________________85
Appendix B: Technical Support 86
Appendix C: Binary to Hexadecimal Conversions 87
Converting Binary to Hexadecimal ____________________________________________87
Conversion Table ______________________________________________________87
Scientific Calculator ____________________________________________________87

xSenso 2100 User Guide 8
Appendix D: Compliance 89
Appendix E: USB-CDC-ACM Device Driver File
for Windows Hosts 91

xSenso 2100 User Guide 9
List of Figures
Figure 2-1 xSenso Product Label ____________________________________________________17
Figure 3-1 xSenso, Front View ______________________________________________________19
Figure 3-2 xSenso Top/Front View ___________________________________________________19
Figure 3-5 xSenso, Side View_______________________________________________________21
Figure 3-6 xSenso Bottom/Back Panel View ___________________________________________21
Figure 5-1 xSenso Home Page______________________________________________________26
Figure 5-2 Device Status Page ______________________________________________________27
Figure 5-4 Live Reading vs. Configuration Pages________________________________________29
Figure 5-5 Components of the Web Manager Page ______________________________________30
Figure 7-1 Analog Inputs 1 and 2 ____________________________________________________36
Figure 8-1 Reading Tab/Page_______________________________________________________39
Figure 9-1 Chart Tab/Page _________________________________________________________40
Figure 10-1 Logging Tab/Page ______________________________________________________42
Figure 18-1 Uploading New Firmware ________________________________________________80
Figure C-2 Windows Scientific Calculator ______________________________________________88
Figure C-3 Hexadecimal Values in the Scientific Calculator _______________________________88

xSenso 2100 User Guide 10
List of Tables
Table 3-3 Analog Input LEDs _______________________________________________________20
Table 3-4 Ethernet LEDs __________________________________________________________20
Table 5-3 Comparing xSenso Home Page and Device Status Page Information _______________28
Table 6-1 Network Interface Settings _________________________________________________33
Table 6-2 Network 1 (eth0) Link Settings ______________________________________________35
Table 7-2 xSenso 2100 DAQ Command ______________________________________________36
Table 7-3 DAQ Settings ___________________________________________________________36
Table 7-4 Analog Input Settings _____________________________________________________37
Table 9-2 Data Chart Settings ______________________________________________________41
Table 10-2 Data Logging Settings ___________________________________________________42
Table 11-1 Tunnel Accept Mode Settings _____________________________________________44
Table 12-1 Alarm Settings _________________________________________________________46
Table 13-1 DNS Settings __________________________________________________________48
Table 13-2 FTP Settings __________________________________________________________49
Table 13-3 Syslog Settings ________________________________________________________49
Table 13-4 HTTP Settings _________________________________________________________50
Table 13-5 HTTP Authentication Settings _____________________________________________52
Table 13-6 RSS Settings __________________________________________________________52
Table 14-1 SSH Server Host Keys ___________________________________________________54
Table 14-2 SSH Client Known Hosts _________________________________________________55
Table 14-3 SSH Server Authorized Users _____________________________________________56
Table 14-4 SSH Client Users _______________________________________________________56
Table 14-5 Certificate and Key Generation Settings _____________________________________58
Table 14-6 Upload Certificate Settings _______________________________________________59
Table 14-7 Trusted Authority Settings ________________________________________________60
Table 15-1 File Display Settings ____________________________________________________61
Table 15-2 File Modification Settings _________________________________________________62
Table 15-3 File Transfer Settings ____________________________________________________62
Table 15-4 IP Network Stack Settings ________________________________________________63
Table 15-5 ICMP Network Stack Settings _____________________________________________64
Table 15-6 ARP Network Stack Settings ______________________________________________64
Table 15-7 SMTP Network Stack Settings _____________________________________________65
Table 15-8 Query Port Settings _____________________________________________________65
Table 15-9 Ping Settings __________________________________________________________67
Table 15-10 Traceroute Settings ____________________________________________________67
Table 15-11 Log Settings __________________________________________________________68

xSenso 2100 User Guide 11
Table 15-12 System Settings _______________________________________________________70
Table 16-1 Email Configuration _____________________________________________________71
Table 16-2 CLI Configuration Settings ________________________________________________72
Table 16-3 Telnet Settings ________________________________________________________73
Table 16-4 SSH Settings __________________________________________________________73
Table 16-5 XML Exporting Configuration ______________________________________________74
Table 16-6 Exporting Status ________________________________________________________75
Table 16-7 Import Configuration from Filesystem Settings ________________________________76
Table 19-1 Short and Long Name Settings ____________________________________________83
Table C-1 Binary to Hexadecimal Conversion __________________________________________87

xSenso 2100 User Guide 12
1: Using This Guide
Purpose and Audience
This guide provides the information needed to configure, use, and update the xSenso. It is
intended for software developers and system integrators who are installing this product into their
designs.
Summary of Chapters
The remaining chapters in this guide include:
Chapter Description
2: Introduction Main features of the product and the protocols it supports.
Includes technical specifications.
3: Installation of xSenso 2100 Instructions for installing the xSenso.
4: Using DeviceInstaller Instructions for viewing the current configuration using
DeviceInstaller.
5: Configuration Using Web Manager Instructions for accessing Web Manager and using it to configure
settings for the device.
6: Network Settings Instructions for configuring network settings.
7: Analog Settings Instructions for configuring analog settings.
8: Reading Instructions for reading live analog data on the Reading page.
9: Chart Instructions for viewing and configuring live analog chart data on
the Chart page.
10: Logging Instructions for running and configuring live data logs on the
Logging page.
11: Tunnel Settings Instructions for configuring line and tunnel settings.
12: Alarm Settings Instructions for configuring alarm settings.
13: Services Settings Instructions for configuring DNS, FTP, HTTP and Syslog settings.
14: Security Settings Instructions for configuring SSL security settings.
15: Maintenance and Diagnostics
Settings
Instructions to maintain the , view statistics, files, and diagnose
problems.
16: Advanced Settings Instructions for configuring email, CLI and XML settings.
17: Security in Detail Provides additional information on security settings available.
18: Updating Firmware Instructions for obtaining the latest firmware and updating the .
19: Branding the xSenso Instructions on how to brand your device.
Appendix A: Technical Specifications
Appendix B: Technical Support Instructions for contacting Lantronix Technical Support.
Appendix C: Binary to Hexadecimal
Conversions
Instructions for converting binary values to hexadecimals.
Appendix D: Compliance Lantronix compliance information.

1: Using This Guide
xSenso 2100 User Guide 13
Additional Documentation
Visit the Lantronix Web site at www.lantronix.com/support/documentation for the latest
documentation and the following additional documentation.
Appendix E: USB-CDC-ACM Device
Driver File for Windows Hosts
Information about the device driver file for windows host.
Document Description
xSenso Command Reference Instructions for accessing Command Mode (the command line
interface) using a Telnet connection, SSH connection or through the
USB port. Detailed information about the commands. Also provides
details for XML configuration and status.
xSenso Quick Start Guide Instructions for getting the xSenso 2100 up and running.
DeviceInstaller Online Help Instructions for using the Lantronix Windows-based utility to locate the
xSenso 2100 and to view its current settings.
Chapter (continued) Description

xSenso 2100 User Guide 14
2: Introduction
xSenso 2100 is a compact DIN-rail or wall mount solution that enables sensors with analog
outputs (voltage or current) to easily and transparently send real-time data to any node on the
network or over the Internet. xSenso is an ideal solution for remote monitoring and data logging of
critical events in process control and automation applications. With its low port density, xSenso
can be affordably installed in dispersed locations. In applications where analog sensors and
controllers are used, xSenso can be configured to send alarms via emails or text messages when
readings are outside predefined ranges. These alarms allow control engineers to take immediate
corrective action when certain thresholds are met. Its embedded web server makes it possible to
monitor the input readings, chart or log the data using browsers on computers, smartphones, and
tablets from anywhere in the world.
Key Features
Power Supply: 9-30 VDC input voltage (1 terminal screw block and 1 barrel jack, where
when both are used, may operate as redundancy and failover)
Ethernet: 1 Port Ethernet 10Base-T or 100Base-TX (auto-sensing for speed, duplex and
cross-over CAT5 cable)
Analog Inputs: 2 configurable analog inputs with available ranges: ±100mV, ±1V, ±10V or
±20mA
USB Ports: One 2.0 full speed USB port for device management and configuration
Temperature Range: Storage and operating temperature between -40° to +85°C
Applications
The xSenso device server connects analog sensors such as those listed below to Ethernet
networks using the IP protocol family.
Temperature Gage
Environmental Data Sensors
Gas Monitoring Devices
Sensors measuring humidity, pressure, flow, level, force, weight and gas or air quality
Protocol Support
The xSenso device server contains a full-featured IP stack. Supported protocols include:
ARP, HTTP, HTTPS, UDP/IP, TCP/IP, SSH, SSL, RSS, ICMP, BOOTP,DHCP, Auto IP,
Telnet, SMTP, DNS, FTP, TFTP, XML and Syslog for network communications and
management.
TFTP for uploading/downloading files.
FTP and HTTP for firmware upgrades and uploading/downloading files.

2: Introduction
xSenso 2100 User Guide 15
TCP/IP, UDP/IP, Telnet, SSH, SSL, TCP AES and UDP AES for command/response based data
acquisition application or alarm triggered connection
HTTP/HTTPS web based monitoring of input readings, chart and data logging
SMTP for alarm triggered e-mail notification
Troubleshooting Capabilities
The xSenso offers a comprehensive diagnostic toolset that lets you troubleshoot problems quickly
and easily. Available from the CLI or Web Manager, the diagnostic tools let you:
View memory and IP socket information.
Perform ping and traceroute operations.
Conduct forward or reverse DNS lookup operations.
View all processes currently running on the xSenso, including CPU utilization.
View system log messages.
Configuration Methods
After installation, the xSenso 2100 requires configuration. For the unit to operate correctly on a
network, it must have a unique IP address on the network. There are four basic methods for
logging into the xSenso and assigning IP addresses and other configurable settings:
Web Manager: View and configure all settings easily through a web browser using the
Lantronix Web Manager. (See “Configuration Using Web Manager” on page 25.)
DeviceInstaller: Configure the IP address and related settings and view current settings on
the xSenso using a Graphical User Interface (GUI) on a PC attached to a network. You will
need the latest version of DeviceInstaller. (See “Using DeviceInstaller” on page 23.)
Command Mode: There are two methods for accessing Command Mode (CLI): making a
Telnet or SSH connection, or connecting a terminal (or a PC running a terminal emulation
program) to the unit’s USB port. (See Configuration Using the MGMT (USB) Port below and
the xSenso Command Reference Guide for instructions and available commands.)
XML: The xSenso supports XML-based configuration and setup records that make device
configuration transparent to users and administrators. XML is easily editable with a standard
text or XML editor. (See the xSenso Command Reference Guide for instructions and
commands.)
Configuration Using the MGMT (USB) Port
In order to configure and manage the device, connect the computer via USB cable to the xSenso
MGMT port and run a terminal emulation program (e.g., Tera Term).
Note: Device connection will be lost upon reboot. Close the connection (also close
emulation program terminal if needed), unplug and plug in the USB port, and reopen the
connection.
1. Install the USB device driver, as necessary.

2: Introduction
xSenso 2100 User Guide 16
Connection to the MGMT port is via USB-CDC-ACM. This driver is available in Windows. In
order to enable Windows to recognize the USB-CDC-ACM connection to the Lantronix device,
the driver installation file referenced below needs to be provided when prompted by the
Windows Device Driver Installation Wizard. For Windows 7 installation, it is recommended to
manually install the driver before plugging in the USB cable to the xSenso device port. This
can be done by installing a legacy driver for a COM port, with the Have Disk... option.
The device installation file (linux-cdc-acm.inf) may be accessed in one of two ways:
a. DeviceInstaller installation directory (typically at c:\Program File\Lantronix\Device
Installer\4.3).
b. Follow the instructions in Appendix E: USB-CDC-ACM Device Driver File for Windows
Hosts to create the .inf file and follow the windows driver installation steps as outlined
above.
2. Connect the USB cable to the MGMT (USB) port of the xSenso device.
3. Connect the USB cable from the xSenso to the USB port on your computer.
4. Apply power. If drivers are installed, a virtual com port will be created on the computer.
5. Launch an emulation program terminal (e.g., Tera Term) and select the virtual com port.
6. Open up the virtual com port. The serial setting should be 9600, 8,none, and 1.
7. Click OK.
8. Press Enter in the terminal window. You will be prompted to login.
9. Login to the xSenso to configure it. The default login and password:
User Name: admin
Password: PASS
Addresses and Port Numbers
Hardware Address
The hardware address is also referred to as the Ethernet address, physical address, or MAC
address. Sample hardware address:
00-80-A3-14-1B-18
00:80:A3:14:1B:18
IP Address
Every device connected to an IP network must have a unique IP address. This address references
the specific unit.
Port Numbers
Every TCP connection and every UDP datagram is defined by a destination and source IP
address, and a destination and source port number. For example, a Telnet server commonly uses
TCP port number 23.
The following is a list of the default server port numbers running on the xSenso:

2: Introduction
xSenso 2100 User Guide 17
TCP Port 22: SSH Server (Command Mode configuration)
TCP Port 23: Telnet Server (Command Mode configuration)
TCP Port 80: HTTP (Web Manager configuration)
TCP Port 21: FTP
UDP Port 30718: LDP (Lantronix Discovery Protocol) port
TCP/UDP Port 10001: Tunnel 1 (see note below)
Note: Additional TCP/UDP ports and tunnels will be available, depending on the product
type. The default numbering of each additional TCP/UDP port and corresponding tunnel
will increase sequentially (i.e., TCP/UDP Port 1000X: Tunnel X).
Product Information Label
The product information label on the unit contains the
following information about the specific unit:
Bar code
Product Revision
Part Number
Serial Number(MAC Address)
Manufacturing Date Code
Figure 2-1 xSenso Product Label
Note: The hardware address on the
label is also the product serial number.
The hardware address on the label is the
address for the Ethernet (eth0) interface.
Bar Code
Serial Number
Part Number
Country of Origin
& Manufacture
Revision
Manufacturing
Date Code

xSenso 2100 User Guide 18
3: Installation of xSenso 2100
This chapter describes how to install the xSenso 2100 analog device server. It contains the
following sections:
 Package Contents
 User-Supplied Items
 Hardware Components
 Installing the xSenso
Package Contents
The xSenso package includes the following items:
One xSenso2100 device
One 3 Pin Terminal Mating Connector
Two Terminal Blocks for Analog Inputs
Four Rubber Feet
Quick Start Guide
User-Supplied Items
To complete your installation, you need the following items:
Analog devices and sensors that require network connectivity.
An available connection to your Ethernet network and an Ethernet cable.
A working AC power outlet if the unit will be powered from an AC power adapter.
A 9-30VDC power supply either terminal screw or barrel input (both may be used
simultaneously for power redundancy)
Hardware Components
Front/Top Panel
The following components are located on the front panel (Figure 3-1) of the xSenso 2100:
USB Port - for managing and configuring xSenso device.
RJ-45 Ethernet Port (with Ethernet LEDs) - can connect to an Ethernet (10 Mbps) or Fast
Ethernet (100 Mbps) network.
RST Button (the Reset Button inside the pin hole) - power cycles and restores factory default
settings.
LED Indicators (4 Analog Input LEDs, 2 Ethernet LEDs, and 1 Diagnostic “X” LED)
- see Table 3-3 and Table 3-4 to learn how to read the LED indicators.

3: Installation of xSenso 2100
xSenso 2100 User Guide 19
LED Indicators
The analog input LEDs and the ethernet LEDs are located on the front panel (Figure 3-1) and a
diagnostic “X” LED (Figure 3-2) is located on the top of the xSenso device.
Figure 3-1 xSenso, Front View
Figure 3-2 xSenso Top/Front View
Table 3-3 and Table 3-4 below explain the LED information displayed in Figure 3-1 and Figure 3-2
above.
Analog
Input LEDs
USB Ethernet Reset
Port Port Button
(pin hole)
Ethernet LEDs
L R
Note: Though there are
four LEDs located on the
front/top panel, only the two
right Input LEDs are
supported in xSenso 2100.
Diagnostic “X” LED

3: Installation of xSenso 2100
xSenso 2100 User Guide 20
Table 3-3 Analog Input LEDs
Table 3-4 Ethernet LEDs
Reset Button
You can reset the xSenso to factory default settings, including clearing the network settings. The
IP address, gateway, and netmask are set to 00s.
To reset the unit to factory defaults:
1. Place the end of a paper clip or similar object into the reset opening (see Figure 3-1) and press
and hold down micro switch during a power cycle for a minimum of 25 seconds.
2. Remove the paper clip to release the button. The unit will continue the boot process restoring
it back to the original factory default settings.
To only power cycle the unit without resetting the unit to factory defaults:
1. Place the end of a paper clip or similar object into the reset opening (see Figure 3-1) and press
and hold down micro switch during a power cycle for 3 to 5 seconds.
2. Remove the paper clip to release the button. The unit will reboot.
LED Color ON OFF
“X” on top of
xSenso device
(Diagnostic)
Orange ORANGE ON - power present
ORANGE Blink - during boot process after power cycle or
reset. Also blink patterns represent error conditions:
Loss of Redundant Power: one slow blink followed by
two fast blinks (repeat)
No Ethernet Link: two slow blinks followed by two fast
blinks (repeat)
No IP Address: three slow blinks followed by three fast
blinks (repeat)
No power
Analog Input 1 Green
or
Orange
Input Type (voltage or current)
GREEN represents 100mV, 1V or 10V input range is
selected
ORANGE represents 20mA input range is selected
Input not utilized
Analog Input 2 Green
or
Orange
Input Type (voltage or current)
GREEN represents 100mV, 1V or 10V input range is
selected
ORANGE represents 20mA input range is selected
Input not utilized
Ethernet LEDs Description
Left (L) GREEN ON - 100 Mbps link established
GREEN Blink - 100Mbps activity
AMBER ON - 10 Mbps link established
AMBER Blink - 10 Mbps activity
Right (R) GREEN ON - Full duplex
OFF - Half duplex
