QUICK START GUIDE DAB-DG301
1 | P a g e

QUICK START GUIDE DAB-DG301
2 | P a g e
Table of Contents
Whats in the Box...................................................................................................................................2
Front and back product views..............................................................................................................3
Turning the radio on.............................................................................................................................4
FM Mode...............................................................................................................................................4
Setting preset stations..........................................................................................................................4
Specification..........................................................................................................................................5
Trouble shooting...................................................................................................................................5
IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS
- Read all instructions carefully before use.
- Retain manuals for future reference.
- Use this productonly in the manner described.
-Only use awater-dampened soft-cloth to clean the surface of this product.
-Ensure all ventilation holes arenotblocked when using this product,if present.
-Electronic devices should beused in wellventilated areas and not exposed to excess
vibration.
-Only recommendedbatteries and accessories should beused with this product.
- The following will damage this product: any liquid such as wateror moisture,extreme heat;
cold; humidity, dusty or sandy environments.
- Only place this device on stable surfaces and ensure that any attached cables aresecure
and will not cause thedevice to fall.
- If this product has re-moveablebatteries or a power cord, remove or disconnect them before
long periods of in-active use. Removing the batteries prevents damagedue to leakage.Always
insert batteries according to the + and - signs and replace both batteries with the same type at
the same time.
- There are no user serviceable parts in this product.
-Un-authorized attempts to dismantle orrepair this product will void product warranty and
may resultin dangerous electric shock.
- Do notusethis productif you are in control of dangerous machinery such as a motor
vehicle.
- Remove anypower or data cords by pulling them from the plug and not the cord.
WHATS IN THE BOX
1 x DAB-DG301 , 1 x Mains Power Adaptor, 1 x User Manual

QUICK START GUIDE DAB-DG301
3 | P a g e
FRONT AND BACK PRODUCT VIEWS

QUICK START GUIDE DAB-DG301
4 | P a g e
TURNING THE RADIO ON
There is one mainpowerswitch on the rear of the unitand one standbypowerbutton on the
front of the unit.
It isreccomended to usethe rear main powerswitch when operating from batteries.
DAB+ MODE
DAB/FM: Press the DAB/FM button to switch between FM and digital radio modes.
Auto Scan: Fully extend the antenna and press the Scan button. Ifyou have changed your
location since the previous scan, it is recommended thatyou perform another full scan in case
there are any new stations in that area.
Forward or Reverse: Press Up button or Down button to selectdifferent stations
Manual Tuning : Press and hold the Enter button. Manual tuning will appear on the
screen. Press or press and hold the forward or reverse buttons to search for a frequency. If a
channel is available on the selected frequency, the tuning message willdisappear and the
station name and details willbe displayed.
Press the forward or reverse buttons to change to another channel,
Press the Enter button to browse stations within the channel
Press forward or reverse buttons to change anotherstation within the channel
Press Enter button when you find a station you wantto listen to
Display Information: Press INFO button repeatedly to step through the display mode:
Program Type/ Multiplex Name/ Multiplex Number & Frequency/ Audio Bit Rate/ Signal
Strength / Time & Date/ DLS Scrolling Text
FM MODE
Press the DAB/FM button to setthe device to FM mode
Auto Scan: Fully extend the antenna and press the Scan button. Ifyou have changed your
location since the previous scan, it is recommended thatyou perform another full scan in case
there are any new stations in that area.
Press the forward or reverse buttons to select different stations
SETTING PRESET STATIONS
Your DAB-DG301 can storeup to 10 DAB+ and 10FMpresetstations, which form yourfavourite
list.
Storing a station preset
Turn yourradio to the station you wish to store as preset

QUICK START GUIDE DAB-DG301
5 | P a g e
Press and hold the Preset button untill “ Preset Empty 1” appears, forexample.
Using the forward orreverse buttons,select the presetnumberyou wish to use andpress
Enter to storethat station into memory
Recalling a preset station
Press the Preset button untill the first preset appears
Using the forward orreverse buttons to scroll through the station presets
Press the Enter button to select the station you wish to listen to
SPECIFICATION
TROUBLE SHOOTING
The reception is poor in my area. Will your
DG301 work ok?
We recommend that you conducta full
station scan upon firstuse. This willlocateall
available stations in yourarea and check and
improve any weak signals.
Also you can visit www.digitalradioplus.com.au
to check the radio coverage in your area
I experience a lot of interference when
using digital radios. What could cause this?
Otherelectronic/electrical devices may be
disrupting the supply of power to your
DG301.Itis recommended thatyou trial the
unit on another powersocket(circuit) to start
your trouble shooting procedure
How do I ensure that I am receiving the
strongest signal possible? Make sure the antenna is fully extended and free from any obstruction.
What other factors can affect signal
quality?
Geographical obstructions such as being at
the bottom of a valley or behind large hills will
reduce your ability to receive a strong signal
Does the DG301 have a better/stronger
signal receiving capabilities than other
brands on the market?
The technologiesbehind common DAB+
brands in the marketare reasonably identical.
As such there is no real reception difference
between different brands in the market

QUICK START GUIDE DAB-DG301
6 | P a g e
For further product information and instruction please visit our product web page at
www.laserco.netor email [e-mail]
Please note: As continual improvements are made to this product,slight operational
differences may occur. Forthe most up-to-date user manual,please visit our web site.
Warranty Against Defects
Laser Corporation Pty Ltd (“Laser”) warrants your new product to be free from defects in materials and
workmanship for 12 months, fromthedate ofpurchase,provided that theproduct is used inaccordance
with accompanying recommendations or instructions where provided. The benefitof this warranty is in
addition to your rights under theAustralian ConsumerLaw and to other rightsand remedies of the
consumerundera lawin relation to the goodsorservices to which thewarranty relates.
Through a networkof retailersand resellers,Laser will provideyou with your choice ofa refund,repair
or exchange (where possible) for this product if it becomes defective within the warranty period. This
warranty will no longerapply where the defect is a result of alteration, accident,misuse, abuse, normal
wear and tear,neglector improperstorage.
Please retain your receipt as proof of purchase
How to make a product warranty claim:
Step 1: Find your receipt whichproves the date of purchase. Where thedate of purchasecannot be
verified, your place of purchase or Laser will make an assessment based on the date of manufacture,
the condition of the Laser Product and the type of defect.
Step 2a): Contact your placeof purchase. They willassess the natureof the fault and refund or replace
the product as per their store refund or warranty policy.
Step 2b): If your place of purchase cannot be contacted, then you can contact Laser . Customer Service
with detailsof your defective Laser Product: Phone: [phone]; or Email: [email protected].au
or online www.laserco.net/support/warranty (click on “Consumers (End Users)”). Our business address
is at 1/6-8 Byfield Street, North Ryde, NSW 2113
Step 3: Laser. will issue you witha Return Authorisation (RA)number within 48hours. When
requested, send us the defective Product and a copy of your receipt. Laser willcover the cost of the
return delivery.
Step 4: Wait for us to contact you. Once we have received your defective Laser Product for inspection,
we will inform you ofour assessment of your claim within 7 days. When we contact you, we will firstly
letyou know whether youhavea valid claim under thisWarranty, and ifso, wewill informyou whether
your defective Laser Product will be replaced or repaired, together with the number of days you can
expect to wait to receive your replaced or repaired Laser Product.
Our goodscome with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement orrefund fora majorfailure and compensation forany other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does notamount to a major failure.
