LAUNCH TECH X-431 EURO TAB User manual

Version: V1.00.000
Revised date: 3-26-2018
Statement:
All information, specifications and illustrations in this manual are based on the
latest information available at the time of release. LAUNCH reserves the rights
to make changes at any time without notice.
User Manual

X-431 Throttle User Manual
i
Copyright Information
Copyright © 2018 by LAUNCH TECH. CO., LTD. All rights reserved. No part of
this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of LAUNCH. The information
contained herein is designed only for the use of this unit. LAUNCH is not
responsible for any use of this information as applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser of this unit or
third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: Accident, misuse, or abuse of this unit, or
unauthorized modifications, repairs, or alterations to this unit, or failure to strictly
comply with LAUNCH operating and maintenance instructions. LAUNCH shall
not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original LAUNCH
Products or LAUNCH Approved Products by LAUNCH.
Statement:LAUNCHownsthecompleteintellectualpropertyrightsforthesoftware
usedbythisproduct.Foranyreverseengineeringorcrackingactionsagainstthe
software,LAUNCHwillblocktheuseofthisproductandreservetherighttopursue
theirlegalliabilities.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD. (LAUNCH) in
China and other countries. All other LAUNCH trademarks, service marks,
domain names, logos, and company names referred to in this manual are either
trademarks, registered trademarks, service marks, domain names, logos,
company names of or are otherwise the property of LAUNCH or its affiliates. In
countries where any of the LAUNCH trademarks, service marks, domain names,
logos and company names are not registered, LAUNCH claims other rights
associated with unregistered trademarks, service marks, domain names, logos,
and company names. Other products or company names referred to in this
manual may be trademarks of their respective owners. You may not use any
trademark, service mark, domain name, logo, or company name of LAUNCH or
any third party without permission from the owner of the applicable trademark,
service mark, domain name, logo, or company name. You may contact
LAUNCH at www.launchusa.com, or write to LAUNCH Tech (USA), Inc., 1820 S.
Milliken Ave. Ontario, CA 91761, to request written permission to use Materials
on this manual for purposes or for all other questions relating to this manual.

X-431 Throttle User Manual
ii
Important Safety Precautions
Important: To avoid personal injury, property damage, or accidental damage to
the product, read all of the information in this section before using the product.
yNever collide, throw, or puncture X-431 Throttle, and avoid falling, extruding
and bending it.
yDo not insert foreign objects into or place heavy objects on your device.
Sensitive components inside might cause damage.
yDo not use X-431 Throttle in exceptionally cold or hot, dusty, damp or dry
environments.
yIn places using X-431 Throttle may cause interference or generate a potential
risk, please turn it off.
yX-431 Throttle is a sealed unit. There are no end-user serviceable parts
inside. All internal repairs must be done by an authorized repair facility or
qualified technician. If there is any inquiry, please contact the dealer.
yNever place X-431 Throttle into apparatus with strong electromagnetic field.
yKeep X-431 Throttle far away from magnetic devices because its radiations
can damage the screen and erase the data stored on X-431 Throttle.
yDANGER: Do not attempt to replace the internal rechargeable lithium battery.
Contact the dealer for factory replacement.
yCAUTION: Please use the included battery and charger. Risk of explosion if
the battery is replaced with an incorrect type.
yDo not disconnect power abruptly when X-431 Throttle is being formatted or
in process of uploading or downloading. Or else it may result in program
error.
yDo not delete unknown files or change the name of files or directories that
were not created by you, otherwise your X-431 Throttle software might fail to
work.
yBe aware that accessing network resources can leave your X-431 Throttle
vulnerable to computer viruses, hackers, spyware, and other malicious
activities that might damage your device, software or data. It is your
responsibility to ensure that you have adequate protection in the forms of
firewalls, antivirus software, and anti-spyware software and keep such
software up to date.

X-431 Throttle User Manual
iii
Precautions on Using X-431 Throttle
Before using this test equipment, please read the following safety information
carefully.
yAlways perform automotive testing in a safe environment.
yIf the diagnostic connector remains unused for a long period of time, it is
suggested to unplug the connector from vehicle’s DLC to conserve battery
power.
yWear an ANSI-approved eye shield when testing or repairing vehicles.
yThe vehicle shall be tested in a well-ventilated work area, as engines produce
various poisonous compounds (hydrocarbon, carbon monoxide, nitrogen
oxides, etc.)
yDo not connect or disconnect any test equipment while the ignition is on or
the engine is running.
yPut blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
yKeep the test equipment dry, clean, free from oil, water or grease. Use a mild
detergent on a clean cloth to clear the outside of the equipment as
necessary.
yDo not drive the vehicle and operate the test equipment at the same time.
Any distraction may cause an accident.
yKeep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
yBefore starting the engine, put the gear lever in the Neutral position (for
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
yTo avoid damaging the test equipment or generating false data, please make
sure the vehicle battery is fully charged and the connection to the vehicle
DLC (Data Link Connector) is clear and secure.
yAutomotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
Precautions on Operating Vehicle’s ECU
yDo not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
yDo not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.

X-431 Throttle User Manual
iv
yUse extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
yWhen reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.

X-431 Throttle User Manual
v
TABLE OF CONTENTS
1 INTRODUCTION.............................................................................................. 1
1.1 PRODUCT PROFILE ..................................................................................... 1
1.2 FEATURES .................................................................................................. 2
1.3 TECHNICAL SPECIFICATIONS ....................................................................... 3
1.3.1 X-431 Throttle handset ...................................................................... 3
1.3.2 VCI connector.................................................................................... 3
2 KNOWLEDGE OF X-431 THROTTLE............................................................. 5
2.1 X-431 THROTTLE TABLET............................................................................ 5
2.1.1 Top view............................................................................................. 5
2.1.2 Front view .......................................................................................... 6
2.1.3 Rear view........................................................................................... 7
2.2 DOCKING STATION ...................................................................................... 8
2.3 VCI CONNECTOR ........................................................................................ 8
2.4 PACKAGE LIST .......................................................................................... 10
3 PREPARATIONS ........................................................................................... 11
3.1 CHARGING X-431 THROTTLE .................................................................... 11
3.2 USING YOUR BATTERY.............................................................................. 11
3.3 POWER ON/OFF......................................................................................... 11
3.3.1 Power on.......................................................................................... 11
3.3.2 Power off.......................................................................................... 12
3.4 TIPS ON FINGER OPERATIONS................................................................... 12
3.5 LOCK &UNLOCK SCREEN ......................................................................... 12
3.5.1 Lock the screen ............................................................................... 12
3.5.2 Unlock the screen............................................................................ 13
3.6 SCREEN LAYOUT....................................................................................... 13
3.7 ADJUST BRIGHTNESS................................................................................ 13
3.8 SET STANDBY TIME................................................................................... 13
3.9 CHANGING LANGUAGE .............................................................................. 14
3.10 WI-FI SETUP........................................................................................... 14
3.9.1 Connect to a Wi-Fi network ............................................................. 14

X-431 Throttle User Manual
vi
3.9.2 Disconnect from a Wi-Fi network .................................................... 14
4 INITIAL USE................................................................................................... 15
4.1 GETTING STARTED.................................................................................... 15
4.2 REGISTER &DOWNLOAD DIAGNOSTIC SOFTWARE..................................... 15
4.2.1 User registration .............................................................................. 15
4.2.2 Function modules ............................................................................ 18
4.2.3 Vehicle menu layout ........................................................................ 20
4.3 CONNECTIONS .......................................................................................... 21
4.3.1 Preparation ...................................................................................... 21
4.3.2 DLC location .................................................................................... 21
4.3.3 Vehicle connection........................................................................... 22
4.4 COMMUNICATION SETUP ........................................................................... 23
4.4.1 Pairing up via wireless (BT) communication ................................... 23
4.4.2 USB cable connection ..................................................................... 24
5 DIAGNOSIS ...................................................................................................25
5.1 INTELLIGENT DIAGNOSIS (AUTODETECT)................................................... 25
5.2 MANUAL DIAGNOSIS.................................................................................. 30
5.2.1 Health Report (Quick Test) .............................................................. 32
5.2.2 System Scan.................................................................................... 34
5.2.3 System Selection............................................................................. 35
5.3 TECH TO TECH (REMOTE DIAGNOSIS) ....................................................... 42
5.3.1 Interface layout ................................................................................ 43
5.3.2 Add Friends...................................................................................... 43
5.3.3 Start instant messaging ................................................................... 45
5.3.4 Launch remote diagnosis (Device-To-Device) ................................ 46
5.3.5 Launch remote diagnosis (Device-To-PC) ...................................... 49
5.4 MANAGE REPORTS ................................................................................... 52
5.4.1 Health Report................................................................................... 52
5.4.2 Remote Report ................................................................................ 52
5.4.3 Playback .......................................................................................... 52
5.5 I/M READINESS ......................................................................................... 53
5.6 HOW TO VIEW DIAGNOSTIC HISTORY? ...................................................... 55

X-431 Throttle User Manual
vii
5.7 DIAGNOSTIC FEEDBACK ............................................................................ 55
5.8 VIEW REPAIR INFORMATION ...................................................................... 56
6 SOFTWARE UPDATE ................................................................................... 58
6.1 UPDATE DIAGNOSTIC SOFTWARE &APP................................................... 58
6.2 RENEW SOFTWARE SUBSCRIPTION ............................................................ 59
7 PROFILE........................................................................................................ 60
7.1 PROFILE ................................................................................................... 60
7.2 EMAIL ....................................................................................................... 60
7.3 CHANGE PASSWORD................................................................................. 60
7.4 FREE UPGRADE PERIOD ........................................................................... 60
7.5 ABOUT ...................................................................................................... 60
7.6 EXIT FROM CURRENT ACCOUNT................................................................. 61
8 SETTINGS......................................................................................................62
8.1 GENERAL.................................................................................................. 62
8.1.1 Units of Measurement ..................................................................... 62
81.2 Expiration Reminder ......................................................................... 62
8.1.3 Identifix Settings .............................................................................. 62
8.1.4 Auto Update ..................................................................................... 62
8.2 VCI........................................................................................................... 62
8.3 VCI MANAGEMENT.................................................................................... 62
8.4 ACTIVATE VCI........................................................................................... 63
8.5 FIRMWARE FIX .......................................................................................... 63
8.6 ICON SIZE ................................................................................................. 63
8.7 COLOR THEME.......................................................................................... 63
8.8 PRINTER SET ............................................................................................ 63
8.9 PRINT INFORMATION ................................................................................. 65
8.10 DATA STREAM SAMPLE ........................................................................... 65
8.11 VEHICLE VOLTAGE .................................................................................. 65
8.12 DIAGNOSTIC SOFTWARE CLEAR .............................................................. 65
8.13 BACKUP/RESTORE .................................................................................. 66
9 SENSORBOX (TOOLBOX)........................................................................... 67

X-431 Throttle User Manual
viii
9.1 PRODUCT SUMMARY................................................................................. 67
9.2 STRUCTURE &ACCESSORIES.................................................................... 68
9.2.1 Sensorbox structure ........................................................................ 68
9.2.2 Sensorbox accessories ................................................................... 69
9.3 SENSOR SIMULATION ................................................................................ 70
9.3.1 Connections..................................................................................... 70
9.3.2 Simulation test ................................................................................. 70
9.3.3 Precautions on checking vehicle sensor ......................................... 74
10 MULTIMETER (TOOLBOX).........................................................................76
10.1 MAIN MENU ............................................................................................ 76
10.2 TEST SAMPLE ......................................................................................... 77
11 BATTERYBOX (TOOLBOX)........................................................................79
11.1 PRODUCT SUMMARY............................................................................... 79
11.2 TEST ENVIRONMENT ............................................................................... 80
11.2.1 Test environment............................................................................ 80
11.2.2 Battery status and description ....................................................... 80
11.3 BATTERYBOX STRUCTURE &ACCESSORIES ............................................ 81
11.3.1 Batterybox structure....................................................................... 81
11.3.2 Test accessories ............................................................................ 81
11.4. CONNECTIONS &OPERATIONS............................................................... 81
11.4.1 Connection..................................................................................... 81
11.4.2 Inside the vehicle test .................................................................... 82
11.4.3 Outside the vehicle test ................................................................. 85
11.5 PRECAUTIONS ON BATTERY TEST........................................................... 85
12 OSCILLOSCOPE (TOOLBOX).................................................................... 87
12.1 INTRODUCTION ....................................................................................... 87
12.2 STRUCTURE &ACCESSORIES.................................................................. 88
12.2.1 Scopebox structure........................................................................ 88
12.2.2 Scopebox accessories................................................................... 89
12.3 CONNECTION &INITIAL USE .................................................................... 90
12.3.1 Connection..................................................................................... 90
12.3.2 Initial interface introduction............................................................ 90

X-431 Throttle User Manual
ix
12.4 OPERATIONS .......................................................................................... 91
12.4.1 Channel selection and attributes setting ....................................... 91
12.4.2 Auto................................................................................................ 96
12.4.3 View Settings ................................................................................. 96
12.4.4 Measure......................................................................................... 97
12.4.5 File management........................................................................... 99
12.4.6 Expert reference .......................................................................... 100
13 AUTOMOTIVE IGNITION WAVEFORM .................................................... 102
13.1 SECONDARY-DISTRIBUTOR IGNITION ANALYSIS ...................................... 102
13.2 SECONDARY-SIMULTANEOUS IGNITION ANALYSIS................................... 104
13.3 SECONDARY-DIRECT IGNITION ANALYSIS ............................................... 106
13.4 WAVEFORM ANALYSIS MODE ................................................................. 107
14 OTHERS..................................................................................................... 113
14.1 EMAIL ................................................................................................... 113
14.1.1 Configure an email account......................................................... 113
14.1.2 Add an email account .................................................................. 113
14.2 BROWSER............................................................................................. 113
14.2.1 Open browser .............................................................................. 113
14.2.2 Download files ............................................................................. 114
14.3 SYNCHRONIZATION ............................................................................... 114
14.3.1 Connect to PC ............................................................................. 114
14.3.2 Run on PC ................................................................................... 114
14.3.3 Install an application .................................................................... 115
14.4 CLEAR CACHE ...................................................................................... 115
15 FAQ ............................................................................................................ 116

LAUNCH X-431 Throttle User Manual
1
1 Introduction
1.1 Product Profile
X-431 Throttle is an evolutionary smart solution for specialized automotive
diagnosis and maintenance. It is characterized by featuring powerful functions,
and providing precise test result.
Through simple Bluetooth communication / USB cable between the VCI device
and X-431 Throttle handset, it achieves full car model and full system vehicle
trouble diagnosis, which include Reading DTCs, Clearing DTCs, Reading Data
Stream, Actuation Test and Special Functions.
X-431 Throttle adopts a higher performance-price ratio tablet, which is equipped
with Android 7.1 operating system, 8-core 2GHz CPU and 10.1” sunlight
readable capacitive touch screen with a resolution of 1920 x 1200 pixels.
The following illustration shows how the X-431 Throttle system works.

LAUNCH X-431 Throttle User Manual
2
1.2 Features
1. Diagnose:
ySmart Diagnosis (AutoDetect): This module allows you to use the VIN
information of the currently identified vehicle to access its data (including
vehicle information, historical diagnostic records) from the cloud server to
perform quick test.
yLocal Diagnosis: To perform diagnosis by executing on-screen commands
step by step. Diagnosis functions include: Read DTCs, Clear DTCs, Read
Data Stream, Special Functions etc.
yI/M Readiness: I/M refers to Inspection and Maintenance that is legislated by
the Government to meet federal clean-air standards. I/M Readiness indicates
whether or not the various emissions-related systems on the vehicle are
operating properly and are ready for Inspection and Maintenance testing.
yTech-To-Tech: This option aims to help repair shops or technicians launch
instant messaging and remote diagnosis, making the repair job getting fixed
faster.
yMaintenance & Reset: All kinds of common maintenance and reset items
including Oil lamp reset, DPF regeneration, ABS bleeding etc. can be done.
yDiagnostic History: Provides a quick access to the tested vehicles and users
can choose to view the test report or resume from previous diagnostic session,
without the necessity of starting from scratch.
yPre- and Post- Repair Result Comparison: By comparing the pre-repair and
post-repair report, you can clearly determine which vehicle issues have been
fixed and which remained unsolved.
yOne-click Update: Lets you update your diagnostic software online.
yDiagnostic feedback: Enables you to submit the vehicle issue to us for
analysis and troubleshooting.
yRepair Info: Multiple speed dial to professional repair website are available for
helping repair professionals diagnose and repair vehicle efficiently, accurately
and profitably.
yVehicle Coverage: Enables you to quickly check which vehicle models are
supported.
yBackup/Restore: This feature lets you back up the recorded files to external
storage device/restore the recorded data from external storage device.
yAdd-on Modules: Scopebox, Sensorbox, Batterybox and Videoscope (sold
separately) are available for extending the functions of X-431 Throttle.

LAUNCH X-431 Throttle User Manual
3
2. Compatible with Wi-Fi projecting technology: To mirror your X-431 Throttle
screen onto an external projector or monitor with HD I/O interface via wireless
technology.
3. Web browser: Users can make online search and visit any website.
1.3 Technical Specifications
1.3.1 X-431 Throttle handset
Operating system Android 7.1
Processor 8-core 2GHz processor
Battery 9000mAh rechargeable polymer lithium battery
Charging via 5V DC power supply
Memory 4GB
Storage 64GB
Screen 10.1 inch capacitive touch screen with a resolution of
1920 x 1200 pixels
Camera Front-facing 8.0MP camera + rear-facing 13MP
camera
Connectivity
yWLAN (802.11b/g/n/ac)
yUniversal serial BUS Ports (1 x Type-C + 1 x
Type-A)
yBluetooth 2.1 & 2.4
Sensor yGravity Accelerometer
y3-Axis Acceleration Sensor
Working temperature -10℃~ 50℃(14 ~122℉)
Storage temperature -20℃~ 70℃(-4 ~158℉)
1.3.2 VCI connector
Working voltage DC 9 ~18V
Average working current About 35mA

LAUNCH X-431 Throttle User Manual
4
Standby current About 25mA
Working temperature -20℃to 55℃(-4 ~131℉)
Storage temperature -30℃to 70℃(-22~158℉)

LAUNCH X-431 Throttle User Manual
5
2 Knowledge of X-431 Throttle
There are three main components to the X-431 Throttle system:
yX-431 Throttle tablet – the central processor and monitor for the system (See
Chapter “2.1”)
yDocking Station – the platform for charging X-431 Throttle tablet and
extending functions (For details, please refer to Chapter 2.2.)
yVCI device – the device for accessing vehicle data (See Chapter “2.3”)
2.1 X-431 Throttle tablet
The handset acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI connector and then output the test
result.
2.1.1 Top view
Fig. 2-1
1 Memory Card Slot To store the memory card for storage
expansion.
2 Charging Po
r
t Reserved for charging the handset.
3 Power/Screen
Lock Button To turn the handset on/off with long press, or
lock the screen with short press.
4 Volume Buttons To adjust the volume.
*Note: Press and hold [POWER] and [VOL -] key to

LAUNCH X-431 Throttle User Manual
6
capture the current screenshot.
5 Data
Transmission Port
Reserved for add-on modules (such as
Batterybox, Scopebox and Sensorbox), and
other devices with similar port.
2.1.2 Front view
Fig. 2-2
6 Microphone To adjust the volume.
7 Charging indicator It illuminates red while the handset is charging.
Once charging is finished, it will illuminate solid
green.
8 Touch Screen
9 Ambient Light
Sensor
10 Front Camera

LAUNCH X-431 Throttle User Manual
7
2.1.3 Rear view
Fig. 2-3
11 Rear Camera
12 Camera Flash
13 Audio Speake
r
14 Charging Slot Align it with the charging slot on the docking
station to charge the handset.
15 Adjustable
Kickstand Flip out it to any angle and work comfortable at
your desk, or hang it on automotive part.

LAUNCH X-431 Throttle User Manual
8
2.2 Docking Station
Fig. 2-4
1 Charging Slot
2 OBD16 Socket To store the VCI device to avoid loss.
3 Data
Transmission Port Reserved for add-on modules, and other
devices with similar port.
4 Charging Port Use the power adaptor to supply power to the
docking station through connection to AC outlet.
5 Power LED Illuminates solid green when it is powered up.
2.3 VCI Connector
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket directly or via
OBD II extension cable to read the vehicle data and then send it to the X-431
Throttle handset via wireless communication technology.

LAUNCH X-431 Throttle User Manual
9
Fig. 2-5 VCI connector
1 OBD-16 diagnostic
connector To connect on vehicle’s OBD II DLC.
2 Power indicator It lights up while the connector is plugged into
the vehicle’s DLC.
3
Wireless (BT)/data
cable
communication
indicator
yIt indicates wireless (BT) communication
mode if the VCI is energized and illuminates
blue (default mode).
yIt illuminates red when the VCI is connected to
the diagnostic tool via data cable.
4 ECU communication
indicator It flashes when the VCI is communicating with
the vehicle.
5 Data Transmission
port To connect to the handset to perform vehicle
diagnosis via data cable.

LAUNCH X-431 Throttle User Manual
10
2.4 Package List
For different product configurations, the accessories may vary. For detailed
accessory items, please consult from the local agency or check the package list
supplied with X-431 Throttle together.
No. Item Descriptions Qt.
1 X-431 Throttle
handset Indicates the test result. 1
2 Docking station To dock or charge the handset. 1
3 VCI device Collects the vehicle data and sends it
to the handset for analysis. 1
4 OBD II extension
cable
To connect the VCI device to the OBD
II vehicle’s DLC. 1
5 Power adaptor To charge the handset. 1
6 OBD I adaptor An adaptor cable for connecting
non-16 pin connector. 1
7 Cigarette lighter
cable
To supply power to the non-16pin
connector from the vehicle’s cigarette
lighter receptacle.
1
8 Battery clamps
cable
To supply power to the non-16pin
connector through connection to the
vehicle’s battery.
1
9 Password envelope
A piece of paper bearing the product
Serial Number and Activation Code for
product registration.
1
10 Non-16pin adaptor
cable kit
To connect to the vehicle equipped
with non-OBD II management system. (Optional)
