LAUNCH Tyre Changer (TWC-401NIC)
ii
Safety Precautions
Note
zThis manual is a necessary part of the product.
Please read carefully.
zKeep the manual for later use when maintaining
the machine.
zThis machine can only be used for the
designated purposes. Never use it for any
other purpose.
zThe manufacturer is not held responsible for the
damage incurred by improper use or use other
than the intended purpose.
Precautions
zThe equipment can only be operated by qualified
personnel with special training. Modification to
any components or parts, or use the machine for
other purpose without either obtaining the
agreement from the producer, or observing the
requirement of the instructions may lead to direct
or indirect damage to the equipment.
zTWC-401NIC should be installed on the stable
ground.
zKeep the back panel 0.5M away from the wall for
good ventilation. Enough room should be left on
both sides of TWC-401NIC for convenient
operation.
zDo not put TWC-401NIC in a place with high
temperature or moisture, or near the heating
system, water tap, air-humidifier or chimney.
zDo not put TWC-401NIC near the window with
sunlight. Protect the unit with a curtain or
shield if necessary.
zAvoid lots of dust, ammonia, alcohol, thinner or
spraying binder.
zPeople who are no operating the machines
should be kept away when it is used.
zUse appropriate equipment and tools, protective
and safety equipment, including eyeglasses,
earplugs and working boots.
zPay special attention to the marks on the
machine.
zDo not touch or approach the moving parts by
hand during operating.
zDo not remove the safety device or keep it from
working properly.
zUse #2 lithium lubricants (grease) only within the
safety range. Refer the appendix for the safety
data.
zBefore moving the tyre changer, contact
maintenance personnel.

LAUNCH Tyre Changer (TWC-401NIC)
iii
MAX 10bar
Caution should be taken
when separating the tyre
from rim. The bead breaker
shoe will move rapidly and
forcefully when the pedal is
depressed. Keep body and
materials away from the
work area.
If the clamping cylinder is
open during clamping,
squeezing on hands can be
resulted. Remember to
keep hands away from the
inside of the tyre when
clamping.
High voltage power!
Dangerous!
This is where the
compressed air gun is
connected with the air pipe.
Connect the compressed air
gun with the air connector.
The pressure of the
compressed air should not
exceed 10bar.
To prevent accidents from
occurring, make sure to
keep hands and other body
parts away when fastening
the mount/demount head or
when the turntable is
running.
.
Be careful when connecting
and disconnecting air
source Bleed the air in the
cylinder completely when
maintaining the air pipes to
prevent accidents from
occurring.
Don’t keep hands or other
body parts between the
clamping jaw and clamping
rim.
Before inflating check if the
clamping rim and the tyre
match each other, and if
they are in good condition.
Any negligence may result
in fatal explosion. Similar
accident may occur if the
inflating air exceeds the
allowed pressure.
Description of Safety Signs

LAUNCH Tyre Changer (TWC-401NIC)
iv
The Position of Safety Signs
-
Please change the safety signs if it gets blurred or lost.
When one or more safety signs get lost, don’t operate the machine.
The safety signs must be kept within the sight of the operator.

LAUNCH Tyre Changer (TWC-401NIC)
v
Table of Contents
General Information………………………………1
Usage… …………………………….….………1
Features ………………………………..………1
Specifications…………………………..………1
Applicable Range…………………………...….1
Working Conditions……………………..…..…1
Main Structure…………………………………2
Operation………..………………………..……3
Principles ………………………………..…….3
Demounting Tyre …………………….…….…3
Mounting Tyre ………………………….…..…5
Inflating Tyre …………………………….…… 6
Trouble shooting ………………………..……7
Maintenance………………..……………....….8
Storing and Scrapping…………..…………...9
TWC-401NIC Oil Safety Data……….….…10
TWC-401NIC Electrical Diagram….……11
TWC-401NIC Air Passage Diagram……14

LAUNCH Tyre Changer (TWC-401NIC)
1
General Information
Usage
TWC-401NIC is used for demounting, mounting and
inflating tyres of small vehicles. It features simple
operation and high reliability. In addition, it can also be a
great help in car repair garage and tyre dealers.
Features
zThe equipment can be used for different purposes of
demounting, mounting and inflating tyres.
zThe steel mount/demount is cast from excellent alloy
material with special shape and durable performance.
The supplied plastic mount/demount head with the
equipment is made from special engineering plastic
that has enough intensity and not damage the tyre
and rim.
zThe two clamping cylinder ensures accurate central
alignment, so that the tyres can be held tightly.
zThe layout of the pedals gives convenience to the
operating personnel.
zThe bead breaker shoe can be adjusted to match
tyres with different widths.
zThe tyre is conveniently located.
Specifications
Dimensions
Maximum height: 1765mm (69″)
Length: 1020mm (40″)
Width: 810mm (32″)
Weight
Net weight: 212kg
Electric specifications
Voltage to choose:
A C110V(±5%) 60Hz（±1Hz）
AC220V(±5%) 50Hz（±1Hz）
AC230V(±5%) 60Hz（±1Hz）
Power: 1.1kW
Phase: Single
RPM of turntable: 8/min
Air supply
Working pressure: 8－10 bar
Bead breaker force: 14075N
Noise
Working noise: <70dB(A)
Applicable Range
Max. wheel diameter: 960mm(38″)
Max. rim width: 360mm(14″)
Rim clamping diameter(outer): 10″－17″
Rim clamping diameter(inner): 13″－20″
Working conditions
Working temperature:-40℃－45℃
Transport/store temperature:-40℃－55℃
Humidity: 30－95%
Altitude: less than 1000m

LAUNCH Tyre Changer (TWC-401NIC)
2
Main Structure
Fig.01
The main operating parts are shown in Fig. 01.
A Return spring B Hexagonal column
locking handle
C Hexagonal column D Mount/demount head
E Clamping jaw F Turntable H Clamping cylinder
control pedal
I Bead breaker control pedal
J Turntable control
pedal
K Screw handle L Column N Clamping cylinder assembly
O Hanger P Bead breaker handle Q Bead breaker arm S Bead breaker shoe
T Tyre lever V Air Pressure Regulator, Gauge and Lubricator Assembly

LAUNCH Tyre Changer (TWC-401NIC)
3
Accessories provided are shown in Fig.02
001-Tyre lever
002-Gun inflator with a pressure gauge
003-Brush
Fig.02-a
Fig.02-b
Fig.02-c
Operation
Note:
Do not operate the machine before having completing
training and qualified for operating the tyre changer.
Use appropriate equipment, tools and personal
protective equipment, such as eye-glasses, ear-plugs
and working boots, when operating the tyre changer.
Make sure that the power, air sources and the oil level
in the oil cup are in accordance with the
requirements.
Principles
zTo avoid damage when mounting and demounting
tyre, especially the alloy ones, use the special tyre
lever.
zFor easier demounting and better protection of the
tyre and rim, lubricate the area between the rim and
tyre bead, where the bead breaker shoe goes in,
with industrial lubricant or thick soap solution.
zCheck for damages (distortions, surface damages,
excessive runout, erosion or overall wear) before
demounting.
zPay special attention to rotary direction marked on
some flanges or tyres.
zWhen inflating the tyre, make sure the pressure
increases in an even way. Check the rim as often
as possible.
zFit the tyre on the rim of matched size.
zNever ignore the mounting and demounting
requirements of the special wheel.
Demounting Tyre
Preparing
zDeflate the tyre thoroughly.
zRemove all the foreign substance and weights from
therim(Fig.03).
Fig.03
Demounting
Note:
Lubricate the bead with a brush dipped in soap
solution before the shoe touches the bead.
Otherwise the tyre bead will be worn (Fig. 04).
Fig.04
zPlace the tyre between the bead breaker shoe and
rubber pad and keep the shoe between the bead
and rim, about 1cm to the bead (Fig. 05). Depress
pedal I (Fig. 06) to separate the tyre from rim.
zRepeat the above steps on other part of the tyre to
get the tyre separated thoroughly from the rim.

LAUNCH Tyre Changer (TWC-401NIC)
4
Fig.05
Fig.06
zPlace the wheel on the turntable. For the asymmetric
deep groove rim, keep the narrow rim upward.
zDepress pedal H (Fig.07) to the end to clamp the rim
Note: Different types of clamping can be chosen in
accordance with different rims.
Fig.07
Fig.08
¾In case of inward clamping, shrink the jaws
together, place the wheel on the turntable and
depress pedal H to clamp.
¾In case of outward clamping (Fig. 08), enlarge the
jaws outward, place the wheel on the turntable
and depress pedal H to clamp.
zPull back the swing arm and turn the handle of the
screw (12) to put the hexagonal column in working
position (Fig.09), and keep a distance of 1~2mm
from the mount/demount head (Fig.10), and then
lock the hexagonal column with locking handle.
Note:
The angle of the mount/demount head has been
adjusted by manufacturer according to standard rim
(15"). Re-adjustment may be necessary to prevent
scratching the tyre when the rim is extremely large or
small.
Fig.09
Fig.10
zLift the tyre bead onto the mount/ demount head with
tyre lever (Fig. 11). To make it easy, press the tyre
opposite to the mount/demount head. After settling it
down in the rim groove, depress Pedal J（Fig.12）
lightly to turn the turntable clockwise until the rim is
separated. To avoid damage to the tube when there
is one, it is advisable to place the air inflating valve
about 10cm (Fig.13) away from the mount/ demount
head.
Caution:
In case the demounting is hindered, stop the machine
immediately. Lift up the pedal J (Fig.12) to turn the
turntable counter-clockwise to clear away the
hindrance.

LAUNCH Tyre Changer (TWC-401NIC)
5
Fig.11
Fig.12
Fig.13
Fig.14
zIf there is tube in the tyre, remove it.
zLift the lower tyre bead after removing the tube from
the tyre so that the rim at the relative side enters the
groove(Fig.14). Depress pedal H (Fig.07) to loose
the jaw and take the rim off to complete the
demounting
Caution:
Keep hands and the rest of human body away from
the moving parts of the machine. Never wear necklace,
bracelet or loose clothes when operating the machine
as it may cause danger!
Mounting tyre
Note:
Check the size of tyre and rim to see if they match
each other.
zClamp the rim tightly in the same way as demounting
tyre.
zUse lubricant such as thick soap solution on the tyre
and the rim.
zPut the bead on the rim with the left side upward,
and pull back the mount/ demount head to the work
position (Fig.15)
Fig.15
zCheck the coordination of mount/demount head and
rim. Readjust if necessary.
zAdjust relative position between the tyre and the
mount/demount head to make the tyre bead cross
the mount/demount head. At the end of the
mount/demount head, the tyre bead should be
placed on the mount/demount head (Fig.16A). At the
beginning of the mount/demount head, the tyre bead
should be placed under the ball protuberance of the
mount/demount head (Fig.16B).
Fig.16
zPress down the central part of the tyre. Depress the
pedal J (Fig.12) to turn the turntable clockwise,

LAUNCH Tyre Changer (TWC-401NIC)
6
making the lower tyre bead fall into the rim groove
completely.
zIf a tube needs to be installed in the tyre, check first
for the possible damages. Round it onto the rim.
Make sure to keep the tube in the right position
throughout the mounting process.
zTo install the upper tyre bead, place the tyre well and
readjust position of the tyre bead (same as mount of
the lower tyre bead in Fig.17. Press down the tyre
opposite to the mount/demount head to the rim
groove (Fig.18)).
Fig.17
Fig.18
zDepress the pedal J (Fig.12) to turn the turntable
while keeping pressing on the tyre. When only
10~15cm is left, slow down to avoid damage of the
tyre bead. Stop the motor if there is any indication
for damage. Lift the pedal J and turn the turntable
counter-clockwise. Try again when the tyre is back
to the original shape.
Note:
It is not necessary to move the handle of the
screw every time if the size of rim matches the
tyre. Just move the swing arm.
In the process of operation, keep head and
hands away from the area between the tyre and
the swing arm to avoid injury.
Inflating tyre
Danger!!
Inflating can be highly dangerous. Take precautions
and pay close attention to the procedures. Check if
the compressed air is well connected before inflating.
Inflating procedures are shown in Fig.19. The machine is
equipped with a gauge to read the pressure in the tyre.
zLoose the wheel on the turntable.
zConnect the outlet of the gun to the air inflation
valve.
zSlowly press the switch on the inflating gun for
several times during inflation to make sure that the
reading on pressure gauge meets the
manufacturer’s specifications. The pressure
should not exceed 3.5 bar.
zIf the pressure exceeds the limit, press the button on
the gun inflator so that the pressure goes down to
what is required.
Caution: Danger of explosion!
The safety procedures should be closely followed.
Review and abide by the following instructions.
Otherwise serious injury or death can be resulted.
The manufacturer shall not be held responsible for
any possible accident when the safety procedures are
not followed.
Carefully check the dimensions of rim and
tyre to see if they match each other. Check
and make sure that the tyre is not worn or
damaged before inflation.
When a high pressure is required, remove the
tyre from the tyre changer and resume the
inflation in a special protective hood.
Be careful when inflating the tyre. Keep
hands and the rest of human body away from
tyre
.
Fig.19

LAUNCH Tyre Changer (TWC-401NIC)
7
Trouble Shooting
Symptom Cause Solution
Turntable can turn only in
one direction.
Power switch is damaged. Replace the power switch.
Turntable doesn’t turn. Belt is damaged.
Power switch is damaged.
There is problem with
motor.
Belt is loose.
Replace the belt.
Replace the power switch.
Check power wire of motor. If the motor
is damaged, replace it.
Tension the belt.
Turntable can not lock the
rim tightly.
Jaws are worn.
Cylinder pad of the
turntable is damaged.
Replace the jaws.
Clean or replace the pad.
Bead breaker shoe does not
work.
Return spring is damaged. Replace the return spring.
Pedal can not be restored to
its original position.
Return spring is damaged. Replace the return spring.
There is abnormal noise at
the moving part.
The fixing screw is loose.
There is foreign matter
inside.
Tighten the fixing screw.
Get rid of the foreign matter.
The motor does not turn or
the output torque is not
enough.
The moving part is stuck.
The capacitor is failed.
The voltage is too low.
The circuit is open.
Get rid of the stuck point.
Replace the capacitor.
Pause and wait for the device to be
restored.
Repair.
Cylinder is weak in output. There is air leakage.
Mechanical hindrance is
causing the problem.
The pressure of the
compressed air is not high
enough.
Strengthen the muffler.
Fix the mechanical problem.
Replace the compressor.
Air leakage is found. Air hose is damaged.
The outlet of the air valve
is damaged.
The gasket cement is
gone.
Replace the related part.
Add gasket cement.

LAUNCH Tyre Changer (TWC-401NIC)
8
Maintenance
Note:
Only the specialized technician can do the
maintenance. Before any maintenance is performed,
disconnect the power and keep the plug within the
sight of the maintenance personnel. and shut off
compressed air, push the air valve switch to “Off”
position and depress pedal 16 for 3 or 4 times to bleed
the residual compressed air in the machine.
To keep the tyre change in good condition and to
prolong the work life, it is necessary to do regular
maintenance according to the instructions on the user’s
manual. Otherwise, the normal operation and
reliability of the machine will be affected, or personal
injury would be caused.
zKeep the machine and working area clean and
prevent dust or foreign matter from entering the
moving parts.
zKeep the hexagonal column clean and dry (clean
with diesel as in Fig. 20).
zKeep the swing arm clean and lubricate it
periodically so that it can move expectably.
zWeekly clean the turntable, jaws, guideways (Fig.
21); clean and lubricate the column.
zWeekly lubricate the faying surface between moving
parts and rubbing surface with lithium lubricant.
zCheck the oil level in the sprayer regularly. If the oil
level does not reach the second line, fill SAE20 (Fig.
22).
zClear away the condensed material in the water
separator around the sprayer regularly.
zRegularly check and adjust the tension of the belt.
zCheck all connecting parts and bolts regularly and
tighten them if necessary.
Note: About 15 days after starting to use the
equipment, fasten the jaw and positioning boltsA(Fig.
23).
Fig.20
Fig.21
Fig.22
Fig.23

LAUNCH Tyre Changer (TWC-401NIC)
9
Storing and Scrapping
Storing
When the equipment needs to be stored for a long time:
zDisconnect the power and compressed air.
zLubricate all the parts: slide block and groove.
zEmpty all the oil/liquid cups.
zCover the equipment with plastic shield.
Scrapping
When the equipment can no longer be used, disconnect
the power and compressed air and dispose in
accordance with the local regulations.

LAUNCH Tyre Changer (TWC-401NIC)
10
TWC-401NIC Oil Safety Data
No. 2 lithium lubricant
Item Quality Index
Cone penetration (1/10mm) 278
Drop point ℃185
Corrosion (T2 Copper, 100 , 24h)℃No change in the copper
Wire separator (100 , 22h)%℃4
Evaporation (100 , 22h)%℃2
Oxidation stability (99 , 100h)℃0.2
Anti-erosion Grade I
Foreign substance (microscopic method)
Above 10 µm
Above 25 µm
Above 75 µm
Above 125 µm
Lower than 5000
Lower than 3000
Lower than 500
Lower than 0
Relative viscosity (-15 ,10s℃-1), /Pa·s) Lower than 800
Drip loss Lower than 8
SAE20 Lubricant
Item Quality Index
Density (15℃) 0.880
Flash point ℃213
Freezing point ℃-21
Viscosity 40℃66.2
Viscosity 100℃8.2
Viscosity index 95

LAUNCH Tyre Changer (TWC-401NIC)
11
TWC-401NIC Electrical Diagram
AC110V
60Hz
This protective ciruit should be
fulfiled by the customer
EN60947-2
Remarks
EN60309
Mennekes plug 274#
32A/2P+E/230V/IP44
industrial power plug maximum current：32A
protective current：
40A
SW1
PLUG
No.
2.5mm
current：19A
1 53 7
2
QF1
911
2 864 1O 12
air-break switch
industrial power
socket
Name
SOCKET
No.
QF1
Mennekes socket 536#
32A/2P+E/230V/IP44
Model
rated current 40A
industrial power plug
Name
switch
Model
32A
Remarks：if the motor movement is contrary to the right
turning,change the phase wire(Z1 and V1).
U3
U1 U2 Z1V1
U4
Remarks
EN60947-3
EN60309

LAUNCH Tyre Changer (TWC-401NIC)
12
Remarks：if the motor movement is contrary to the right
turning,change the phase wire(Z1 and V1).
current：9.1A
AC230V
60Hz
1.5mm
2
531 79
62 4 1O8
U3
U1 U2 V1 Z1
U4
This protective ciruit should be
fulfiled by the customer
EN60947-2
Remarks
industrial power plug
SOCKET
No.
protective current：
20A
QF1
industrial power plug maximum current：32A
11
QF1
12 No.
SW1
PLUG
rated current 20A
Mennekes socket 536#
32A/2P+E/230V/IP44
industrial power
socket
air-break switch
Name
EN60309
Model
Mennekes plug 274#
32A/2P+E/230V/IP44
Name
switch
Model
16A
Remarks
EN60947-3
EN60309

LAUNCH Tyre Changer (TWC-401NIC)
13
Remarks：if the motor movement is contrary to the right
turning,change the phase wire(Z1 and Z2).
industrial power plug maximum current：32A
AC220V
50HZ
U2U1 Z1 Z2
1.5mm
7
current：9.1A
31 5
2
911
8
42 6 1O 12
QF1
protective current：
20A
No.
PLUG
SW1
This protective ciruit should be
fulfiled by the customer
EN60947-3
EN60309
Remarks
Mennekes plug 274#
32A/2P+E/230V/IP44
rated current 20A
Mennekes socket 536#
32A/2P+E/230V/IP44
air-break switch
industrial power
socket
SOCKET
QF1
No. Name
switch
Name
industrial power plug
Model
EN60309 EN60947-2
Remarks
Model
16A

LAUNCH Tyre Changer (TWC-401NIC)
14
Bead breaking
Jaw clamping
TWC-401NIC Air Passage Diagram

LAUNCH Tyre Changer (TWC-401NIC)
Warranty
THIS WARRANTY IS EXPRESSLY LIMITED TO
PERSONS WHO PURCHASE LAUNCH PRODUCTS
FOR PURPOSES OF RESALE OR USE IN THE
ORDINARY COURSE OF THE BUYER’S
BUSINESS.
LAUNCH electronic product is warranted against
defects in materials and workmanship for one year
(12 months) from date of delivery to the user. This
warranty does not cover any part that has been
abused, altered, used for a purpose other than for
which it was intended, or used in a manner
inconsistent with instructions regarding use. The
exclusive remedy for any automotive meter found to
be defective is repair or replacement, and LAUNCH
shall not be liable for any consequential or incidental
damages. Final determination of defects shall be
made by LAUNCH in accordance with procedures
established by LAUNCH. No agent, employee, or
representative of LAUNCH has any authority to bind
LAUNCH to any affirmation, representation, or
warranty concerning LAUNCH automotive meters,
except as stated herein.
Disclaimer
THE ABOVE WARRANTY IS IN LIEU OF ANY
OTHER WARRANTY, EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
Order Information
Replaceable and optional parts can be ordered
directly from your LAUNCH authorized tool supplier.
Your order should include the following information:
1. Quantity
2. Part number
3. Item description
Customer Service
If you have any questions on the operation of the unit,
please contact us:
Tel: [phone]
Fax: [phone]
E-mail: [e-mail].
If your unit requires repair service, return it to the
manufacturer with a copy of the sales receipt and a
note describing the problem. If the unit is determined
to be in warranty, it will be repaired or replaced at no
charge. If the unit is determined to be out of warranty,
it will be repaired for a nominal service charge plus
return freight. Send the unit pre-paid to:
Attn: Overseas Department
LAUNCH TECH. CO., LTD.
Launch industrial Park,
North WuHe Avenue,
Banxuegang industrial Park,
Longgang District,
ShenZhen,Guangdong Province,
P.R.China.
