LAUNCH TECH TWC-502RMB User manual

LAUNCH TyreChanger(TWC-502RMB)
i
TrademarkInformation
is aregistered trademark of LAUNCH
TECH. CO., LTD. (LAUNCH forshort) inChina and
other countries. All other LAUNCH trademarks,
service marks,domainnames, logos, andcompany
names referred to inthis manualare either
trademarks, registered trademarks, service marks,
domain names, logos, companynames ofor are
otherwise the property of LAUNCH or its affiliates. In
countries where any of the LAUNCH trademarks,
service marks, domain names, logos and company
names are not registered, LAUNCH claimsother
rights associated with unregistered trademarks,
service marks,domainnames, logos, andcompany
names. Other products or company names referred to
in this manual may be trademarks of their respective
owners. You may not useany trademark, service
mark, domain name, logo, or company name of
LAUNCH or any thirdparty without permission from
the owner of the applicable trademark, service mark,
domain name, logo, or company name. You may
contact LAUNCHby visitingLaunch at
http://www.cnlaunch.com, or writing toLAUNCH,
Launch industrial Park,North WuHe Avenue,
Banxuegang industrial Park, Longgang District,
ShenZhen,GuangdongProvince, P.R.China. to
request written permission to use Materials on this
manual for purposes orfor all other questions relating
to this manual.
CopyrightInformation
Copyright 2000 by LAUNCH TECH. CO., LTD. All
rights reserved. No part of this publication may be
reproduced, stored in aretrieval system, or
transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise,
without the prior written permission of LAUNCH. The
information containedhereinis designedonlyfor the
use of this unit. LAUNCH is notresponsible for any
use of this information as applied to other units.
Neither LAUNCH norits affiliates shall beliable to the
purchaser of this unit or third parties for damages,
losses, costs, or expenses incurred by purchaser or
third parties as aresult of: accident, misuse,or abuse
of this unit, or unauthorized modifications, repairs, or
alterations to this unit, or failure to strictly comply with
LAUNCH operating and maintenance instructions.
LAUNCH shall not beliable for anydamages or
problems arisingfrom the useof anyoptionsor any
consumable products other than those designated as
Original LAUNCH Products or LAUNCH Approved
Products by LAUNCH.
GeneralNotice
Otherproductnames usedhereinarefor
identification purposes onlyand may be
trademarks oftheirrespective owners.
LAUNCH disclaimsanyand all rightsin
those marks.

LAUNCH TyreChanger(TWC-502RMB)
ii
SafetyPrecautions
Attention
lThis manual is anecessary part of the product.
Please read carefully.
lKeep the manual forlater usewhen maintaining
the machine.
lThis machinecan onlybeused forthe
designated purposes. Never use itfor any
other purpose.
lThe manufacturer is not held responsible for the
damage incurred byimproper use or useother
than the intended purpose.
Precautions
lThe equipment can only be operated by qualified
personnel with special training. Modification to
any components orparts, or use the machine for
other purposewithout either obtainingthe
agreement from the producer,or observing the
requirement of the instructions may lead to direct
or indirect damage to the equipment.
lTWC-502RMB shouldbe installed on thestable
ground.
lKeep the back panel 0.75M away from the wall
for good ventilation. Enough room should be left
on both sides of TWC-502RMB forconvenient
operation.
lDo not put TWC-502RMB inaplace with high
temperature or moisture, or near the heating
system, water tap, air-humidifier or chimney.
lDo not put TWC-502RMB near the window with
sunlight. Protect the unit with acurtain or
shield if necessary.
lAvoid lots of dust,ammonia,alcohol, thinneror
spraying binder.
lPeople who are no operating themachines
should be kept away when it is used.
lUse appropriate equipment and tools,protective
and safety equipment, including eyeglasses,
earplugs and working boots.
lPay special attention tothe marks onthe
machine.
lDo not touch or approach the moving parts by
hand during operating.
lDo not removethe safetydevice orkeep itfrom
working properly.
lUse #2lithium lubricants(grease) only within the
safety range. Refer the appendixfor the safety
data.
lBefore moving thetyre changer,contact
maintenance personnel.

LAUNCH TyreChanger(TWC-502RMB)
iii
MAX10bar
²Caution should be taken
when separating the tyre
from rim. The bead breaker
shoe will move rapidly and
forcefully when the pedal is
depressed. Keep bodyand
materials away fromthe
work area.
²If the clampingcylinderis
open during clamping,
squeezing on hands canbe
resulted. Rememberto
keep hands away from the
inside of thetyre when
clamping.
²High voltage power!
Dangerous!
²This is where the
compressed air gunis
connected with the air pipe.
Connect the compressed air
gun with the air connector.
²The pressure of the
compressed airshouldnot
exceed 10 bar.
Description ofSafetySigns
²Toprevent accidents from
occurring, make sureto
keep hands andother body
parts away when fastening
the mount/demount heador
when the turntable is
running.
²Be careful when connecting
and disconnecting air
source. Bleedthe airinthe
cylinder completely when
maintaining the air pipes to
prevent accidents from
occurring.
²Don’tkeep hands or other
body parts between the
clamping jaw and clamping
rim.
²Pay attention tothe safety
regulations in the swinging
area of the tilting post to
avoid accidents from
happening.
²Before inflating check ifthe
clamping rim and the tyre
match each other,andif
they are in good condition.
Any negligencemay result
in fatal explosion. Similar
accident may occur if the
inflating air exceeds the
allowed pressure.

LAUNCH TyreChanger(TWC-502RMB)
iv
ThePosition ofSafetySigns
uPlease change the safety signs if it gets blurred or lost.
uWhen one or more safety signsget lost, don’t operate the machine.
uThe safety signs must be kept within the sight of the operator.

LAUNCH TyreChanger(TWC-502RMB)
v
TableofContents
GeneralInformation 1
Usage……………………………….……….…1
Features …………………………………...…..1
Specifications…………………………………..1
ApplicableRange……………………...…..1
Working conditions……………..………….1
MainStructure ... .. 2
Operation .. .. 4
Principles ………………………………….….. 4
Demounting Tyre …………………….….…… 4
Mounting Tyre …………………………………7
Inflating Tyre ………………………………..…8
Troubleshooting 10
Maintenance ....11
Storing and Scrapping .. .12
TWC-502RMBOil SafetyData ..13
TWC-502RMBCircuitDiagram .14
TWC-502RMBPneumaticDiagram.. ...17

LAUNCH TyreChanger(TWC-502RMB)
1
General Information
Usage
TWC-502RMB is used for demounting, mounting and
inflating tyres of small and mediumvehicles.
Mount/demount help device and quick-inflating device
features simple operation and high reliability.In addition, it
can also be agreathelp in car repair garage and tyre
dealers.
Features
lThe equipment can be used for different purposes of
demounting, mounting and inflating tyres.
lThe steel mount/demount is cast from excellent alloy
material with special shape and durable performance.
The supplied plastic mount/demount head with the
equipment ismade from special engineering plastic
that has enoughintensityand notdamagethe tyre
and rim.
lThe two clamping cylinder ensures accurate central
alignment, so that the wheels can be held tightly.
lPneumatically controlled tiltingsystemsaves the
effort and time of the operation.
lMoving up and down of the hexagonal column and
locking of thehorizontalarmis controlled byabutton,
which save operation time and make operation safe.
lHuman design of the mount/demount help greatly
reduces work-intension of the operator,making
tyre-mount and tyre-demount operations convenient
and easy.
lThe quick-inflatingdevicekeeps tyrebeadclose to
the rim tightly,avoiding over-long time inflation or
difficult inflation when the gun inflator is used for the
empty tyre.
lThe layout of the pedals gives convenience to the
operating personnel.
lThe bead breaker shoecan beadjustedto match
tyres with different widths.
Specifications
Dimensions
Maximum height: 1765mm (69″)
Length: 1350mm (53″)
Width: 950mm (37″)
Weight
Net weight: 320kg
Electric specifications
Voltage to choose:
AC110V(±5%)60Hz ±1Hz）
AC220V(±5%)50Hz ±1Hz）
AC230V(±5%)60Hz ±1Hz）
Power: 1.1Kw
Phase: Single
RPM of turntable: 8/min
Air supply
Working pressure: 8－10bar
Bead breaker force: 14075N
Noise
Working noise: <70dB(A)
ApplicableRange
Max. wheel diameter: 1067mm(42″)
Max. rim width: 420mm(17″)
Rim clamping diameter(outer): 10″－20″
Rim clamping diameter(inner): 13″－23″
Working conditions
Working temperature: -40 －45
Transport/store temperature: -40 －55
Humidity: 30－95%
Altitude: less than 1000m

LAUNCH TyreChanger(TWC-502RMB)
2
Main Structure
Fig.01-1
The main structure is shown in Fig. 01-1.
A Return spring B Swing arm C Hexagonal column D Mount/demount head
E Clamping jaw F Turntable G Tilting column
control pedal H Clamping cylinder control pedal
I Bead breaker
control pedal J Turntable control pedal K Hexagonal column locking handle L Tilting column
N Clamping cylinder
assembly O Hanger P Bead breaker
handle Q Bead breaker arm
R Ajusting pin S Bead breaker shoe T Tyre lever U Inflation pedal
V Air Pressure Regulator, Gaugeand LubricatorAssembly W
Supplementary arm
assembly

LAUNCH TyreChanger(TWC-502RMB)
3
Fig.01-2
Fig.01-2-1
Fig.01-2-2
Fig.01-2-3
The Supplementary arm is shown in Fig. 01-2.
a- Swivel arm assembly
b- Disk arm assembly
c- Slide rod assembly
d- Lock cylinder assembly
e- Slide board assembly
f- Post assembly assembly
g- Lifting cylinder assembly
h- Press block
i- Cone
j- Control box assembly
k- Lock bar
Swivel arm assembly is shown in Fig. 01-2-1
a1. Fore swivel arm
a2. Middle swivel arm
a3. Back swivel arm
Disk arm assembly is shownin Fig. 01-2-2
b1. Roller of disk arm
b2. Disk
b3. Disk arm
b4. Locking slide bar
b5. Knob
b6. Control box
b7. Lock cylinder
b8. Lock button
b9. Rise/fall control lever
Slide rod assembly is shown in Fig. 01-2-2
c1. Roller 1
c2. Roller 2
c3. Knob
c4. Slide rod
c5. Lock bar
Accessories provided are shown in Fig.01-2-3
001-Tyre lever
002-Brush
Fig.02-a
Fig.02-b

LAUNCH TyreChanger(TWC-502RMB)
4
Operation
Attention:
The use ofthismachine is reservedtospecially
trained and authorized personnel. Use appropriate
equipment, tools and personal protective equipment,
such as eye-glasses, ear-plugs and working boots,
when operating the tyre changer.Make sure that the
power,air sources andthe oillevel in the oil cupare
in accordance with the requirements.
Principles
lToavoid damage when mounting and demounting
tyre, especially the alloy ones, use the tyre lever
offered by manufacturer.
lFor easier demounting and better protection of the
tyre and rim, lubricate the area between the rim and
tyre bead, where thebead breakershoe goes in,
with industrial lubricant or thick soap solution.
lCheck for damages (distortions, surface damages,
excessive runout, erosion or overall wear) before
demounting.
lPay special attention to rotary direction marked on
some flanges or tyres.
lFit the tyre on the rim of matched size.
lNever ignorethe mounting anddemounting
requirements of the special wheel.
lWhen inflating thetyre, make surethe pressure
increases in an even way.Pay attention to status of
the tyre bead.
Demounting Tyre
Preparing
lDeflate the tyre thoroughly.
lRemove all the foreignsubstance andweights from
the rim (Fig. 03).
Fig.03
Demounting
Attention:
Lubricate the bead with abrush dipped in soap
solution before theshoe touches the bead.
Otherwise the tyre bead willbe worn (Fig. 04).
Fig.04
lPlace the tyre betweenthe bead breaker shoe and
rubber pad and keep the shoe between the tyre
bead and rim, about 1cm to the bead(Fig. 05).
Depress pedal (I)(Fig. 06) to separate the tyre from
rim.
lRepeat the above steps on other part of the tyre to
get the tyre separated thoroughlyfrom the rim.
lPlace the wheel on the turntable. For the asymmetric
deep groove rim, keep the narrow rim upward.
lDepress pedal H(Fig.07) to the end to clamp the rim.
Fig.05
Fig.06

LAUNCH TyreChanger(TWC-502RMB)
5
Fig.07
Note:
Different types ofclamping can be chosen in
accordance with different rims.
ØIn case of inward clamping, shrink the jaws
together,placethe wheelon the turntable and
depress pedal (H) to clamp.
ØIn case of outward clamping, enlargethe jaws
outward (2-3cm away from periphery of the rim)
and place the wheel on the turntable. Draw out
the curve arm. Aim the Location cone at the
central hole of the wheel(Fig.08), press down the
rise/fall control lever tokeep the rimclose to the
jaws, and depress pedal (H) to clamp it (Fig. 09).
Fig.08
Fig.09
lDraw out the roller-1and make it close to the tyre
bead. Press down therise/fall control leverto move
the roller-1 downward 3-5 cm, than turn the lock bar
to lock the slide rod .Depress thepedal J(Fig.10) to
turn the turntable clockwise. Atthe same time,
lubricate the tyre bead with lubricant by abrush (Fig
11).
Fig.10
Fig.11
lDepress pedal (G) (Fig.12) to restore the tilting
column to its working position (Fig.13).
lPress the hexagonal column and draw out the
horizontal arm to make the mount/demount head
touch the clamped rim. Push button (a) (Fig.13) on
the locking handleto clampthe hexagonal column
and horizontal arm. Atthis moment, theinner ring of
the head stays about 1～2mm from the rimto avoid
scratching (Fig.14).
Fig.12

LAUNCH TyreChanger(TWC-502RMB)
6
Fig.13
Fig.14
Attention:
The angle of the mount/demount head has been
adjusted bymanufactureraccordingtostandardrim
(15"). Re-adjustment maybe necessary toprevent
scratching the tyre when the rim is extremely large or
small.
lInsert the tyre lever into between the mount/demount
head and the tyre bead.First releasethe locking of
the slide rod, than lift the rise/fall control lever to
separate the roller-1 with the tyre, and restore it to
original position (Fig. 15).
lTurn thefore swivelarm,and placethe press block
on the upper part of the tyre opposite to the
mount/demount head.Pressdown the rise/fall
control lever to make the press block go down 5-6cm.
Prize the tyre beadonto themount/demount head
(Fig. 16). Figure 17 is section figure.
Fig.15
Fig.16
Fig.17
lDraw out the press block and restore it to the original
position. Depress the pedal J(Fig. 10) to turn the
turntable clockwise until the rim is separated. In case
of atube, it is advisable to place the air inflation
valve on the right side and about 10cm (Fig. 18)
away from the mount/demount head to avoid
damaging.
Fig.18
Caution:
In case thedemountingis hindered, stopthe machine
immediately.Liftup thepedal (J)to turnthe turntable
counter-clockwise to clear away the hindrance.
lIf there is tube in the tyre, remove it first.
lDraw out the tray,and make the tray close to the
lower tyre. Lift the rise/fall control leverup to liftthe
tyre. Make the lower tyrebead opposite to
mount/demount head enter into the rim groove (Fig.
19), and prize the lower tyre bead onto theball
protuberance (Fig. 19). (all operations are showed in

LAUNCH TyreChanger(TWC-502RMB)
7
Fig 20).
lMove the tray,and depress pedalJ(Fig. 10)until the
lower tyre beadis separated fromthe rim. Depress
the pedal G(Fig. 12) ,then depress H,finally
remove the rim to finish demount operation.
Fig.19
Fig.20
Caution:
Keep handsand therestof human bodyawayfrom
the moving parts ofthe machine. Neverwearnecklace,
bracelet or loose clothes when operating the machine
as it may cause danger!
Mountingtyre
Attention:
Check the size of tyre andrim to see if theymatch
each other.
lClamp the rim tightly in the same way as demounting
tyre.
lUse lubricant such as thick soapsolution onthe tyre
and the rim.
lPlace the tyre slantingly on therim with one end
pointing upward(Fig.21).Pressthe pedal G(Fig.22)
to restore the hexagonal column to its operating
position (Fig.21). then push the buttonon the locking
handle.
lCheck the coordinationof mount/demount head and
rim. Readjust if necessary.
Fig.21
Fig.22
lAdjust relative position between the tyre and the
mount/demount head to make the tyre bead cross
the mount/demount head. Atthe end of the
mount/demount head, the tyre bead should be
placed on the mount/demount head (Fig. 23Ais
section figure). Atthe beginning of the
mount/demount head, the tyre bead should be
placed under the ball protuberance of the
mount/demount head (Fig 23B is section figure).
Fig.23
lPress downthe centralpartof thetyre. Depress the
pedal J(Fig.22) to turn the turntable clockwise,
making the lower tyre bead fall into therim groove
completely.
lIf atube needs to be installed in the tyre, check first
for the possible damages. Round itonto the rim.
Make sure to keep the tubein theright position
throughout the mounting process.

LAUNCH TyreChanger(TWC-502RMB)
8
lTo install the upper tyre bead,place the tyre welland
readjust position of the tyre bead(same asmount of
the lower tyre bead in Fig. 24). Draw out the roller-2
and make its side surface 1—2cmaway from
margin of the rim, than press the lock-button to lock
the roller arm. Placethe press blockonthe upper
bead 20cm clockwise away from the mount/demount
head. Press the rise/fall control lever to make the
press block go down 5—7cm to pressthe tyre bead
into the rim groove (Fig. 25). Fig.26 is the section
figure of the operation.
Fig.24
Fig.25
Fig.26
lDepress the pedal J(Fig.22) toturn the turntable
while keeping pressing on the tyre. When only 10—
15cm(Fig.27) is left, slow down to avoid damage of
the tyre bead. Stop the motor if there is any
indication for damage. Lift the pedal Jand turn the
turntable counter-clockwise. Try again when the tyre
is back to the original shape.
Fig.27
Attention:
uIf the rim size does not change, it isnot
necessary to loose thelocking handle
after finishing the mount and demountof
the tyre and adjustthemount/demount
head before mount anddemount of tyre.
The operation will be continued by
depressing the columntilting control
pedal to make the titling column let go
and restore automatically.
uMake sure nobody isbehindthe tilting
post when depressing pedal (G).
uIn the process of clamping, keep head
and hands away from the area between
the tyre and the horizontal arm in case of
injury.
Inflatingtyre
Danger!!
Inflating can behighly dangerous. Take precautions
and pay close attention to the procedures. Check if
the compressed air is well connected before inflating.
The machine is equipped with agauge to read the
pressure in the tyre.
lLoose the wheel on the turntable.
lConnect the outlet ofthe barometer (mounted on
tilting column)to theair inflation valve.,shown in
Fig.28.
Fig.28

LAUNCH TyreChanger(TWC-502RMB)
9
lSlowly and repeatedlydepress the inflation pedal U
Fig.01-1）shortly (toavoid over-high pressure) to
make sure that the reading on pressure gauge
meets manufacture’srequirements. The pressure
should not exceed 3.5 bar.The user may adjust the
reducing valve in the machine to getdifferent
pressures according to requirements.
lIf the tyre hasno thetube andtyre doesnot match
the rim hermetically,inflation method
above-mentioned will has no effect. In thiscase, the
quick-inflation should be adopted. The quick-inflation
method is to depress the inflation pedal U Fig.01-1）
right-hand of the cabinet to its end and loose the
pedal quickly.The quick-inflationis finishedwith a
rat-tat.
lIf the pressure exceeds the limit, press the button on
the barometer so thatthe pressure goesdown to
what is required.
Caution: Danger of explosion!
The safety procedures should be closely followed.
Review and abide by the following instructions.
Otherwise serious injury ordeath can be resulted.
The manufacturer shall not be held responsible for
any possible accident when the safety procedures are
not followed.
uCarefully check the dimensionsof rimand
tyre to see if they match eachother.Check
and make sure that the tyre is not worn or
damaged before inflation.
uWhen a high pressure is required, remove the
tyre from thetyre changer andresumethe
inflation in a special protective hood.
uBe careful when inflating the tyre. Keep
hands and the restof humanbody awayfrom
tyre.

LAUNCH TyreChanger(TWC-502RMB)
10
TroubleShooting
Symptom Cause Solution
Turntable can turn only in
one direction. uPower switch is damaged.
uReplace the power switch.
Turntable doesn’t turn. uBelt is damaged.
uPower switch is damaged.
uThere is problem with
motor.
uBelt is loose.
uReplace the belt.
uReplace the power switch.
uCheck power wire of motor.If the motor
is damaged, replace it.
uTension the belt.
Turntable can notlock the
rim tightly. uJaws are worn. uAir leakage inclamping
cylinder.
uReplace the jaws.
uReplace the cylinder seal.
Bead breaker shoe does not
work. uSpring is damaged. uReplace the spring.
Horizontal arm doesn’tmove
after pushing orpulling.
Vertical shaft can not move
upwards or downwards.
uSquare locking board is
not in correct position.
Hexagonal lockingboard
is not in correct position.
uRefer to the chapter “Maintenance”.
Tilting post tilting istoo fast
or too slow. uThe pushing cylinder expels too muchor too
little air.
uPressure of compressed
air has not reached 8bar.
uOpen the side cover of the cabinet,
slightly adjust two air inflation regulators
by hand to smooth the movement, and
then tighten the cap.
The lock valve is clogged
after the lever is pressed. uO-ring of the valve is damaged.
uThere is problem with
airflow regulating valve.
uReplace the valve or O-ring.
uAdjust or replacethe pressureregulating
valve.
uReplace the airflow regulating valve.
Pedal can notbe restored to
its original position. uReturn spring is damaged.
uReplace the return spring.
There is abnormal noise at
the moving part. uThe fixing screw is loose. uThere is foreign matter
inside.
uTighten the fixing screw.
uGet rid of the foreign matter.
The motor does not turn or
the output torque is not
enough.
uThe moving part is stuck.
uThe capacitor is failed.
uThe voltage is too low.
uThe circuit is open.
uGet rid of the stuck point.
uReplace the capacitor.
uPause and wait for the deviceto be
restored.
uRepair.
Cylinder is weak in output. uThere is air leakage.
uMechanical hindranceis
causing the problem.
uThe pressure of the
compressed air isnot high
enough.
uStrengthen the seal.
uFix the mechanical problem.
uChange the air source.
Air leakage is found. uAir hose is damaged.
uThe outlet of the air valve
is damaged.
uThe gasket cement is
gone.
uReplace the related part.
uAdd gasket cement.
uAdd gasket cement.

LAUNCH TyreChanger(TWC-502RMB)
11
Maintenance
Attention:
Only the specialized technician cando the
maintenance. Beforeany maintenance is performed,
disconnect thepower and keepthe plugwithinthe
sight of the maintenance personnel.Before doing any
maintenance, shutoffpowerand compressed air,
push the airvalveswitch to Off”positionand
depress pedal (H) for 3 or 4 times to bleed the residual
compressed air in the machine.
Tokeep the tyre changerin good conditionand to
prolong the work life,it isnecessaryto doregular
maintenance according to the instructions on the user’s
manual. Otherwise, the normal operation and reliability
of the machine will be affected, or personal injury would
be caused.
lKeep the machineand working area clean, prevent
dust or foreign matterfromentering the moving
parts.
lKeep the hexagonal column clean and dry (clean
with diesel as in Fig. 29).
lKeep the horizontal armandhorizontalpole clean
and lubricate them periodically so thatit can move
expectably.
lWeekly clean theturntable,jaws, guideways (Fig.
30).
lWeekly clean and lubricate base pin.
lWeekly lubricate thefaying surface between moving
parts and rubbing surface with lithium lubricant
(grease).
lCheck theoil levelin the oilcup regularly.Ifthe oil
level does not reach the second line, fill SAE#20
(Fig.31).
lRegularly drain the condensed material in the air
cleaner.
lRegularly check and adjust the tension of the belt.
lCheck all connecting parts andbolts regularly and
tighten them if necessary.
Fig.29
Fig.30
Fig.31
lCheck and adjust thelocking mechanism of
hexagonal column periodically to insure the
distance between hexagonal columnand rim
(regularly 2~3 mm approximately) after the
hexagonal column is locked.
Attention:
Tighten the fixing screws (shownin Fig.32as part A)
on the turntable after every 15 days of operation.
Fig.32
If the verticalclearanceof thehexagonalcolumn is
too much, adjust it according to the following steps:
lShut off compressed air.
lRemove the protectivehood ofthe hexagonal
column.
lAdjust the retaining nutof lead screwor the pushing
screw at the front of locking board by wrench.
lTurn onthe compressed air andthencheck the

LAUNCH TyreChanger(TWC-502RMB)
12
position after locking.
If the horizontal arm can not be moved smoothly or
the clearance is too much after locking, do the
adjustment according to the following procedures:
lOpen the protective cover of the tilting post.
lAdjust the M6 screws at bothends by wrench and
push the arm at the same time until it can be
moved smoothly.Then tighten the nut.
lAdjust the screw at middle by wrench and lock the
horizontal arm to see the change until the
clearance is satisfactory.Then tighten the nut.
Periodically cleanthecontrolvalves forclamping
jaws and bead breaker to insure their normal
operation.
lRemove the side cover of the cabinet.
lLoosen the control valve mufflerand airbleed
valve muffler,and clean them with compressed air.
(Fig.33)
Fig.33
Storing
Storing
When the equipment needs to be stored for a long time:
lDisconnect the power and compressed air.
lLubricate all theparts:slide blockand groove on
the turntable.
lEmpty all the oil/liquid cups.
lCover the equipment with plastic shield.
Scrapping
When the equipment can nolongerbe used,disconnect
the power and compressed air and dispose in
accordance with the local regulations.

LAUNCH TyreChanger(TWC-502RMB)
13
TWC-502RMBOil SafetyData
No.2lithiumlubricant
Item QualityIndex
Cone penetration (1/10mm) 278
Drop point 185
Corrosion (T2Copper, 100 , 24h) Nochange inthe copper
Wireseparator(100 , 22h)% 4
Evaporation (100 , 22h)% 2
Oxidation stability(99 , 100h) 0.2
Anti-erosion Grade I
Foreign substance(microscopicmethod)
Above10 μm
Above25 μm
Above75 μm
Above125 μm
Lowerthan 5000
Lowerthan 3000
Lowerthan 500
Lowerthan 0
Relativeviscosity(-15 ,10s-1), /Pa·s) Lowerthan 800
Driploss Lowerthan 8
SAE20Lubricant
Item QualityIndex
Density(15 ) 0.880
Flashpoint 213
Freezingpoint -21
Viscosity40 66.2
Viscosity100 8.2
Viscosityindex 95

LAUNCH TyreChanger(TWC-502RMB)
14
TWC-502RMBCircuitDiagram
75
2.5mm2
current
：
19A
9
U3U2U1 Z1V1
U4
1242 86 1O
protective current
：
40A
industrial power plug maximum current
：
32A
QF1
No.
QF1 SOCKET
Name
industrial power
socket
air-break switch
SW1 PLUG
No.
industrial power plug
switch
Name
Remarks
Model
rated current 40A
EN60947-2 EN60309
Mennekes socket 536#
32A/2P+E/230V/IP44
32A
Mennekes plug 274#
32A/2P+E/230V/IP44
Model
EN60309
EN60947-3
Remarks
This protective circuit should be
fulfiled by the customer
Remarks：if the motor movement is contrary to the right
turning,change the phase wire(Z1 and V1).
AC110V
60Hz
111 3

LAUNCH TyreChanger(TWC-502RMB)
15
Remarks：if the motor movement is contrary to the right
turning,change the phase wire(Z1 and V1).
current：9.1A
AC230V
60Hz
1.5mm
2
531 7 9
62 4 1O8
U3U1 U2 V1 Z1
U4
This protective ciruit should be
fulfiled by the customer
EN60947-2
Remarks
industrial power plug
SOCKET
No.
protective current
：
20A
QF1
industrial power plug maximum current
：
32A
11
QF1
12 No.
SW1
PLUG
rated current 20A
Mennekes socket 536#
32A/2P+E/230V/IP44
industrial power
socket
air-break switch
Name
EN60309
Model
Mennekes plug 274#
32A/2P+E/230V/IP44
Name
switch
Model
16A
Remarks
EN60947-3
EN60309
