Lava KKT 07 User manual

-I-
User Manual
KKT 07

-II-
Contents
1. Getting to know your phone ...................... 1
1.1 Your Phone............................................. 1
1.2 Installing SIM card and battery................ 1
1.3 Installing Storage card............................. 1
1.4 Battery charging...................................... 1
1.5 Power on/ off........................................... 2
1.5.1 Power on.......................................... 2
1.5.2 Power off.......................................... 2
2.Using Call Function..................................... 2
2.1 Making a call........................................... 2
2.2 Answering or rejecting a call.................... 2
2.2.1 Answer a call .................................... 2
2.2.2 Reject a call...................................... 2
2.3 Adjusting call volume............................... 2
2.4 Ending a call........................................... 2
3. Call logs...................................................... 2
3.1 Missed calls............................................ 2
3.2 Dialed calls ............................................. 2
3.3 Received calls......................................... 2
3.4 Rejected calls..........................................2
3.5 Delete all.................................................3
3.6 Call timers ...............................................3
4. Contacts.......................................................3
4.1 View a contact .........................................3
4.2 Adding a new contact...............................3
5. Multimedia...................................................3
5.1 Video Recorder........................................3
5.2 Audio player.............................................3
5.3 Video player.............................................3
5.4 FM radio..................................................4
5.5 Sound recorder........................................4
6. Camera ........................................................4
7. Message.......................................................4
7.1 Write message.........................................4
7.2 Inbox.......................................................4
7.3 Outbox.....................................................4
7.4 Drafts.......................................................4
7.5 Sentbox...................................................4

-III-
7.6 Security message box .............................4
7.6 Templates................................................4
7.7 Broadcast message.................................5
7.8 Voice mail server.....................................5
8. Games .........................................................5
8.1 Eat n Run................................................5
8.2 Lock D Block...........................................5
9. Tools............................................................5
9.1 My files....................................................5
9.2 Calendar .................................................5
9.3 Alarm.......................................................5
9.4 Calculator................................................5
9.5 World clock..............................................5
9.6 Ebook......................................................6
9.7 Bluetooth.................................................6
9.8 FlashLight ...............................................6
10.Settings ......................................................6
10.1 Dual SIM settings ..................................6
10.2 Phone settings.......................................6
10.2.1 Date & time.....................................6
10.2.2 Language settings...........................6
10.2.3 Dedicated keys............................... 6
10.2.4 Scheduled power on/off .................. 6
10.2.5 Power management........................ 7
10.3 Display settings..................................... 7
10.3.1 Wallpaper settings........................... 7
10.3.2 Brightness....................................... 7
10.3.3 Backlight......................................... 7
10.3.4 Keypad backlight time..................... 7
10.4 Security settings.................................... 7
10.4.1 PIN................................................. 7
10.4.2 Modify PIN2.................................... 8
10.4.3 Phone locked.................................. 8
10.4.4 Change phone password ................ 8
10.4.5 Privacy............................................ 8
10.4.6Auto keypad lock............................. 8
10.4.7 Lock screen by end-key.................. 9
10.4.8 Mobile tracker................................. 9
10.5 Call settings .......................................... 9
10.5.1 Call divert ....................................... 9
10.5.2 Call waiting (Need network support) 9
10.5.3 Call barring..................................... 9

-IV-
10.5.4 Hide ID (Need network support)...... 9
10.5.5 Others ............................................ 9
10.5.6 Blacklist........................................ 10
10.6 User Profiles ....................................... 10
10.7 Connections........................................ 10
10.8 Restore factory settings....................... 10
11. Gallery..................................................... 10
12. Safety Precaution ....................................11
12.1 Usage environment..............................11
12.2 Medical devices ...................................11
12.2.1 Pacemaker....................................11
12.2.2 Hearing aids ................................. 12
12.2.3 Emergency calls ........................... 12
12.3 Password access................................ 12
12.3.1 Phone password........................... 12
12.3.2 PIN code....................................... 13
12.3.3 PIN2 code..................................... 13
12.3.4 PUK code..................................... 13
12.3.5 PUK2 code................................... 13
12.4 Cautions for battery charging............... 14
12.5 Cautions for battery usage .................. 14
12.6 Cautions for spare parts usage.............15
12.7 Other safety information.......................16

-1-
1. Getting to know your phone
1.1 Your Phone
1.2 Installing SIM card and battery
(1) Hold on【End Key】for about three seconds to
switch off the phone.
(2) Remove the battery cover.
(3) Remove the battery.
(4) Follow the sign for SIM1 and SIM2 on the
phone to install SIM1 and SIM2. Please make
sure that the golden contacts of the card face
into the phone and the notched corner has the
same direction with the card slot, then push the
other side of the card gently until it fixes itself in
the card slot.
(5) Replace the battery with its golden contact part
facing the set phone battery contact piece, and
then replace the battery cover.
1.3 Installing Storage card
(1) Hold on 【End Key】for about three seconds
to switch off the phone.
(2) Remove the battery cover.
(3) Remove the battery.
(4) Follow the arrow direction of "OPEN" on the
T-Card slot cover, open card slot cover, put the
T-Card into the slot vertically, make sure that
the gold contacts of the card face upwards, until
the card fixes itself in the card slot.
(5) Follow the arrow direction of "LOCK" on the
T-Card slot cover, pull card slot cover to lock
the card slot.
1.4 Battery charging
Charged by the travel charger
(1) Install the battery correctly into the phone.
(2) Insert the lead of the travel charger to
connecting slot of the phone, and then connect
the charger to a standard power socket.

-2-
When charging is complete, unplug the charger
from the standard power socket first, and then
disconnect the phone and charger.
1.5 Power on/ off
1.5.1 Power on
Hold on【End Key 】for three seconds to switch on
the phone.
1.5.2 Power off
Hold on【End Key 】for three seconds to switch off
the phone.
2.Using Call Function
2.1 Making a call
(1) On the Home Screen, input the area code and
phone number.
(2) Select <Options→Call→SIM1/SIM2> to select
SIM1 or SIM2 to call.
2.2 Answering or rejecting a call
2.2.1 Answer a call
When there is an incoming call, you can press【Left
Soft Key】to answer.
2.2.2 Reject a call
When there is an incoming call, you can press
【End Key】to reject it.
2.3 Adjusting call volume
During a call, you can press 【Up/Down Key】to
adjust the earphone volume.
2.4 Ending a call
Press 【End Key】to end the call.
3. Call logs
Enter the main menu, and then select [Call logs] to
enter the call list.
3.1 Missed calls
Display recent calls unpicked up.
3.2 Dialed calls
Display recent calls dialed.
3.3 Received calls
Display recent calls received.
3.4 Rejected calls
Display recent calls rejected.

-3-
3.5 Delete all
Delete all the call entries.
3.6 Call timers
Select the desired SIM Card, and then you can view
all relevant information about the SIM Card.
4. Contacts
4.1 View a contact
Enter the phonebook, the phone is defaulted to
show contact list with all entries.
4.2 Adding a new contact
On the Contacts list, select<Options →New>to
create a new contact.
Phone: You can input the contact name, mobile
phone, etc. You can also set special ring for the
contact entry.
SIM1: The input record will be saved to SIM1,
with each name one phone number.
SIM2: The input record will be saved to SIM2,
with each name one phone number.
5. Multimedia
5.1 Video Recorder.
Enter the main menu, and select [Multimedia→
Video Recorder.] to enter the video preview screen,
and press 【OK Key】to start recording the video.
5.2 Audio player
Enter the main menu, and select [Multimedia→
Audio] to enter the Audio Player screen:
Press【OK Key】to play or pause
Press【Left/Right Key】to skip to last /next one
Press【Up/Down Key】to adjust the playing
volume
5.3 Video player
Enter the Main menu, and click [Multimedia→
Video].
Press【OK Key】to play or pause
Press【Up/Down Key】to skip to last /next one
Press【Left/Right Key】to adjust the playing
volume

-4-
5.4 FM radio
Enter the Main menu, then select [Multimedia→FM
radio].
Press【OK Key】to play or pause
Press 【Left/Right Key 】to adjust the radio
frequency.
Press【Up/Down Key】to adjust the playing
volume
5.5 Sound recorder
Enter the main menu, select [Multimedia →
Recorder], and press【OK Key】to start recording.
After ceasing the recording, the recorded file will be
automatically save in the folder [Audio], select
<Options→Record file list> to check.
6. Camera
Enter the main menu, and select [Multimedia→
Camera] to enter the camera preview screen, press
【OK Key】to take a photo.
7. Message
7.1 Write message
Enter the main menu and select [Message→Write
message] to edit a new SMS directly.
After writing an SMS, press【OK Key】to send the
message.
7.2 Inbox
Store all received SMS.
7.3 Outbox
Store all SMS failed to be sent.
7.4 Drafts
Save edited SMS haven’t sent.
7.5 Sentbox
Store all the SMS successfully sent out.
7.6 Security message box
The mail security management.
7.6 Templates
While editing messages, you can directly cite the
preset common phrases. Select <Edit> to set the
common phrases by yourselves.

-5-
7.7 Broadcast message
You can receive broadcast text messages with
various contents via network service, such as news,
weather or traffic information. For more details,
please consult your network operator.
7.8 Voice mail server
This function works like an answering machine,
which can transfer a missed call to your personal
voice mail, allowing the caller to leave a voice
message and notify you by an SMS. Voice Mail is a
part of the bundled software provided by network
operator, therefore, you need to register to active
this function, and manually set the phone. Please
contact with your network operator for more details.
8. Games
8.1 Eat n Run
For specific operation, please refer to Help option of
the game.
8.2 Lock D Block
For specific operation, please refer to Help option of
the game.
9. Tools
9.1 My files
This menu allows you to manage files stored in the
phone or storage card.
9.2 Calendar
Once you enter this menu, there is a monthly-view
calendar for you to keep track of important
appointments, etc.
9.3 Alarm
On the Home Screen, press【Left Soft Key】to enter
the main menu, and select [Tools→Alarm], then
you can set the alarm name, time, ring and mode.
9.4 Calculator
Directly input numbers, press【Navigation Key】to
select your desired operation symbols (+, -, /, X).
Press 【OK Key】to get the answer.
9.5 World clock
This function allows you to check the standard time

-6-
in different areas of the world.
9.6 Ebook
You can view file in TXT format by Ebook and copy
the TXT file to the [Ebook] folder in the phone or
memory card from your PC.
9.7 Bluetooth
With Bluetooth, you can make a wireless
connection to other compatible devices, such as
mobile phones, headsets and car kits. You can use
the Bluetooth to send images, video clips, music,
sound clips and notes, and transfer files from your
compatible pc.
9.8 FlashLight
You can use this function to turn on/off the
flashlight.
10.Settings
10.1 Dual SIM settings
Standby mode: You can select the standby
mode for SIM card, either to have one SIM card
standby, or to have both SIM cards standby
simultaneously.
Reply by master SIM: You can activate the
function to reply from current SIM card for call
and SMS.
Set SIM name: You can name the Card as you
want.
10.2 Phone settings
10.2.1 Date & time
Set time: Directly input the time or press 【Up
/Down Key】to set it.
Set date: Directly input the date or press 【Up
/Down Key】to set it.
10.2.2 Language settings
You can select the language you want.
10.2.3 Dedicated keys
You can change the responsible shortcuts for
【Navigation Key】and 【Right Soft Key】under
standby mode.
10.2.4 Scheduled power on/off
You can set the phone to switch on/off at a
scheduled time.
