Lava Parallel-PCIe User manual

LAVA Parallel-PCIe
Quick Installation Guide
Rev. A00
LAVA COMPUTERS
PARALLEL-PCIe
P.N. MOKO L145.x
MADE
IN
CANADA
SEMICONDUCTOR
MCS9901CV-AA
INSL10200
4E42503 - 06 0743
RoHS
Pb

1Windows Hardware and
Driver Installation
1. Before opening the casing of your computer, make sure that all
power is off.
2. Locate an unused PCIe slot and insert the Parallel-PCIe card into it.
Ensure that the card is well seated.
3. Screw the metal bracket of the Parallel-PCIe card to your PC’s casing
and replace the machine’s cover.
4. Connect your parallel cable to the port on the Parallel-PCIe card and
turn the PC on.
5. When Windows starts, it will find a Parallel-PCIe Controller and will
ask you for a driver for this device.When prompted, insert the
installation CD into your computer. After copying the necessary files
from the CD,Windows may restart your PC in order to complete the
installation of the Parallel-PCIe card.Windows XP/Vista may display a
message to the effect that the drivers are not digitally signed.This
warning can be ignored.
6. The Parallel-PCIe card will appear in Control Panel|System|Device
Manager under Ports, as a listing similar to the one below. If
required, settings may be customized by clicking on the Parallel-
PCIe listing and then clicking Properties.

2
Release Notes:
A. Because the Parallel-PCIe card uses PCIe (not ISA) I/O address ranges,
it will never be seen by your BIOS at boot-up as a standard parallel
port (occupying 0278h or 0378h) even if the address has been
changed in Windows using the above procedure.This is normal, and
does not indicate a fault in your Parallel-PCIe card.
B. In standard installations of Windows 2000/XP/Vista, the I/O address
cannot be changed to a legacy address.

LAVA Computer MFG Inc.
LAVA
Technical Support
9:00 am to 5:30 pm Monday to Friday (Eastern Time)
Tel: [phone]
Fax: + 416 674-8262
E-mail: [e-mail]
Internet: www.lavalink.com
