Lava E Tab Connect User manual

- 1 -
Contents
1.1 Outlook ForYour Computer............................................................................- 4 -
Front View& Back View .....................................................................................- 4 -
Side View..............................................................................................................- 4 -
1.2Attachment.........................................................................................................- 4 -
1.3 Install SIM card and SD card..........................................................................- 5 -
SIM card...............................................................................................................- 5 -
SD card.................................................................................................................- 5 -
1.4 Charging and headphones................................................................................- 5 -
Charging...............................................................................................................- 5 -
headphones...........................................................................................................- 5 -
1.5 Turning On/Off..................................................................................................- 6 -
Turning On...........................................................................................................- 6 -
Turning Off ..........................................................................................................- 6 -
Standby.................................................................................................................- 6 -
2.1 Home Screen......................................................................................................- 7 -
The main key........................................................................................................- 7 -
Status Bar.............................................................................................................- 7 -
Shortcuts...............................................................................................................- 8 -
Widgets.................................................................................................................- 8 -
Wallpapers ...........................................................................................................- 8 -
Touch screen.........................................................................................................- 8 -
2.2 Volumes..............................................................................................................- 9 -
Set the volumes ....................................................................................................- 9 -
Call volumes.........................................................................................................- 9 -
2.3 People.................................................................................................................- 9 -
New contact..........................................................................................................- 9 -
Edit contacts/ Delete contacts.............................................................................- 9 -
Backup contacts.................................................................................................- 10 -
Import contacts..................................................................................................- 10 -
Favorite contacts................................................................................................- 10 -
3.1 Phone................................................................................................................ - 11 -
Make a phone call.............................................................................................. - 11 -
Receive calls ....................................................................................................... - 11 -
Handsfree ........................................................................................................... - 11 -
Mute.................................................................................................................... - 11 -
Telephone conference........................................................................................ - 11 -
Call history.........................................................................................................- 12 -
Emergency call...................................................................................................- 12 -
3.2 Message............................................................................................................- 12 -
Write messages...................................................................................................- 12 -

- 2 -
Answer messages ...............................................................................................- 13 -
Write MMS ........................................................................................................- 13 -
4.1 Use the GoogleAccount login.........................................................................- 14 -
Regain your Google account's password.........................................................- 14 -
Set data synchronization...................................................................................- 14 -
4.2 Gmail................................................................................................................- 14 -
Write a new Gmail.............................................................................................- 14 -
4.3 E-mail...............................................................................................................- 15 -
E-mail account settings.....................................................................................- 15 -
Write and send messages ..................................................................................- 15 -
View and save e-mail.........................................................................................- 16 -
Reply e-mail .......................................................................................................- 16 -
5.1 Mobile Networks.............................................................................................- 17 -
Check your network connection.......................................................................- 17 -
5.2 WLAN..............................................................................................................- 17 -
On / off the WLAN............................................................................................- 17 -
Search and connect WLAN ..............................................................................- 17 -
5.3 Browser............................................................................................................- 17 -
View the links in the page.................................................................................- 18 -
Zoom pages. .......................................................................................................- 18 -
Set your browser.................................................................................................................... - 18 -
6.1 Using Bluetooth...............................................................................................- 19 -
On / off the Bluetooth........................................................................................- 19 -
Connect the equipment to the new equipment ...............................................- 19 -
Disconnect the Bluetooth and equipment........................................................- 19 -
7.1 Music................................................................................................................- 20 -
Play music ..........................................................................................................- 20 -
7.2 Camera.............................................................................................................- 20 -
Photo Options ....................................................................................................- 21 -
View image .........................................................................................................- 22 -
Share pictures. ...................................................................................................- 22 -
Edit photos. ........................................................................................................- 22 -
7.3 Camcorder.......................................................................................................- 22 -
Video options......................................................................................................- 23 -
View the video....................................................................................................- 23 -
Manage video.....................................................................................................- 23 -
7.4 Sound Recorder...............................................................................................- 24 -
8.1 USB connection ...............................................................................................- 25 -
8.2 SD card.............................................................................................................- 25 -
9.1Alarm Clock.....................................................................................................- 26 -
Add alarm ..........................................................................................................- 26 -

- 3 -
9.2 Calendar........................................................................................................... - 26 -
New event ........................................................................................................... - 26 -
Edit the event. .................................................................................................... - 26 -
9.3 Maps................................................................................................................. - 26 -
Use the maps ...................................................................................................... - 27 -
View Map ........................................................................................................... - 27 -
Get Directions. ................................................................................................... - 28 -
10.1 Device Settings............................................................................................... - 29 -
10.2 Date & time.................................................................................................... - 29 -
10.3 Language & input ......................................................................................... - 30 -
10.4 Display............................................................................................................ - 30 -
Set the screen brightness................................................................................... - 30 -
Sleep.................................................................................................................... - 30 -
10.5 Factory data reset. ........................................................................................ - 30 -
10.6
11
Protect your device........................................................................................ - 31 -
Protect your SIM card by PIN ......................................................................... - 31 -
Screen security
SAR
...................................................................................................
..........................................................................................
- 31 -
- 31 -
Information

- 4 -
Chapter 1 Quick Start
1.1 Outlook For Your Computer
Front View& Back View
Side View
1.2 Attachment
Your packing box comprises the following attachments
•Tablet PC
• USB Line
• Charger
• User Guide
• Headphones

- 5 -
1.3 Install SIM card and SD card
SIM card
·Install SIM card
Locate the SIM card slot, then insert the SIM card with its gold
contacts facing down and its cut-off corner facing out the card slot.
·remove SIM card
To remove the SIM card, please turning off the product ,or it will be
damage to SIM card.
SD card
You need a SD card to store photos, music, video and other data.
·Install SD card
Locate the SD card slot, then insert the SD card with its gold contacts
facing down and its cut-off corner facing out the card slot
·remove SD card
1. Please make sure to disconnect the SD card and device.
Click > Settings>Storage>Unmount SD card
2. Open the SD card protection cover.
3. Use your fingertips to tap the SD card, SD card from the slot in
the pop-up.
1.4 Charging and headphones
Charging
When the battery is charging, the，the icon appears in the status
bar. When the battery is fully charged, the icon appears in the status
bar.
headphones
When the user wants to use headsets or listening to music, plug the
headset into the headphone jack, the icon appears in the status bar.
Note:·when using headphones, you hear outside sounds may be limited.
·When it is a threat to your safety, please do not use headphones.
·When using headphones, please do not set the volume to the maximum,

- 6 -
because it may damage your hearing.
1.5 Turning On/Off
Turning On
Press and hold power key to turning on the product，it takes about
30 seconds to enter the main screen.
Turning Off
Press and hold power key ，Pop-up "Device Options" menu，Click Shut
Down. Select OK in the pop-up menu.
Standby
1. If you do not unlock within a long time(about 10 seconds) , device
will automatic dark screen.
2. Light up the screen by pressing any side buttons.
3. Hold and slide up the green lock icon to the ceiling to unlock ;
also press the menu key to unlock.

- 7 -
Chapter 2 Basic Operation
2.1 Home Screen
Main screen contains five screens , horizontal sliding switch to the
extended screen.
The main key
·Menu :Open the application menu.
·Google Search :Use google search.
·The main screen key :Back to the main screen.
·Back key :Return to the previous operation screen.
·Daemon icon :Recently used applications, click the desired
application can be opened.
Status Bar
Status bar will display various status information.You can
click to turn off the status bar.
Icon
Explain
Icon
Explain
No Sim card
Signal strength
3g signal
GSM signal
EDGE
Airplane mode
Charging
Low power
Full power
Silent mode
Vibration mode
Alarm
GPS open
Wifi is
connected
USB is connected
Bluetooth
Note：The machine software is constantly upgraded, the status indicator

- 8 -
may be different with your device, subject to the actual equipment.
Shortcuts
To customize different home screen, you can add apps shortcut;
reposition the shortcut.
·Click to open the application menu，long press and drag the
icon to be added to the main screen.
Widgets
You can add a clock, music player and calendar widgets on the main
screen.
Click to open the application menu,then click
Or sliding screen to the left into the widgets page,long press any
widget drag it to the screen.
Wallpapers
1.Touch and hold on home screen ，popup dialog box.
Click “Gallery”Can select the system your own pictures as
wallpapers.
Click “Live Wallpapers”Can select the system live wallpapers as
wallpapers.
Click “Wallpapers”Can select the system pictures as wallpapers.
2. Click >Settings>Display>Wallpaper
Touch screen
Steps:
1. Short Press touch screen: Use the tip of your finger to press
exactly on the touch key you want, being careful not to touch the keys
for other functions.
2. Long press touch screen: Press for more than 1.5 seconds to get
into the submenu.
3. Drag: Press and hold the scroll bar and drag up or down. On some
screens such as web pages, you can also scroll side to side.
4. Zoom: when you view page, you can double-click the screen to zoom
in or out the page.

- 9 -
2.2 Volumes
·Media volumes：Set the volumes of music, video, games and other
media players.
·Ringtone volumes ：Set the volumes of the ringtone and
notifications.
·Alarms volumes：Set the alarm volumes.
·Call volumes：Set the volumes of calls.
Set the volumes
Steps：> Settings>Sound>Volumes
·Set vibrate
Steps：> Settings>Sound>Volumes
Check“Vibrate on ring”to Turned on or off the equipment vibration.
Call volumes
During a call, you can press the left side of the volume up and down
key to adjust the call volume.
2.3 People
You can save contacts, phone numbers and e-mail and other related
content.
New contact
Steps：> People> new contact
1. Enter your contact’s information.
2. Click “DONE”to save the contact.
Edit contacts/ Delete contacts
Edit contacts:
1. Click ，open the contact list.
2. Choose the contact you want to edit，click . After editing, click

- 10 -
“DONE”to save the contact.
Delete contacts:
1. Click ，open the contact list.2.Click ，in the pop-up menu,
choose “Delete”
3. Check the contacts you want to delete, click “OK” to delete the
checked contacts.
Backup contacts
You can export your contact data to the SD card.
Steps：
1. Click ，open the contact list.
2. Click > Import/export.
3. Click “Export to storage”
Import contacts
·Import from SD card
Steps:1. Click ，open the contact list.
2. Click > Import/export.
3.Click “Import from storage”.
Favorite contacts
You can add commonly used contacts and special contacts to your
collection, in order to find and use.
Steps:
Select a contact in your contact list, then click the star icon to
make it turn blue.

- 11 -
Chapter 3 Use the device
3.1 Phone
Make a phone call
1. > Phone
2. Press the number keys, enter the phone number.
3. Click ，make a call.
4. When the call is completed, press the hang up to end the call.
Note：1.Click can remove the number.
1. You can also select a contact to call.
2. During a call，click can open the dial pad to the digital
input.
Receive calls
When the incoming call, the device will issue a prompt，you can hold
down the ，drag it to the to receive calls；or drag it to the to hang
up.
Note：you can hold down the and drag it to the message icon to hang
up the phone and send a message.
Handsfree
You can use the handsfree to ensure traffic safety while driving.
Use hands-free speaker / microphone device / Bluetooth headset to make
and receive calls.
Mute
During a call, you can make the other side can not hear your voice.
Press the mute, turn on or turn off mute.
Telephone conference
1. > Phone.

- 12 -
2. Press the number keys to input the number of the first person.
3. Outgoing calls.
4. The other party answers，click .
5. Press the number keys to enter the next party calls and outgoing
calls.
6.Click to connect the two sides call.
Call history
You can view the received calls, missed calls, dialed calls and other
information in the call history.
Steps：> Phone.
Click to view the call history.
Emergency call
1. > Phone（If the device is locked, click Emergency Call.）
2. Press the number keys to enter the emergency number.
Note：1. Different countries have different emergency call numbers, so
the emergency call number in your device is not effective in all regions.
Sometimes due to network, environmental, or interference with the impact
of events, an emergency call may not call.
2. The phone features of the device must be turned on when you make
an emergency call.
3.2 Message
Write messages
Steps：> Messaging> new message.
1. Enter the message receiver，you can also press ，Find a
receiver from the contacts.
2. Enter the text you want to send.
3. Click ，send the message.

- 13 -
Answer messages
The top status bar will be prompted when you receive new information.
Steps：> Messaging
Select the message you want to reply：
1. Enter the text you want to send.
2. Click ，send the message.
Write MMS
Steps：> Messaging> new message.
Enter the message receiver，you can also press ，Find a receiver
Next, in the following ways you can make a SMS converted into a MMS.
1.Click >add subject.
2.Click to add pictures, music or video files for MMS。

- 14 -
Chapter 4 E-mail
4.1 Use the Google Account login
Using the Google Account login can make your device synchronized with
the server,and you must use a Google account to synchronize Google Apps,
Google Talk,and Android Market.
Steps：Click > Setting> Accounts & sync>ADD ACCOUNT>Google
Click “Sign in”, enter your user name and password, then click
“Sign in”. After logging in,all e-mail, contacts and calendar in your
Google account will be synchronized to the device.
Note：If you do not have a Google account, click Create.
Regain your Google account's password
If you have forgotten your Google account's password, you can perform
the following steps to obtain the password：
1. On tn the computer, open a browser and go to:
http://google.com/accounts
2. In the right side of the web page ,click“Can't access your
account? ”.
3. Select “I don't know my password”.
4. Then follow the procedure t to reset your password.
Set data synchronization
You can bind a Google account for synchronize the contacts in the
device to the website. This will facilitate the continuous update of the
Google application information.
Steps：
1. Click > Setting> Accounts & sync.
2. Click the account you want to synchronize.
4.2 Gmail
Write a new Gmail
Steps：1.Click > Gmail.
2.Click , then select“Compose”.

- 15 -
Enter the recipient's e-mail address and message content, and then
press to Send the mail.
4.3 E-mail
You can use email to send or receive e-mail messages.
Note：1. You must set up your e-mail at first，and then send or receive e-mail.
2. E-mail must be send by internet connection.You can consult your
specific setup parameters with your network service provider.
E-mail account settings
Steps：Click > E-mail.
Account setup：
1. Enter the e-mail address and password,and then click “Next”.
2. Select the type of the Email account：POP3/IMAP/Exchange。If you
do not know the configuration parameters, you can consult the e-mail
service provider.
3. You can set the frequency of mail checks.After setting, click Next.
4. Created name and signature,for your account.
You can also set multiple email addresses：
1．After Set the initial e-mail address，Click ，select "Settings"
option to enter the account settings page.
2. Click the "Add Account" to add other email accounts.
Write and send messages
Steps：Click > E-mail.
1. Click to editor the e-mail message.
2. Enter the E-mail address of the recipient.
3. Enter a subject.
4. Write the message content.
5. Click to send the E-mail.

- 16 -
View and save e-mail
Receiving e-mail messages stored in the network service provider's
mail server before downloading to the device.
·Select the e-mail to read in the Inbox.
·Click the attachment icon can view e-mail attachments.
·Click Save to download attachments, attachments are usually stored
in your SD card.
Reply e-mail
·In the Inbox, select the mail you want to reply,click to reply.

- 17 -
Chapter 5 Network and Browser
5.1 Mobile Networks
When your device insert the SIM / UIM card, you can use your network
operator's 2G/3G business.
Check your network connection
1. Click > Settings
2. WIRELESS & NETWORKS >More>Mobile networks.
3. Click“Access Point Names（APN）” to check your network connection.
5.2 WLAN
On / off the WLAN
Steps：Click > Settings>WIRELESS & NETWORKS
Click switch to turn on or off the WLAN.
Search and connect WLAN
1. Click > Settings>WIRELESS & NETWORKS
2. Open the WLAN,your device will automatically lists the networks.
·If you select an open network, you can directly connect to the
network.
·If you select an encrypted network, you must enter a password
to connect to the network.
·Click on the "Add Network" can add a new WLAN.
When your device is connected to the network，Will appear in
the status bar.
Note：When you enter the network coverage, and your WLAN is turned on,
your device will automatically reconnect to the network you have
connected.
5.3 Browser
Use the browser allows your devices to access Web pages and Web-based

- 18 -
applications..Consult with your network service provider for how to
connect.
Note：The network connection type depending on your network service
provider.Use a different type of connection, your network connection
costs are different.Specific tariff details, please consult your network
service provider.
Steps：Click > Browser.
·You can click on the tab bar to open pages.
·Click ×you can close the page.
·Click ＋you can create a new page.
·Click you can refresh the page.
·Click you can back or forward to view the page.
·Click you can add a bookmark of the current page.
·Click you can search or enter the URL.
·Click you can view all of your bookmarks, history, saved pages.
·Click you can do more actions.
View the links in the page
You can click the link in the page to open it.
Tap and hold the link in a Web page can choose to open the link in
a new window or bookmark.it. You can also enter the URL you want to access
directly in the address bar.
Zoom pages
Double-click the web page to zoom the page.
Drag up and down the page, you can quickly browse the Web.
Set your browser
Steps:
Click > Browser > >Settings.

- 19 -
Chapter 6 Bluetooth
6.1 Using Bluetooth
On / off the Bluetooth
Steps：Click > Settings>Bluetooth
Click switch to turn on or off the Bluetooth.
Connect the equipment to the new equipment
1. To confirm the device you want to pair with Bluetooth connectivity
is turned on and visible.
3. After turn on Bluetooth,click “SEARCH FOR DEVICES”.
4.Select a device in the list to connect.
5. Enter the PIN (eg 0000),then press the “Pair”to connect the
device.
When Bluetooth is turned on，will be displayed in the status bar.
Note：Bluetooth device connection methods may be different,.This manual
is for reference only.
Disconnect the Bluetooth and equipment
Click the device name,which you want to disconnect in the list,and
then click “Unpair”to disconnect.
