Lava QPAD R704 User manual

1
Content
Content..............................................................................................................................................1
1 Introduction....................................................................................................................................2
1.1 Acknowledgement...............................................................................................................2
1.2 Announcements...................................................................................................................3
1.3 Safety Instruction................................................................................................................3
1.4 Abbreviation/Terminology..................................................................................................4
2 Device Introduction........................................................................................................................5
2.1 Device Operation and Preparation......................................................................................5
2.2 Device Status and Reminder........................................................................................5
3 Quick Start Guide...........................................................................................................................6
3.1 Keys Function.....................................................................................................................6
3.2 Startup and Shutdown.........................................................................................................6
3.3 Open and Close of the Screen.............................................................................................7
3.4 Usage of Touch Screen........................................................................................................7
3.5 Home Page..........................................................................................................................8
3.6 Visit Application Procedures.............................................................................................10
3.7 USB Connection ...............................................................................................................10
3.8 Typing words.....................................................................................................................11
3.9 Operation Technique.........................................................................................................13
4 Basic Setting ................................................................................................................................13
4.1 SIM Management..............................................................................................................13
4.2 Wireless and Internet.........................................................................................................14
4.3 Bluetooth....................................................................................................................15
4.4 Data Usage........................................................................................................................16
4.5 More..................................................................................................................................17
4.14 Language and Input Method ......................................................................................33
4.16 Date and Time.................................................................................................................36
5 Multi-Media.................................................................................................................................38
5.1 Music.................................................................................................................................38
5.2 Video.................................................................................................................................39
5.3 Photo Gallery ....................................................................................................................39
5.4 Camera..............................................................................................................................40
5.5 FM Radio ..........................................................................................................................40
6 Communication Function.............................................................................................................41
6.1 Phone.................................................................................................................................41
6.2 Text Message.....................................................................................................................42
6.3 Contact List.......................................................................................................................42
7 Internet.........................................................................................................................................43
7.2 Email.................................................................................................................................43
8 Other Application Procedures......................................................................................................45

2
7.1 Browser.............................................................................................................................45
8.1 Clock.................................................................................................................................45
8.2 Calculator..........................................................................................................................45
8.3 File Manager.....................................................................................................................46
9 Installation of Procedures.............................................................................................................49
9.1 Installation.........................................................................................................................49
9.2 Uninstall............................................................................................................................49
10 Trouble Shooting........................................................................................................................49
1 Introduction
1.1 Acknowledgement
Thanks for your purchase of our product. QPAD R704 is a high definition tablet PC.
The product is designed with various functions, including WCDMA, WIFI, BT, GPS, FM,
voice call and so on. It is easy to achieve wireless communication and internet, you have access to
surf the internet anytime and anywhere; it is also built with high accuracy GPS module, so that it
can be used for navigating through installing map software. There are many sensors which offer
you brand-new operation and entertainment; besides, it has camera shooting, which leads
electronic consumption to enter into a fresh palm internet entertainment time.
The manual systemically introduces the functions, use techniques and announcements, please
read this manual carefully before your operation.

3
1.2 Announcements
Preventive maintenance
Please always keep the device dry. To avoid the device short trouble, corrosion fault
and electric short, please prevent the device, battery and charger from water and
moisture, and don’t operate the device or charger by wet hand.
To avoid failure of device, battery and charger, please prevent the device, battery,
charger from violent shock or shake.
To avoid failure of device, battery and charger, please prevent the device, battery,
charger of all over heating or too cold circumstance
Never disassemble the device and accessories arbitrarily, otherwise the device and
accessories are not in our company warranty scope.
1.3 Safety Instruction
Before the operation of the device, please refer to the safety instructions and announcement.
Never use the device when driving car, in order to ensure safe driving.
In the medical area, please abide by related rules and regulations. Please shut
down the device when it is near to the medical area.
To avoid the wireless signal to interrupt the plane- controlled signal, please shut
down the device or using airplane mode when you are boarding a flight,
To avoid electronic equipment failure, please shut down the device in the vicinage
of high-accuracy electronic equipment.
Please don’t disassemble the device and accessories. Only authorized agent has
access to service the device.
Please keep the device far away from magnetic equipment, the radiation of device
may erase the data stored in the magnetic equipment.
Never use the device in the vicinage of high temperature, inflammable gas (gas
station).
Protect the device and accessories from kids reach scope, and avoid the kids to use
the device without parents’supervision.
Please comply with related rules and regulations, and respect others’privacy and

4
legal rights while using the device.
Please strictly adhere to related instructions in the manual when using USB cable
to ensure the safety of the device or PC.
1.4 Abbreviation/Terminology
Abbreviation/Terminology
Full Name
Description
WIFI
Wireless Fidelity
Base on IEEE 802.11b standard
wireless LAN
T F
TransFlash
Alternative name Micro SD,super
miniature memory card

5
2 Device Introduction
2.1 Device Operation and Preparation
Battery Charging
If this navigator is first used, please use AV adaptor to fully charge it.
1. Apply the power adaptor to charge for DEVICE.
2.2Device Status and Reminder
Reminder icons
When some remind message appears in your reminder window, please click column and slip
the screen to open the reminder list. Choose the menu you need, and confirm the information.
Then you can close the reminder window through clicking the column to slide up. Please refer to
below status icons:
New email
Airplane Mode on
USB connected
USB debugging connected
Return button
Downloading
Display recently-used
application
Home button
Current electric
volume.
WIFI connected, internet is
available

6
Reminder board
Reminder icons will work while receiving emails, WIFI is open, you can open the reminder
board to view the detailed information.
Open the reminder board
When the reminder column shows new reminder icon, please hold the column and slip down
your finger, then the reminder board is opened.
3 Quick Start Guide
3.1 Keys Function
Keys Function Description：
Power button
Short press to sleep/wake up, long press to startup and
shutdown.
Volume +（up）
increase the volume
Volume -（down）
decrease the volume
HOME button （home）
Click it in any interface will return to main interface.
Back button（back）
click it in any interface will return to previous menu
Menu button
This button will display in menu interface.
Setting button
display recently browsed history
3.2 Startup and Shutdown
Startup
Long press POWER key for three seconds, you can enter into startup picture. The system
enters into screen lock status, please unlock it.
Shutdown

7
1．Long press POWER, it will pop up shutdown window.
2．Shutdowm window contains mute mode, airplane mode, reboot mode and shutdown
four options.
3．Click Shutdown is the last step.
3.3 Open and Close of the Screen
Screen will be closed on its own when no operation happens.
1. Screen will be closed on its own if no operation happens for some time to save battery
power
2. When screen is open, press POWER key, the screen will be closed immediately.
Open the screen when it is closed.
If the screen is closed, short press POWER to open the screen. The screen will be locked
open it, it will show the picture as below picture, left slide to unlock and enter into camera, right
slide the unlock icon to unlock the screen.
Picture 3.1
3.4 Usage of Touch Screen
DEVICE Operating Methods
There are below methods to view the main screen, menu and application procedure in your device.

8
Click
When you want to use the screen keyboard typing or choose application in the main interface, you
only need to touch it by your finger.
Press on
If you want to open some item( textbox or the link in the webpage), or shortcut and main
procedure move, you can press on this item.
Quickly slide or slide
Quickly slide or slide indicates make quick vertical or horizontal movement by finger.
Pull
Before you pull, you need to hold the it with strength until you pull it into the position you want.
Rotate
For most pictures, you only need to rotate the device sidewise to change the screen direction from
horizontal to vertical. For instance, when you are typing , and watching movies.
3.5 Home Page
Main interface as below picture 3.2, long press the blank and it will popup windows to set
wallpaper, folder, widgets, and shortcut.
Picture 3.2
search
Display recently
browsed history
Home
return
time
Battery
volume
Notice
column

9
The extended home page
The home page can be extended beyond the wideness of screen to provide more space,
which you can put new-added shortcuts and widgets. Click the blank space in home page
then slide right or left to extend to the right or left of the screen. In the home page, there are
two extended pictures, as Picture 3.3.
Picture 3.3
The shortcut icons management in desktop application.
Create folder icon in desktop
1. Drag the icons need to be put together on one icon(can also overlay several
icons)as Picture 3.4.
2. Then click the overlaid icons, the applications can be folded, as Picture 3.5.
Picture 3.4

10
Picture 3.5
Remove the icons in desktop
1. Long press the icons need to be remove, then on the right above of the screen, it
will appear icons.
2. Drag the icon to the above of the remove icon, till the icon become red, then move
your finger to delete the icon.
Change the wallpaper of desktop
1．In home page, long press any blank space in main screen, it will pop up a
window to change the wallpaper.
2．Click the gallery or wallpaper gallery to select the wallpaper
3.6 Visit Application Procedures
Click in right top of Picture 3.2, enter into main interface as Picture 3.6,
choose the application procedure you want to visit.
Picture 3.6
3.7 USB Connection
DEVICE Storage Configuration
Before transmitting documents, you have to conduct storage configuration for your device:
1. Connect the device and computer by USB cable, the reminder column will show the
remind information.
2. Open the reminder board; please view the device status and reminder to learn how to
open the board.
Return to
home page

11
3. In the reminder board, click the “USB Connected”, it will as below Picture 3.4, then
click “open USB storage configuration”.
4. Now the USB is connected successfully.
Picture 3.7
Copy the document into memory card
1. Connect the device to computer with USB cable.
2. As device storage configuration, it is connected with computer successfully.
3. Open the “My computer” in your computer, check the items in “removable disc”.
4. Copy the documents you need into “removable disc”.
5. After copying finishes, click “shutdown the USB storage configuration” to uninstall.
Notice: When the device is connected with USB cable, and you open the USB storage
configuration, you can’t view the memory card through the device. Only after you detach the
USB cable, you can view the memory card in the device.
3.8 Typing words
Use the screen keyboard
When you start the procedure or choose the words or numbers edition, it will show the screen
keyboard. The keyboard contains below typing options:
1. Android keyboard
2. Google Pinyin

12
Choose the typing method you want
1. Click Setting pocedure application.
2. Click Language and Keyboard.
3. In the text setting area will reveal all the installed words-typing methods in your
DEVICE.
4. Tick the typing method you want.
Use and switch of input method
Picture 3.8
1
switch the capital and small letter
2
switch the mode of words input
3
click to insert the space
4
click input to enter
5
delete the character in the left of cursor, click and hold to delete all the
characters in the left of the cursor.
①
②
③
3
⑤
④

13
3.9 Operation Technique
Enter widgets interface
In the application interface, click widgets on the above of screen, or slide the screen, it
will switch into widgets interface. Long press any widget to create its shortcut, then
you can enter into the application through the shortcut icon.
Create application shortcut icons in the desktop
In the application interface or widgets interface, long press any icon to switch into
desktop automatically, drag and hold the icon, you can move to any position in the
desktop.
4 Basic Setting
4.1 SIM Management
4.1-1 Voice call
Your device permits you to use voice call.
4.1-2 Video Call
Click on call log and then click on the contact with whom you want to make a video
call and then on the right top corner there is a option for video call. as Picture 4.1
Picture 4.1
4.1-3 Message

14
Click in main menu, choose message and then write the message.
4.1-4 Data Connection
Click setting application in main menu, click data connection ON.
4.2 Wireless and Internet
1. Connect Wi-Fi
1) In the main menu or interface, choose setting application procedure.
2) Click WLAN, open wifi, device will automatically search the available
Wifi wireless internet.
3) Choose the Wi-Fi internet you want to connect, if it has password, it will
pop up the password window, enter password, click connect.
Picture 4.2
2. Add Network
1) Click “+” icon in right top
2) Input network SSID, the wireless network name, click save.
3) Click user name already saved, click connect to use network Network Notice
If you open Network Notice, when WIFI signal appears, the right bottom will
remind you available WLAN network.
3. Keep WI-FI on during sleep.
1. Click icon in right top, select advanced.
2. Click Keep WI-FI on during sleep,

15
Picture 4.3
4.3 Bluetooth
Bluetooth function operation
1. Click setting application in main menu interface
2. Click bluetooth and open it.
3. Click the available Bluetooth device, it will popup request window, enter into related
password, and match the device to connect.
4. After match successfully, choose the operation you want to, click to enter into
Picture 4.11.

16
Picture 4.4
Bluetooth setting
1. Rename tablet
Click icon in right top select rename tablet, you can rename it as you want
2. Check visibility timeout
Select visibility timeout setting, choose the time you want to set.
3Display the file you received
3. Choose display the file you received, you can view download and upload files.
Open Bluetooth distance induction device, when two Bluetooth devices distance is quite far or
connection is cut off, the Bluetooth will remind you with sound.
4.4 Data Usage
Check SIM card data usage, as Picture 4.5

17
Picture 4.5
Check WIFI data usage
Click icon in right top of Picture 4.5, click Data Usage, as Picture 4.6
Picture 4.6
4.5 More
4.5-1 Airplane Mode
Airplane Mode can turn off WIFI and GSM card function quickly, when airplane mode is
turned on, WIFI and GSM can’t get any signal, then airplane mode is turned off, WIFI and GSM

18
module will recover to previous state.
4.5-2 VPN
Open VPN, click add VPN network, Input name and server address, then save.
Click VPN, as Picture 4.18, input VPN user name and password, click connect.
Picture 4.7
4.5-3 Network sharing and portable hotspots
Portable WI-FI hotspots
1. Click setting application in main menu.
2. Click more when wifi is well connected, open network share and portable hotspot

19
Picture 4.8
Picture 4.9
3. Click keep WI-FI hotspots on, choose open time.
4. Return to previous menu, open portable WLAN hotspots, click configure WI-FI
hotspots.

20
Picture 4.10
5. Set passwords you want to, password should be more than 8 numbers.
4.5-4 Mobile Networks
1. 3G service
Click 3G service, as Picture 4.22, choose available defaulted SIM card, GSM is 2G network,
WCDMA is 3G network.
Picture 4.22
2. Access Point Name( APN)
Click mobile network, as Picture 4.23
