Lavi Industries Queue Guard User manual

27810 Avenue Hopkins, Valencia, CA 91355 • www.lavi.com • 800.624.6225
Part No. 87-230 Page 1
Installation Instructions
Queue Guard™Germ Shields
STEP
1
1
STEP
To ensure the public’s safety, please follow the best practices outlined below when configuring the layout of a Queue
Guard™ barrier system.
for 78-inch-tall system using 80-inch-tall Beltrac®stanchions
Parts List:
A. Beltrac 3000 80-inch Posts
B. Queue Guard™Protective Panel
C. Panel Spacers
Read First: Safety Recommendations
STEP
1
2
STEP
If you received posts that were shipped knockdown, attach each base to a post. Please
refer to Assembly Instructions shipped with each post. If you received pre-assembled
posts or are using existing stanchions, please skip to Step 3.
Attach Post Bases
Tools Required:
F. Allen Wrench†
†To attach post base when
shipped knockdown. Included
with all knockdown posts.
• Use Beltrac 3000 Heavy Base Posts for every
start and end post
• Use Beltrac 3000 Heavy Base Posts for every
4th post
• Incorporating 90-degree turns will increase the
stability of the system
• Do not remove the “Do Not Lean” safety labels
axed to each panel
AB C
*Posts sold separately.
Installation Instructions
27810 Avenue Hopkins, Valencia, CA 91355 • www.lavi.com • 800.624.6225
Part No. 8X-XXXX
Lower the post tube onto the base insert.
The bottom rim of the post tube should be flat and
flush against base.
or
Tilt post on its side while maintaining flush fit between post and base.
On bottom of the base: Use supplied Allen wrench (5/16 drive) to
tighten the center hex bolt until fully secured.
A SECURE CONNECTION IS IMPERATIVE: Torque until the bolt
is tight and cannot be turned by hand any further.
Check placement of post on the base and re-tighten hex bolt if
necessary. Stand post upright and position post for use.
STEP
1
1
STEP
Beltrac® Post
Rubber or Metal Base Insert
Parts:
A. Post
B. Beltrac® Rubber Base Insert
or Beltrac® Metal Base Insert
C. Allen Wrench
A B C
Attach Post to Base
STEP
1
2
STEP
Secure the Connection
Rubber Base Insert
Metal Base Insert

Part No. 87-230 Page 2
Installation Instructions
27810 Avenue Hopkins, Valencia, CA 91355 • www.lavi.com • 800.624.6225
Queue Guard™Germ Shields
1
3
STEP
Slide Panel Spacers into the grooves of posts
where Queue Guard Panels will be installed.
Spacers are placed into opposing post grooves
to control the height of the panels.
Insert Panel Spacers
STEP
1
4
STEP
For safety, please use 2 people for this step.
Confirm panel is right side up by verifying “Arrow Label”
position on panel (remove label after installation).
Lift Queue Guard Panel so the dovetail edges which
start halfway up the frame side, align with groove
openings at the top of 2 opposing Tall Posts.
Carefully slide panel down post until it rests on the
Panel Spacers.
TIP: Slide both sides of panel down in tandem, keeping
the panel parallel to floor. This will allow panel to slide
more smoothly.
Install Queue Guard™Panels
SPACERS
FACE INWARD
POST POSITION
SIDES OF FRAME
INTO GROOVES
SPACERS
FACE INWARD
THIS
SIDE UP
THIS
SIDE UP
Only use a Microfiber cloth and Windex or other window
cleaning agents. DO NOT use paper towels of any kind, as
they scratch the plastic and over time will make it cloudy.
Cleaning Panels
